O5ZIFA-930Numeric Radio Paging Receiver

FLEX ALPHA DISPLAY PAGER Operating Manual SHINIL INDUSTRIAL Co., Ltd, 2 CONTENTS - FEATURES ----------------------------------------------------------------------------------------------- 3 - DESCRIPTION OF INDICATORS & SYMBOLS ------------------------- 4 - CONTROL BUTTONS ------------------------------------------------------------------------- 5 - OPERATION -------------------------------------------------------------------------------------------- 5 Turning Pager On --------------------------------------------------------------------------------- 5 Turning Pager Off ----------------------------------------------------------------------------- 5 Read Personal Message ------------------------------------------------------------------ 5 Delete Personal Message ---------------------------------------------------------------- 6 Lock Personal Message ---------------------------------------------------------------- 6 Unlock Personal Message ---------------------------------------------------------------- 6 Move Personal Message to Notebook ------------------------------------------ 6 Read Mail-Drop / Delete Individual & All Mail-Drop ------------------ 6 Function Menu ------------------------------------------------------------------------------------ 7 1) Calendar ----------------------------------------------------------------------------------------- 7 2) Setting the Incoming Message Alert --------------------------------------- 7 3) Setting the Date and Time ---------------------------------------------------------- 8 4) Setting the Alarm ------------------------------------------------------------------------ 8 5) Setting Auto Power On/Off -------------------------------------------------------- 9 6) Setting the Scroll On/Off ------------------------------------------------------------- 9 7) Reminder Alert for Unread Message --------------------------------------- 9 8) Setting the Display Duration Time -------------------------------------------- 10 9) Setting the Character Type ------------------------------------------------------- 10 Notebook --------------------------------------------------------------------------------------------- 10 Others ----------------------------------------------------------------------------------------------------- 10 1) Easy Way to Change Alert Mode 2) Out of Range 3) Battery Indicator 4) Automatic Message Deletion 5) Lamp On/Off 3 FEATURES - 2/4 Line Display besides Icon Indicator Line - 16/21 Character Display per Line - Address Capability: 16 - Message Storage: 30,000 Characters Maximum - Personal Message Slot: 70 (including 20 Notebook Slots) - Mail-Drop Message Slot: 16 - Message Lock up to 30 Personal Messages - 8 User Selectable Alert (3 Tones, 5 Melodies) - Message Scrolling On/Off (On ; Normal / Slow / Fixed / Fast ; Off ) - Incoming Message Time & Date Stamping - User Selectable Date Display (Date/Month/Year or Month/Date/Year or Year/Month/Date) - Message Deletion (All or Individual Message) - Backlight (button press to turn on) - Remind Alert for Unread Message (2, 5, 10, 15 and 30 min) - Backup Battery (For retention memory when replacing battery) - Battery Replacement Alarm - User Selectable Alert Mode: Alert / Vibration / Alert after Vibration / Silence - Memory Full Indication - Duplicate Message Indication - 5 Selectable Display Duration Times (4, 8, 12, 16, 20 sec) - Service Area Indication - Auto Power On/Off - Mail-Drop Alert On/Off - Time Clock - Alarm Function (TIME=Time of Day, DAY=Day of Week plus Time, DATE=Calendar Date plus Time) - Calendar 4 DESCRIPTION OF INDICATORS & SYMBOLS ! !! ! Indicators ! !! ! Symbols ! !! ! Duplicate Message Service Area Unread Message Battery Indicator Vibration Mo de Audible Mode Message Remain to Read Read Mail-Drop Calendar Set Incoming message Alert Set Time, Date Set Alarm Set Auto Power On/Off Set Scrolling Speed Set Alert Periodic Time for Unread Message Set Time for Display Duration Tur n Pa ger Off Individual Message 'DELETE' All Message 'DELETE' Lock Message Unlock Message Duplicate Message Unread Message Read Message Return to previous screen Audible Alert Vibrating Alert Audible Alert with Vibration Silence Alert On for Incoming Mail Alert Off for Incoming Mail 5 CONTROL BUTTONS א Used to go left through the Function menu and your messages, to decrease the numbers through the functions like time, alarm, date settings. ∂ Used to go right through the Function menu and your messages, to increase the numbers through the functions like time, alarm, date settings. Used to read messages, to select a pager function If pressing for 1 second at Function menu, return to the previous menu. OPERATION Turning Pager On Press . " Pager On? Yes " is displayed. Press again. When the pager is on and no activity is taking place, the Standby screen is displayed. The Standby screen displays the service areaindicator and may display other indicators according to the current pager status. Turning Pager Off ❶ From the Top screen, ❷ Press ∂ or א to move the cursor to Function Set, press . ❷ Press ∂ or א to move the cursor to . ❸ Press . " Pager Off? No " is displayed. ❹ Press ∂ or א to display " Pager Off? Yes ". ❺ Press again to turn the pager off. Your pager is now off and the screen is blank. Read Personal Message 6 ❶ From the Top screen, ❷ Press ∂ or א to move the cursor to Read Message, press . The number indicates the count of messages that are unread. ❷ Press to display the Message status screen. ❸ The very left black envelope symbol means the latest and unread message. On the right lower corner, the pager shows the date when the message was received. : Unread Message : Read Message : Locked Message (See Lock Message on page 7 ) ❹ Press to read the message after moving the flashing cursor by ∂ or א . ❺ In the message screen, "07" indicates the message is 7th incoming one and the receiving time is am 11:34. indicates the message Message Screen is duplicate Delete Personal Message ❶ From the Message Screen, …

Text truncated - open the document above for the full version.

KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 1 of 2 External photo KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 2 of 2 External photo

KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 1 of 1 FCC ID Sample Label Model Number: FCC ID : O5ZFA-930 SHINIL Industrial Co., Ltd. Made in Korea This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 1 of 1 Label location FCC Label Location KTI02EF0156 FCC ID: O5ZIFA-930

KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 1 of 2 Internal photo KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 2 of 2 Internal photo

KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 1 of 12 Test Report Test Report No.:KTI02EF0156 Registration No.:99058 Applicant:SHINIL Industrial Co., Ltd. Applicant Address:119-1,SASA-DONG,ANSAN-SHI,KYUNGI-DO,425-220,KOREA Product:Paging ReceiverFrequency Range:929.0125-931.9875 FCC ID:05ZIFA-930Model No.IFA-930 Receipt No.:KTI20020122Date of receipt:January 22, 2002 Date of Issue:February 7, 2002 Testing location Korea Technology Institute Co., Ltd. 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea Test Standards:ANSI. C63.4 : 1992 Rule Parts:FCC Part 15, Subpart B Equipment Class:Numeric Radio Paging Receiver(CYY) Test Result:The above mentioned product has been tested and passed. Tested by: S. B. Kim/ Engineer Signature Date Approved by: G. C. Min/ President Signature Date Other Aspects : Abbreviations : • OK, Pass=passed • Fail=failed • N/A=not applicable  This test report is not permitted to copy partly without our permission.  This test result is dependent on only equipment to be used.  This test result is based on a single evaluation of one sample of the above mentioned.  This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government.  We certify this test report has been based on the measurement standards that is traceable to the national or international standards. KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 2 of 12  Contents  1. 2. 3. 4. 5. 6. Annex1 Annex2 Contents List of Tables List of Figures List of Photographs General Test Site 2.1 Location 2.2 List of Test and Measurement Instruments 2.3 Test Data 2.4 Test Environment Description of the tested samples 3.1 Rating and Physical characteristics 3.2 Submitted documents Measurement conditions 4.1 Modes of operation 4.2 Uncertainty 4.3 Test Setup Emission Test 5.1 Conducted Emissions 5.2 Radiated Emissions Photographs of the Test Set-up Label Photographs of EUT 2 2 2 3 3 3 3 4 4 4 5 5 5 6 6 6 7 8 8 10 13 14~15 16~21  List of Tables Table 1 List of test and measurement equipment Table 2 Test Data. Conducted Emissions Table 3 Test Data. Radiated Emissions  List of Photographs Photograph 1 Setup for Radiated Emissions 4 9 11 13 KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 3 of 12 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Korea Technology Institute Co., LTD. And were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Korea Technology Institute Co., LTD 2.1 Location 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea The Test Site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 4 of 12 KTI02EF0156 FCC ID: O5ZIFA-930 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment • Conducted Emissions Kind of Equipment Type S/N Calibrated until Spectrum Analyzer R3261C 61720417 11.2002 Field Strength Meter ESPC 832827/011 9.2002 LISN KNW407 8-1157-2 10.2002 LISN ESH2- Z5 8254601019 6.2002 Conducted Cable N/A N/A 11.2002 • Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESPC 832827/011 9.2002 Spectrum Analyzer R3261C 61720417 11.2002 Pre Amplif ier HP 8447D 2944A06874 11.2002 BiconiLog Antenna EMCO 3142B 1705 12.2002 Bilog Antenna KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 5 of 12 3. Description of the tested samples The EUT is Paging Receiver(CYY). 3.1 Rating and Physical Characteristics • Frequency range : 929.0125  931.9875MHz • Using battery:1.5VDC( AAA size Alkaline) • Bit Rate(s): 1600 2level bps • Crystal/Oscillator(s): 75.634  75.8823MHz • Antenna: Loop • Receiving System: Double superheterodyne, Crystal • Signal System: FLEX • Dimensions: 56  43  18 mm • Weight: 38g(including battery) 3.2 Submitted Documents • User’s Guide • Block Diagram KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 6 of 12 4. Measurement Conditions Testing Input Voltage : DC 1.5V(AAA size) 4.1 Modes of Operation The EUT was in the following normal mode during all testing; Prior to a measurement, the Pager shall be operated until stabilization has been reached. 4.2 Uncertainty 1) Radiated disturbance UC (Combined standard Uncertainty) = ± 1.8dB Expanded uncertainty U=KUc K = 2  U = ± 3.6dB 2) Conducted disturbance UC = ± 0.88dB U = KUc=2xUc = ± 1.8dB KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 7 of 12 4.3 Test setup EUT KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 8 of 12 5.EMISSION Test 5.1Conducted Emissions Result: (n/a Battery Operated Only) The line-conducted facility is located inside a 2.3M x 3.5M x 5.5M shielded closure. The shielding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 605- 05. A 1m x 1.5m wooden table 80cm high is placed 80cm away from the conducting ground plane and 40cm away from the sidewall of the shielded room. Rohde & Schwarz Model ESH2-Z5 (9kHz-30MHz)50ohm/50 uH Line-Impedance Stabilization Networks (LISN) are bonded to the shielded room. The EUT is powered from the Rohde & Schwarz LISN and the support equipment is powered from the Rohde & Schwarz LISN. Power to the LISN are filtered by a high-current high-insertion loss shield enclosures power line filters (100dB 14kHz-1GHz). The purpose of the filter is to attenuate ambient signal interference and this filter is also bonded to the shielded enclosure. All electrical cables are shielded by braided tinned copper zip…

Text truncated - open the document above for the full version.

KTI02EF0156 FCC ID: O5ZIFA-930 Korea Technology Institute Co., Ltd. Page 1 of 1 6. Photograph of the Test Set-Up Photograph 1 : Setup for radiated Emissions
