Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 1 of 38 FCC Radio Test Report FCC ID: O4GTKCOMBO This report concerns (check one): Original Grant Class II Change Issued Date : Nov. 02, 2011 Project No. : 1110C176 Equipment : Bike Combo transmitter Model Name : Interchange Combo Applicant : Dayton Industrial Co. Ltd. Address : 2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong Manufacturer : Kendy Electronics (Dongguan) Co. Ltd. Address : Xingsi Huangtang Village, Hengli Town, Dongguan City, Guangdong Province, P.R. China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Oct. 21, 2011 Date of Test: Oct. 21, 2011 ~ Nov. 01, 2011 Testing Engineer : (Ivan Cao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 2 of 38 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 3 of 38 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 MEASUREMENT INSTRUMENTS LIST 12 4.1.3 TEST PROCEDURE 13 4.1.4 DEVIATION FROM TEST STANDARD 13 4.1.5 TEST SETUP 13 4.1.6 EUT OPERATING CONDITIONS 13 4.1.7 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 RADIATED EMISSION LIMITS 15 4.2.2 MEASUREMENT INSTRUMENTS LIST 16 4.2.3 TEST PROCEDURE 19 4.2.4 DEVIATION FROM TEST STANDARD 19 4.2.5 TEST SETUP 20 4.2.6 EUT OPERATING CONDITIONS 21 4.2.7 TEST RESULTS (BELOW 30MHz) 22 4.2.8 TEST RESULTS (BETWEEN 30 – 1000 MHz) 23 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 25 4.2.10 TEST RESULTS (2400 – 2483.5 MHz) 29 5 . BANDWIDTH TEST 30 5.1 MEASUREMENT INSTRUMENTS LIST 30 5.2 TEST PROCEDURE 30 5.3 DEVIATION FROM STANDARD 30 5.4 TEST SETUP 30 5.5 EUT OPERATION CONDITIONS 30 5.6 TEST RESULTS 31 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 4 of 38 Table of Contents Page 6 . ANTENNA CONDUCTED SPURIOUS EMISSION 32 6.1 APPLIED PROCEDURES / LIMIT 32 6.1.1 MEASUREMENT INSTRUMENTS LIST 32 6.1.2 TEST PROCEDURE 32 6.1.3 DEVIATION FROM STANDARD 32 6.1.4 TEST SETUP 32 6.1.5 EUT OPERATION CONDITIONS 32 6.1.6 TEST RESULTS 33 7 . EUT TEST PHOTO 36 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 5 of 38 1. CERTIFICATION E q u i p m e n t : Bike Combo transmitter Brand Name : N/A Model Name. : Interchange Combo A p p l i c a n t : Dayton Industrial Co. Ltd. Date of Test : Oct. 21, 2011 ~ Nov. 01, 2011 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.249)/ ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1110C176) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 6 of 38 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) StandardSection FCC Test Item Judgment Remark 15.207 Conducted Emission - Note(1) 15.209 Radiated Emission PASS 15.249 Radiated Spurious Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) The EUT used new battery. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1110C176 Page 7 of 38 2.1 TEST FACILITY The test facilities used to collect the test data in this report is DG-C02/DG-CB03at the location of No.3,Jinshagang 1st Road, ShiXia, Dalang Town,Dong Guan, China.523792 Neutron's test firm number for FCC 319330 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of ap…
