O6M-PW250CF Wireless LAN Card

CF Wireless LAN Card PW250 Userís Manual Rev 0.2 CF Wireless Network Card Userís Manual 2 Regulatory compliance FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ! Reorient or relocate the receiving antenna. ! Increase the separation between the equipment and receiver. ! Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ! Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. CF Wireless Network Card Userís Manual 3 About this manual This Userís Manual describes how to install and operate your CF Wireless LAN Card. Please read this manual before you install the product. This manual includes the following topics: " Product description and features. " Software installation procedure. " Hardware installation procedure. " FAQ CF Wireless Network Card Userís Manual 4 Table of Contents Regulatory compliance About this manual Chapter 1- Introduction5 Features5 What is Wireless LAN?6 Wireless LAN Modes6 Notes on Wireless LAN Configuration7 Chapter 2 - Installation and Configuration of the PCI adapter for Windows8 What You Will Need 8 Software and Driver Installation 8 Uninstall Procedures14 Chapter 3 ñ Hardware Installation16 Package Contents16 System Requirements for the Card16 Install the PCI Card16 LEDs Indicators17 Connecting External Antenna to the card18 Chapter 4 ñ Installing Network Protocols19 Installing the Network Protocols for Windows 98 and Millennium Chapter 5 ñ Configuring the Wireless PCI Card22 Appendix A ñ FAQ27 Appendix B ñ Specifications28 CF Wireless Network Card Userís Manual 5 Chapter 1 - Introduction Thank you for purchasing the CF Wireless LAN Card. This high-speed CF Wireless LAN Card provides you with an innovative wireless networking solution. The Card is easy to set up and use. With this innovative wireless technology, you can share files and printers on the networkówithout inconvenient wires! The Card is a network card with a rate of 1, 2, 5.5, and 11 Mbps operating in the ISM band using Direct Sequence Spread Spectrum (DSSS) transmission implementing the IEEE 802.11b standard. This card provides Device Drivers for Windows 98, Windows 2000 and Windows ME. It also provides tools for the configuration of the card. The tool, as well as the installation steps of the plug- and-play procedure for the Microsoft Windows 98, Windows ME and Windows 2000 operating systems, is described in this document. Features The CF Wireless LAN Card offers compliance with the IEEE 802.11b specification. This feature allows them to communicate with other wireless devices that support the standard. Features of the card are: # Uses 2.4GHz frequency band, which complies with worldwide requirement # Wireless interface following the IEEE 802.11b standard # Using CF TypeII interface # Enciphering/deciphering of wireless data by the implementation of the WEP algorithm # Wire-free access to networked resources from anywhere for PDA # Allows users move between Access Points without resetting their connection reconfiguration # Delivers data rate up to 11 Mbps # Supports 11, 5.5, 2, and 1 Mbps rates # Provide CF Wireless LAN Card Configuration utility # The Card uses build-in strip Antenna with LED indicating Link # Supports most popular operating systems: Win CE CF Wireless Network Card Userís Manual 6 What is Wireless LAN? Wireless Local Area Network (WLAN) systems offer a great number of advantages over traditional wired systems. WLAN is flexible and easy to setup and manage. They are also more economical than wired LAN systems. Using radio frequency (RF) technology, WLAN transmit and receive data through the air. WLAN combine data connectivity with user mobility. For example, users can roam from a conference room to their office without being disconnected from the LAN. Using WLAN, users can conveniently access-shared information, and network administrators can configure and augment networks without installing or moving network cables. WLAN technology provides users with many convenient and cost saving features: • Mobility: WLAN provide LAN users with access to real-time information anywhere in their organization, providing service opportunities that are impossible with wired networks. • Ease of Installation: Installing is easy for novice and expert users alike, eliminating the need to install network cables in walls and ceilings. • Scalability: WLAN can be configured in a variety of topologies to adapt to specific applications and installations. Configurations are easily changed and range from peer-to-peer networks suitable for a small number of users to full infrastructure networks of thousands of users roaming over a br…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 3 Page 4

FCC ID: Label Location

Page 5 Page 6

FCC ID: O6M-PW250 ADT No.900801R01 Operational Description The transmitter of the EUT (CF Wireless LAN Card) is powered by host equipment and plugged in PCMCIA slot. The antenna used in this product is patch antenna. There is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: O6M-PW250 ADT No.: 900801R01 FCC TEST REPORT REPORT NO.: RF900801R01 MODEL NO.: PW250-IF (for Bromax) WCF11 (for Linksys) ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: BROMAX COMMUNICATIONS, INC. ADDRESS: No.20, Kuang Fu Road, Hsin Chu Industrial Park, Hu Kou, Hsin Chu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 FCC ID: O6M-PW250 ADT No.: 900801R01 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: O6M-PW250 ADT No.: 900801R01 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: O6M-PW250 ADT No.: 900801R01 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -1 dBi or 0.79 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241267.612.06 6243768.872.08 11246269.182.09 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: O6M-PW250 Report No.: RF900801R01 1 Issued: August 14, 2001 FCC TEST REPORT REPORT NO.: RF900801R01 MODEL NO.: PW250-IF (for Bromax) WCF11 (for Linksys) RECEIVED: August 1, 2001 TESTED: August 1 ~ August 7, 2001 APPLICANT: BROMAX COMMUNICATIONS, INC. ADDRESS: No.20, Kuang Fu Road, Hsinchu Industrial Park Hukou, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: O6M-PW250 Report No.: RF900801R01 2 Issued: August 14, 2001 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS ................................................................... 5 3GENERAL INFORMATION............................................................................ 6 3.1GENERAL DESCRIPTION OF EUT.............................................................. 6 3.2DESCRIPTION OF TEST MODES ................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................... 7 3.4DESCRIPTION OF SUPPORT UNITS .......................................................... 8 4TEST TYPES AND RESULTS ....................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .............................. 9 4.1.2TEST INSTRUMENTS................................................................................... 9 4.1.3TEST PROCEDURES ................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS ................................................................ 11 4.1.6TEST RESULTS .......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................. 18 4.2.2TEST INSTRUMENTS................................................................................. 19 4.2.3TEST PROCEDURES ................................................................................. 20 4.2.4TEST SETUP .............................................................................................. 21 4.2.5EUT OPERATING CONDITIONS ................................................................ 21 4.2.6TEST RESULTS .......................................................................................... 22 4.36DB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 27 4.3.2TEST INSTRUMENTS................................................................................. 27 4.3.3TEST PROCEDURE.................................................................................... 28 4.3.4TEST SETUP .............................................................................................. 28 4.3.5EUT OPERATING CONDITIONS ................................................................ 28 4.3.6TEST RESULTS .......................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 33 4.4.2TEST INSTRUMENTS................................................................................. 33 4.4.3TEST PROCEDURES ................................................................................. 34 4.4.4TEST SETUP .............................................................................................. 34 4.4.5EUT OPERATING CONDITIONS ................................................................ 34 FCC ID: O6M-PW250 Report No.: RF900801R01 3 Issued: August 14, 2001 4.4.6TEST RESULTS .......................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ...................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 36 4.5.2TEST INSTRUMENTS................................................................................. 36 4.5.3TEST PROCEDURE.................................................................................... 37 4.5.4TEST SETUP .............................................................................................. 37 4.5.5EUT OPERATING CONDITIONS ................................................................ 37 4.5.6TEST RESULTS .......................................................................................... 38 4.6BAND EDGES MEASUREMENT ................................................................ 42 4.6.1LIMITS OF BAND EDGES MEASUREMENT .............................................. 42 4.6.2TEST INSTRUMENTS................................................................................. 42 4.6.3TEST PROCEDURE.................................................................................... 42 4.6.4EUT OPERATING CONDITION .................................................................. 43 4.6.5TEST RESULTS .......................................................................................... 43 4.7ANTENNA REQUIREMENT ........................................................................ 46 …

Text truncated - open the document above for the full version.

FCC ID: O6M-PW250 Report No.: RF900801R01 47 Issued: August 14, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O6M-PW250 Report No.: RF900801R01 48 Issued: August 14, 2001 RADIATED EMISSION TEST

FCC ID: O6M-PW250 Report No.: RF900801R01 47 Issued: August 14, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O6M-PW250 Report No.: RF900801R01 48 Issued: August 14, 2001 RADIATED EMISSION TEST
