O4O-EYFPACordless Impact Wrench

C.E. Electronics 2107 Industrial Drive Bryan, OH 43506 419.636.6705 phone 419.636.2516 fax www.ceelectronics.com March 13, 2015 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for C.E. Electronics, Inc. 2107 Industrial Drive Bryan, OH 43506 for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following C.E. Electronics, Inc. product: Cordless Impact Wrench with 2.4GHz radio interface under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither C.E. Electronics, Inc. nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, C.E. Electronics, Inc. will notify the Federal Communications Commission if, at any time, the situation changes causing C.E. Electronics, Inc. to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 419-636-6705. Sincerely, Garry L. Courtney President C.E. Electronics

1 C.E. Electronics 2107 Industrial Drive Bryan, OH 43506 419.636.6705 phone 419.636.2516 fax www.ceelectronics.com March 13, 2015 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, C.E. Electronics, Inc. would like to declare that the application being submitted for the device with FCC ID: O4O-EYFPA, has not been submitted to another TCB or FCC for certification. If you have any questions, please do not hesitate to contact us at (419) 636-6705 Sincerely, Sincerely, Garry L. Courtney President C.E. Electronics

C.E. Electronics 2107 Industrial Drive Bryan, OH 43506 419.636.6705 phone 419.636.2516 fax www.ceelectronics.com March 13, 2015 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, C.E. Electronics, Inc, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission’s Rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at 419-636-6705. Sincerely, Sincerely, Garry L. Courtney President C.E. Electronics

SAR Exclusion Justification This device FCC ID: is excluded from SAR testing by the following justification The maximum power that the transmitter is capable of is 0.21 mW Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 100.00% V alue 1-g (mW) 10-g (mW) 0.07 (354) -211 "Value" is  3 , the SAR test exclusion threshold 1-g power limit 10-g power limit 96 239 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission < 50mm power limits for above caclulation using specified frequency O4O-EYFPA Max Peak Power (dBm) Min Separation distance (mm) Frequency (Ghz) When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 2.465 5 -6.72 SAREXJUST-B-0-43 REV A 01/21/2014

Report Number: B50219D2 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Impact Wrench Model: EYFPA1JR Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 15 FCC PART 15, SUBPART B and C TEST REPORT for CORDLESS IMPACT WRENCH Model: EYFPA1JR Prepared for C.E. ELETRONICS, INC. 2107 INDUSTRIAL DRIVE BRYAN, OHIO 43506 Prepared by:_____________________ KENNETH LEE Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: FEBRUARY 20, 2015 REPORTAPPENDICESTOTAL BODYA B C D E PAGES 15 2 2 2 13 29 63 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50219D2 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Impact Wrench Model: EYFPA1JR Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 15 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 9 6. TEST SITE DESCRIPTION 10 6.1 Test Facility Description 10 6.2 EUT Mounting, Bonding and Grounding 10 6.3 Facility Environmental Characteristics 10 7. TEST PROCEDURES 11 7.1 RF Emissions 11 7.1.1 Radiated Emissions (Spurious and Harmonics) Test – Lab B 11 7.1.2 Radiated Emissions (Spurious and Harmonics) Test – Lab D 13 7.1.3 RF Emissions Test Results 14 8. CONCLUSIONS 15 Report Number: B50219D2 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Impact Wrench Model: EYFPA1JR Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 15 LIST OF APPENDICES LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site 2 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1.0 Radiated Emission Results APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models D Diagrams, Charts and Photos  Test Setup Diagrams  Antenna Factors  Test Setup Photos E Data Sheets Report Number: B50219D2 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Impact Wrench Model: EYFPA1JR Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 15 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: Cordless Impact Wrench Model: EYFPA1JR S/N: N/A Product Description: The equipment under test is a Cordless Impact Wrench. Modifications: The equipment under test was not modified in order to meet the specifications. Manufacturer: C.E. Electronics, Inc. 2107 Industrial Drive Bryan, Ohio 43506 Test Date: February 19, 2015 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, AC Lines, 150 kHz – 30 MHz This test is not applicable because the EUT is DC powered and does not connect to the public AC mains. 2 Radiated RF Emissions, 10 KHz – 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.205, 15.209 and 15.249 *U = Expanded Uncertainty with a coverage factor of k=2 Report Number: B50219D2 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Cordless Impact Wrench Model: EYFPA1JR Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 15 1. PURPOSE This document is a qualification test report based on the emissions tests performed on the Cordless Impact Wrench, Model: EYFPA1JR. The emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test,…
