1 User Manual xTablet T1175 1501 Boyson Square Drive – Suite 101 Hiawatha, Iowa 52233 | PH: 319.363.4121 | RuggedTabletPC.com xTablet T1110 2 User Manual xTablet T1175 Contents Copyright and Trademark Notice 3 FCC Information 4 IC Statements 5 Safety Instructions 6 Introduction 8 Product Overview 9 Specifications 13 Power Supply 14 Battery 15 xTablet T1175 3 Copyright and Trademarks Notice All marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied. We reserve the right to make changes to this document without prior notice. Revision History ►Version: 1.0 ►Date: 10, 2023 xTablet T1175 4 FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa- tion. This equipment generates, uses and radiates radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ►Reorient or relocate the receiving antenna. ►Increase the separation between the equipment and receiver. ►Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ►Consult the dealer or an experienced radio TV technician for help. NOTE ►The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. ►Shield interface cables and AC power cord, if any, must be used in order to comply with the emission limits. FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: ►This device may not cause harmful interference. ►This device must accept any interference received, including interference that may cause undesired operation. FCC/IC RF Radiation Exposure and SAR Statements This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device was tested for typical lap held operations with the device contacted directly to the human body to the back side of the notebook computer. To maintain compliance with FCC RF exposure compliance requirements, avoid direct contact to the transmitting antenna during transmitting SAR information 1.318W/Kg@1g (body). Prohibit operating transmitters in the 5.925-7.125 GHz frequency band to control or communicate with unmanned aerial vehicle systems. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux CNR exempts de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1) Cet dispositif ne peut causer des interférences; et (2) Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l’appareil. 5 CE Conformity This device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. Battery Regulations European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compli- ance with the local regulations. BSMI: For better environmental protection, waste batteries should be collected separately for recycling or special disposal. California, USA: The button cell battery may contain perchlorate material and requires special handling when recycled or disposed of in California. For further information please visit: http://www.dtsc.ca.gov/hazardouswaste/perchlorate/ Safety Guideline for Using Lithium Battery Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer’s instructions. WEEE Statement European Union: Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and electronic equipment” cannot be discarded as municipal waste anymore and manufacturers of cov- ered electronic equipment will be obligated to take back such products at the end of their useful life. This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The device is designed to meet the requirements for exposure to radio waves established by the Industry Canada. These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for using at the body is 1.318 W/kg. Cet équipement est conforme aux limites d’exposition aux rayonnements d’industrie Canada établies pour un environnement non contrôlé. L’utilisateur final doit suivre les instructions d’utilisation spécifiques pour satisfaire à la conformité à l’exposi- tion aux RF. Cet émetteur ne doit pas être co-implanté ou exploité conjointement avec toute autre antenne ou émetteur. L’appa…

Text truncated - open the document above for the full version.

The complete user manual is an electronic file, users can download it via the QR code or website. Click on “Downloads” then “Documentation” then the xTablet T1175 User Guide link. www.ruggedtabletpc.com/xTablet-T1175 User Manual xTablet T1175 1501 Boyson Square Drive – Suite 101 Hiawatha, Iowa 52233 | PH: 319.363.4121 | RuggedTabletPC.com Unpacking ►xTablet T1175 ►Type-C/Power delivery adapter and AC power cord ►Hand strap ►Brief case handle ►Stylus (optional) ►Stylus holder (optional) ►Quick Guide Product Overview 7 123 54 10 9 11 12 13 8 6 15141617 1. Volume 2. Power 3. Barcode scanner 4. Status LEDs 5. Front camera 6. USB 2.0 type-C PD-IN port 7. Dock connector 8. Speaker 9. USB 3.1 Gen 1 port 1 10. USB 3.1 Gen 1 port 2 11. Headphone 12. RJ-45 connector 13. Kensington lock 14. F1 Function - scanner 15. Battery latch 16. Rear camera 17. F2 Function - programmable Power Supply AC/DC Adapter Ensure the xTablet T1175 is connected to an AC power source via the AC adapter before turning it on for the first time. If the xTablet automatically shuts down due to low battery power, it is likely to cause system failure. Below are some Dos and Don’ts for an AC/DC adapter. Plug the AC/DC Adapter • Plug the DC end into the USB-C Power Delivery (PD) port of the xTablet T1175. • Plug the AC/DC adapter into the power outlet. • When removing, follow steps in reverse order.
