OCZRC-03RFID Security access controller (LF)

How to Install an ISONAS PowerNet™ Reader-Controller Copyright © 2006-2012, ISONAS Security Systems All rights reserved ISONAS Inc. FCC ID: 0CZRC-03 IC: 8431A-RC03 This device complies with Part 15 of the FCC Rules and RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.  Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.  This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.  For RF Safety and per FCC and Industry Canada regulations, the product should never be installed within 8-inches (20cm) of typical people locations. Table of Contents 1: BEFORE YOU BEGIN ............................................................................................................................ 5 1.1: GENERAL REQUIREMENTS: ...................................................................................................... 5 1.2: POWERNET READER-CONTROLLER SPECIFICATIONS: .................................................. 6 1.3: INSTALLATION LOCATION GUIDELINES .............................................................................. 7 2: WIRING AT THE DOOR AND READER-CONTROLLER ............................................................ 11 2.1: POWERING THE READER-CONTROLLERS ......................................................................... 11 2.1.1: POWER OVER ETHERNET (PoE) OPTION .......................................................................... 11 2.1.2: ADDITIONAL POWER OPTIONS ........................................................................................... 13 2.2: WIRING THE DOORS .................................................................................................................. 16 2.2.1: READER-CONTROLLER CONTROL-LEADS DESCRIPTION ......................................... 17 2.2.2: LOCK WIRING -- BASIC .......................................................................................................... 19 2.2.3: WIRING THE REX BUTTON ................................................................................................... 22 2.2.4: WIRING THE AUX INPUT ....................................................................................................... 22 2.2.5: WIRING THE DOOR SENSE .................................................................................................... 23 2.2.6: LOCK WIRING -- LOW-VOLTAGE 12VDC POWER OPTION ......................................... 24 2.2.7: LOCK WIRING -- EXTERIOR DOOR KIT ............................................................................ 25 2.2.8: LOCK WIRING -- 2 READERS TO 1 LOCK .......................................................................... 27 2.2.9: USING THE TTL LEADS .......................................................................................................... 28 2.2.10: USING THE POWERNET’S RS-232 INPUT ......................................................................... 28 2.2.11: WIRING THE WIEGAND INTERFACE MODULE ............................................................ 29 2.2.12: WIRING THE DUAL-SRM ...................................................................................................... 31 2.2.13: WIRING THE QUAD-SRM...................................................................................................... 33 2.2.11: MANAGING INDUCTIVE LOAD CHALLANGES .............................................................. 35 2.2.12: MANAGING IN-RUSH CURRENT LOADS .......................................................................... 36 2.3: CONFIGUATION EXAMPLES ........................................................................................................ 37 2.3.1: PoE --- ELECTRIC STRIKE ...................................................................................................... 37 2.3.2: PoE --- EXTERNAL PWR FOR ELECTRIC STRIKE ........................................................... 38 2.3.3: 12VDC – ELECTRIC STRIKE .................................................................................................. 39 2.3.4: PoE --- MAGNETIC LOCK ........................................................................................................ 40 2.3.5: PoE --- MAGNETIC LOCK & PIR ........................................................................................... 41 2.3.6: PoE --- MAGNETIC LOCK, EDK & PIR ................................................................................. 42 2.3.7: DUAL POWER SOURCES ......................................................................................................... 43 3: CONFIGURING THE READER-CONTROLLER’S COMMUNICATIONS ................................ 44 3.1: ETHERNET-BASED TCP/IP READER-CONTROLLERS .........................…

Text truncated - open the document above for the full version.

ISONAS HQ 4720 Walnut St, Suite 200, Boulder, CO 80301 800-581-0083 www.isonas.com • Provide a statement for how your device Complies with FCC15.203 Antenna requirement: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. This requirement does not apply to carrier current devices or to devices operated under the provisions of §§15.211, 15.213, 15.217, 15.219, or 15.221. Further, this requirement does not apply to intentional radiators that must be professionally installed, such as perimeter protection systems and some field disturbance sensors, or to other intentional radiators which, in accordance with §15.31(d), must be measured at the installation site. However, the installer shall be responsible for ensuring that the proper antenna is employed so that the limits in this part are not exceeded. Model: RC-03: The antenna is an internal antenna directly attached to the pc board and is not accessible to the user. Furthermore, the product requires professional installation.

RF Exposure Project #: G100744278 Test Area: Intertek Louisville Test Method: FCC CFR47 Part 1.1310 Test Date: 06/11/2012 06/12/2012 EUT Model #: RC-03-HLF-K EUT Serial #: FCC1 Manufacturer: Isonas Security Systems EUT Description: The product tested is a Low-Frequency, network-enabled, RFID Security Access Reader with keypad. The product transmits at 122.8kHz only. Notes: Worst-case measurement: 90.37 VDC Configuration – Axis 1 The following limit is from table 1 (B) Limits for General Population/Uncontrolled Exposure in FCC part 1.1310: 1 mW/cm² The following calculation was used to determine compliance to the above limit. The calculation is from FCC OET bulletin 65. S=PG/4πR² Where: S=power density (in appropriate units, e.g. mW/cm²) P=power input to the antenna. G=power gain of the antenna in the direction of interest relative to an isotropic radiator. R=distance to the center of radiation of the antenna (appropriate unit, e.g., cm) In this case 20cm will be used. Maximum radiated field strength = 90.37dBuV/m at 3-meters = 0.327mW (see test report 100744278DEN-001) Maximum gain declared by the manufacture – unknown, < 6dBi Power Density Power (mW) Gain (dbi) Gain numeric Distance (cm) Power Density (mW/cm²) 0.327 0 1.0 20 0.000065 0.327 6 4.0 20 0.000260 Delta Limit: 0.00260mW/cm² - 1.0mW/cm² = -0.99740mW/cm 2 Results: The unit complies with the requirements for Maximum Permissible Exposure (MPE) under FCC part 1.1310.

ISONAS HQ 4720 Walnut St., Suite 200, Boulder, CO 80301 800-581-0083 www.isonas.com Attention: Application Examiner Re: Request for confidentiality Applicant: ISONAS Security Systems FCC ID: OCZRC-03 To whom it may concern, Request is hereby submitted by ISONAS Security Systems to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Tune up procedure • Parts list • Internal photos – photos will reveal components and circuitry that make our product unique among our competitors. Our products are potted to protect this proprietary information. Rationale for Request for Confidentiality : ISONAS Security Systems has invested considerable time and materials in research and development to produce the referenced product(s). Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products but would also disclose succesful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact me at your convenience. Sincerely, Matt Morrison Chief Engineer ISONAS Security Systems

Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: Model:RC-03-PRX-K, RC-03-PRX Description: RFID Security access controller/reader. Dated this 17 th day of September, 2012. Signature: Name: Matt Morrison Title: Chief Engineer Company: ISONAS Security Systems Telephone: 303-567-6516 Ext. 122

RC-03 External Product Photos External View Front of Product External View Front of Product Back of Product

Note: Model Number can be the following: RC-03-PRX (product without keypad) RC-03-PRX-K (product with keypad) Z-Ultimate 3000T White A pearl white topcoated polyester thermal transfer facestock with permanent acrylic adhesive. Ideal for thermal transfer applications that require outstanding print quality and unparalleled smear and scratch resistance. UL recognized for indoor and outdoor use when used with compatible Zebra Resin Ribbons. Recommended for use in a wide variety of applications, including shelf or scan-pallet labels, water-immersed labels, or labels in contact with moving parts. Features - Chemical Resistant - High Durability - High Heat - Water Resistant Media Characteristics Label: Thermal Transfer Facestock Material: Polyester Resistance: Abrasion, Ammonia, Bleach, Blood, Body Fluid, Grease, IPA, Oil, Water, Window Cleaner, Alcohol, Salt Water Physical Characteristics Finish: Gloss, Coated Adhesive: Permanent Acrylic Liner Description: 50# SBK Adhesive Caliper: 1 mils Facestock Caliper: 2 mils Liner Caliper: 3 mils Total Caliper: 6 mils Surface To Label Use: Glass, Metals, Pebbled Surfaces, Plastics Operating Characteristics Acceptance: CSA Acceptance, UL Recognized Min Application Temperature: 50° F (10° C) Min Service Temperature: -40° F (-40° C) Max Service Temperature: 302° F (150° C)

ISONAS HQ 4720 Walnut St., Suite 200, Boulder, CO 80301 800-581-0083 www.isonas.com RC-03 product Label Location 12/4/2012 MJM The ability to add more information on the reader is simply not possible due to the fact that the label as it exists does not have room for more text as these can be installed in dark areas requiring larger print for the installer. Further, an additional label is not an option due to the fact that there is no room for another label. On one end we have only mounting screw access and on the other we have mounting screw access plus the tamper detection window which cannot be covered up. On the left side the distance from the existing label to the left edge of the controller is 0.6” which includes the mounting hole. On the right side the distance from the right side of the tamper window edge to the right side of the controller is 1” which also includes the mounting hole. The largest open spot is between the tamper window right edge to the mounting hole which is 0.5”. I see no way to get another label applied.
