O5ZIWP-930MNumeric Radio Paging Receiver

PLL POCSAG NUMERIC DISPLAY PAGER Operating Manual Model:IWP-930M SHINIL INDUSTRIAL Co., Ltd, USER'S MANUAL FOR POCSAG NUMERIC PAGER 1. Self Test When user puts battery in the battery compartment, Pager starts self-test with alert tone and vibration. 2. Display Indicators - Message Protected: Message is saved. - Service area indicator: Antenna symbol indicates that the pager is within the service area. - Duplicated Message: If you receive a page that same page is already within your beeper, the duplicated message symbol will display. - Automatic Power On/Off: The pager shuts on and off at the selected time of the user. - Alarm: The pager will alert you at the time the user has selected. - Alert Mode: There are three kinds of alerts. 1) Chirp alert: Short beep tones 2) Audio alert 3) Vibrating alert: Vibration (no alert tone) - Low battery: It needs replacement if battery level is low - Message Continuation: When the message is longer than 12 characters the message continuation symbol is displayed. 3. Function description Pager on from the off screen In the pager off screen, pressing any button more than 2 seconds will turn your Pager on. A start-up screen is displayed momentarily followed by a short beep alert. While the pager is on, the standby screen is displayed. Turning your Pager Off a. From the standby screen, press and release the Mode button until "PAGER OFF” is displayed. b. Press the Read button to turn the pager off. The off screen will be displayed without any icons. Receiving and Reading Message Your Pager can receive up twenty numeric messages. When a message is received, your Pager alerts (vibration, audio, or chirp) for eight seconds. In the corner of screen, there will be a number. The number indicates how many numeric messages were received. a. Press any button to stop the alert. b. Press the Read button to display the numeric message. c. Press the Read button again to display the second screen of the message. Message continuation When the numeric message is longer than 12 characters, the message continuation symbol is displayed. When the message continuation symbol is displayed, press the read button again to display the reminder of the numeric message. Message Full When the Pager receives up to 20 messages, “--FULL—” is displayed for 4 seconds. If a new message is received, the oldest unlocked message will be replaced with the new message. . Unread messages / No page a. Unread message If the messages are unread "UNREAD" will be displayed with the number of unread messages (ex. 01, 02, 03, etc.). b. No page If no messages are received, "NO PAGES" is displayed for one second when you press read button. c. Tone Only When tone only is displayed on the pager's screen, the caller paged you without sending a numeric message. Duplicate Message If a new numeric message is received and is exactly the same as a message already in memory, the duplicated symbol is displayed to indicate that. The new duplicated message will be replaced the old duplicated message and the time stamp will also be replaced with the newer message as well. Emergency Message If the caller needs to send an emergency page, the tone of the numeric message received will be different from the set alert. The caller must press 999 and then the numeric message in order to activate this option. Message Hold time When you need to display your message longer than standard time (8 seconds), press and hold the read button for over 4 seconds. Setting pager alert There are 3 different types of alert - Tone alert: 5 different short beep tones - Melody alert: 5 different of melodic tones - Motor alert: Vibrator with no alert tone Setting the tone alert a. From the standby screen, press and release the mode button until "ALERT TONE" is displayed. b. Press the read button until "TONE" is displayed. c. Press and release the mode button until your choice of TONE 1, TONE 2, TONE 3, TONE 4 or TONE 5 is displayed. The pager produces a sample of each tone alert. d. Press the read button twice to activate your selection and to return the standby screen. Setting the melody alerts There are 5 melody alerts to choose from. Please follow the tone-setting instructions to set the melody alert. Setting the vibrator alert a. From the standby screen, press mode button until ALERT TONEis displayed. b. Press and release Read button until MOTORis displayed. c. Press Mode button to activate your selection and return to the standby screen. Setting the silent Follow the vibrator alert-setting instructions to set pager silent. Setting the alert time User can set Pager how long it alerts when the message is coming. a. At the standby screen, press and release Mode button until "ALERT TIMEis displayed. b. Press and release Read button until your choice of 8-SEC, 12-SEC, or 4-SEC is displayed. c. Press Mode button to activate the selection and return to the standby screen. Protecting and Unprotecting messages You can protect up to 10 messages so they are not erased or replaced by new messages. a. To protect messages While the message is displayed, press Mode button until the lock icon it is displayed on the screen. b. To unprotect message: While the protected message is displayed with lock icon, press Mode button. The lock icon will disappear. When you have protected messages 10 messagesLOC FULLis displayed. Erasing message(s) a. Erasing an Individual Message From the standby screen, press and release the Mode button until “Erase?” is displayed. At this point, Press the read button to select ERASE ONEthen press the mode button to select the message that is to be erased. After finding the message to be erased, press the read button. "SURE ? will be displayed. Press the Mode button and then ERASEDis displayed. After 4 seconds, you will return the standby screen. He message selected will be completely erased. All remaining message Will be moved to the next available message slot. b. Erasing all message Follow the erasing individual message instructions a…

Text truncated - open the document above for the full version.

KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 1 of 2 External photo-Front KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 2 of 2 External photo-Rear

Korea Technology Institute Co., Ltd. Page 1 of 1 FCC ID Sample Label Model Number: IWP-930M FCC ID : 05ZIWP-930M SHINIL Industrial Co., Ltd. Made in Korea This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

Korea Technology Institute Co., Ltd. Page 1 of 1 Label location LABEL LOCATION

KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 1 of 3 Internal photo KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 2 of 3 Internal photo KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 3 of 3 Internal photo KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 3 of 3 Internal photo

KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 1 of 12 Certificate of Compliance Test Report No.: KTI01E-F1149 Registration No.: 99058 Applicant: SHINIL Industrial Co., Ltd. Applicant Address: 119-1,SASA-DONG,ANSAN-SHI,KYUNGI-DO,425-220,KOREA Product: Paging Receiver Frequency Range: 929.0125-931.9875 FCC ID: 05ZIWP-930M Model No. IWP-930M Receipt No.: KTI20011031 Date of receipt: Oct, 31, 2001 Date of Issue: Nov, 6, 2001 Testing location Korea Technology Institute Co., Ltd. 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea Test Standards: ANSI. C63.4 : 1992 Rule Parts: FCC Part 15, Subpart B Equipment Class: Numeric Radio Paging Receiver(CYY) Test Result: The above mentioned product has been tested and passed. Tested by: S. B. Kim/ Engineer Signature Date Approved by: G. C. Min/ President Signature Date Other Aspects : Abbreviations : OK, Pass=passed Fail=failed N/A=not applicable This test report is not permitted to copy partly without our permission. This test result is dependent on only equipment to be used. This test result is based on a single evaluation of one sample of the above mentioned. This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. We certify this test report has been based on the measurement standards that is traceable to the national or international standards. KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 2 of 12 Contents 1. 2. 3. 4. 5. 6. Annex1 Annex2 Contents List of Tables List of Figures List of Photographs General Test Site 2.1 Location 2.2 List of Test and Measurement Instruments 2.3 Test Data 2.4 Test Environment Description of the tested samples 3.1 Rating and Physical characteristics 3.2 Submitted documents Measurement conditions 4.1 Modes of operation 4.2 Uncertainty 4.3 Test Setup Emission Test 5.1 Conducted Emissions 5.2 Radiated Emissions Photographs of the Test Set-up Label Photographs of EUT 2 2 2 3 3 3 3 4 4 4 5 5 5 6 6 6 7 8 8 10 13 14~15 16~21 List of Tables Table 1 List of test and measurement equipment Table 2 Test Data. Conducted Emissions Table 3 Test Data. Radiated Emissions List of Photographs Photograph 1 Setup for Radiated Emissions 4 9 11 13 KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 3 of 12 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Korea Technology Institute Co., LTD. And were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Korea Technology Institute Co., LTD 2.1 Location 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea The Test Site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 4 of 12 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment Conducted Emissions Kind of Equipment Type S/N Calibrated until Spectrum Analyzer R3261C 61720427 11.2001 Field Strength Meter ESPC 832827/011 9.2002 LISN ESH3-Z5 8254601019 9.2002 LISN KNW407 8-1097-7 9.2002 Pulse limiter ESH3Z2 357.8810.52 9.2002 Conducted Cable N/A N/A 11.2001 Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESPC 832827/011 9.2002 Spectrum Analyzer R3261C 61720427 11.2001 Pre Amplifier 8447D 2944A06874 11.2001 Log Periodic Antenna 3146 9105-1343 11.2001 Biconical Antenna 3110 9105-3100 11.2001 Open Site Cable N/A N/A 11.2001 Antenna Mast DETT-03 N/A N/A Antenna & Turntable controller DETT-03 91X519 N/A 2.3 Test Date Date of Application : Oct. 31, 2001 Date of Test : Nov. 2, 2001 2.4 Test Environment See each test item’s description. KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 5 of 12 3. Description of the tested samples The EUT is Paging Receiver. 3.1 Rating and Physical Characteristics Frequency range : 929.0125-931.9875MHz Using battery:1.5V 3.2 Submitted Documents User’s Guide Block Diagram KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 6 of 12 4. Measurement Conditions Testing Input Voltage : DC 1.5V 4.1 Modes of Operation The EUT was in the following normal mode during all testing; Prior to a measurement, the Pager shall be operated until stabilization has been reached. 4.2 Uncertainty 1) Radiated disturbance UC (Combined standard Uncertainty) = 1.8dB Expanded uncertainty U=KUc K = 2 U = 3.6dB 2) Conducted disturbance UC = 0.88dB U = KUc=2xUc = 1.8dB KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 7 of 12 4.3 Test setup EUT KTI01E-F1149 FCC ID : 05ZIWP-930M Korea Technology Institute Co., Ltd. Page 8 of 12 5. EMISSION Test 5.1 Conducted Emissions Result : Not Applicable The line-conducted facility is located inside a 2.3M x 3.5M x 5.5M shielded closure. The shielding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 605- 05. A 1m x 1.5m wooden table 80cm. High is placed 80cm away from the vertical wall and 1.5m away from the side wall of the shielded room. R&S Model ESH3-Z5(10kHz-30MHz) 50ohm/50 uH line-Impedance Stabilization Networks(LISN) are bonded to the shielded room. The EUT is powered from the R&S LISN and the support equipment is powered from the Kyoritsu LISN. Power to the LISN are filtered by a high-current high-insertion loss shield enclosures power line filters(100dB 14kHz-1Ghz). The purpose of the filter is to attenuate ambient signal interference and this filter is also bonded to the shielded enclosure. All electrical cables are shielded by braided tinned copper zipper tubing with inner diameter of 1/2”.…
