O7X-NERFPS2-01Wireless Controller

™ DuraGripDuraGripDuraGrip DuraGrip Thank you for purchasing the NERF DURAGRIP WIRELESS CONTROLLER by Pelican. Be sure to read this manual and the PS2 console manual and follow all instructions carefully before using this product. Merci d’avoir acheté le contrôleur sans fil DuraGrip nerf par pelican. Veuillez lire avec soin ce manuel et le manuel de la console ps2 et conformez-vous aux instructions avant d’utiliser ce produit. Care and Safety/EntrEtiEn Et sécurité : Do not use excessive force when handling your Nerf DuraGrip Wireless Controller,. n’appliquez aucune force excessive quand vous manipulez votre contrôleur sans fil DuraGrip nerf. Warranty Information Pelican warrants to the original consumer purchaser that the product will be free from defects in materials and / or workmanship for a period of 1 year from the date of purchase. If a defect covered by this warranty occurs during this period, Pelican at its option will repair or replace, at no charge, any part that Pelican determines to be defective. To obtain warranty service during the warranty period, send the defective product postage pre-paid, with a money order for $4.00 to cover the return postage and handling, along with proof of purchase and the date of purchase to: 1840 East 27th Street Vernon, CA 90058 This warranty shall not apply if the product has been damaged by abuse, misuses, negligence, accident, modification, tampering or by any other causes unrelated to defective materials and / or workmanship. Repair or replacement as provided under this warranty is Pelican’s exclusive prerogative. ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY LIMITED TO 5 YEARS FROM THE DATE OF PURCHASE AND ARE SUBJECT TO THE CONDITIONS SET FORTH IN THIS LIMITED WARRANTY. IN NO EVENT SHALL PELICAN BE RESPONSIBLE FOR INCIDENTAL DAMAGES RESULTING FROM THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTIES. This warranty gives you specific legal rights, and you may also have other legal rights, which vary from state to state. informations sur la Garantie pelican garantit au premier consommateur acheteur que ce produit sera exempt de défauts de matériaux et/ou de fabrication pour une période de 1 année à partir de la date d’achat. si un défaut couvert par cette garantie se produit pendant cette période, pelican, à sa seule discrétion, réparera ou remplacera, gratuitement, toute pièce que pelican jugera défectueuse. pour obtenir le service de la garantie pendant la période de couverture, vous devez envoyer le produit défectueux en port prépayé, avec un mandat de 4 usD pour couvrir le coût de l’envoi en retour et de la manutention, sans oublier de joindre la preuve d’achat et la date d’achat à : 1840 east 27th street Vernon, ca 90058 usa cette garantie ne s’appliquera pas si le produit a été endommagé par suite d’une utilisation abusive, incorrecte, négligente, d’un accident, d’une modification, d’une mauvaise manipulation ou toute cause autre que des matériaux défectueux et/ou un défaut de fabrication. la décision de réparation ou de remplacement couverts par cette garantie est de la seule prérogative de pelican. toutes Garanties iMplicites, Y coMpris les Garanties De coMMercialisation et D’aDÉQuation À un usaGe particulier sont liMitÉes À 5 ans À partir De la Date D’acHat et sont assuJetties auX conDitions fiXÉes Dans cette Garantie liMitÉe. en aucun cas pelican ne pourra Être tenue responsaBle De DoMMaGes accessoires pour le ManQueMent À une Garantie Quelle soit eXpresse ou iMplicite. cette garantie vous donne des droits légaux spécifiques. Vous pouvez avoir éventuellement d’autres droits qui varient d’État à État. CONSOLE PROTECTION GUARANTEE If Pelican’s Nerf DuraGrip Wireless Controller causes damage to your PlayStation®2 console through normal operation, Pelican will repair or replace your system at no charge. Visit Pelican’s Website for additional details and warranties. Garantie De protection De Votre console si le contrôleur sans fil DuraGrip nerf de pelican endommage votre console playstation®2 lors d’une utilisation normale, pelican réparera ou remplacera votre système gratuitement. Visitez le site Web de pelican pour tous détails complémentaires et garanties. PELICAN TEChNICAL SUPPORT/ assistance tecHniQue De pelican Telephone/téléphone :: 800.331.3844 Email/courriel : [email protected] ADDRESS /aDresse : pDp 1840 east 27tH street Vernon, ca 90058 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. cet appareil est conforme à l’article 15 du règlement de la fcc. son fonctionnement est soumis aux deux conditions suivantes : (1) ce dispositif ne doit pas causer d’interférence indésirable et (2) il ne doit accepter aucune interférence reçue, incluant une interférence qui pourrait causer un fonctionnement indésirable. © 2006 hasbro All Rights Reserved © 2006 Hasbro tous droits réservés Warning Please verify that all batteries are new, matching alkaline batteries, and are inserted correctly. Always dispose of old batteries in accordance with local and national disposal regulations. Do not heat, open, puncture, or dispose of batteries in fire. avertissement Vérifiez que les piles sont alcalines, neuves et du type correct ; et qu’elles ont été insérées correctement. Éliminez toujours les piles usagées conformément à la réglementation locale ou nationale de mise au rebut. les piles ne doivent pas être chauffées, ouvertes, perforées ou jetées dans le feu. To avoid injury and damage to your Nerf DuraGrip Wireless Controller, do not throw your controller with excessive force on the ground, at walls, or at someone’s eyes or face. pour éviter des blessures et d’endommager votre contrôleur sans fil DuraGrip nerf, ne le jetez pas au sol, contre les…

Text truncated - open the document above for the full version.

Response to ATCB Comments FCC ID: O7X-NERFFPS2-01 1 Washington Laboratories, Ltd. 7560 LINDBERGH DRIVE GAITHERSBURG, MD 20879 (301) 417 – 0220 FAX # (301) 417 - 9069 October 30, 2006 Mr. David Waitt American Telecommunications Certification Body Inc. 6731 Whittier Ave McLean, VA 22101 RE: Comments of October 23, 2006 APPLICATION: O7X-NERFFPS2-01 Pelican Accessories Dear Mr. Waitt: Below are the comments that you have provided regarding the application for certification referenced above. Our responses to those comments are in bold italic. Many responses refer you to additional exhibit(s) which has been uploaded to the application folder at the ATCB website. Thank you for your attention. Please feel free to contact us for any additional information that you may require. Regards, Gregory M. Snyder Chief EMC Engineer, Wireless/Telco Services Manager Brian J. Dettling Documentation Specialist WLL Project: 9409 1) Recent FCC policy does not allow the FCC ID of a Part 15 device to be placed under the battery cover in the battery compartment of the device. Please relocate the FCC ID to the outside of the device keeping in mind that FCC also does not allow the FCC ID to be placed on the battery cover. R. The label issue was discussed at the recent TCB training (October 2006). The policy you reference was aimed at cell phones where the batteries are pre-installed, usually in the store, and thus the consumer does not readily see and note the FCC ID. With the Pelican controller the batteries are always installed by the end user, thus the FCC ID is visible to the consumer. Additionally, the entire unit is contoured NERF material making it difficult to locate the ID in the body of the unit. The only other labeling on the unit has been on the battery cover. The manufacturer has committed to molding their FCC ID in the hard plastic battery compartment as has been accepted in the past. Response to ATCB Comments FCC ID: O7X-NERFFPS2-01 2 2) Please a FCC non modification statement to the user manual per 15.21. R. A warning statement is included in the User Manual. A snapshot of that section is provided here: 3) The test report (page 7 of 17) indicates that this unit uses pulsed transmissions. Please elaborate. Is the transmission really pulsed? If so, there does not appear to be any duty cycle correction applied to the peak emission levels. R. In normal operational mode the transmit is pulsed, however, the test article was set to a continuous transmission for the testing.

Request for Confidentiality September 11, 2006 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: O7X-NERFPS2-01 Controller Please be advised that under the provision of 47 CFR 0.459 the following exhibits are held confidential on behalf of Pelican Accessories: • Schematic • Operational Description • Block Diagram The application contains technical information that Pelican Accessories deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Shilo Prychak Director of Product Pelican Accessories

September 11, 2006 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Pelican Accessories authorizes Washington Laboratories, Ltd. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signed, Shilo Prychak Project Manager

External Photos ©2006 Washington Laboratories, Ltd External Photos ©2006 Washington Laboratories, Ltd External Photos ©2006 Washington Laboratories, Ltd External Photos ©2006 Washington Laboratories, Ltd

FCC ID: O7X-NERFPS2-01 Battery Compartment

Internal Photos ©2006 Washington Laboratories, Ltd Internal Photos ©2006 Washington Laboratories, Ltd Internal Photos ©2006 Washington Laboratories, Ltd Internal Photos ©2006 Washington Laboratories, Ltd Internal Photos ©2006 Washington Laboratories, Ltd Internal Photos ©2006 Washington Laboratories, Ltd Internal Photos ©2006 Washington Laboratories, Ltd

FCC Certification Test Report For the Pelican Accessories, Inc. PL-6881 Nerf Controller O7X-NERFPS2-01 WLL JOB# 9409 October 16, 2006 Prepared for: Pelican Accessories, Inc. 1840 East 27th Street Vernon, CA 90058 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 Pelican Accessories, Inc. PL-6881 Nerf Controller FCC Certification Test Report October 2006 FCC Certification Test Report for the Pelican Accessories, Inc. PL-6881 Nerf Controller O7X-NERFPS2-01 October 16, 2006 WLL JOB# 9409 Prepared by: Brian J. Dettling Documentation Specialist Reviewed by: Gregory M. Snyder Chief EMC Engineer Pelican Accessories, Inc. PL-6881 Nerf Controller FCC Certification Test Report October 2006 WLL Report #9409-01 - ii - © 2006 Washington Laboratories, Ltd. Abstract This report has been prepared on behalf of Pelican Accessories, Inc. to support the attached Application for Equipment Authorization. The test report and application are submitted for an Intentional Radiator under Part 15.249 of the FCC Rules and Regulations. This Certification Test Report documents the test configuration and test results for a Pelican Accessories, Inc. PL-6881 Nerf Controller. Testing was performed on an Open Area Test Site (OATS) of Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Site description and site attenuation data have been placed on file with the FCC's Sampling and Measurements Branch at the FCC laboratory in Columbia, MD. Washington Laboratories, Ltd. has been accepted by the FCC and approved by NIST NVLAP (NVLAP Lab Code: 200066-0) as an independent FCC test laboratory. The Pelican Accessories, Inc. PL-6881 Nerf Controller complies with the limits for an Intentional Radiator device under FCC Part 15.249. Pelican Accessories, Inc. PL-6881 Nerf Controller FCC Certification Test Report October 2006 WLL Report #9409-01 - iii - © 2006 Washington Laboratories, Ltd. Table of Contents Abstract ........................................................................................................................................... ii 1 Introduction..........................................................................................................................1 1.1 Compliance Statement .....................................................................................................1 1.2 Test Scope ........................................................................................................................1 1.3 Contract Information........................................................................................................1 1.4 Test Dates ........................................................................................................................1 1.5 Test and Support Personnel .............................................................................................1 1.6 Abbreviations ...................................................................................................................2 2 Equipment Under Test .........................................................................................................3 2.1 EUT Identification & Description ...................................................................................3 2.2 Test Configuration ...........................................................................................................3 2.3 Testing Algorithm............................................................................................................3 2.4 Test Location ...................................................................................................................3 2.5 Measurements ..................................................................................................................4 2.5.1 References....................................................................................................................4 2.6 Measurement Uncertainty................................................................................................4 3 Test Equipment ....................................................................................................................5 4 Test Results ..........................................................................................................................6 4.1 Occupied Bandwidth: (FCC Part §2.1049) ......................................................................6 4.2 Radiated Emissions: (FCC Part §2.1053) ......................................................................11 4.2.1 Test Procedure.........................................................................................................11 List of Tables Table 1. Device Summary............................................................................................................... 3 Table 2: Test Equipment List.......................................................................................................... 5 Table 3. Occupied Bandwidth Results.......................................................................................... 10 Table 4. Radiated Emissions Limits .............................................................................................11 Table 5: Radiated Emission Test Data, Fundamental ................................................................... 12 Table 6: Radiated Emission Test Data, Spurious Emissions ........................................................ 13 List of Figures Figure 4-1. Occupied Bandwidth, Low Channel, 2407MHz .......................................................... 7 Figure 4-2. Occupied Bandwidth, Mid Channel, 2439MHz........................................................... 8 Figure 4-3. Occupied Bandwidth, High Channel, 2470MHz ......................................................... 9 Pelican Accessories, Inc. PL-6881 Nerf Controller FCC Certification Test Report October 2006 WLL Report #9409-01 - Page 1 of 13 - © 2006 Was…

Text truncated - open the document above for the full version.

Test Setup Photos ©2006 Washington Laboratories, Ltd Test Setup Photos ©2006 Washington Laboratories, Ltd Test Setup Photos ©2006 Washington Laboratories, Ltd
