O6M-UW200FreePort 11M USB WLAN Adapter

Wireless USB Network Adapter User Manual USB 11M WLAN Adapter User Manual 2 Regulatory compliance FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ü Reorient or relocate the receiving antenna. ü Increase the separation between the equipment and receiver. ü Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ü Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. About this manual This User manual describes how to install and operate your USB 11M WLAN Adapter. Please read this manual before you install the product. This manual includes the following topics: ÿ Product description and features. ÿ Hardware installation procedure. ÿ Software installation procedure. USB 11M WLAN Adapter User Manual 3 Table of Contents Section 1 Introduction4 1.1 Package Contents4 1.2 System Requirements4 1.3 Features4 Section 2 Hardware Installation6 2.1 Connecting the USB Adapter6 2.2 Status LEDs6 2.3 Disconnecting the USB Adapter6 Section 3 Installation and Configuration Procedures Under Windows 987 3.1 What You Need to Know About Windows 987 3.2 What You Will Need7 3.3 Installing the Driver Under Windows 987 3.4 Configuration Under Windows 9811 3.5 Uninstall Procedure Under Windows 9812 Section 4 Installation and Configuration Procedures Under Windows 200013 4.1 What You Need to Know About Windows 200013 4.2 What You Will Need13 4.3 Installing the Driver Under Windows 200013 4.4 Configuration Under Windows 200017 4.5 How to Unplug the Device Under Windows 200018 4.6 Uninstall Procedure Under Windows 200019 Section 5 Installation and Configuration Procedures Under Windows ME20 5.1 What You Need to Know About Windows ME20 5.2 What You Will Need20 5.3 Installing the Driver Under Windows ME20 5.4 Configuration Under Windows ME21 5.5 Uninstall Procedure Under Windows ME22 Section 6 Configuration and Monitor Application23 6.1 How to Install the Configuration and Monitor Application23 6.2 Using the Configuration and Monitor Application23 6.3 How to Uninstall the Configuration and Monitor Application27 USB 11M WLAN Adapter User Manual 4 Section 1 - Introduction The USB 11M WLAN Adapter is a network adapter with a rate of 1, 2, 5.5, and 11 Mbps operating in the ISM band using Direct Sequence Spread Spectrum (DSSS) transmission implementing the IEEE 802.11b standard. This adapter provides Device Drivers for MS Windows ® 98, Windows ® 2000 and Windows ® ME. It also provides tools for the configuration and firmware upgrade of the adapter. These tools, as well as the installation steps of the plug-and-play procedure for the Microsoft Windows 98, Windows ME and Windows 2000 operating systems, are described in this document. 1.1 Package Contents Please make sure that items below are included on package. ̧ A USB 11M WLAN Adapter ̧ A USB cables ̧ Floppy Diskette (include Device Drivers and User Manual) 1.2 System Requirements ÿ Operating System: MS Windows 98, Windows 2000, Windows ME ÿ Desktop PC or notebook PC ÿ One free USB port 1.3 Features The USB 11M WLAN Adapter offers compliance with the IEEE 802.11b specification. This feature allows them to communicate with other wireless devices that support the standard. Features of the adapter are: ̧ Uses 2.4GHz frequency band, which complies with worldwide requirement ̧ Wireless interface following the IEEE 802.11b standard ̧ Using Universal Serial Bus (USB) interface ̧ Enciphering/deciphering of wireless data by the implementation of the WEP algorithm (WEP-40 bits) ̧ Wire-free access to networked resources from anywhere beyond the desktop ̧ Allows users move between Access Points without resetting their connection reconfiguration ̧ Delivers data rate up to 11 Mbps ̧ Supports 11, 5.5, 2, and 1 Mbps rates ̧ Roaming ̧ Provide USB 11M WLAN Configuration utility USB 11M WLAN Adapter User Manual 5 ̧ Dielectric Antenna is built in to the Adapter with LEDs indicating Power and Link ̧ Supports most popular operating systems: Window 98/2000 & Windows ME USB 11M WLAN Adapter User Manual 6 Section 2 - Hardware Installation This chapter covers connecting your USB 11M WLAN Adapter to the desktop / notebook PC’s USB port. 2.1 Connecting the USB Adapter NOTE: These instructions apply to most notebook computers. For detailed information on inserting USB adapters into your desktop/notebook PC, consult the desktop/notebook PC User manual. With the adapter’s USB connector facing the desktop / notebook PC’s USB ports, connect the adapter into an available USB port. 2.2 Status LEDs The following table describes the meaning of the LEDs: LEDMEANING PWR Indicates that the Card is powered on. Link Indicates link status. It is normally blinking. When blinking, indicates that the card is scanning the channels, and the link is not active. When lit, indicates that the card is locked to a channel, and the link is active. 2.3 Disconnecting the USB Adapter In Win 98/ME op…

Text truncated - open the document above for the full version.

FCC ID: O6M-UW200 Report No.: RF900321041Issued: April 16, 2001 ANNEX2 PHOTOGRAPHS OF EUT FCC ID: O6M-UW200 Report No.: RF900321042Issued: April 16, 2001 FCC ID: O6M-UW200 Report No.: RF900321043Issued: April 16, 2001

FCC ID LABEL LOCATION

FCC ID: O6M-UW200 Report No.: RF900321044Issued: April 16, 2001 FCC ID: O6M-UW200 Report No.: RF900321045Issued: April 16, 2001 FCC ID: O6M-UW200 Report No.: RF900321046Issued: April 16, 2001

FCC ID: O6M-UW200 Report No.: RF90032104 1 Issued: April 16, 2001 FCC TEST REPORT REPORT NO.: RF90032104 MODEL NO.: BUW200-AF RECEIVED: March 21, 2001 TESTED: April 13, 2001 APPLICANT: BroMax Communications, Inc. ADDRESS: No.20, Kuang Fu Road, Hsinchu Industrial Park, Hukou, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 13-1, Lane 19, Wen Shan 3 rd St., Kweishan, Taoyuan Hsien, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Accredited Laboratory FCC ID: O6M-UW200 Report No.: RF90032104 2 Issued: April 16, 2001 Table of Contents 1CERTIFICATION .................................................................................................. 4 2SUMMARY OF TEST RESULTS......................................................................... 5 3GENERAL INFORMATION ................................................................................ 6 3.1GENERAL DESCRIPTION OF EUT ................................................................................ 6 3.2DESCRIPTION OF TEST MODES ................................................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................... 7 3.4DESCRIPTION OF SUPPORT UNITS.............................................................................. 7 4TEST PROCEDURES AND TEST RESULTS .................................................... 8 4.1CONDUCTED EMISSION MEASUREMENT................................................................. 8 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...........................................................8 4.1.2TEST INSTRUMENTS ....................................................................................................................8 4.1.3TEST PROCEDURES ......................................................................................................................9 4.1.4TEST SETUP ..................................................................................................................................10 4.1.5TEST RESULTS .............................................................................................................................11 4.2RADIATED EMISSION MEASUREMENT ................................................................... 17 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT .............................................................17 4.2.2TEST INSTRUMENTS ..................................................................................................................18 4.2.3TEST PROCEDURES ....................................................................................................................19 4.2.4TEST SETUP ..................................................................................................................................20 4.2.5TEST RESULTS .............................................................................................................................21 4.36dB BANDWIDTH MEASUREMENT ........................................................................... 25 4.3.1LIMITS OF 6 D B BANDWIDTH MEASUREMENT.....................................................................25 4.3.2TEST INSTRUMENTS ..................................................................................................................25 4.3.3TEST PROCEDURE.......................................................................................................................26 4.3.4TEST SETUP ..................................................................................................................................26 4.3.5EUT OPERATING CONDITION...................................................................................................26 4.3.6TEST RESULTS .............................................................................................................................27 4.4MAXIMUM PEAK OUTPUT POWER........................................................................... 31 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT......................................31 4.4.2INSTRUMENTS.............................................................................................................................31 4.4.3TEST PROCEDURES ....................................................................................................................32 4.4.4TEST SETUP ..................................................................................................................................32 4.4.5EUT OPERATING CONDITION...................................................................................................32 4.4.6TEST RESULTS .............................................................................................................................33 4.5POWER SPECTRAL DENSITY MEASUREMENT ...................................................... 34 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................................................34 4.5.2TEST INSTRUMENTS ..................................................................................................................34 4.5.3TEST PROCEDURE.......................................................................................................................35 FCC ID: O6M-UW200 Report No.: RF90032104 3 Issued: April 16, 2001 4.5.4TEST SETUP ..................................................................................................................................35 4.5.5EUT OPERATING CONDITION...................................................................................................35 4…

Text truncated - open the document above for the full version.

FCC ID: O6M-UW200 Report No.: RF90032104 34 Issued: April 16, 2001 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Limit of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Aug. 04, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: O6M-UW200 Report No.: RF90032104 35 Issued: April 16, 2001 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP For the actual test configuration, please refer to the related Item – Photographs of the Test Configuration. 4.5.5 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Attenuator FCC ID: O6M-UW200 Report No.: RF90032104 36 Issued: April 16, 2001 4.5.6 TEST RESULTS EUTFreePort 11M USB WLAN AdapterModelBUW200-AF Environmental Conditions 22°C, 60%RHTe s t e d B ySteven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 KHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAI L 12412-15.268PASS 62437-14.908PASS 112462-14.908PASS FCC ID: O6M-UW200 Report No.: RF90032104 37 Issued: April 16, 2001 CH1 FCC ID: O6M-UW200 Report No.: RF90032104 38 Issued: April 16, 2001 CH6 FCC ID: O6M-UW200 Report No.: RF90032104 39 Issued: April 16, 2001 CH11 FCC ID: O6M-UW200 Report No.: RF90032104 40 Issued: April 16, 2001 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz RB). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 848926/005 846839/018 Dec 03, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A Notes: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months. And the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: O6M-UW200 Report No.: RF90032104 41 Issued: April 16, 2001 4.6.4 EUT OPERATING CONDITION The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. 4.6.5 TEST RESULTS The spectrum plots are attached below. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). FCC ID: O6M-UW200 Report No.: RF90032104 42 Issued: April 16, 2001 4.6.6 NOTE ON BAND EDGE EMISSION The band edge emission plot on page 43 shows 44.51dB delta between carrier maximum power and local maximum emission in restrict band (2.484GHz). The emission of carrier strength list in table of page 24 is 95.3dBμV/m, so the maximum field strength in restrict band is 95.3-44.51=50.79 dBμV/m which is under 54 dBμV/m limit. FCC ID: O6M-UW200 Report No.: RF90032104 43 Issued: April 16, 2001 FCC ID: O6M-UW200 Report No.: RF90032104 44 Issued: April 16, 2001 FCC ID: O6M-UW200 Report No.: RF90032104 45 Issued: April 16, 2001 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product are Built-in Dielectric Antenna. There is no antenna connector. And the maximum Gain of this antenna is only -1dBi. FCC ID: O6M-UW200 Report No.: RF90032104 46 Issued: April 16, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O6M-UW200 Report No.: RF90032104 47 Issued: April 16, 2001 RADIATED EMISSION TEST FCC ID: O6M-UW200 Report No.: RF90032104 48 Issued: April 16, 2001 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited by the following approval agencies according to ISO/IEC Guide 25 or EN 45001: USA FCC, NVLAP Germany TUV Rheinland Japan VCCI New Zealand RFS Norway NEMKO, DNV U.K. INCHCAPE R.O.C. BSMI Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Design Center: Tel: 886-2-26093195 Fax: 886-2-26093184 Email: [email protected] Web Site: www.adt.com.tw

FCC ID: O6M-UW200 Report No.: RF90032104 1 Issued: April 16, 2001 ANNEX 1 PROCESSING GAIN OF DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT 1. 1.1. 1. LIMITS OF PROCESSING GAIN OF A DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT The limit of processing gain is 10dB 1.1 TEST INSTRUMENTS & SUPPORT UNIT Description & ManufacturerModel No.Serial No. Anritsu Spectrum Analyzer, 9kHz to 30GHz MS2667CM10281 Anritsu Signal Generator, 10kHz to 20GHz 68247B984703 Hewlett Packard Power Meter,HP438A2743A04416 Hewlett Packard Power Sensor, -30 to 20dBm 8485A2942A08387 Hewlett Packard Step Attenuator, 10dB ste ps HP8496B3247A18505 Mini-Circuits Power SplitterZN2PD-9GNA DELL Laptop ComputerInspiron 5000eNA Campaq Laptop ComputerPPX99125 FCC ID: O6M-UW200 Report No.: RF90032104 2 Issued: April 16, 2001 1.2 METHOD OF MEASUREMENT The processing gain may be measured using the CW jamming margin method. Section 4.7.4 shows the test configuration. The test consists of stepping a signal generator in 50 kHz increments across the passband of the system. At each point, the generator level required to produce the recommended Bit Error Rate (BER) is recorded. This level is jammer level. The output power of the transmitting unit is measured at the same point. The jammer to Signal (J/S) ratio is then calculated. Discard the worst 20% of the J/S data points. The lowest remaining J/S ratio is used when calculating the Process Gain. The reference PER is specified as 8%. The corresponding Es/No (signal to noise ratio per symbol) is 16.4 dB. The curve is attached as below. This value and the measured J/S ratio are used in the following equation to calculate the Process Gain (Gp) of the system. Where: (S/N) o : Signal to noise ratio for the chosen BER. Gp = (S/N) o +Mj+Lsys FCC ID: O6M-UW200 Report No.: RF90032104 3 Issued: April 16, 2001 Mj : Maximum jammer to Signal Ratio recorded at the detected BER. Lsys : System losses . For the purpose of this processing gain calculation, we assume Lsys at its minimum value of 2 dB. TEST SETUP 7 NOTEBOOK EUT ANRITSU SIGNAL GENERATOR EUT NOTEBOOK PWR SENSOR 8485A Power meter HP 438A Mini-Circuits 15542 ZNZPD-9G HP8496D STEP ATTN 110dB (10dB steps) Matched Cables RECEIVER Transmitter FCC ID: O6M-UW200 Report No.: RF90032104 4 Issued: April 16, 2001 1.3 TEST PROCEDURES Obtain the simplex link shown. Perform all independent instrumentation calibrations prior to this procedure. Set operating power levels using fixed and variable attenuators in system to meet the following objectives: Signal Power at receiver approximately –55dBm (above thermal sensitivity such that thermal noise does not cause bit errors. Signal Power at power meter between –20 and –30dBm for optimal linearity. Use spectrum analyzer to monitor test. Ensure that CW Jammer generator RF output is disabled and measure the power at the power meter port using the power meter. This is the relative signal power, Sr. Disable Transmitter, and set CW Jammer generator RF output frequency equal to the carrier frequency and enable generator output. Set reference CW Jammer power level at power meter port 8.4dB below Sr (minimum J/S, or 10dB processing gain reference level). Note the power level setting on the generator, this is the reference CW Jammer power setting, Jr. Disable CW Jammer, re-establish link. PER test should be operating essentially error -free. Enable CW Jammer at the reference power level and verify that the PER test indicates a PER of less than 8%. Alternatively, adjust the CW Jammer level to that which causes 8% PER and verify that the S/J is less than 8.4dB. Repeat step 7 for uniform steps in frequency increments of 50 kHz across the receiver passband with the CW Jammer. In this case the receiver passband is +/- 8.5 MHz. The numerical data associated with the following radio channel is tabulated and presented for Channel 1,6, and 11. Note:Since the jamming signal will be blocked by the IF filter if the jamming frequency is far form the center of the carrier frequency. So, only those frequencies around carrier frequency are shown here. FCC ID: O6M-UW200 Report No.: RF90032104 5 Issued: April 16, 2001 1.4 EUT OPERATING CONDITION The software provided by client to set the EUT to transmit at lowest, middle and highest channel. 1.5 TEST RESULTS EUTFreePort 11M USB WLAN AdapterModelBUW200-AF Environmental Conditions20°C,65%RHTe s t e d B ySteven Lu Although the theoretical processing gain is lower than 10 dB, but the CCK coding provides an extra coding gain of 2.2dB. 11Mbps CHANNEL 1 Processing Gain Gp = (S/N)+ Mj + Lsys Freq.Gp(S/N)Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.4095 11.516.4-6.9 2 2.40955 13.416.4-5 2 2.4096 13.416.4-5 2 2.40965 13.416.4-5 2 2.4097 1116.4-7.4 2 2.40975 1116.4-7.4 2 2.4098 10.916.4-7.5 2 2.40985 10.916.4-7.5 2 2.4099 11.316.4-7.1 2 2.40995 11.316.4-7.1 2 2.41 10.616.4-7.8 2 2.41005 10.816.4-7.6 2 2.4101 10.816.4-7.6 2 2.41015 11.616.4-6.8 2 2.4102 11.716.4-6.7 2 2.41025 11.516.4-6.9 2 2.4103 11.116.4-7.3 2 2.41035 11.516.4-6.9 2 2.4104 11.116.4-7.3 2 2.41045 11.216.4-7.2 2 2.4105 11.616.4-6.8 2 2.41055 1116.4-7.4 2 2.4106 10.916.4-7.5 2 2.41065 11.216.4-7.2 2 2.4107 11.216.4-7.2 2 2.41075 11.116.4-7.3 2 2.4108 10.916.4-7.5 2 FCC ID: O6M-UW200 Report No.: RF90032104 6 Issued: April 16, 2001 11Mbps CHANNEL 1 Processing Gain Gp = (S/N)+ Mj + Lsys Freq.Gp(S/N)Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.41085 11.916.4-6.5 2 2.4109 12.116.4-6.3 2 2.41095 1216.4-6.4 2 2.411 11.416.4-7 2 2.41105 11.216.4-7.2 2 2.4111 11.116.4-7.3 2 2.41115 11.416.4-7 2 2.4112 11.916.4-6.5 2 2.41125 1216.4-6.4 2 2.4113 11.116.4-7.3 2 2.41135 11.616.4-6.8 2 2.4114 11.216.4-7.2 2 2.41145 10.916.4-7.5 2 2.4115 11.616.4-6.8 2 2.41155 1116.4-7.4 2 2.4116 11.216.4-7.2 2 2.41165 11.416.4-7 2 2.4117 11.716.4-6.7 2 2.41175 11.616.4-6.8 2 2.4118 11.416.4-7 2 2.41185 11.516.4-6.9 2 2.4119 10.816.4-7.6 2 2.41195 10.616.4-7.8 2 2.412 10.516.4-7.9 2 2.41205 10.516.4-7.9 2 2.4121 10.916.4-7.5 2 2.41215 11.716.4-6.7 2 2.4122 10.816.4-7.6 2 2.41225 10.616…

Text truncated - open the document above for the full version.

FCC ID: O6M-UW200 Report No.: RF90032104 46 Issued: April 16, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O6M-UW200 Report No.: RF90032104 47 Issued: April 16, 2001 RADIATED EMISSION TEST
