O555731205.7 inch 3G Smart Phone

SWAGTEK

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Nov 19, 2020
Application Purpose: Original Equipment
Date of Application: Nov 19, 2020
Equipment Note: 5.7 inch 3G Smart Phone
Frequency Range: 1852.40000000 - 1907.60000000
Company: SWAGTEK
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Know your phone 1 Table of Contents Know your phone ..................... 错误!未定义书签。 1. SIM/SD Card Installatioan ..... 6 Install SIM /SD card .............................................. 6 Headphone and USB jack ..................................... 7 Recharge .............................................................. 8 Side and back functions ........................................ 9 2. Menu functions ...................... 10 Contacts ............................................................. 10 Message ............................................................. 10 Phone ................................................................. 10 Gmail .................................................................. 10 Camera ............................................................... 10 Gallery .................................................................11 FM Radio .............................................................11 YT Music ..............................................................11 Files .....................................................................11 Bluetooth .............................................................11 SIM Toolkit .......................................................... 12 Calendar ............................................................. 12 Clock .................................................................. 12 Calculator ........................................................... 12 3. Accessories ........................... 13 4. FCC Regulations ................... 14 5. SAR ........................................ 16 6. Technical Specifications ....... 17 2 Foreword Honorific mobile phones user, thank you for choosing our mobile phone! Our cellular phones is according with the communication industry standards of PRC, and also according with the standards of European, and are approved for GSM networks. Your phone may be used internationally with various networks depending on your roaming arrangements with your service provider. To use this phone you must subscribe to a GSM service from a provider. We have included many features in this device but their function depends on the features available with your subscribed wireless network. Please contact your service provider for more information. We strongly recommend you carefully read and understand this manual before using your phone in order to keep it under best conditions for your effective usage and utmost satisfaction. Safety Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use. As a general rule, always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, swimming pool...). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than - 10°C and higher than + 55°C. Please note that the ambient temperature range for normal charging of mobile phones is 0 °C ~ 45 °C. Do not charge at an ambient temperature below 0 ° C or above 45 ° C, as this will result in reduced battery performance and reduced life. Charging for too long at too high or too low ambient 3 temperatures can damage unfilled or swelled batteries, and there is a risk of battery explosion The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested). Electrical safety Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate. Aircraft safety When traveling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations. Explosive materials Please comply with warning signs at petrol station when personnel asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way. Electronic equipment To avoid the risk of demagnetization, do not let electronic devices close to your phone for a long time. Electronic medical equipment Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 5mm be maintained between the phone and an implant. Your doctor or the manufacturers of such equipment will be able to give you any advice you may need in 4 this area. Hospitals Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff. Road safety Do not use your phone when driving. In order to give your full attention to driving, stop and park safely before making a call. You must comply with any current legislation. Distance of operation This phone model has been tested and meets radiofrequency exposure guidelines when used As follows: ·Against the ear: place or receive a phone call and hold the phone as you would a wire line telephone. ·Body worn: when transmitting, place the phone in a carry accessory that contains no metal and positions the phone a minimum of 5mm form your body. Use of other accessories may not ensure compliance with radiofrequency exposure guidelines. If you do not use a body worn accessory and are not holding the phone at the…

Text truncated - open the document above for the full version.

Cover Letter(s)

SWAGTEK DATE :2020-10-22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 055573120 Product Name: 5.7 inch 3G Smart Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description • BOM • TUNEUP These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2020-10-22 By: Charles Cheng Signature Printed Title: Manager On behalf of : SWAGTEK Telephone: 1-305-421-9938

Cover Letter(s)

SWAGTEK DATE:2020-10-22 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appointJianYanTesting Group Shenzhen Co. , Ltd..; 1st Floor, Block No.B- C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will hav e affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with 10205 NW 19th St. Suite 101, Miami, FL, 33172 Dated this 2020-10-22 By : Charles Cheng Signature Printed Title: Manager On behalf of : SWAGTEK Telephone: 1-305-421-9938

Cover Letter(s)

D eclaration Letter We, SWAGTEK declared that our 5.7 inch 3G Smart Phone item No.: X57A,NEO,W57A, were identical inside, the electrical circuit design, layout, components used and internal wiring. LOGIC model corresponds to the trademark X57A. iSWAG model correspond to the trademark NEO UNONU model corresponds to the trademark W57A. Sincerely yours Signature: N ame/Title: Charles Cheng/ Manager Tel. No. 1-305-421-9938 E- Mail: C ompany: S WA G T E K Brand：LOGIC,iSWAG, UNONU Da te：2020-10-22

External Photos

ID Label/Location Info

Location:

Internal Photos

Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 44 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 45 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 46 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 47 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 48 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 49 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 50 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 51 of 52 Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 52 of 52 ------End of report------

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZE201003801 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Swagtek Address of Applicant: 10205 NW 19th St. Suite 101, Miami, FL, 33172 Equipment Under Test (EUT) Product Name: 5.7 inch 3G Smart Phone Model No.: X57A, NEO, W57A Trade mark: LOGIC, iSWAG, UNONU FCC ID: O55573120 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 29 Oct., 2020 ~ 06 Nov., 2020 Test Result: Maximum Reported1-g SAR (W/kg) Head: 0.272 Body: 0.651 Hotspot: 0.685 Report No: JYTSZE201003801 JianYan Testing Gr oup Shenzhen Co., Ltd. Project No.: JYTSZE2010038 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 2 of 120 2 Version Version No. Date Description 00 16 Nov., 2020 Original Prepared by: Date: 16 Nov., 2020 Report Clerk Reviewed by: Date: 16 Nov., 2020 Project Engineer Report No: JYTSZE201003801 JianYan Testing Gr oup Shenzhen Co., Ltd. Project No.: JYTSZE2010038 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 3 of 120 3 Contents 1 COV ER P AGE ................................................................................................................................................................................. 1 2 VERSION........................................................................................................................................................................................... 2 3 CONTENTS ...................................................................................................................................................................................... 3 4 SAR RES ULTS SUM MARY ....................................................................................................................................................... 5 5 GENERAL INFORMATION ........................................................................................................................................................ 6 5.1 CLIENT INFORMATION....................................................................................................................................................................... 6 5.2 GENERAL DESCRIPTION OF EUT ..................................................................................................................................................... 6 5.3 MA XI MUM RF OUTPUT POWER........................................................................................................................................................ 7 5.4 ENVIRONMENT OF TEST SITE........................................................................................................................................................... 7 5.5 TEST SA MP LE PLAN ......................................................................................................................................................................... 7 5.6 TEST LOCA TION................................................................................................................................................................................ 7 6 INTRODUCTION............................................................................................................................................................................. 8 6.1 INTRODUCTION ................................................................................................................................................................................. 8 6.2 SAR DEFINITION .............................................................................................................................................................................. 8 7 RF EXP OSURE LIMITS ............................................................................................................................................................... 9 7.1 UNCONTROLLED ENVIRONMENT ...................................................................................................................................................... 9 7.2 CONTROLLED ENVIRONMENT ........................................................................................................................................................... 9 7.3 RF EXPO SURE LIMITS ...................................................................................................................................................................... 9 8 SAR M EASUREM ENT S YSTEM............................................................................................................................................10 8.1 E-FIELD PROBE.........................................…

Text truncated - open the document above for the full version.

RF Exposure Info

EUT Photos (Model: X57A) EUT Antenna Locations SAR Test Setup Photos Head Right Cheek Right Tilted Left Cheek Left Tilted Body Front side (10mm) Back side(10mm) Top side(10mm) Bottom side(10mm) Left side(10mm) Right side(10mm)

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZE201003701 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT (GSM & WCDMA) Applicant: Swagtek Address of Applicant: 10205 NW 19th St. Suite 101, Miami, FL, 33172 Equipment Under Test (EUT) Product Name: 5.7 inch 3G Smart Phone Model No.: X57A, NEO, W57A Trade mark: LOGIC, iSWAG, UNONU FCC ID: O55573120 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E Date of sample receipt: 16 Oct., 2020 Date of Test: 17 Oct., to 05 Nov., 2020 Date of report issued: 06 Nov., 2020 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 52 2. Version Version No. Date Description 00 06 Nov., 2020 Original Tested by: Date: 06 Nov., 2020 Test Engineer Reviewed by: Date: 06 Nov., 2020 Project Engineer Report No: JYTSZE201003701 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2010037 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 52 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST ENVIRONMENT AND MODE, AND TEST SAMPLES PLANS ............................................................................... 7 5.4 DESCRIPTION OF TEST AUXILIARY EQUIPMENT .................................................................................................... 7 5.5 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 5.6 ADDITIONS TO, DEVIATIONS, OR EXCLUSIONS FROM THE METHOD....................................................................... 7 5.7 LABORATORY FACILITY .......................................................................................................................................... 7 5.8 LABORATORY LOCATION ....................................................................................................................................... 7 5.9 TEST INSTRUMENTS LIST ....................................................................................................................................... 8 6. TEST RESULTS ........................................................................................................................................................... 9 6.1 CONDUCTED OUTPUT POWER, ERP AND EIRP .................................................................................................. 9 6.2 PEAK-TO-AVERAGE POWER RATIO .................................................................................................................... 12 6.3 OCCUPY BANDWIDTH .......................................................................................................................................... 14 6.4 MODULATION CHARACTERISTIC .......................................................................................................................... 20 6.5 OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................................................................. 20 6.6 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ............................................................................... 27 6.7 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT............................................................................. 32 6.8 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT .....................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Charles Cheng(Manager)

[email protected]1-305 421 9938Fax: 1-305 471 9011

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	24E	1.85 GHz - 1.91 GHz	142.60 mW	4M14F9W	0.1 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission exposure conditions are 0.27 W/kg, 0.65 W/kg, 0.69 W/kg, and 0.82 W/kg respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
