O552451234G Flip phone

SWAGTEK

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Feb 04, 2024
Application Purpose: Original Equipment
Date of Application: Feb 04, 2024
Equipment Note: 4G Flip phone
Frequency Range: 2402.00000000 - 2480.00000000
Company: SWAGTEK
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Thanks for selecting this mobile phone. For the best performance we recommend that you read the manual carefully. Contents Overview. ..............................................................................................2 1. Introduction .........................................................................................3 2. Function of main menu.............................................................................4 3. Maintenance and service............................................................................9 2 ◼ Overview Please read the following concise rules carefully. Nonobservance to the rules may lead to danger or violence of the laws. The user’s manual gives details about the safety precautions. ◼ Emergency call Make sure the equipment is in the covered area of the network service and the calling f unction is activated. As per the specific requirements, press the key of finish to clear the screen and return to the standby state. Input the emergency call number （112）and press the call key. ◼ Function Description The phone is a perfect combination of humanized design and exquisite workmanship, the streamline and ingenious body is comfortable to hold. With streamline and ingenious frame, it feels comfortable to hold the mobile phone in your hand. It supports TXT electronic book, Blue-tooth, dual SIM cards with one standby, network camera, camera, FM and etc，It makes your work more convenient and your free time more fun with the combination of keyboard, florid colored screen, pleasant bells, cartoon head portrait for incoming calls, strong file management function (supporting T-FLASH card), fashionable camera function and long time tape recording function, music player, video player. 3 ◼ Introduction Insert the SIM card and the battery Ask your SIM card dealer whether he has provided SIM card service and the method of usage who may be service provider or other dealers，SIM card and its contacts are vulnerable to scratch or bending. Attention shall be attached when use, insert or take out the card. ◼ Inserting/taking out T-FLASH CARD Only use approved and compatible T-FLASH card applicable to the mobile phone. Approved memory card trade standard is applied; however, certain bands may not be completely compatible with the mobile phone. Using incompatible memory card may damage not only the card and the mobile, but also the data stored in the card. ◼ Charging the battery Check the model number of the charger before using it to charge the mobile，Only use approved battery, charger and accessories applicable to the specific mobile model. Using other types of battery, charger and accessories may violate the certification or warranty terms of the equipment and may result in danger，Refer to the dealer for supply of relative approved accessories. ◼ Startup and shutdown Press the key of power supply to start up or shut down the mobile phone，If it is prompted to input PIN or UPIN, please input the required password (shown as **** on the screen). 4 Function of main menu ◼ Contacts Save the information of contacts , including names and telephone numbers in the contacts. ◼ Message Write a message: You can choose to send the complete message from SIM card 1 or SIM card 2, You can choose multiple receivers to send the message to more than 1 person.. ◼ Call logs By telephone if you need to check you call logs>click select call logs menu>View: 1.All calls 2.SIM1/2 missed calls 3.SIM1/2 Dialed calls 4.SIM1/2 Received calls 5.SIM1/2 Rejected calls 6.Delete call logs 7.call timers. ◼ Settings Phone settings 1.1.Date&Time :You can set the phone's time and date and the format. 1.2.Language Settings:You can select the phone’s display language . 1.3.Shortcut Settings:You can set the phone right soft keys and the navigation key shortcut functions. 1.4.Auto power on/off:After setting the time, and by that time the phone will auto power on/off. 1.5.Power management:Battery remains. 1.6.Restore factory settings:Enter the correct password of the phone will have to change your phone settings back to factory default state value, the user of the function be used with caution. (Default password: 1234). Display Settings 1.1.Animation effect:Set power on/off animation. 1.2.Wallpaper setting:Set wallpaper. 5 1.3.Idle display settings:You can choose to display or not display. 1.4.Brightness:The menu is to control of mobile phone screen brightness 1.5.Display backlight :The menu is to control of mobile phone display backlight time. 1.6.Keypad backlight :The menu is to control of mobile phone Keypad backlight time. Call settings This is some of the communications settings.There are have Dual-SM,Call divert,Call waiting,Call barring,Hide ID and others. Security PIN/PIN2:The SIM1/2 security setting need provided network operator .for more details, please contact your operator. Phone locked: You can switch on or off to activate the phone lock function to protect your phone. Modify the phone password:You can change password here. The default password is “0000”. Privacy:You can open the privacy protection function, set up mobile privacy. Auto keypad lock:You can set the on/off automatically lock screen mobile phone. Lock screen by end key:Set end key as dedicated key to lock the phone. Fixed dialing:You can set a fixed dialing. Connections Configure the network parameter in the place. ◼ Multimedia ◼ Camera In the options of camera, you may set the photometry mode, flash light，exposure compensation, avoidance of flickering, postponing shooting, white balance, photo quality, photo size, special effect, profile and etc. You may enter the album to check the formats that the cell phone supports. 6 ◼ Image viewer Check the pictures in the memorial card in formats supported by the cell phone. ◼ Video Recorder phone provides video recording, select video footage that can enter the video recording. In the preview video press OK button to begin, press stop again, can have white balance, exposure compensation, n…

Text truncated - open the document above for the full version.

Attestation Statements

SWAGTEK Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date:1/31/2024 FCC ID: O55245123 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing SWAGTEK certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing SWAGTEK certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: SWAGTEK Address: 10205 NW 19th Street STE101 Miami, FL33172 Contact Person: Charles Cheng Tel.: 1-305 421 9938 Email: [email protected] Sincerely, Signature:

Attestation Statements

Attestation Statements 2023-12-27 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID:O55245123) SWAGTEK, the undersigned, hereby authorize SWAGTEK to act as our designated U.S. agent for service of process, SWAGTEK accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. SWAGTEK accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: SWAGTEK Contact Name: Charles Cheng FRN: 0021846670 Address: 10205 NW 19th Street STE101 Miami, FL33172 Telephone No: + 1-305 421 9938 Email: [email protected] Signature: Charles Cheng U.S. Agent Information: Company name: SWAGTEK Contact Name: Charles Cheng FRN: 0021846670 Address: 10205 NW 19th Street STE101 Miami, FL33172 Telephone No: + 1-305 421 9938 Email: [email protected] Email: [email protected] Contact Name: Charles Cheng Signature:

Block Diagram

SWAGTEK Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 31, 2024 Subject; Request for Confidentiality FCC ID: O55245123 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Charles Cheng Title: Manager

Cover Letter(s)

1 项目Project：F19-4G不带开关调试报告 No switch debugging report 频段Frequency：GSM 天线Antenna：熊锡巍 XiweiXiong 日期Date：2024年01月06日 The west side of the first floor, the third floor, Building 1, Shayi North Yongfa Science Park, Xinhe Road, Gonghe Community, Shajing Street, Baoan District, Shenzhen Shenzhen QIXIN TongDATechnology Co., LTD 测试项目与设备Test project and devices 测试项目test project设备devices 1.S参数 s parameter 1.回损(RL) 2.驻波比(VSWR) 网络分析仪network analyzer：Agilent 5071B 2.耦合功率测试 Coupled power test 1.发射功率（power） 2.接收灵敏度(level) 综测仪integrated measuring instrument： CMW500/8960 暗室DARK ROOM：6*4*3微波暗室 length：24mm Wide：32mm 3 调试版本记录Debug version record 版本version日期date调试概述Debugging overview 2024-01-06 4 主板型号图示 picture of mainboard 5 主信号源匹配电路图Main signal source matching circuit diagram Element Value E1 0.5PF E2 未更改no change E3 未更改no change E4 未更改no change 原主板并地电容0.5PF保持不变The parallel ground capacitance of the original mainboardremains unchanged at 0.5PF 地脚并地2.0NH电感Base parallel 2.0NH inductance 6 天线辐射测试数据（无源）Antenna radiation test data BandMax GainBandMax Gain GSM900 -0.97 LTE-FDD-B4 1.64 DCS1800 1.89 LTE-FDD-B5 0.42 GSM850 0.42 LTE-FDD-B8 -0.97 PCS1900 1.17 LTE-FDD-B12 0.14 WCDMA 850 0.42 LTE-FDD-B13 0.29 WCDMA1700 1.64 LTE-FDD-B17 0.17 WCDMA1900 1.17 LTE-FDD-B66 1.22 LTE-FDD-B2 1.17 LTE-FDD-B28 0.17 7 天线辐射测试数据（BT无源）Antenna radiation test data Frequency Gain (dB) 2400MHz 0.23 2425MHz 0.27 2450MHz 0.31 2475MHz 0.33 2500MHz 0.29 8 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 9 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 10 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 11 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 12 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 13 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 14 天线辐射测试数据（方向图）Antenna radiation test data (direction chart) 15 天线辐射测试数据（BT方向图）Antenna radiation test data (BT direction chart) 16 天线辐射测试数据（BT方向图）Antenna radiation test data (BT direction chart) 17 整机环境处理environment of the sample 上盖PCB的漏铜区域上贴一整块导电布覆盖显示屏An entire conductive cloth is affixed to the copper leakage area of the top PCB to cover the display 18 整机环境处理environment of the sample 喇叭的磁钢用导电泡棉接地The magnetic steel of the horn is grounded with conductive foam

Cover Letter(s)

SWAGTEK Declaration Letter of Model Difference Date: 1/31/2024 Tested Model Number: Z1L Adding Model Number(s): UF1L Trademark: UNONU, LOGIC, iSWAG The differences between the various models in this application are only different in model name for different customers and different sales areas, Other is the same. . Yours Sincerely, Title: Manager Email: [email protected] On behalf of: SWAGTEK Sincerely, Signature:

Cover Letter(s)

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 SWAGTEK Date：1/31/2024 Product Model Number: Z1L, UF1L FCC ID：O55245123 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. Signature: By: Charles Cheng Contact Listed on FCC Wesbite Title: Manager Email: [email protected] On behalf of: SWAGTEK

External Photos

Page 1 of 5 Report No.: LGT23L044 Appendix - External Photographs of EUT Constructional Details Model: Z1L Photo 1 Photo 2 Page 2 of 5 Report No.: LGT23L044 Photo 3 Photo 4 Page 3 of 5 Report No.: LGT23L044 Photo 5 Photo 6 Page 4 of 5 Report No.: LGT23L044 Photo 7 Photo 8 Page 5 of 5 Report No.: LGT23L044 Photo 9

ID Label/Location Info

Label SWAGTEK 4G FLIP PHONE Model: Z1L FCCID: O55245123

Internal Photos

Page 1 of 8 Report No.: LGT23L044 Appendix - Internal Photographs of EUT Constructional Details Model: Z1L Photo 1 Photo 2 Page 2 of 8 Report No.: LGT23L044 Photo 3 Photo 4 Page 3 of 8 Report No.: LGT23L044 Photo 5 Photo 6 Page 4 of 8 Report No.: LGT23L044 Photo 7 Photo 8 Page 5 of 8 Report No.: LGT23L044 Photo 9 Photo 10 Page 6 of 8 Report No.: LGT23L044 Photo 11 Photo 12 BT ANT Page 7 of 8 Report No.: LGT23L044 Photo 13 Photo 14 Page 8 of 8 Report No.: LGT23L044 Photo 15 GSM/WCDMA/LTE ANT

RF Exposure Info

SAR Dipole Performance Measurement Report If dipoles are verified in return loss<-20dB, (within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head 835 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2022.02.11 -25.67 - 54.4 - 2023.02.08 -27.048 5.37 56.211 1.81 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 835MHz Head 1800 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2022.02.11 -28.69 - 51.9 - 2023.02.08 -25.320 -11.75 47.250 -4.65 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 1800 MHz ※※※※※END OF THE REPORT※※※※※

RF Exposure Info

! " # $#"% "& & "# ' #& &! % ! " $ #( " !# # &) & #" & " * $" " # + ,-$ ., /0123/456/4&) 650/7819456:61/205 5;<987=0535>4 381>5?@/A59:5#05B1>65"8;<89 @C$ !#*"# /0123/41896/45+-- DEEFGHIJKJILMNOPQRSTU VELWGKXKIYKZYGLM[[[\EL]FKE\]F <5:>58^4<58^3/;23/96/964<5/;;35614/418935^5359;5>1>738<121456^38_/9`357386:;4189 abccde fgINHLEhiGMJWFGNGMJNJgGiGJgLHKMHFGNhYJN]FLiKMKEEFGHIJGHjklkVDmnQoIGYHpFLZG EKYIZFKJILMWGF]LFiGHKJlqrshNIMtJgGjDuvpmkwnJGNJZGMEgs]LFhNG[IJgKlqrjklk VDm NxNJGiLMYx\fgGJGNJFGNhYJNELXGFGHZxKEEFGHIJKJILMKFGJFKEGKZYGJLJgGvMJGFMKJILMKYVxNJGiL] yMIJNzVv{\ & #"*1506$3825/0123/4189"57834 Ref : ACR.41.6.23.BES.A !"#$%&&&%'%((%)*+,%-../0!#1)1."$234567 89:;<=>?@AB;9CCA=BDEFE=<?><GH>FB:AI?CC=E:AFEBGJ:B9=?BB9JE:BBAFFE=KC=ILMNO89:AI=E@B:=A>=AB:A<9E:A:;B=D?;< = ACPI=EB9F?EF=;I=EJ9:>9:B:;;?D@:BB<A<:;A=BB=DEC;<:AJ9=C=EFEBJ:B9=?BJE:BBAFFE=KC=ILMNO Q@R?A>B:=ASBT:AB?E EFE<DPUVWXYZ[\]^Z]_`a]bcdb`beZW f9>g<DPUVWXYZ[\]^Z]_`a]bcdb`beZW hFFE=K<DPijb``^k\lba`[bmkWblkWnoaWZ]lkW f?;B=@EQ@ S:;BE:D?B:=A [p^qr_Z`s_Z`t ^Zul^Z]_`kcken vkwx[lyw z;;?Q@SBL=<:I:>B:=A; {UVWXYZ[\]|`alabcWZcZbuZ }~}~} ~~~~ Ref: ACR.41.6.23.BES.A 2/10/2023 2/10/2023 2/10/2023 2/10/2023 ~ ~ !"#$%&&&%'%((%)*+,%-../0!#1)1."$234567 89:;<=>?@AB;9CCA=BDEFE=<?><GH>FB:AI?CC=E:AFEBGJ:B9=?BB9JE:BBAFFE=KC=ILMNO89:AI=E@B:=A>=AB:A<9E:A:;B=D?;< = ACPI=EB9F?EF=;I=EJ9:>9:B:;;?D@:BB<A<:;A=BB=DEC;<:AJ9=C=EFEBJ:B9=?BJE:BBAFFE=KC=ILMNO Q RSTUVSWXYSZ[S\]^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^_ ` aZbYcV]RS\VZUd]UbX^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^_ `^QeSXSZfghXibZjf]UbXkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkk_ l mSf\cZSjSX]mS]nbY^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^_ l^QoUXSfZU]pkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkk_ l^`qSX\U]UTU]pkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkk_ l^lobrSZRS]SV]UbXoUjU]kkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkks l^_h\b]Zbdpkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkks l^Q tbcXYfZpuiiSV]kkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkks _mSf\cZSjSX]WXVSZ]fUX]p^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^v s wfgUxZf]UbXmSf\cZSjSX]yS\cg]\^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^v s^Q qSX\U]UTU]pUXfUZkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkv s^` oUXSfZU]pkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkz s^lqSX\U]UTU]pUXgU{cUYkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkk| s^_ h\b]Zbdpkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkk} voU\]biu{cUdjSX]^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^Q~ Ref: ACR.41.6.23.BES.A !"#$%&&&%'%((%)*+,%-../0!#1)1."$234567 89:;<=>?@AB;9CCA=BDEFE=<?><GH>FB:AI?CC=E:AFEBGJ:B9=?BB9JE:BBAFFE=KC=ILMNO89:AI=E@B:=A>=AB:A<9E:A:;B=D?;< = ACPI=EB9F?EF=;I=EJ9:>9:B:;;?D@:BB<A<:;A=BB=DEC;<:AJ9=C=EFEBJ:B9=?BJE:BBAFFE=KC=ILMNO Q R S TUVWXUYZ[U\]U^_ `abcdaefgahijiklm`iknjoemnhopnoq`rmiso jtuvwtdxvyayjz{ j|}a~kko kayct~vaykor{i ry|}vdxh|u}cxc|uuava} pyavaudfmtua|wry|a{{ macxtuda|weyaa`cg|~atxh|uuadx|y `cg|~amj `cg|~amj `cg|~amj S {oomlqnpimjleni ¡¢£¤¥¦§ ̈©ª«¬¦ª¦¬®¥§ ̄¥°tdd|y}tudax|xanohnooo±²tu}phh ³`s²`xtu}ty} ́μ¶· ̧Q¹LMNº»L»¼½¾¿=;:@BE:>ÀI:C<E=D ry|aqaux qaux|wnu}cbc}vt~`cg|~a jtÁcvaÁxayut~}ctaxay² ry|aecgoÁxayut~`ctaxay `cxtudaaxaau}cg|~agy|aaÁxyacxf ÂSÃ eanohnooo±²tu}phh³`s²`xtu}ty}gy|bc}ayad|au}a}gytdxcdaw|y xagy|adt~cytxc|uÄcud~v}cuxagayw|ytudadtytdxaycxcd|wcuxayaxtu}ax|}fcdx| taxacytwwadxl~~dt~cytxc|uatvyaauxgayw|ya}aaxxaw|yaauxc|ua}xtu}ty} qnolmneÅ eaabt~vtxc|u|wxa~cuatycxft}|uacuwyaagtdavcuxatbavc}aÄgayw|ycutg|ay aagx|d|bayxaklmytuaÆÇx|ÆÇ koknenzneÅ eaaucxcbcxfwtdx|y|wxaxyaa}cg|~aaya}axaycua}vcutx|xagdt~cytxc|uax|}tcy tu}xcvacv~txcu~cvc}vcutbavc}at|vx~cua}cuxaxtu}ty} Ref: ACR.41.6.23.BES.A Used …

Text truncated - open the document above for the full version.

RF Exposure Info

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China SAR TEST REPORT Product Name: 4G Flip phone Model Name: Z1L Family Model: UF1L FCC ID: O55245123 Issued For : SWAGTEK 10205 NW 19th Street STE101 Miami, FL33172 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT23L044HA01 Sample Received Date: Dec.21, 2023 Date of Test: Dec. 21, 2023 ~ Jan. 04, 2023 Date of Issue: Jan. 18, 2024 Max. SAR (1g): Head: 1.253 W/kg Body: 1.355 W/kg Reprot No.: LGT23L044HA01 Page 2 of 101 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 15 6. SAR Evaluation Procedures 16 7. EUT Antenna Location Sketch 17 7.1 SAR test exclusion consider table 18 8. EUT Test Position 22 8.1 Define Two Imaginary Lines on the Handset 22 8.2 Hotspot mode exposure position condition 23 9. Uncertainty 24 9.1 Measurement Uncertainty 24 10. Conducted Power Measurement 25 10.1 Test Result: 25 11. EUT and Test Setup Photo 41 11.1 EUT Photos 41 11.2 Setup Photos 44 12. SAR Result Summary 50 12.1 Head SAR 50 12.2 Body SAR 53 13. Equipment List 60 Appendix A. System Validation Plots 61 Appendix B. SAR Test Plots 77 Appendix C. Probe Calibration and Dipole Calibration Report 101 Reprot No.: LGT23L044HA01 Page 3 of 101 Revision History Rev. Issue Date Contents 00 Jan. 18, 2024 Initial Issue Reprot No.: LGT23L044HA01 Page 4 of 101 TEST REPORT CERTIFICATION Applicant: SWAGTEK Address: 10205 NW 19th Street STE101 Miami, FL33172 Manufacture: SWAGTEK Address: 10205 NW 19th Street STE101 Miami, FL33172 Product Name: 4G Flip phone Trademark: UNONU, LOGIC, iSWAG Model Name: Z1L Family Model: UF1L Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Zane Shan Engineer Vita Li Manager Reprot No.: LGT23L044HA01 Page 5 of 101 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name: 4G Flip phone Trademark: UNONU, LOGIC, iSWAG Model Name: Z1L Family Model: UF1L Model Difference: Only different in model name Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version T11_ MB _V2.0 Software Version T11_WEL_W245_V01_12142023 Frequency Range GSM 850: 824 ~ 849 MHz PCS 1900: 1850 ~ 1910 MHz WCDMA Band II: 1850 ~ 1910 MHz WCDMA Band IV:1710 ~ 1755 MHz WCDMA Band V: 824 ~ 849 MHz LTE Band 2:1850 ~1910 MHz LTE Band 4:1710 ~1755 MHz LTE Band 5:824 ~ 849 MHz LTE Band 12:699~716 MHz LTE Band 13:777~787MHz LTE Band 17:704 ~ 716 MHz LTE Band 66:1710~1780 MHz Bluetooth: 2402 ~ 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Head:0mm Body:10mm Mode Head (W/ kg) Body Worn (W/ kg) GSM 850 0.316 0.422 PCS 1900 0.237 0.284 WCDMA Band II 0.461 0.529 WCDMA Band IV 0.791 1.179 WCDMA Band V 0.362 0.249 LTE Band 2 0.631 0.652 LTE Band 4 0.886 1.338 LTE Band 5 0.311 0.383 LTE Band 12 0.314 0.176 LTE Band 13 1.253 1.075 LTE Band 17 0.376 0.148 Reprot No.: LGT23L044HA01 Page 6 of 101 LTE Band 66 1.188 1.355 Bluetooth Note 0.210 0.210 1-g Sum SAR 1.463 1.565 Battery Rated Voltage:3.7V Capacity: 1000mAh Description test modes SIM 1 and SIM 2 is a chipset unit and tested as single chipset, SIM 1 is used to tested Operating Mode: GSM: GSM Voice; GPRS WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM Bluetooth: GFSK +π/4DQPSK+8DPSK Antenna Specification GSM/WCDMA/LTE: FPC Antenna Bluetooth: Monopole Antenna Operating Mode Maximum continuous output Hotspot Mode Not Support DTM Mode Not Support Note 1: The BT value was Estimated. Reprot No.: LGT23L044HA01 Page 7 of 101 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate FCC Registration No.: 746540 A2LA Certificate No.: 6727.01 IC Registration No.: CN0136 Reprot No.: LGT23L044HA01 Page 8 of 101 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial- Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Charles Cheng(Manager)

[email protected]1-305 421 9938Fax: 1-305 471 9011

Technical Contact

SWAGTEK

[email protected]

United States

Test Firm

Shenzhen LGT Test Service Co., Ltd.Wen Wen

[email protected]0755-89668180

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	4.80 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted power. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.0 cm separation between the device and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory and simultaneous transmission use conditions is 0.21W/kg, 0.21W/kg and 1.57W/kg respectively.
