O555734205.7 inch 4G smart phone

SWAGTEK

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Nov 19, 2020
Application Purpose: Original Equipment
Date of Application: Nov 19, 2020
Equipment Note: 5.7 inch 4G smart phone
Frequency Range: 2510.00000000 - 2560.00000000
Company: SWAGTEK
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Moblie Appearance pictue 1 Table of Contents Moblie Appearance picture ................... 1 Table of Contents .................................. 2 Foreword ............................................... 3 Getting to know your touch phone ...... 7 Phone ID map introduction ................... 9 Starting up the device ......................... 10 Introduce the basic phone function ... 15 Technical Specifications ..................... 22 SAR ...................................................... 23 2 Foreword Safety In order to ensure the phone is used safely and correctly, please read the precautions below carefully before use. 1.1 General precaution ·Your phone is only suitable for the battery and charger approved by our company or else it may cause the battery to leak, overheat, explode or even catch fire. ·Do not knock, vibrate or throw the phone heavily to avoid malfunction, fire, overheating, explosion or fire. ·If there are abnormal phenomena, like temperature rising, color change or distortion during the usage, charging or storage of the battery, please stop using it and replace it with a new battery. ·It may burn the skin if liquid in the battery leaks onto skin or clothes. If this happens please flush with plenty of clean water immediately and go to a hospital at once. ·Please keep the battery away from fire to avoid fire and explosion if the battery leaks or emits a strange smell. ·Do not place expose the battery to moisture or it may cause overheating, fumes and corrosion. ·Do not use or place the battery under direct sunlight, or in hot places, it may cause leakage and overheating, thus reducing performance and shortening the lifespan. ·Do not charge the battery for over 24 hours continuously. ·Use careful with the earphone maybe possible excessive sound presure from earphones and headphones can cause hearing loss. 3 1.2 Precaution for the use of charger ·Do not cause short circuit to the charger, or it may cause electric shock, fumes and damage to the charger. ·Do not use the charger if the power wire is broken, or it may cause fire and electric shock. ·Please remove accumulated dust on the power plug. ·Do not put water containers next to the power supply to avoid overheating, fire, electric shock and malfunction in case they come into contact. ·Do not disassemble or tamper with the charger or it may cause personal injury, electric shock, fire and the damage of the charger. ·Do not use the charger in places of high humidity, like bathrooms, or it may cause electric shock, fire and damage of charger. ·Do not touch the charger, power cord or power plug with wet hands or it can cause electric shock. ·Do not put heavy objects on the power cord or change the power cord or it may cause electric shock and fire. ·Please unplug the power socket before cleaning and maintenance. ·Please hold the charger to unplug the socket as pulling the power cord may damage the power wire and cause electric shock and fire. 1.3 Cleaning and maintenance ·As the phone, battery and charger are not waterproof, do not use them in places of high humidity and avoid them being wet by rain. ·Please clean the battery and charger with a soft dry cloth. ·Never use alcohol, thinner or solutions, like benzene, to wipe the phone. ·Dirty sockets can cause poor contact and power 4 down, and even make recharging unavailable. So, please clean them periodically. 1.4 Common Precaution Mobile Phone: ·Please use the phone in an environment with temperature between -20°C- 45°Cand humidity of <75%. ·Please use the phone far away from regular telephones, TV sets, radio sets and office automation equipment, to avoid affecting the normal use of these equipments and mobile phone. Battery: ·Store the battery in cool and ventilated place without direct sunlight. ·The battery has a limited lifespan. The usage of battery will be shortened progressively due to frequent charging. Once the battery is out of use, it means that its lifespan has ended, and you will need to replace it with an approved new battery. ·Do not dispose of old batteries as household waste. Give them to specified disposal places and follow any stipulated instructions for disposal. CAUTION:RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCYIONS. charger: ·Do not charge in the following places: - direct sunlight - Please note that the ambient temperature range for normal charging of mobile phones is 0 °C ~ 45 °C. Charging at ambient temperatures below 0 ° C or above 45 ° C can result in reduced battery performance and reduced life. Charging for too long at too high or too low ambient temperatures can damage unfilled or 5 swelled batteries, and there is a risk of battery explosion. - Places near the TV (may affect images and sounds), such as TVs, radios, etc. 6 Getting to know your touch phone 7 8 Phone ID map introduction Front camera:A camera placed on the front of the phone that can be used for mirroring photos. Receiver:It used to answer the call. Flash:Mirroring in the low light, you can add light to the subject. Display screen:It can display relevant content about the phone. Microphone:It is used to transmit sound when making a call. Battery cover open position:Use this position as the cut-in port, open the back cover of the phone to install or unload the battery. USB port:It is used as an interface between the phone and the computer to transfer files. Earphone port:Headset jack: A port that can be plugged into the headset and can be used to answer calls. Back camera:A camera placed on the back of the phone that can be used to select objects in the field of view to take photos. Flash light:Bright light can be added in low light places. Battery cover:It protects the card slot and battery in the phone from damage. Speaker:It converts electrical energy into sound energy. It is also known as a sounder. Side key:You can use this up and down button to adjust the sound size. Power on/off key:It controls the…

Text truncated - open the document above for the full version.

External Photos

ID Label/Location Info

Location:

Internal Photos

Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 53 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 54 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 55 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 56 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 57 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 58 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 59 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 60 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 61 of 62 Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 62 of 62 ------End of report------

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZE200905301V01 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Swagtek Address of Applicant: 10205 NW 19th St. Suite 101, Miami, FL, 33172 Equipment Under Test (EUT) Product Name: 5.7 inch 4G smart phone Model No.: L57, OMEGA, UN57 Trade mark LOGIC, iSWAG, UNONU FCC ID: O55573420 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 21 Oct., 2020 ~ 25 Oct., 2020 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 0.294 Body: 0.759 Hotspot: 1.438 Maximum Reported 10-g SAR (W/kg) Extremity: 2.822 Report No: JYTSZE200905301V01 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 2 of 170 2 Version Version No. Date Description 00 11 Nov., 2020 Original 01 20 Nov., 2020 1. Update LTE Band 7 power on page 7/44. 2. Update LTE Band 7 SAR results on page 1/ 5/51 to 55/59 to 62. Tested by: Date: 20 Nov., 2020 Report Clerk Reviewed by: Date: 20 Nov., 2020 Project Engineer Report No: JYTSZE200905301V01 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 3 of 170 3 Contents 1 COV ER P AGE ................................................................................................................................................................................. 1 2 VERSION........................................................................................................................................................................................... 2 3 CONTENTS ...................................................................................................................................................................................... 3 4 SAR RES ULTS SUM MARY ....................................................................................................................................................... 5 5 GENERAL INFORMATION ........................................................................................................................................................ 6 5.1 CLIENT INFORMATION....................................................................................................................................................................... 6 5.2 GENERAL DESCRIPTION OF EUT ..................................................................................................................................................... 6 5.3 MA XI MUM RF OUTPUT POWER........................................................................................................................................................ 7 5.4 ENVIRONMENT OF TEST SITE........................................................................................................................................................... 8 5.5 TEST SA MP LE PLAN ......................................................................................................................................................................... 8 5.6 TEST LOCA TION................................................................................................................................................................................ 8 6 INTRODUCTION............................................................................................................................................................................. 9 6.1 INTRODUCTION ................................................................................................................................................................................. 9 6.2 SAR DEFINITION .............................................................................................................................................................................. 9 7 RF EXP OSURE LIMITS .............................................................................................................................................................10 7.1 UNCONTROLLED ENVIRONMENT .................................................................................................................................................... 10 7.2 CONTROLLED ENVIRONMENT ......................................................................................................................................................... 10 7.3 RF EXPO SURE LIMITS .................................................................................................................................................................... 10 8 SAR M EASUREM ENT S YSTEM...........................…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No: JYTSZE200905301 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 101 of 172 Test Laboratory: CCIS Date/Time: 10.21.2020 11:10:42 DUT: 5.7 inch 4G smart phone; Type: L57; Serial: 3# Communication System: UID 0, GPRS(4 Slots) (0); Frequency: 1880 MHz; Duty Cycle: 1:1.99986 Medium parameters used: f = 1880 MHz; σ = 1.412 S/m; ε r = 39.136; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(8.14, 8.14, 8.14); Calibrated: 09.23.2020;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 07.27.2020  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) GPRS 1900 4Slots Body Bottom/Middle Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 24.14 V/m; Power Drift = -0.29 dB Peak SAR (extrapolated) = 1.39 W/kg SAR(1 g) = 0.695 W/kg; SAR(10 g) = 0.341 W/kg Maximum value of SAR (measured) = 1.03 W/kg GPRS 1900 4Slots Body Bottom/Middle Channel/Area Scan (41x51x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.979 W/kg 0 dB = 0.979 W/kg = -0.09 dBW/kg Report No: JYTSZE200905301 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 102 of 172 Test Laboratory: CCIS Date/Time: 10.21.2020 13:41:40 DUT: 5.7 inch 4G smart phone; Type: L57; Serial: 3# Communication System: UID 0, UMTS-FDD(WCDMA) (0); Frequency: 1732.6 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 1732.6 MHz; σ = 1.372 S/m; ε r = 40.674; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(8.43, 8.43, 8.43); Calibrated: 09.23.2020;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 07.27.2020  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) WCDMA 1700 Body Bottom/Middle Channel/Area Scan (41x51x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 1.13 W/kg WCDMA 1700 Body Bottom/Middle Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 29.58 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 1.45 W/kg SAR(1 g) = 0.745 W/kg; SAR(10 g) = 0.379 W/kg Maximum value of SAR (measured) = 1.18 W/kg 0 dB = 1.18 W/kg = 0.72 dBW/kg Report No: JYTSZE200905301 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 103 of 172 Test Laboratory: CCIS Date/Time: 10.21.2020 16:34:49 DUT: 5.7 inch 4G smart phone; Type: L57; Serial: 3# Communication System: UID 0, UMTS-FDD(WCDMA) (0); Frequency: 1852.4 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 1852.4 MHz; σ = 1.399 S/m; ε r = 39.745; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(8.14, 8.14, 8.14); Calibrated: 09.23.2020;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 07.27.2020  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) WCDMA 1900 Body Bottom/Low Channel/Area Scan (41x51x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 1.33 W/kg WCDMA 1900 Body Bottom/Low Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 34.22 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 1.82 W/kg SAR(1 g) = 0.934 W/kg; SAR(10 g) = 0.472 W/kg Maximum value of SAR (measured) = 1.47 W/kg 0 dB = 1.47 W/kg = 1.67 dBW/kg Report No: JYTSZE200905301 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 104 of 172 Test Laboratory: CCIS Date/Time: 10.21.2020 20:10:32 DUT: 5.7 inch 4G smart phone; Type: L57; Serial: 3# Communication System: UID 0, LTE-Fdd(USA) 1RB QPSK (0); Frequency: 1860 MHz; Duty Cycle: 1:1 Medium parameters used: f = 1860 MHz; σ = 1.403 S/m; ε r = 39.573; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3924; ConvF(8.14, 8.14, 8.14); Calibrated: 09.23.2020;  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1373; Calibrated: 07.27.2020  Phantom: SAM 5.0; Type: QD000P40CD; Serial: TP:1765  Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) LTE Band 2 1RB(20MHz) Body Bottom/Low Channel/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 32.57 V/m; Power Drift = -0.24 dB Peak SAR (extrapolated) = 1.89 W/kg SAR(1 g) = 0.946 W/kg; SAR(10 g) = 0.467 W/kg Maximum value of SAR (measured) = 1.47 W/kg LTE Band 2 1RB(20MHz) Body Bottom/Low Channel/Area Scan (41x51x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 1.39 W/kg 0 dB = 1.39 W/kg = 1.43 dBW/kg Report No: JYTSZE200905301 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009053 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail: [email protected] Page 105 of 172…

Text truncated - open the document above for the full version.

RF Exposure Info

EUT Photos (Model: L57) EUT Antenna Locations SAR Test Setup Photos Head Right Cheek Right Tilted Left Cheek Left Tilted Body Front side (10mm) Back side(10mm) Top side(10mm) Bottom side(10mm) Left side(10mm) Right side(10mm) Extremity Bottom side(0mm)

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZE200905201 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certif ication mark. The manuf acturer should ensure that all products in series production are in conf ormity w ith the product sample detailed in this report. This report may only be reproduced and distributed in f ull. If the product in this report is used in any conf iguration other than that detailed in the report, the manuf acturer must ensure the new system complies w ith all relevant standards. This document cannot be reproduced except in f ull, w ithout prior w ritten approval of the Company. Any unauthorized alteration, f orgery or f alsif ication of the content or appearance of this document is unlaw f ul and off enders may be prosecuted to the f ullest extent of the law . Unless otherw ise stated the results show n in this test report ref er only to the sample(s) tested and such sample(s) are retained f or 90 days only. 1. Cover Page FCC REPORT (GSM & WCDMA) Applicant: Swagtek Address of Applicant: 10205 NW 19th St. Suite 101, Miami, FL, 33172 Equipment Under Test (EUT) Product Name: 5.7 inch 4G smart phone Model No.: L57, OMEGA, UN57 Trade mark: LOGIC, iSWAG, UNONU FCC ID: O55573420 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E FCC CFR Title 47 Part 27 Subpart L Date of sample receipt: 18 Sep., 2020 Date of Test: 18 Sep., to 10 Nov., 2020 Date of report issued: 11 Nov., 2020 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 62 2. Version Version No. Date Description 00 11 Nov., 2020 Original Tested by: Date: 11 Nov., 2020 Test Engineer Reviewed by: Date: 11 Nov., 2020 Project Engineer Report No: JYTSZE200905201 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 62 3. Contents Page 1. COV ER P AGE ................................................................................................................................................................................. 1 2. VERSION........................................................................................................................................................................................... 2 3. CONTENTS ...................................................................................................................................................................................... 3 4. TEST SUM MARY ........................................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................................ 5 5.1 CLIENT INFORMATION............................................................................................................................................................. 5 5.2 GENERAL DESCRIPTION OF E.U. T. ..................................................................................................................................... 5 5.3 TEST ENVIRONMENT AND MODE, AND TEST SAMPLES PLANS......................................................................................... 7 5.4 DESCRIPTION OF SUPPORT UNITS ...................................................................................................................................... 7 5.5 MEASUREMENT UNCERTAINTY............................................................................................................................................. 7 5.6 ADDITIONS TO, DEVIATIONS, OR EXCLUSIONS FROM THE METHOD ............................................................................... 7 5.7 LABORATORY FACILITY .......................................................................................................................................................... 8 5.8 LABORATORY LOCATION........................................................................................................................................................ 8 5.9 TEST INSTRUMENTS LIST ....................................................................................................................................................... 8 6. TEST RES ULTS ............................................................................................................................................................................. 9 6.1 CONDUCTED OUTPUT POWER, ERP AND EIRP .............................................................................................................. 9 6.2 PEAK-TO-AVERAGE POWER RATIO................................................................................................................................... 13 6.3 OCCUPY BANDWIDTH ........................................................................................................................................................... 16 6.4 MODULATION CHARACTERISTIC......................................................................................................................................... 25 6.5 OUT OF BAND EMISSION AT ANTENNA TERMINALS...........................................................................................…

Text truncated - open the document above for the full version.

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No: JYTSZE200905205 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the JYT product certification mark. The manufacturer should ensure that all products in series production are in conformity w ith the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies w ith all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful, and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT (LTE) Applicant: Swagtek Address of Applicant: 10205 NW 19th St. Suite 101, Miami, FL, 33172 Equipment Under Test (EUT) Product Name: 5.7 inch 4G smart phone Model No.: L57, OMEGA, UN57 Trade mark: LOGIC, iSWAG, UNONU FCC ID: O55573420 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 24 Subpart E FCC CFR Title 47 Part 27 Subpart L FCC CFR Title 47 Part 27 Subpart M Date of sample receipt: 18 Sep., 2020 Date of Test: 18 Sep., to 10 Nov., 2020 Date of report issued: 11 Nov., 2020 Test Result: PASS* *In the configuration tested, the EUT complied with the standards specified above. Report No: JYTSZE200905205 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZE2009052 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Charles Cheng(Manager)

[email protected]1-305 421 9938Fax: 1-305 471 9011

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
13	27	2.51 GHz - 2.56 GHz	84.50 mW	18M0W7D	0.07 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for Part 22, EIRP for Part 24 and Part 27. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), simultaneous transmission exposure conditions, and product specific 10-g SAR are 0.29 W/kg, 0.76 W/kg, 1.44 W/kg, 1.44 W/kg, and 2.82 W/kg respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
