O6Y-CDM7026Cellular/ PCS CDMA Phone

UTStarcom Korea Technologies Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: May 29, 2007
Application Purpose: Original Equipment
Date of Application: May 29, 2007
Equipment Note: Cellular/ PCS CDMA Phone
Frequency Range: 1851.25000000 - 1908.75000000
Company: UTStarcom Korea Technologies Ltd.
Country: South Korea
