O6M-UW302Wireless USB Network Adapter

USB Wireless Network Adapter User’s Manual Rev 1.0 USB Wireless Network Adapter User’s Manual Regulatory compliance FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: y Reorient or relocate the receiving antenna. y Increase the separation between the equipment and receiver. y Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. y Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. IMPORTANT NOTE: Federal Communications Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. This transmitter must not be co-located or operation in conjunction with any other antenna or transmitter. 2 USB Wireless Network Adapter User’s Manual About this manual This User’s Manual describes how to install and operate your USB Wireless Network Adapter. Please read this manual before you install the product. This manual includes the following topics: ¾ Product description and features. ¾ Hardware installation procedure. ¾ Software installation procedure. ¾ FAQ 3 USB Wireless Network Adapter User’s Manual Table of Contents Regulatory compliance.............................................................................2 About this manual.....................................................................................3 Chapter 1 - Introduction..................................................5 Features.............................................................................................5 What is Wireless LAN?.......................................................................6 Wireless LAN Modes..........................................................................6 Notes on Wireless LAN Configuration................................................7 Chapter 2 - Hardware Installation....................................8 Package Contents..............................................................................8 System Requirements for the Adapter................................................8 Connecting the USB Adapter..............................................................8 LED Indicators....................................................................................9 Disconnecting the USB Adapter.......................................................10 Chapter 3 – Driver Installation for Windows..................11 Driver installation for Windows 98....................................................11 Driver installation for Windows 2000.................................................14 Driver installation for Windows ME...................................................17 Driver installation for Windows XP....................................................19 Chapter 4 – Using the Wireless Utility...........................21 Install Wireless LAN Utility................................................................21 In Windows XP...........................................................................24 Use Windows Wireless Network Configuration....................................25 Use Wireless LAN Utility......................................................................28 Use Wireless LAN Utility In Windows 98, 2000 and ME.............31 Configuring the USB Wireless Network Adapter...............................31 Chapter 5 – Installing Network Protocols......................36 Installing the Network Protocols for Windows 98 and Millennium.....36 Appendix A – FAQ.........................................................39 Appendix B – Specifications..........................................40 4 USB Wireless Network Adapter User’s Manual Chapter 1 - Introduction Thank you for purchasing the USB Wireless Network Adapter. This high-speed USB Wireless Network Adapter provides you with an innovative wireless networking solution. The Adapter is easy to set up and use. With this innovative wireless technology, you can share files and printers on the network—without inconvenient wires! Now you can carry the LAN in your pocket! The Adapter is a network adapter with a rate of 1, 2, 5.5, and 11 Mbps operating in the ISM band using Direct Sequence Spread Spectrum (DSSS) transmission implementing the IEEE 802.11b standard. This adapter provides Device Drivers for Windows 98, Windows 2000, XP and Windows ME. It also provides tools for the configuration of the adapter. The tool, as well as the installation steps of the plug-and-play procedure for the Microsoft Windows 98, 2000, XP and Windows ME operating systems, is described in this document. Features The USB Wireless Network Adapter offers compliance with the IEEE 802.11b specification. This feature allows them to communicate with other wireless devices that support the standard. Features of the …

Text truncated - open the document above for the full version.

FCC ID :O6M-UW302

BROMAX COMMUNICATIONS, INC. No.20, Kuang Fu Road, Hsin Chu Industrial Park, Hu Kou,Hsin Chu 303, Taiwan, R.O.C. TEL: +886-03-597-2988*8370 FAX: +886-03-568-3414 [email protected] Inform Letter Dear Customer, According to FCC’s regulation, the following Declaration of Conformity has to be made by a company located in USA. They are: This device has been confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number RF910715R04. And this compliance is subject to the following two conditions: (1) This device may not cause harmful interference and, (2) This device must accept any interference received, including interference that may cause undesired operation. This declaration can be a separate sheet and be sure that the following message will be also included in this declaration: 1) Product name, model name and trade name. 2) Company name, and address of the one who is responsible for this declaration. 3) Name, title, telephone and fax number as well as the signature of the contact person. Thanks for your attention.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5 Page 6

FCC ID: O6M-UW302 ADT No.910715R04 Operational Description The transmitter of the EUT is powered by host equipment from USB port. The antenna is Inverted F Antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: O6M-UW302 ADT No.: 910715R04 FCC TEST REPORT REPORT NO.: RF910715R04 MODEL NO.: UW302 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:BROMAX COMMUNICATIONS, INC. ADDRESS:No. 20, Kuang Fu Road, Hsin Chu Industrial Park, Hu Kou, Hsin Chu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: O6M-UW302 ADT No.: 910715R04 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20cm away from the body of the user. Warning statement for keeping 20cm separation distance and the prohibition of operating next to a person has been printed on the user’s manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: O6M-UW302 ADT No.: 910715R04 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: O6M-UW302 ADT No.: 910715R04 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -2dBi or 0.63 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241242.071.45 6243743.151.47 11246243.251.47 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: O6M-UW302 Report No.: RF910715R041Issued: September 3, 2002 FCC TEST REPORT REPORT NO.: RF910715R04 MODEL NO.: UW302 (for other models please refer to page 6) RECEIVED: July 15, 2002 TESTED: July 25 ~ August 29, 2002 APPLICANT: BROMAX COMMUNICATIONS, INC. ADDRESS: No. 20, Kuang Fu Road, Hsin Chu Industrial Park, Hu Kou, Hsin Chu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: O6M-UW302 Report No.: RF910715R042Issued: September 3, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2 TEST INSTRUMENTS .................................................................................. 9 4.1.3 TEST PROCEDURES ................................................................................ 10 4.1.4 DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5 TEST SETUP.............................................................................................. 11 4.1.6 EUT OPERATING CONDITIONS ............................................................... 12 4.1.7 TEST RESULTS ......................................................................................... 13 4.2RADIATED EMISSION MEASUREMENT................................................... 19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 19 4.2.2 TEST INSTRUMENTS ................................................................................ 20 4.2.3 TEST PROCEDURES ................................................................................ 21 4.2.4 DEVIATION FROM TEST STANDARD ....................................................... 21 4.2.5 TEST SETUP.............................................................................................. 22 4.2.6 EUT OPERATING CONDITIONS ............................................................... 22 4.2.7 TEST RESULTS ......................................................................................... 23 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 27 4.3.2 TEST INSTRUMENTS ................................................................................ 27 4.3.3 TEST PROCEDURE ................................................................................... 28 4.3.4 DEVIATION FROM TEST STANDARD ....................................................... 28 4.3.5 TEST SETUP.............................................................................................. 28 4.3.6 EUT OPERATING CONDITIONS ............................................................... 28 4.3.7 TEST RESULTS ......................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 33 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT........... 33 4.4.2 INSTRUMENTS.......................................................................................... 33 4.4.3 TEST PROCEDURES ................................................................................ 34 4.4.4 DEVIATION FROM TEST STANDARD ....................................................... 34 4.4.5 TEST SETUP.............................................................................................. 34 4.4.6 EUT OPERATING CONDITIONS ............................................................... 34 FCC ID: O6M-UW302 Report No.: RF910715R043Issued: September 3, 2002 4.4.7 TEST RESULTS ......................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 36 4.5.2 TEST INSTRUMENTS ................................................................................ 36 4.5.3 TEST PROCEDURE ................................................................................... 37 4.5.4 DEVIATION FROM TEST STANDARD ....................................................... 37 4.5.5 TEST SETUP.............................................................................................. 37 4.5.6 EUT OPERATING CONDITION.................................................................. 37 4.5.7 TEST RESULTS ......................................................................................... 38 4.6BAND EDGES MEASUREMENT................................................................ 42 4.6.1 LIMITS OF BAND EDGES MEASUREMENT ............................................. 42 4.6.2 TEST INSTRUMENTS ........…

Text truncated - open the document above for the full version.

FCC ID: O6M-UW302 Report No.: RF910715R0447Issued: September 3, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O6M-UW302 Report No.: RF910715R0448Issued: September 3, 2002 RADIATED EMISSION TEST
