O6Z-HARN1006CAR AUDIO

201901015 Renault R0-20 MID Manual for MFicertification . 2 Title Confidential Table of Contents Faceplate keys (1/2) Faceplate keys (2/2) SWC Keys Firmware check Firmware update via USB storage Bluetooth Pairing Bluetooth music (A2DP) Phone calling via Bluetooth (Incoming) Phone calling via Bluetooth (Outgoing) R&Goscenes : App download R&Goscenes : Launch R&Go, Agreement, Home screen R&Goscenes : Multimedia controls R&Goscenes : Volume controls 3 Title Confidential Faceplate keys (1/2) Product Image | D E GHIJKLM LCD Area <Front View> A B C F : used for iPod control 4 Title Confidential Faceplate keys (2/2) ButtonIndexButtonName Button on Faceplate Operation Functional Controls Key Action (iPod)Key Action (Radio) Short PressLong PressShort PressLong Press Rotary1 leftA push : ON/OFFPressOFF + PlayPauseN/AOFF + PlayPauseN/A scrolling : Vol+/- Turn Left Vol - N/A Vol - N/A TurnRight Vol + N/A Vol + N/A Buttons BRADIO/MEDIAPress Switch FM, DR, AM --> iPod/USB* --> BT* (*if connected) Previous radio mode (FM or DR) List update Switch FM, DR, AM --> iPod/USB* --> BT* (*if connected) Radiorelated function CTELPressOpen TEL MENU Redial last call + at the end of call = >previous audio source Open TEL MENU Redial last call + at the end of call = >previous audio source DTEXT/SETUPPressOpen SETUP MENUFull ID3 Tag DisplayOpen setup menuDepend oncurrent mode EBack (icon)PressN/AN/ABack 1 level in menuExit current menu Rotary2 rightF push: OKPressOpen the list & SelectN/ASelect ItemN/A Scrolling: Next/Previous+ Scrolling through items Turn Left Open list , start browse with the focus on the next item N/A if list is open , start browse with the focus on the next item N/A TurnRight Open list , start browse with the focus on the previous item N/A if list is open , start browse with the focus on the previous item N/A Buttons G1 / MIXPressToggle Random ModeN/A Toggle Mix Mode or PRESET 1 STORE PRESET 1 H2/ RPTPress Toggle Repeat Mode(Repeat one -> Repeat All -> Repeat None -> Repeat one) N/A Toggle Repeat Mode or PRESET 2 STORE PRESET 2 I3PressN/AN/APRESET 3STORE PRESET 3 J4PressN/AN/APRESET 4STORE PRESET 4 K5PressN/AN/APRESET 5STORE PRESET 5 L6PressN/AN/APRESET 6STORE PRESET 6 USB SocketM------- Vol- Vol+ Down Up Ok Tel Back Setup Source 5 Title Confidential SWC Keys Product Image | ButtonIndexButtonNameOperation Functional Controls Action (iPod)Action (Radio) Short PressLong PressShort PressLong Press SWC keys Buttons A Audio Source up Press Cycle through FM, DR, AM --> iPod/USB* --> BT* (*if connected) N/ASourceChangeN/A B Audio Source Down Press Cycle through FM<--DR<--AM<-- USB/iPod*<--BT* (*if connected) N/A SourceChangeN/A C Vol +PressIncrease vol. 1 stepCONTINUOUS VOL +Increase vol. 1 stepCONTINUOUS VOL + D Vol -PressDecrease vol. 1 stepCONTINUOUS VOL -Decrease vol. 1 stepCONTINUOUS VOL - E Rotary Scroll Turn Left TRACK +/-without opening the list, or browse the list after opening by "OK" N/A TRACK +/- without opening the list N/A TurnRightN/AN/A F ModePressValidate selection / OKBackselection / OKBack C + D MutePressMUTE + PlayPauseN/AMUTE + PlayPauseN/A AB F <Front View> C D <Back View> E E A B F <Side View> C D : used for iPod control Vol- Vol+ Prev Next Source Source 6 Title Confidential Firmware check Sofware version Software Version Screen Sofware Version : XXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXX Down Ok Back Audio Settings USER Menu Screen Clock Radio Settings Audio Settings Setup 7 Title Confidential Firmware update via USB storage INSERT USB Valid Audio Unit SW on USB? Previous Audio Screen No Yes No Screen takes format: -Description "Upgrading to V X.X" -Warning -Progress percentage Progress percentage could be replaced by progress bar -should be parrallelto c ountdown. For every screens, ARROWS sh all be replaced by BACKLIGHT selection style if USB contains more than 1 upgrade ver sion files, just show the latest version. After reboot Update not started Previous Update Failed Update Failed Package detected 3sec s Yes Once the reboot is done, radio shall start on FM radio source. If the USB stick with reflash files ins ertion is connected during the OFF_ USER/OFF modes, the reflash oper ation shall not start. RADIO EMERGENCY BOOT AFTER SOFTWAR E DOWNLOAD ERROR. MAIN MEMORY CORR UPTED. START IN RECOVERY BACKUP MODE. USB Loading period Software Update detected Plea se wait Incompatibility Screen Software Package error or Incompatible Update Error Screen Software Update error Insert USB Software package User choice Screen Update SW : V0.1 To SW : V0.2 Yes No Update Screen Updating : Do not remove USB. Do not stop or start engine 87% Update Screen Update completed successfully Radio will restart Audio Previous Source 11:53 To choose To select Down Up Ok 3se cs 3se cs 8 Title Confidential Bluetooth Pairing No -Go to the main phone menu Yes -Goto delete device Pair Device Cell phone input of pin Timeout after 60 seconds returns to pair device menu Return to current Audio source BT DEVICE with default pincode (0000) if no response is received for 1min the Pairing Failure Screen is entered or the connection is interrupted or timed out no HMI displayed no action needed at least one of the requested p rofiles (HFP, A2DP) is support ed by the BT Device neither HFP nor A2DP are not supp orted by the BT Device or the connection is interrupted or timed out might be that the device can never be connected as it does not support HFP or A2DP assumption is it is shown in the lists but connection attempt allways results in failure Return to Tel Menu Screen (previous selection enlighted) By pressing OK, customer confirm that Radio and BT device display same code on successful pairing PRESS on BACK results in pair ing failure and returns to device selection there might be some devices wh ich have a different fixed pin cod e which will not be supported Simple Pairing Screen Push on OK to confirm pass word XXXXXX for pairing to BT Device Radio ready to pair Screen Ready To Pair Enter : 0000 0:59s Pairing in Progre…

Text truncated - open the document above for the full version.

Humax Co., Ltd. HUMAX BLDG., 2, Yeongmun-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea Date: Jan. 13, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 ,Industry Canada c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA FCC ID : O6Z-HARN1006 To whom it may concern: I, the undersigned, hereby authorize Technical Manager Issac Jin of MOVON CORPORATION and here after referred to as MOVON CORPORATION, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these m atters. Any and all acts carried out by Technical Manager Issac Jin of MOVON CORPORATION on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MOVON CORPORATION as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Humax Co., Ltd. HUMAX BLDG., 2, Yeongmun-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, In seok Seo / Project Manager Humax Co., Ltd. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Humax Co., Ltd. HUMAX BLDG., 2, Yeongmun-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: O6Z-HARN1006 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics / Block Diagram / Operational Description / Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. 2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos / Internal Photos / Test Setup Photos / User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, In seok Seo / Project Manager Humax Co., Ltd.

Declaration of Equivalence For declaration of equality between a product variant to be certified with reference to an original product. To be issued and signed by the company responsible for the product variant. Declare on our sole responsibility that the product - Original Model Product Information Product ID: HARN1006 are in all relevant parts identical to the product - Variant Model Product Information Product ID: HARN3001 - The difference between (original design) and (variant design) is : Hardware Hardware version is same. Software Software Version is same. - Model HARN3001 is identical to basic model HARN1006 except for removed front panel and buyer model name We, the undersigned, hereby declare that the Second Manufacturer Design is identical in both design and implementation. Signed by Company Name : Humax Co.,Ltd. Korea / Jan 13, 2020 (Place, date of issue) (Signature / stamp) In seok Seo / Project Manager

Copyright ⓒ Movon Corporation. All rights Reserved. External Photos Copyright ⓒ Movon Corporation. All rights Reserved. External Photos Front Rear Copyright ⓒ Movon Corporation. All rights Reserved. External Photos Left Right Copyright ⓒ Movon Corporation. All rights Reserved. External Photos Top Bottom

Copyright ⓒ Movon Corporation. All rights Reserved. Label Informaion Copyright ⓒ Movon Corporation. All rights Reserved. Label information Drawing

Copyright ⓒ Movon Corporation. All rights Reserved. Internal Photos Copyright ⓒ Movon Corporation. All rights Reserved. Internal Photos Main Board Front Main Board Rear Copyright ⓒ Movon Corporation. All rights Reserved. Internal Photos Sub Board Front Sub Board Rear Copyright ⓒ Movon Corporation. All rights Reserved. Internal Photos Module Inside Copyright ⓒ Movon Corporation. All rights Reserved. Internal Photos Antenna Antenna

1. Regulation 2. RF Exposure Compliance Issue f=frequency in MHz, *= plane-wave equivalent power density MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01 S = power density [mW/cm 2 ] P = Power input to antenna [mW] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [cm] The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. 300 ~ 1 500//f/1 50030 1 500 ~ 15 000//130 1.34 ~ 30824/f2.19/f*(180/f2)30 30 ~ 30027.50.0730.230 According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. RF EXPOSURE Limits for Maximum Permissive Exposure: RF exposure is calculated. Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.346141.63*(100)30 Frequency Range Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [mW/cm 2 ] Averaging Time [minute] () SPGRRPGS4 4 2 == Copyright ⓒ Movon Corporation. All rights Reserved. ( R : Distance to the center of the radiation of the antenna20cm ) EIRP : Equivalent Isotropic Radiated Power (mW) - NOTE P : Max tuneup Power (dBm) G : Maximum Peak Antenna Gain (dBi) Power Density at the specific separation - NOTE- S dBi 2.90dBm =1.95mW = 4.00dBm+ mW/cm 2 = 0.000 388 -1.10 - EIRP=P + G = Minimum :1.00 1.95/( 4 X 20^2 X π ) = EIRP / (4 X R 2 π) = S : Maximum Power Density (mW/cm 2 ) dBm) - Maximum Output Power for the Calculation :4.00 dBm Maximum :4.00 dBm The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the The MPE calculation for this exposure is shown below. dBi (& - Maximum Peak Antenna Gain :-1.10 1.50 dB - Measured RF Output Power (Peak) :3.08 dBm - Target Power & Tolerance :2.50 dBm&± MPE Calculations : Bluetooth BDR - Frequency Range :2 402 MHz~2 480 MHz Copyright ⓒ Movon Corporation. All rights Reserved. ( = 0.000 388 mW/cm 2 EIRP : Equivalent Isotropic Radiated Power (mW) R : Distance to the center of the radiation of the antenna20cm ) Power Density at the specific separation - S= EIRP / (4 X R 2 π) - NOTE =1.95/( 4 X 20^2 X π ) S : Maximum Power Density (mW/cm 2 ) P : Max tuneup Power (dBm) =2.90dBmG : Maximum Peak Antenna Gain (dBi) =1.95mW =4.00dBm+-1.10dBi - Maximum Output Power for the Calculation :4.00 dBm The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the The MPE calculation for this exposure is shown below. - EIRP=P + G- NOTE Minimum :1.00 dBm) - Maximum Peak Antenna Gain :-1.10dBi dB (Maximum :4.00 dBm& - Measured RF Output Power (Peak) :3.74 dBm - Target Power & Tolerance :2.50 dBm&±1.50 MPE Calculations : Bluetooth EDR - Frequency Range :2 402 MHz~2 480 MHz Copyright ⓒ Movon Corporation. All rights Reserved.

MOVON CORPORATION Report Number: MOV-20-RF-I013 Page : (1) of (47) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. FCC Part 15 Subpart B&C §15.247 RSS-247 Issue 2 Test Report Equipment Under Test CAR AUDIO Model Name HARN1006 Variant Model Name HARN3001 FCC ID O6Z-HARN1006 FCC Applicant Humax Co., Ltd. Date of Test(s) 2019. 12. 20 ~ 2020. 01. 02 Date of Issue 2020. 01. 14 In the configuration tested, the EUT complied with the standards specified above. Issue to Issue by Humax Co., Ltd. HUMAX BLDG., 2, Yeongmun-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea Tel.: +81-31-697-4883 Fax: +81-31-697-4804 MOVON CORPORATION 498-2, Geumeo-ro, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 17030 Tel.: +82-31-338-8837 Fax: +82-31-338-8847 MOVON CORPORATION Report Number: MOV-20-RF-I013 Page : (2) of (47) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Revision history Revision Date of issue Description Revised by -- 2020.01.14 Initial - -- MOVON CORPORATION Report Number: MOV-20-RF-I013 Page : (3) of (47) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Table of contents 1. Applicant Information ................................................................................................... 4 2. Laboratory Information ................................................................................................. 4 3. Summary of test results................................................................................................ 5 4. EUT Description ............................................................................................................ 6 5. Measurement equipment .............................................................................................. 7 6. Antenna requirement .................................................................................................... 8 7. 20 ㏈bandwidth & 99% bandwidth .............................................................................. 9 8. Peak output power ...................................................................................................... 16 9. Carrier frequency separation ..................................................................................... 21 10. Number of hopping frequencies .............................................................................. 23 11. Time of occupancy (Dwell time) ............................................................................... 26 12. Transmitter radiated spurious emissions and conducted spurious emissions .. 28 MOVON CORPORATION Report Number: MOV-20-RF-I013 Page : (4) of (47) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 1. Applicant Information 1.1. Details of applicant Applicant : Humax Co., Ltd. Address : HUMAX BLDG., 2, Yeongmun-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea Contact Person : Il Kwon Lee Telephone : +81-31-697-4883 Fax : +81-31-697-4804 1.2. Manufacturer Information Manufacturer : Humax Co., Ltd. Address : HUMAX BLDG., 2, Yeongmun-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea 2. Laboratory Information Company name : MOVON CORPORATION Test site number : FCC (KR0151) Address : 498-2, Geumeo-ro, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, South Korea Web site : http://www.movonlab.co.kr Telephone : +82-31-338-8837 Facsimile +82-31-338-8847 MOVON CORPORATION Report Number: MOV-20-RF-I013 Page : (6) of (47) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 4. EUT Description Kind of product CAR AUDIO Model Name HARN1006 Variant Model Name HARN3001 FCC ID O6ZHARN1006 Power supply DC 13.50 V Frequency range 2 402 MHz ~ 2 480 MHz Modulation technique GFSK, Pi/4DQPSK, 8DPSK Number of channels 79 ch Antenna gain - 1.10㏈i Test Site Registration Number FCC (KR0151) H/W version / S/W version 1.0 / 1.0 Test S/W version TESCOM_TC-3000B(Bluetooth Tester) 4.1. Table for Test Modes and Frequency (Bluetooth) Preliminary tests were performed in different data rate to find the worst radiated emission. The data rate shown in the table below is the worst-case rate with respect to the specific test item. Investigation has been done on all the possible configurations for searching the worst cases. The following table is a list of the test modes shown in this test report. Mode Data rate (Worst case) Frequency (Freq. MHz) BDR DH5 Lowest (2 402) / Middle (2 441) / Highest (2 480) EDR 3-DH5 Lowest (2 402) / Middle (2 441) / Highest (2 480) 4.2. Information about the FHSS characteristics 4.2.1. Pseudorandom frequency hopping sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is1600 hops/s. 4.2.2. Medium access protocol The manufacturer declares that the device uses Bluetooth protocol. It confirmed that Medium access protocol is implemented. MOVON CORPORATION Report Number: MOV-20-RF-I013 Page : (7) of (47) The results shown in this test…

Text truncated - open the document above for the full version.

Copyright ⓒ Movon Corporation. All rights Reserved. Test Setup Photos Copyright ⓒ Movon Corporation. All rights Reserved. Test Setup Photos Radiated Emission_9 kHz ~ 30 MHz Test distance : 3 m, height of table : 0.8 m Radiated Emission_30 MHz ~ 1 GHz Test distance : 3 m, height of table : 0.8 m Copyright ⓒ Movon Corporation. All rights Reserved. Test Setup Photos Radiated Emission_1 GHz ~ 18 GHz Test distance : 3 m, height of table : 1.5 m Radiated Emission_18 GHz ~ 26 GHz Test distance : 3 m, height of table : 1.5 m
