O725346XTouchChip � Silicon Fingerprint Reader

STMicroelectronics TouchChip (R) Fingerprint Sensor 1.0 USB installation notes: This diskette contains the file needed for plug and play installation of the STMicroelectronics TouchChip (R) Fingerprint Sensor for USB. 2.0 Installation Overview You will need a TouchChip USB Sensor, this diskette, and the Windows '98 CD. During the installation Windows will install the "StillImage" device class. If this is the first time you are adding a device of this class, Windows will require you to reboot your machine. 3.0 Procedure: Plug in the sensor. You should see the Windows "Add New Hardware Wizard" appear. Follow the instructions. When you see "What do you want Windows to do?", select "Search for the best driver for your device. (Recommended)". Depending on which versio n of the se nsor you ha ve, yo u may ha ve to go throug h t he Add Hardw are process several times for each of the functions the device supports (mouse, sensor, etc.) . When Windows asks you where to look for new drivers, you should select the "Floppy disk drives" and "CD-ROM drive" option. Have your Windows '98 CD in t he CD-ROM drive, and have this diskette inserted in a floppy drive. Once you have installed all the drivers, they will be loaded automatically every time the sensor is connected. 4.0 Verifying Installation: You can verify the installation and functioning of the USB driver in the following way: First make sure the device is attached. Open the System properties control panel by selecting Start:Settings:Control Panel:System. When the System Properties window appears, click on the "Device Manager" tab. Scroll down to "Scanning Device" and you should find "STMicroelectronics TouchChip Fingerprint Sensor" as one of the listed devices. Select this device and click on the "Properties" button. When the properties window appears, you should be able to see "This device is working properly" under the "Device Status" field of the "General" tab. Select the "Driver" tab, then click on "Driver File Details". You should see C:\WINDOWS\SYSTEM32\DRIVERS\usbscan.sys C:\WINDOWS\SYSTEM\VMM32.VXD(ntkern.vxd) If you do not see this, try reinstalling the driver: Go back to the "System Properties: Device Manager" tab. Select the "STMicroelectronics TouchChip Fingerprint Sensor" and then hit the "Remove" button. Unplug the device and then plug it back in to restart the plug and play. FCC NOTICE INFORMATION FOR THE USER FCC ID: O725346X This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installatio n. If this equipment does cause harmf ul interference to radio or televisio n reception, which can be determined by turning the equipment off and on, the user is enco uraged to try to correct the interference by o ne or more of the follo wing measures: 1)Reorient or relocate the receiving antenna. 2)Increase the separation between the equipment and receiver. 3)Connect the equipment into an outlet on a circuit different from that to which the receiver is co nnected. 4)Consult the dealer of an experienced radio/TV technician for help. The user may find the following publicatio n prepared by the Federal Communicatio ns Commission helpful: "How to Identify and Reso lve Radio-TV Interference Problems" (Stock Number 004-000-00345-4). Available exclusively from the Superintendent of Documents, Government Printing Office, Washingto n, DC 20402 (telepho ne 202-512-1800). FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance to Part 15 of the FCC Rules could void the user's authority to operate the equipment.

TITLE: PLI Evaluation Report (RFI) FCC ID: O725346XPage 1 of 1 DRAWING: 117850 Issued: 17 Aug 2000 BY: Zane TraubApproved: Lee Pulver Pulver Laboratories Inc. 320 North Santa Cruz Avenue Los Gatos, California 95030-7243 Telephone: 408.399.7000 Facsimile: 408.399.7001 www.PulverLabs.com 1.0 Mandatory Labeling and Operators' Manual Information and Shipping Documents 1.1 Label Illustration 1.0 on the next page illustrates the actual label (three times the actual size) with the appropriate wording. Note the letters "EMI" on the label which abbreviate "Electromagnetic Interference". Organizations like the Federal Communications Commission and their respective limits are listed on the label. Also notice the letters "NRTL", which abbreviate "Nationally Recognized Testing Laboratory" as recommended by OSHA and the National Electrical Code for the United States. For Pulver Laboratories product Certification labels used for safety Certification, the phrase "SAFETY" appears on the label. Safety Certifying organizations like Pulver Laboratories are listed on the label adjacent to the testing standards used during equipment evaluation. A rough sketch of the label location is shown below. Base Plate of EUT Illustration 1.0 {three times the size of actual FCC Label} Alternative Label Label FCC ID: O725346X

TITLE: PLI Evaluation Report (RFI) FCC ID: O725346XPage 1 of 42 DRAWING: 117852 Issued: 17 Aug 2000 BY: Zane TraubApproved: Lee Pulver Pulver Laboratories Inc. 320 North Santa Cruz Avenue Los Gatos, California 95030-7243 Telephone: 408.399.7000 Facsimile: 408.399.7001 www.PulverLabs.com This drawing consists of pages issued or re-issued on dates shown in the following list. Italic underlined words indicate content changes or additions on revised pages. PAGEISSUED 1 - 4217 Aug 2000 COMPANY CONFIDENTIAL This report is the property of Pulver Laboratories Inc. The information contained in this report can only be divulged to persons authorized by Pulver Laboratories Inc. Portions of this report contain information proprietary to STMicroelectronics; other portions of this report contain information proprietary to Pulver Laboratories and the RFI Controls Company. Except for agencies like the Federal Communications Commission, companies must sign Non-Use and Non-Disclosure Agreements before authorized to read this report. All rights reserved. No part of this report may be reproduced or transmitted in any form or by any means without permission in writing from Pulver Laboratories Inc. Copyright 1983 - 2000 Pulver Laboratories Inc. PLI223F11W.FRMx2 Q534604FCCW.DWG TITLE: PLI Evaluation Report (RFI) FCC ID: O725346XPage 2 of 42 DRAWING: 117852 Issued: 17 Aug 2000 BY: Zane TraubApproved: Lee Pulver Pulver Laboratories Inc. 320 North Santa Cruz Avenue Los Gatos, California 95030-7243 Telephone: 408.399.7000 Facsimile: 408.399.7001 www.PulverLabs.com TABLE OF CONTENTS PageSectionDescription 10.0Drawing; Client; Product; Standards 61.0Engineering Considerations 1.1General Engineering Considerations 1.1.1October 1999 FCC Conformance Statement 71.2Specific Engineering Considerations 1.3Product Description and Intended Use 91.4Abbreviated List of Photographs 1.5Equipment Used During Measurements 172.0Mandatory Labeling, Manual Information, and Shipping Documents 2.1FCC Label 18Illustration 1.0: FCC Label 192.2Operators’ Manual Information 2.3FCC User Information 202.4Illustration 2.0: Industry Canada 21Clock Oscillators 22EUT Orientation 233.0Radiated Electromagnetic Interference - Test Configuration 254.0Radiated EMI – Results 355.0Conducted EMI -Test Configuration 6.0Conducted EMI - Results 42Last Page of Report TITLE: PLI Evaluation Report (RFI) FCC ID: O725346XPage 3 of 42 DRAWING: 117852 Issued: 17 Aug 2000 BY: Zane TraubApproved: Lee Pulver Pulver Laboratories Inc. 320 North Santa Cruz Avenue Los Gatos, California 95030-7243 Telephone: 408.399.7000 Facsimile: 408.399.7001 www.PulverLabs.com Pulver Laboratories Inc. (PLI) File Number:5346 Pulver Laboratories Inc. (PLI) Project Number: C2730 Product Names:EUT ) TouchChip ® Silicon Fingerprint Reader (EUT = Equipment Under Test) Model Numbers:TCRU1A Serial Numbers: 0013-000030 Applicant:STMicroelectronics 2001Center Street, Suite 500 Berkeley, California 94704-1204 Telephone: 510.647.1200 Facsimile:510.665.9730 Location Certified:STMicroelectronics 2001Center Street, Suite 500 Berkeley, California 94704-1204 Telephone: 510.647.1200 Facsimile:510.665.9730 Manufacturing Location:STMicroelectronics 2001Center Street, Suite 500 Berkeley, California 94704-1204 Telephone: 510.647.1200 Facsimile:510.665.9730 Pulver Laboratories Inc. (PLI) Control Number: 5346X Equipment Category Information Technology Equipment including Electrical Business Equipment TITLE: PLI Evaluation Report (RFI) FCC ID: O725346XPage 4 of 42 DRAWING: 117852 Issued: 17 Aug 2000 BY: Zane TraubApproved: Lee Pulver Pulver Laboratories Inc. 320 North Santa Cruz Avenue Los Gatos, California 95030-7243 Telephone: 408.399.7000 Facsimile: 408.399.7001 www.PulverLabs.com Evaluated to the Following Standards PLI Certification. Certified by Pulver Laboratories Inc. to comply with the following standards. FCC Certification. Federal Communications Commission (FCC, USA) Category Classification:Class B - Residential FCC ID number - O725346X • American National Standards Institute C63.4-1992 entitled Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. • Federal Communications Commission Rules and Regulations located in the Code of Federal Regulations, Title 47, Part 2 entitled Frequency Allocations and Radio Treaty Matters; General Rules and Regulations; and Part 15 entitled Radio Frequency Devices, October 1999 Edition. ICAN Verification. Industry Canada (ICAN) Category Classification:Class B - Residential • Canadian Standards Association (CSA) C108.8-M1983 entitled Electromagnetic Emissions for Data Processing Equipment and Electronic Office Machines. • Canadian Standards Association (CSA) CAN3-C108.3.1-M84 entitled Limits and Measurement Methods of Electromagnetic Noise from AC Power Systems. • Industry Canada (ICAN) Interference-Causing Equipment Standard ICES- 003, Issue 1, June 1991, entitled "Digital Apparatus". • Industry Canada (ICAN) Radio Interference Regulation amendment dated 15 September 1988 (Radio Act Registration SOR/88-475); 3862 01 Data Processing Equipment. CE Certification mark. International Community Category Classification:Class B - Residential • EN 55011: 15 Sept 1998. Specification for Limits and methods of measurement of radio disturbance characteristics of industrial, scientific, and medical (ISM) radio-frequency equipment. • EN55022 / CISPR 22 entitled Limits and methods of measurement of radio disturbance characteristics of information technology equipment, 1995 Edition. TITLE: PLI Evaluation Report (RFI) FCC ID: O725346XPage 5 of 42 DRAWING: 117852 Issued: 17 Aug 2000 BY: Zane TraubApproved: Lee Pulver Pulver Laboratories Inc. 320 North Santa Cruz Avenue Los Gatos, California 95030-7243 Telephone: 408.399.7000 Facsimile: 408.399.7001 www.PulverLabs.com • EN55022 / CISPR 22 entitled Limits and methods of measurement of radio disturbance characteristics of information technology equipment, 1998 …
