Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com February 3, 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Palm, Inc. FCC ID: O8F93001 Palm Inc. has confirmed to Celltech Labs Inc. that the CDMA transmitter, battery power supply, and transmitter supply voltage used in this device are identical to the CDMA transmitter, battery power supply, and transmitter supply voltage used in the recently certified Palm device (FCC ID: O8FJIMI). Based on above statement, the frequency stability measurement data from the previously certified device (FCC ID: O8FJIMI) has been uploaded with this application as evidence of compliance to the frequency stability requirements under FCC §2.1055 and §24.235. If you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jonathan Hughes General Manager Celltech Labs Inc. cc: Palm, Inc.

Federal Communications Commission Date : May 09, 2006 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: FCC ID: O8F93001 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Tune-up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request for 45 days on the following attachments External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards David Woo David Woo / Senior Compliance Engineer Palm , Inc.

Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 1 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 RF EXPOSURE EVALUATION SPECIFIC ABSORPTION RATE SAR TEST REPORT FOR PALM, INC. DUAL-BAND PCS/CELLULAR CDMA-2000 PHONE WITH BLUETOOTH MODEL(S): TREO XXX FCC ID: O8F93001 IC: 3905A-93001 Test Report Serial Number 121405O8F-T705-S24C Test Report Issue No. S705C-020106-R0 Test Lab Celltech Compliance Testing & Engineering Lab (Celltech Labs Inc.) 1955 Moss Court Kelowna, BC Canada V1Y 9L3 Test Report Prepared by: Cheri Haight Test Report Writer Celltech Labs Inc. Test Report Approved By: Jonathan Hughes General Manager Celltech Labs Inc. Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 2 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information Palm, Inc. 950 West Maude Avenue Sunnyvale, CA 94085-2801 United States FCC IDENTIFER: O8F93001 IC IDENTIFIER: 3905A-93001 Model(s): Treo XXX SAR Test Requirement(s): FCC 47 CFR §2.1093; Health Canada Safety Code 6 SAR Test Procedure(s): FCC OET Bulletin 65, Supplement C (01-01) Industry Canada RSS-102 Issue 2 IEEE Standard 1528-2003; IEC 62209-1:2005 FCC Classification: PCS Licensed Transmitter held to ear (PCE) Device Description: Dual-Band PCS/Cellular CDMA-2000 Portable Phone with Bluetooth Transmit Frequency Range(s): 1851.25 - 1908.75 MHz (PCS CDMA) 824.70 - 848.31 MHz (Cellular CDMA) 2402 - 2480 MHz (Bluetooth) Max. RF Output Power Tested: 24.7 dBm (0.295 Watts) Conducted (PCS CDMA) 24.4 dBm (0.275 Watts) Conducted (Cellular CDMA) 0 dBm (1 mW) Peak Conducted (Bluetooth) Battery Type(s) Tested: Lithium-ion 3.7 VDC (P/N: 157-10014-00) Antenna Type(s) Tested: External Fixed Stubby (CDMA) Internal (Bluetooth) Body-Worn Accessories Tested: Leather Side Case with Belt-Clip (SKU#3256WW) Leather Pouch and Swivel Belt-Clip (SKU#3179WW) Addit. Body-worn Config. Tested: 1.5 cm Air-Gap Spacing (Front and Back Sides of DUT) Audio Accessories Tested: Generic Ear-Microphone Max. SAR Level(s) Measured: Head: 1.13 W/kg (PCS CDMA); 1.48 W/kg (Cellular CDMA) Body: 0.678 W/kg (PCS CDMA); 0.896 W/kg (Cellular CDMA) Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 2, IEEE Standard 1528-2003, and IEC International Standard 62209-1:2005 for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Tested By: Sean Johnston Compliance Technologist Celltech Labs Inc. Reviewed By: Spencer Watson Senior Compliance Technologist Celltech Labs Inc. Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 3 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 TABLE of CONTENTS 1.0 INTRODUCTION___________________________________________________________________ 4 2.0 DESCRIPTION of Device Under Test (DUT) _____________________________________________ 4 3.0 SAR MEASUREMENT SYSTEM _______________________________________________________ 5 4.0 MEASUREMENT SUMMARY _________________________________________________________ 6 MEASUREMENT SUMMARY (Cont.) ______________________________________________________ 7 MEASUREMENT SUMMARY (Cont.) ______________________________________________________ 8 MEASUREMENT SUMMARY (Cont.) ______________________________________________________ 9 MEASUREMENT SUMMARY (Cont.) _____________________________________________________ 10 MEASUREMENT SUMMARY (Cont.) _____________________________________________________ 11 …

Text truncated - open the document above for the full version.

Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 107 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 APPENDIX F - PROBE CALIBRATION

Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 106 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 APPENDIX E - SYSTEM VALIDATION 835 MHz System Validation Dipole (Brain) Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 x Fax. 250-448-7046 x e-mail: [email protected] www.celltechlabs.com 2005 Celltech Labs Inc. 1 of 12 835 MHz SYSTEM VALIDATION DIPOLE Type: Serial Number: Place of Calibration: Date of Calibration: Celltech Labs Inc. hereby certifies that this device has been calibrated on the date indicated above. Calibrated by: Approved by: 835 MHz Validation Dipole 411 Celltech Labs Inc. March 30, 2005 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 2 of 12 1. Validation Dipole Construction & Electrical Characteristics The validation dipole was constructed in accordance with the IEEE Standard “Annex G (informative) Reference dipoles for use in system validation”. The electrical properties were measured using an HP 8753ET Network Analyzer. The network analyzer was calibrated to the validation dipole N-type connector feed point using an HP85032E Type N calibration kit. The dipole was placed parallel to a planar phantom at a separation distance of 15.0mm from the simulating fluid using a loss-less dielectric spacer. The measured input impedance is: Feed point impedance at 835MHz Re{Z} = 47.627: Im{Z} = -0.67188: Return Loss at 835MHz -31.954dB 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 3 of 12 2. Validation Dipole VSWR Data 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 4 of 12 3. Validation Dipole Dimensions Frequency (MHz) L (mm) h (mm) d (mm) 300 420.0 250.0 6.2 450 288.0 167.0 6.2 835 161.0 89.8 3.6 900 149.0 83.3 3.6 1450 89.1 51.7 3.6 1800 72.0 41.7 3.6 1900 68.0 39.5 3.6 2000 64.5 37.5 3.6 2450 51.8 30.6 3.6 3000 41.5 25.0 3.6 4. Validation Phantom The validation phantom is the SAM (Specific Anthropomorphic Mannequin) phantom manufactured by Schmid & Partner Engineering AG. The SAM phantom is a Fiberglass shell integrated in a wooden table. The shape of the shell corresponds to the phantom defined by SCC34-SC2. It enables the dosimetric evaluation of left and right hand phone usage as well as body mounted usage at the flat phantom region. A cover prevents evaporation of the liquid. Reference markings on the phantom allow the complete setup of all predefined phantom positions and measurement grids by manually teaching three points in the robot. Shell Thickness: 2.0 ± 0.1 mm Filling Volume: Approx. 25 liters Dimensions: 50 cm (W) x 100 cm (L) 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 5 of 12 5. 835 MHz System Validation Setup 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 6 of 12 6. 835 MHz Validation Dipole Setup 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 7 of 12 7. Measurement Conditions The SAM phantom was filled with 835 MHz simulated brain tissue mixture having the following parameters: Relative Permittivity: 39.5 Conductivity: 0.90 mho/m Fluid Temperature: 20.4 qC Fluid Depth: t 15.0 cm Environmental Conditions: Ambient Temperature: 20.5 qC Barometric Pressure: 102.2 kPa Humidity: 32 % Measurements were made at the planar section of the SAM phantom using a dosimetric E-field probe ET3DV5 (S/N: 1590, conversion factor 6.71). The 835 MHz simulated brain tissue mixture consisted of the following ingredients: IngredientPercentage by weight Water 40.71% Sugar 56.63% Salt 1.48% HEC 0.99% Dowicil 75 0.19% Target Dielectric Parameters at 22 qC H r = 41.5 V = 0.90 S/m 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 8 of 12 8. SAR Measurement The SAR measurement was performed with the E-field probe in mechanical detection mode only. The setup and determination of the forward power into the dipole was performed using the following procedures. PM1 Att1 x Dipole 3D Probe positioner Flat Phantom Field probe Signal Generator AmpLow Pass 3dB Att3 Dir.Coupler Att2 PM2 Cable PM3 d First the power meter PM1 (including attenuator Att1) is connected to the cable to measure the forward power at the location of the dipole connector (X). The signal generator is adjusted for the desired forward power at the dipole connector (taking into account the attenuation of Att1) as read by power meter PM2. After connecting the cable to the dipole, the signal generator is readjusted for the same reading at power meter PM2. If the signal generator does not allow adjustment in 0.01dB steps, the remaining difference at PM2 must be taken into consideration. PM3 records the reflected power from the dipole to ensure that the value is not changed from the previous value. The reflected power should be 20dB below the forward power. 835 MHz System Validation Dipole (Brain) 2005 Celltech Labs Inc. 9 of 12 9. Validation Dipole SAR Test Results Ten SAR measurements were performed in order to achieve repeatability and to establish an average target value. Validation Measurement SAR @ 0.25W Input averaged over 1g SAR @ 1W Input averaged over 1g SAR @ 0.25W Input averaged over 10g SAR @ 1W Input averaged over 10g Peak SAR @ 0.25W Input Test 1 2.45 9.80 1.60 6.40 3.65 Test 2 2.44 9.76 1.59 6.36 3.66 Test 3 2.45 9.80 1.60 6.40 3.67 Test 4 2.44 9.76 1.59 6.36 3.64 Test 5 2.44 9.76 1.59 6.36 3.62 Test 6 2.43 9.72 1.59 6.36 3.61 Test 7 2.45 9.80 1.60 6.40 3.65 Test 8 2.43 9.72 1.59 6.36 3.62 Test 9 2.43 9.72 1.59 6.36 3.61 Test10 2.45 9.80 1.60 6.40 3.65 Average SAR 2.44 9.76 1.59 6.3…

Text truncated - open the document above for the full version.

Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 23 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 APPENDIX A - SAR MEASUREMENT DATA Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 24 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 Date Tested: 12/15/2005 Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Channel 384 DUT: Palm Inc. Model: Treo XXX; Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth; Serial: VC1CUBX50184 Ambient Temp: 23.5 qC; Fluid Temp: 22.5 qC; Barometric Pressure: 103.3 kPa; Humidity: 30% Communication System: Cellular CDMA Li-ion Battery Pack (P/N: 157-10014-00) RF Output Power: 24.4 dBm (Conducted) Frequency: 836.52 MHz; Channel 384; Duty Cycle: 1:1 Medium: HSL835 (ı = 0.88 mho/m; İ r = 39.9; ȡ = 1000 kg/m 3 ) - Probe: ET3DV6 - SN1387; ConvF(6.47, 6.47, 6.47); Calibrated: 18/03/2005 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE4 Sn353; Calibrated: 15/06/2005 - Phantom: SAM 4.0; Type: Fiberglas; Serial: 1033 - Measurement SW: DASY4, V4.6 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 159 Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Mid Channel/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Mid Channel/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 33.0 V/m; Power Drift = -0.0894 dB Peak SAR (extrapolated) = 1.80 W/kg SAR(1 g) = 1.36 mW/g; SAR(10 g) = 0.988 mW/g Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Mid Channel/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 33.0 V/m; Power Drift = -0.0894 dB Peak SAR (extrapolated) = 1.73 W/kg SAR(1 g) = 1.17 mW/g; SAR(10 g) = 0.772 mW/g  Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 25 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 Date Tested: 12/15/2005 Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Channel 1013 DUT: Palm Inc. Model: Treo XXX; Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth; Serial: VC1CUBX50184 Ambient Temp: 23.5 qC; Fluid Temp: 22.5 qC; Barometric Pressure: 103.3 kPa; Humidity: 30% Communication System: Cellular CDMA Li-ion Battery Pack (P/N: 157-10014-00) RF Output Power: 23.8 dBm (Conducted) Frequency: 824.70 MHz; Channel 1013; Duty Cycle: 1:1 Medium: HSL835 (ı = 0.88 mho/m; İ r = 39.9; ȡ = 1000 kg/m 3 ) - Probe: ET3DV6 - SN1387; ConvF(6.47, 6.47, 6.47); Calibrated: 18/03/2005 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE4 Sn353; Calibrated: 15/06/2005 - Phantom: SAM 4.0; Type: Fiberglas; Serial: 1033 - Measurement SW: DASY4, V4.6 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 159 Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Low Channel/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Low Channel/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 31.6 V/m; Power Drift = 0.178 dB Peak SAR (extrapolated) = 1.57 W/kg SAR(1 g) = 1.16 mW/g; SAR(10 g) = 0.845 mW/g Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Low Channel/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 31.6 V/m; Power Drift = 0.178 dB Peak SAR (extrapolated) = 1.67 W/kg SAR(1 g) = 1.19 mW/g; SAR(10 g) = 0.829 mW/g  Applicant: Palm, Inc. FCC ID: O8F93001 IC ID: 3905A-93001 Model: Treo XXX DUT Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth Freq. Range(s): 1851.25-1908.75 MHz 824.70-848.31 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 26 of 108 Test Report S/N: 121405O8F-T705-S24C Report Issue Date: February 01, 2006 Test Date(s): Dec.15-16, 19-20, 2005 & Jan. 23-24, 2006 Report Issue No.: S705C-020106-R0 Test Type(s): RF Exposure SAR Evaluation FCC 47 CFR 2.1093 IC RSS-102 Issue 2 Date Tested: 12/15/2005 Head SAR - Cellular CDMA - Right Ear - Cheek/Touch Position - Channel 777 DUT: Palm Inc. Model: Treo XXX; Type: Portable Dual-Band CDMA-2000 Phone with Bluetooth; Serial: VC1CUBX50184 Ambient Temp: 23.5 qC; Fluid Temp: 22.5 qC; Barometric Pressure: 103.3 kPa; Humidity: 30% Communication System: Cellular CDMA Li-ion Battery Pack (P/N: 157-10014-00) RF Output Power: 24.2 dBm (Conducted) Frequency: 848.31 MHz; Channel 777; Duty Cycle: 1:1 Medium: HSL835 (ı = 0.88 mho/m; İ r = 39.9; ȡ = 1000 kg/m 3 ) - Probe: ET3DV6 - SN1387; ConvF(6.47, 6.47, 6.…

Text truncated - open the document above for the full version.

SAR & HAC Instruments for Wireless • Consulting • Research • Standards • Compliance • Training Since 1981 Assessment of Compliance for Hearing Aid Compatibility Mobile phone, CDMA TREO 700p Palm Inc. 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] May 2005 APREL Project No.: PALB Treo 700P-CDMA- 5158 Since 1981 www.aprel.com [email protected] 51 Spectrum Way Ottawa ON Canada K2R 1E6 © 2005 APREL Laboratories P PALB-Treo 700p-CDMA-5158 Page 2 Phone (613) 820-2730 Fax (613) 820-4161 SAR & HAC Instruments for Wireless • Consulting • Research • Standards • Compliance • Training E E n n g g i i n n e e e e r r i i n n g g R R e e p p o o r r t t Subject: Assessment of Compliance with respect to ANSI PC63.19-2005 D3.6 Hearing Aid Compatibility, RF Emissions FCC ID: O8F93001 Product: Mobile Phone, CDMA Model: TREO 700p Client: Palm Inc 950 West Maude Ave Sunnyvale, CA 94085 USA Project #:PALB-Treo 700p-CDMA-5158 Prepared by: APREL Laboratories Regulatory Compliance Divisions 51 Spectrum Way Nepean, Ontario K2R 1E6, Canada Since 1981 www.aprel.com [email protected] 51 Spectrum Way Ottawa ON Canada K2R 1E6 © 2005 APREL Laboratories P PALB-Treo 700p-CDMA-5158 Page 3 Phone (613) 820-2730 Fax (613) 820-4161 SAR & HAC Instruments for Wireless • Consulting • Research • Standards • Compliance • Training HAC Report Contents Engineering Summary 4 Introduction 5 Equipment Tested 7 Product information Batteries Antenna description Picture of the device Test Equipment 8 Performance Criteria ANSI C63.19 11 Methodologies System Validation 12 Dipole validation (Part of the system validation) 12 Results for Dipole validation 15 RF Field Probe Modulation Factor 17 Results for Modulation Factors 19 RF Emissions Test Procedure 20 Flow Diagram of Test Instruction 21 Applicable Standards 23 Data Summary 24 Data Plots 25 Appendices Calibration Reports of Probes 49 Measurement Uncertainty Tables 80 Equipment List 83 Zero Span & Wideband Plots 85 Since 1981 www.aprel.com [email protected] 51 Spectrum Way Ottawa ON Canada K2R 1E6 © 2005 APREL Laboratories P PALB-Treo 700p-CDMA-5158 Page 4 Phone (613) 820-2730 Fax (613) 820-4161 SAR & HAC Instruments for Wireless • Consulting • Research • Standards • Compliance • Training ENGINEERING SUMMARY This report contains the results of the engineering evaluation performed on the PALM CDMA mobile phone model TREO 700p. The analysis was carried out in accordance with the requirements of ANSI/IEEE C63.19-2005, Rev 3.6, “American National Standard for Methods of Measurement of Compatibility between Wireless Communications Devices and Hearing Aids” PALM provided APREL laboratories with…
