O556025206.09 inch 4G Smart Phone

User Manual Contents Contents ..................................................................................................................................................... 1 1. Appearance and Keypad Operations .............................................................................................. 2 2. Using Memory Card as U Disk ...................................................................................................... 2 3. Wi-Fi .............................................................................................................................................. 3 4. Bluetooth ........................................................................................................................................ 4 5. Calculator ....................................................................................................................................... 5 6. Calendar ......................................................................................................................................... 5 7. Camera ........................................................................................................................................... 6 8. Clock .............................................................................................................................................. 8 9. Contacts.......................................................................................................................................... 9 10. FM Radio ................................................................................................................................... 12 11. Gmail .......................................................................................................................................... 13 12. Messaging .................................................................................................................................. 13 13. Phone.......................................................................................................................................... 15 14. Gallery........................................................................................................................................ 17 15. Settings ....................................................................................................................................... 19 16. Notices for the use of phone ...................................................................................................... 21 2 1. Appearance and Keypad Operations Keys Functions home Short press this button to return home from any application or interface. Long press it to open Google search. recent Short press it to open the recent items back Press it to return to the previous interface，or to close dialog box ,options’ menu ,notification panel or the keypad. power Short press this button to lock or unlock the screen. Long press it to open the phone’s menu，then you could choose to Power off, Restart, Airplane mode, Screenshot and Emergency. up Press it to increase the volume. down Press it to decrease the volume. 2. Using Memory Card as U Disk If you want to send music, pictures or other files to the phone’s memory card from the computer，you should set memory card as u disk first. Set memory card as u disk 1) Connect the phone to the computer with USB cable. The notification icon will appear in the status box. 2) Use USB mobile transmission line will connected to the computer 3) In the notification panel, touch USB is connected，And then touch the USB connected as a media device Notice: On the PC operation assistant tool such as mobile phone, Must be open the USB debugging. USB for file transfer 3 3. Wi-Fi Wi-Fi provides as far as 300feet (100M) range of wireless network access. If you use cell phone to connect Wi-Fi , you should connect to the wireless access point or 「hot spots」. Notices：The availability and coverage of Wi-Fi signal depend on the number, infrastructure and other objects penetrated by the signal. Open Wi-Fi and to connect to the wireless network 1) Enter settings. 2) Select the Wi-Fi box，to open Wi-Fi. Phone will automatically scan for available wireless networks. 3) Touch Wi-Fi settings. Then a list of Wi-Fi network will show the founded network name and security settings. (open network or WEP、WPA/WPA2 with password).If you enable the notification in Wi-Fi settings, The status box will show this icon () when open available wireless network founded. 4) Touch one of the Wi-Fi choices to connect the network. When you choose open network, phone will connect to it automatically. If you choose WEP、WPA/WPA2 with password, you should type the password first, then touch to connect it. Notices：when the phone is connected to the wireless network, the status box will show this Wi-Fi icon （）, and the approximate signal strengthen (the number of lit bars).If touch the connected network，will display the name of Wi-Fi network, status ,speed ,signal, strength, security, information and IP address. If you want to delete the wireless settings, please touch “FORGET” as in the picture below. If you want to connect to this network, you should re-enter these settings. Notice： Unless you choose to forget the network, otherwise, there is no need to re-enter the corresponding password when next time connecting to the previously encrypted wireless network. Wi-Fi will search automatically, that is, phone needn’t to perform additional steps to connect Wi-Fi networks. Connect to other Wi-Fi networks In the interface of wireless and network, touch Wi-Fi settings. The founded Wi-Fi networks will show on the Wi-Fi network list. Touch other Wi-Fi networks, and then you can connect to this network. 4 Notices: in addition, mobile phone can also surf the Internet by GPRS. Our current SIM card GPRS to open after the default boot. Users can manually choose to open data connection, when for the single card, direct drop do…

Text truncated - open the document above for the full version.

SWAGTEK Agent Authorization Company: SWAGTEK Address: 10205 NW 19th St. Suite 101, Miami, FL, 33172 Product Name: 6.09 inch 4G Smart Phone Model Number(s): L61, PRIME, UN61 Product Description: 6.09 inch 4G Smart Phone We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-08-05 Name: Charles Cheng Title: Manager Company: SWAGTEK

SWAGTEK Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-06-28 Subject; Request for Confidentiality FCC ID: O55602520 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Charles Cheng Title: Manager

Declaration Letter We, SWAGTEK declared that our 6.09 inch 4G Smart Phone item No.: L61, PRIME, UN61, were identical inside, the electrical circuit design, layout, components used and internal wiring, with only difference being model name and trademark. L61 model corresponds to the trademark LOGIC. PRIME model correspond to the trademark iSWAG. UN61 model corresponds to the trademark UNONU. Sincerely yours Signature: Name/Title: Charles Cheng /Manager Tel. No. 1-305-421-9938 E-Mail: [email protected] Company: SWAGTEK Date：2020-8-5
