O6QPS40WVEGAPULS 42 radar sensor for continuous level measurement

VEGA Grieshaber KG

Click to zoom

Application Details

Equipment Class: LPR - Level Probing Radar
Date of Grant: May 11, 2023
Application Purpose: Original Equipment
Date of Application: May 11, 2023
Equipment Note: VEGAPULS 42 radar sensor for continuous level measurement
Frequency Range: 75000.00000000 - 85000.00000000
Company: VEGA Grieshaber KG
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

VEGA Grieshaber KG Am Hohenstein 113 77761 Schiltach VEGAPULS 42 1 European Union Hereby, VEGA Grieshaber KG declares that the radio equipment type VEGAPULS 42 are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.vega.com 2 USA FCC ID: O6QPS40W FCC § 15.19 Labelling requirements This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC § 15.21 Information to user "Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." FCC §15.105 statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF Exposure Requirements To comply with FCC RF exposure compliance requirements, the device must be installed to provide a separation distance of at least 20 cm from all persons. 3 Canada IC: 3892A-PS40W This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Canada Class B statement This Class B digital apparatus complies with Canadian ICES-003 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. RF Exposure Requirements This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Déclaration d’exposition aux radiations: Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.

Users Manual

Operating Instructions Radar sensor for continuous level measurement VEGAPULS 42 Three-wire with IO-Link (2 x transistor or 4 ... 20 mA plus 1 x transistor) Document ID: 1016153 2 Contents VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 ... 20 mA plus 1 x transistor) 1016153-EN-230223 Contents 1 About this document ...............................................................................................................4 1.1 Function ...........................................................................................................................4 1.2 Target group .....................................................................................................................4 1.3 Symbols used...................................................................................................................4 2 For your safety .........................................................................................................................5 2.1 Authorised personnel .......................................................................................................5 2.2 Appropriate use ................................................................................................................5 2.3 Warning about incorrect use .............................................................................................5 2.4 General safety instructions ...............................................................................................5 2.5 Country of use - Radar signal ...........................................................................................6 2.6 Installation and operation in the USA and Canada ...........................................................6 3 Product description .................................................................................................................7 3.1 Configuration ....................................................................................................................7 3.2 Principle of operation........................................................................................................8 3.3 Adjustment .......................................................................................................................9 3.4 Packaging, transport and storage .....................................................................................9 3.5 Accessories....................................................................................................................10 4 Mounting .................................................................................................................................11 4.1 General instructions .......................................................................................................11 4.2 Mounting instructions .....................................................................................................11 5 Connecting to power supply .................................................................................................16 5.1 Preparing the connection ...............................................................................................16 5.2 Connection procedure ....................................................................................................16 5.3 Wiring plan .....................................................................................................................17 5.4 Switch-on phase.............................................................................................................17 6 Access protection ..................................................................................................................18 6.1 Bluetooth radio interface ................................................................................................18 6.2 Protection of the parameterization ..................................................................................18 6.3 Storing the codes in myVEGA ........................................................................................19 7 Setup with smartphone/tablet (Bluetooth) ..........................................................................20 7.1 Preparations ...................................................................................................................20 7.2 Connecting .....................................................................................................................20 7.3 Parameter adjustment ....................................................................................................21 8 Setup with PC/notebook (Bluetooth) ...................................................................................22 8.1 Preparations ...................................................................................................................22 8.2 Connecting .....................................................................................................................22 8.3 Parameter adjustment ....................................................................................................23 9 Menu overview .......................................................................................................................24 9.1 VEGA Tools app and DTM (Bluetooth) ...........................................................................24 10 Diagnostics and servicing ....................................................................................................27 10.1 Maintenance ..................................................................................................................27 10.2 Rectify faults ...................................................................................................................27 10.3 Diagnosis, fault messages .............................................................................................28 10.4 Status messages according to NE 107 .................…

Text truncated - open the document above for the full version.

Users Manual

Supplementary instructions Regulations for radar level measuring instruments with radio approvals VEGAPULS 42 Document ID: 1017542 2 Contents VEGAPULS 42 • 1017542-EN-221107 Contents 1 About this document ...............................................................................................................3 1.1 Function ...........................................................................................................................3 2 Certificates and approvals ......................................................................................................4 2.1 Europe .............................................................................................................................4 2.2 USA ..................................................................................................................................4 2.3 Canada ............................................................................................................................5 Editing status: 2022-11-07 3 1 About this document VEGAPULS 42 • 1017542-EN-221107 1 About this document 1.1 Function This manual is an additional document to the respective operating instructions manual of VEGAPULS 42 radar level measuring instru- ments. It contains regulations for the use of the instruments according to the radio approvals. Therefore, read them before setup and keep them as a product component in the immediate vicinity of the instrument and accessible at all times. 4 2 Certificates and approvals VEGAPULS 42 • 1017542-EN-221107 2 Certificates and approvals 2.1 Europe The instrument was tested according to the latest issue of the follow- ing harmonized standards: • EN 302372 - Tank Level Probing Radar In the countries of the EU, the use inside closed vessels is therefore permitted. In the countries of the CEPT the use is permitted, provided that the corresponding rules of the radio regulation ECC Recommenda- tion 70-03 have been implemented. For the receiver test, which covers the influence of an interfering sig- nal on the device, the performance criterion has at least the following performance level according to ETSI TS 103 361 [6]: • Performance criterion: Variation of the measured value during distance measurement under interference conditions • Performance level: Δd ≤ ± 50 mm For operation inside of closed vessels, points a to f in annex E of EN 302372 must be fulfilled. 2.2 USA FCC § 15.19 Labelling requirements This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation FCC § 15.21 Information to user "Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." FCC § 15.105 statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and Standards fulfilled Scope Receiver test Operating conditions Fulfilled standards 5 2 Certificates and approvals VEGAPULS 42 • 1017542-EN-221107 on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help FCC § 15.209 statement This device is approved for unrestricted use only inside closed, sta- tionary vessels made of metal, reinforced fiberglass or concrete. RF Exposure Requirements To comply with FCC RF exposure compliance requirements, the device must be installed to provide a separation distance of at least 20 cm from all persons. 2.3 Canada This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation Le présent appareil est conforme aux CNR d'Industrie Canada ap- plicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscep- tible d'en compromettre le fonctionnement. Canada Class B statement This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB- 003 du Canada. RF Exposure Requirements This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Déclaration d’exposition aux radiations Cet équipement est conforme aux limites d’exposition aux rayonne- ments IC établies pour un environnement non contrôlé. Cet équi- pement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. This device has been approved for cl…

Text truncated - open the document above for the full version.

Cover Letter(s)

External Photos

External pictures VEGAPULS 42 VEGAPULS 42 with plastic lid, without status display VEGAPULS 42 with stainless steel lid, without status display

ID Label/Location Info

Label draft for VEGAPULS 42 The type plate is lasered on the stainless steel body of the device. Location for IDs Label Draft for VEGAPULS 42 with plastic lid, HVIN PS40WM Label Draft for VEGAPULS 42 with stainless steel lid, HVIN PS40WE

Internal Photos

Internal photos Cover print PULSFA1-IO-M/E Main electronic PULSFA1-W-IO Bluetooth print PULSFA1-W-IO

RF Exposure Info

VEGA Grieshaber KG Am Hohenstein 113 77761 Schiltach Germany Phone +49 7836 50-0 [email protected] www.vega.com Limited Partnership Registered office: Wolfach Registrar of companies: Freiburg HRA 680687 Commerzbank Villingen-Schwenningen IBAN: DE39 6424 0071 0220 0657 00 BIC: COBADEFF642 Personally liable partners: Isabel Grieshaber Grieshaber Holding GmbH Registered office: Wolfach HRB 680271 Baden-Wuerttembergische Bank IBAN: DE51 6005 0101 7413 5002 00 BIC: SOLADEST600 Directors: Isabel Grieshaber Guenter Kech Markus Kniesel Deutsche Bank Freiburg IBAN: DE79 6647 0035 0044 2400 00 BIC: DEUTDE6F664 Tax-no. 14079/33608 Tax office Offenburg VAT no. DE143030199 EORI no. DE2446677 Sparkasse Wolfach IBAN: DE34 6645 2776 0001 0695 50 BIC: SOLADES1WOF 04.05.2023 RF Exposure Considerations for the VEGAPULS 42 FCC ID: O6QPS40W The VEGAPULS 42 operates at 2402-2480 MHz (Bluetooth LE) and 75-85 GHz (Tank Level Probing Radar). The transmitters can transmit simultaneously. The FCC requires that the calculated MPE be equal to or less than a given limit dependent on frequency at a distance of 20 cm from a device to the body of a user. The following FCC Rule Parts and procedures are applicable: Part 1.1310 – Radiofrequency radiation exposure limits Part 2.1091 – Radiofrequency radiation exposure evaluation: mobile devices KDB447498 D01 v06 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorisation Policies VEGAPULS 42 MAXIMUM TRANSMITTER POWER CONSIDERATIONS 75-85 GHz: Tx Power: EIRP = -50.4dBm (maximum measured output power). 2402-2480 MHz: Tx Power: 4.0 dBm +/- 1.0 dBm (conducted) Antenna gain: -2.0 dBi EIRP = 4.0 dBm + 1.0 dBm – 2.0 dBi = 3.0 dBm VEGA Grieshaber KG Am Hohenstein 113 77761 Schiltach Germany Phone +49 7836 50-0 [email protected] www.vega.com Limited Partnership Registered office: Wolfach Registrar of companies: Freiburg HRA 680687 Commerzbank Villingen-Schwenningen IBAN: DE39 6424 0071 0220 0657 00 BIC: COBADEFF642 Personally liable partners: Isabel Grieshaber Grieshaber Holding GmbH Registered office: Wolfach HRB 680271 Baden-Wuerttembergische Bank IBAN: DE51 6005 0101 7413 5002 00 BIC: SOLADEST600 Directors: Isabel Grieshaber Guenter Kech Markus Kniesel Deutsche Bank Freiburg IBAN: DE79 6647 0035 0044 2400 00 BIC: DEUTDE6F664 Tax-no. 14079/33608 Tax office Offenburg VAT no. DE143030199 EORI no. DE2446677 Sparkasse Wolfach IBAN: DE34 6645 2776 0001 0695 50 BIC: SOLADES1WOF MPE CALCULATIONS The MPE calculation to calculate the safe operating distance for the user is. S = EIRP/4 π R 2 Where S = Power density EIRP = Effective Isotropic Radiated Power R = distance to the centre of radiation of the antenna (safe operating distance) For 75-85 GHz: Values: EIRP = -50.4 dBm = 9x10 -6 mW R = 20cm Power Density Requirement From table 1 (e) - Limits for General Population/ Uncontrolled Exposure of FCC Rule Part 1.1310 for 75-85 GHz S req1 = 1.0 mW/cm 2 Calculation: S = 9x10 -6 /4 π R 2 S = 9x10 -6 /(12.56 x 20 2 ) S = 9x10 -6 /(5024) S 1 = 1.79 x 10 -9 mW/ cm 2 (<1.0 mW/cm 2 ) For 2402-2480 MHz: Values: EIRP = 3.0 dBm = 2.0 mW R = 20cm Power Density Requirement VEGA Grieshaber KG Am Hohenstein 113 77761 Schiltach Germany Phone +49 7836 50-0 [email protected] www.vega.com Limited Partnership Registered office: Wolfach Registrar of companies: Freiburg HRA 680687 Commerzbank Villingen-Schwenningen IBAN: DE39 6424 0071 0220 0657 00 BIC: COBADEFF642 Personally liable partners: Isabel Grieshaber Grieshaber Holding GmbH Registered office: Wolfach HRB 680271 Baden-Wuerttembergische Bank IBAN: DE51 6005 0101 7413 5002 00 BIC: SOLADEST600 Directors: Isabel Grieshaber Guenter Kech Markus Kniesel Deutsche Bank Freiburg IBAN: DE79 6647 0035 0044 2400 00 BIC: DEUTDE6F664 Tax-no. 14079/33608 Tax office Offenburg VAT no. DE143030199 EORI no. DE2446677 Sparkasse Wolfach IBAN: DE34 6645 2776 0001 0695 50 BIC: SOLADES1WOF From table 1 (b) - Limits for General Population/ Uncontrolled Exposure of FCC Rule Part 1.1310 for 2402-2480 MHz S req2 = 1.0 mW/cm 2 Calculation: S = 2.0/4 π R 2 S = 2.0/(12.56 x 20 2 ) S = 2.0/(5024) S 2 = 0.0004 mW/ cm 2 (<1.0 mW/cm 2 ) KDB447498 D01 v06 Section 7.2 SIMULTANEOUS TRANSMISSION CONSIDERATIONS The equipment operates from a single antenna. All transmitters can transmit simultaneously. As per KDB, summation of calculated MPE ratios for 75-85 GHz and 2402-2480 MHz: ΣMPE ratios = (S 1 / S req1 ) + (S 2 / S req2 ) = (1.79x10 -9 /1.0) + (0.0004/1.0) = 0.0004 Σ of MPE ratios<1.0, so in accordance with KDB447498 Section 7.2, simultaneous transmission test exclusion applies for the transmitters. Conclusion The required 20cm RF exposure limits for General Population/Uncontrolled Exposure will not be exceeded for the VEGAPULS 42.

Test Report

UL International (UK) LTD Unit 1-3 Horizon, Kingsland Business Park, Wade Road, Basingstoke, Hampshire, RG24 8AH, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP14415455-416B Customer : VEGA Grieshaber KG HVIN : PS40WM PMN : VEGAPULS 42 ISED Certification No. : IC: 3892A-PS40W Technology : Level Probing Radar Test Standard(s) : Innovation, Science and Economic Development Canada RSS-211 Issue 1 March 2015 RSS-Gen Issue 5 February 2021 Test Laboratory : UL International (UK) Ltd, Basingstoke, Hampshire, RG24 8AH, United Kingdom 1. This test report shall not be reproduced except in full, without the written approval of UL International (UK) Ltd. 2. The results in this report apply only to the sample(s) tested. 3. The sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 4.0 supersedes all previous versions. Date of Issue: 24 April 2023 Checked by: Ben Mercer Lead Project Engineer, Radio Laboratory Company Signatory: Sarah Williams RF Operations Leader, Radio Laboratory TEST REPORT SERIAL NO: UL-RPT-RP14415455-416B VERSION 4.0 ISSUE DATE: 24 APRIL 2023 Page 2 of 46 Customer Information & Manufacturer Information Customer Company Name: VEGA Grieshaber KG Address: Am Hohenstein 113 D- 77761 Schiltach Germany Manufacturer Company Name: VEGA Americas, Inc. Address: 3877 Mason Research Parkway Ohio Mason 45036 United States of America Company Name: VEGA India Level and Pressure Measurement Pvt. Ltd Address: Plot No. 1, Gat No. 181, Village – Phulgaon Tal. Haveli Pune 412216 India Report Revision History Version Number Issue Date Revision Details Revised By 1.0 02/03/2023 Initial Version Ben Mercer 2.0 05/04/2023 HVIN & IC number updated Ben Mercer 3.0 17/04/2023 HVIN updated Ben Mercer 4.0 24/04/2023 HVIN updated Ben Mercer TEST REPORT SERIAL NO: UL-RPT-RP14415455-416B VERSION 4.0 ISSUE DATE: 24 APRIL 2023 Page 3 of 46 Table of Contents Customer Information & Manufacturer Information .................................................................. 2 Report Revision History .............................................................................................................. 2 Table of Contents ......................................................................................................................... 3 1 Attestation of Test Results ....................................................................................................... 4 1.1 Description of EUT 4 1.2 General Information 4 1.3 Summary of Test Results 5 1.4 Deviations from the Test Specification 5 2 Summary of Testing.................................................................................................................. 6 2.1 Facilities and Accreditation 6 2.2 Methods and Procedures 6 2.3 Calibration and Uncertainty 7 2.4 Test and Measurement Equipment 8 3 Equipment Under Test (EUT) ................................................................................................. 11 3.1 Identification of Equipment Under Test (EUT) 11 3.2 Modifications Incorporated in the EUT 11 3.3 Additional Information Related to Testing 12 3.4 Description of Available Antennas 12 3.5 Description of Test Setup 13 4 Antenna Port Test Results ..................................................................................................... 18 4.1 Transmitter Duty Cycle 18 4.2 Transmitter 99% Occupied Bandwidth 19 4.3 Transmitter Fundamental Emission Bandwidth 21 4.4 Transmitter Frequency Stability (Temperature Variation) 23 4.5 Transmitter Frequency Stability (Voltage Variation) 25 5 Radiated Test Results ............................................................................................................. 26 5.1 Transmitter Radiated Emissions <1 GHz 26 5.2 Transmitter Radiated Emissions >1 GHz 31 6 AC Power Line Conducted Emissions Test Results ......................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Patrick Friedmann(Product Compliance & QM)

[email protected]+49783650537Fax: +49783650201

Technical Contact

Vega Grieshaber KGPatrick Friedmann

[email protected]+49 7836 537

Am Hohenstein 113 · Schiltach · Germany

Non-Technical Contact

Vega Grieshaber KGPatrick Friedmann

[email protected]+49 7836 537

Test Firm

UL International (UK) LtdScott D'Adamo

[email protected]44 1256 312101Fax: 44 1256 312001

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15.209	75.00 GHz - 85.00 GHz	-

Confidentiality

Long Term

Grant Notes

The marketing of this equipment to residential customers is prohibited. This device must be professionally installed. This device is approved when installed in a fully enclosed metal or concrete vessel.
