O6Y-CDMRF101Cellular/ PCS CDMA Modem

UTStarcom Korea Technologies Ltd.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Jun 03, 2007
Application Purpose: Original Equipment
Date of Application: Jun 03, 2007
Equipment Note: Cellular/ PCS CDMA Modem
Frequency Range: 1851.25000000 - 1908.75000000
Company: UTStarcom Korea Technologies Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CDMRF101 TCU Phone Module Component Technical Specification Manual Ver. 00.1 Apr. 27. 2007 Notice All data and information contained in or disclosed by this document are confidential and proprietary information of UTStarcom Inc., and all rights therein are expressly reserved. By accepting this material, the recipient agrees that this material and the information contained therein are held in confidence and in trust and will not be used, copied, reproduced, or distributed in whole or in part, nor its contents revealed in any manner to others without the express written permission of UTStarcom Inc. UTStarcom Inc. does not assume any liability arising out of the application or use of its products. UTStarcom Inc. assumes no responsibility for any damage or loss resulting from the misuse of its products. UTStarcom Inc. assumes no responsibility for any loss or claims by third parties, which may arise through the use of its products. UTStarcom Inc. assumes no responsibility for any damage or loss caused by the deletion or loss of data as a result of malfunctions or repairs. The information contained in this document is subject to change without notice. Information contained herein is for reference only and does not constitute a commitment on the part of UTStarcom Inc. Although the information in this document has been carefully reviewed and it’s believed to be reliable, UTStarcom Inc. assumes no responsibility or liability for any errors or inaccuracies that may appear in this document nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this document. It is advised for the customers to contact our engineers for more information with respect to Keypad, audio interface, RF interface and input power supply before they start an actual design. OEM integrators and installers are instructed that the phrase. This device contains transmitter FCC ID: O6Y-CDMRF101 must be placed on the outside of the host. Warning: Exposure to Radio Frequency Radiation The radiated output power of this device is far below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact during normal operation is minimized. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna should not be less than 20cm during normal operation. The gain of the antenna for Cellular band must not exceed 0dBi. The gain of the antenna for PCS band must not exceed -3dBi. Table of Contents CDMRF101 ........................................................................................................................................................... 1 TCU PHONE MODULE ........................................................................................................................................ 1 1 INTRODUCTION / OVERVIEW ................................................................................................................... 6 1.1 MSM 6050 Chipset ................................................................................................................................. 6 1.1.1 MSM 6050 Features........................................................................................................................ 6 1.2 IS- Mobile Standards ............................................................................................................................. 7 1.3 Acronym Definitions.............................................................................................................................. 8 1.4 Development Tools for the Phone Module..........................................................................................8 1.4.1 LT Box ............................................................................................................................................. 8 ..................................................................................................................................................................... 8 2 MECHANICAL DESCRIPTION ................................................................................................................... 9 2.1 Phone Module Mechanical Outline ...................................................................................................... 9 2.2 Phone Module I/O Connector ............................................................................................................... 9 2.2.1 I/O Connector Drawing and Supplier Part Number......................................................................... 9 2.2.2 I/O Connector Electrical Characteristics .......................................................................................10 2.2.2.1 I/O Connector Pin Assignment .............................................................................................. 10 3 OPERATING TEMPERATURE AND STORAGE ..................................................................................... 13 3.1 Temperature ......................................................................................................................................... 13 3.1.1 Storage Temperature .................................................................................................................... 13 3.1.2 Operating Temperature................................................................................................................. 13 4 ELECTRICAL INTERFACE....................................................................................................................... 14 4.1 Design Guidelines ............................................................................................................................... 14 4.1.1 Component Derating ..................................................................................................................... 14 4.1.1.1 Ceramic Capacitors / Parallel Plate Capacitors...............…

Text truncated - open the document above for the full version.

External Photos

ID Label/Location Info

U T S t a r co m C onfid ent ia l 4 Packing Pedro CDMRF101 Device label for m at & Location SERIAL # :F : Foxconn (Manufacture) 0715 : Date code (YYW W) 000001: Serial Number Model # : CDMRF101FCC ID # : O6Y-CDMRF101 Model # : CDMRF101FCC ID # : O6Y-CDMRF101 Model # : CDMRF101FCC ID # : O6Y-CDMRF101

Internal Photos

RF Exposure Info

FCC ID: O6Y-CDMRF101 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna FCC ID: O6Y-CDMRF101 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr 2-1. CELLUAR BAND Max Peak output Power at antenna input terminal (dBm) 24.010 Max Peak output Power at antenna input terminal (mW) 251.189 Prediction distance (cm) 20.000 Prediction frequency (MHz) 848.310 Antenna Gain(typical) (dBi) 0.000 Antenna Gain(numeric) 1.000 Power density at prediction frequency (mW/cm²) 0.050 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 0.566 2-2. PCS BAND Max Peak output Power at antenna input terminal (dBm) 24.010 Max Peak output Power at antenna input terminal (mW) 251.189 Prediction distance (cm) 20.000 Prediction frequency (MHz) 1908.750 Antenna Gain(typical) (dBi) -3.000 Antenna Gain(numeric) 0.501 Power density at prediction frequency (mW/cm²) 0.025 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.000 3. RESULTS The power density level at 20 cm is 0.050 mW/cm², which is below the uncontrolled exposure limit of 0.550 mW/cm² at 848.31 MHz for Cellular band. The power density level at 20 cm is 0.025 mW/cm², which is below the uncontrolled exposure limit of 1 mW/cm² at 1908.75 MHz for PCS band.

Test Report

Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr D . TEST PLOTS Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA MODE (1013 CH.) Conducted Spurious Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA MODE (384 CH.) Conducted Spurious Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA MODE (777 CH.) Conducted Spurious Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA MODE (25 CH.) Conducted Spurious Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA MODE (600 CH.) Conducted Spurious Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA MODE (1175 CH.) Conducted Spurious Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA MODE (1013 CH.): Channel Power Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA MODE (384CH.) : Channel Power Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA Mode (777 CH.) : Occupied Bandwidth Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA Mode (25 CH) : Occupied Bandwidth Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA Mode (600 CH) : Occupied Bandwidth Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA Mode (1175 CH) : Occupied Bandwidth Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA Cellular (1013 CH.) Band Edge Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA Cellular (777 CH.) Band Edge Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS Mode Band Edge (25 CH.) Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS Mode Band Edge (1175 CH.) Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA (1013 CH) Test Mode: POWER OUT Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA (384 CH) Test Mode: POWER OUT Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CDMA (777 CH) Test Mode: POWER OUT Report No.: HCT-SAR07-0505 FCC ID:O6Y-CDMRF101 DATE: May 15, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr PCS CDMA (2…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Chung-Sung Lee(Director, R&D)

[email protected]82-2-368-9023Fax: 82-2-2057-0181

Technical Contact

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

HCT Co., LTDSang Lee

[email protected]82-31-645-6420Fax: 82-31-645-6401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	249.00 mW	1M25F9W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is Conducted. This device is approved for mobile operation, pursuant to 2.1091 and may only be marketed to OEM installers. The antenna installation must provide a minimum separation distance of 20 cm from users and nearby persons and must not be co-located or operate in conjunction with any other antenna or transmitter. The antenna gain must not exceed 0 dBi in the Cellular Band and -3dBi in the PCS Band. OEM installers must be provided with antenna installation instruction and transmitter operating conditions for satisfying RF exposure compliance.
