OCZRC-03MRFID Security access controller (LF 122kHz or HF 13.56MHz)

How to Install an ISONAS PowerNet™ Reader-Controller Copyright © 2006-2012, ISONAS Security Systems All rights reserved ISONAS Inc. FCC ID: 0CZRC-03 IC: 8431A-RC03 This device complies with Part 15 of the FCC Rules and RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.  Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.  This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.  For RF Safety and per FCC and Industry Canada regulations, the product should never be installed within 8-inches (20cm) of typical people locations. Table of Contents 1: BEFORE YOU BEGIN ............................................................................................................................ 5 1.1: GENERAL REQUIREMENTS: ...................................................................................................... 5 1.2: POWERNET READER-CONTROLLER SPECIFICATIONS: .................................................. 6 1.3: INSTALLATION LOCATION GUIDELINES .............................................................................. 7 2: WIRING AT THE DOOR AND READER-CONTROLLER ............................................................ 11 2.1: POWERING THE READER-CONTROLLERS ......................................................................... 11 2.1.1: POWER OVER ETHERNET (PoE) OPTION .......................................................................... 11 2.1.2: ADDITIONAL POWER OPTIONS ........................................................................................... 13 2.2: WIRING THE DOORS .................................................................................................................. 16 2.2.1: READER-CONTROLLER CONTROL-LEADS DESCRIPTION ......................................... 17 2.2.2: LOCK WIRING -- BASIC .......................................................................................................... 19 2.2.3: WIRING THE REX BUTTON ................................................................................................... 22 2.2.4: WIRING THE AUX INPUT ....................................................................................................... 22 2.2.5: WIRING THE DOOR SENSE .................................................................................................... 23 2.2.6: LOCK WIRING -- LOW-VOLTAGE 12VDC POWER OPTION ......................................... 24 2.2.7: LOCK WIRING -- EXTERIOR DOOR KIT ............................................................................ 25 2.2.8: LOCK WIRING -- 2 READERS TO 1 LOCK .......................................................................... 27 2.2.9: USING THE TTL LEADS .......................................................................................................... 28 2.2.10: USING THE POWERNET’S RS-232 INPUT ......................................................................... 28 2.2.11: WIRING THE WIEGAND INTERFACE MODULE ............................................................ 29 2.2.12: WIRING THE DUAL-SRM ...................................................................................................... 31 2.2.13: WIRING THE QUAD-SRM...................................................................................................... 33 2.2.11: MANAGING INDUCTIVE LOAD CHALLANGES .............................................................. 35 2.2.12: MANAGING IN-RUSH CURRENT LOADS .......................................................................... 36 2.3: CONFIGUATION EXAMPLES ........................................................................................................ 37 2.3.1: PoE --- ELECTRIC STRIKE ...................................................................................................... 37 2.3.2: PoE --- EXTERNAL PWR FOR ELECTRIC STRIKE ........................................................... 38 2.3.3: 12VDC – ELECTRIC STRIKE .................................................................................................. 39 2.3.4: PoE --- MAGNETIC LOCK ........................................................................................................ 40 2.3.5: PoE --- MAGNETIC LOCK & PIR ........................................................................................... 41 2.3.6: PoE --- MAGNETIC LOCK, EDK & PIR ................................................................................. 42 2.3.7: DUAL POWER SOURCES ......................................................................................................... 43 3: CONFIGURING THE READER-CONTROLLER’S COMMUNICATIONS ................................ 44 3.1: ETHERNET-BASED TCP/IP READER-CONTROLLERS .........................…

Text truncated - open the document above for the full version.

ISONAS HQ 4720 Walnut St, Suite 200, Boulder, CO 80301 800-581-0083 www.isonas.com • Provide a statement for how your device Complies with FCC15.203 Antenna requirement: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. This requirement does not apply to carrier current devices or to devices operated under the provisions of §§15.211, 15.213, 15.217, 15.219, or 15.221. Further, this requirement does not apply to intentional radiators that must be professionally installed, such as perimeter protection systems and some field disturbance sensors, or to other intentional radiators which, in accordance with §15.31(d), must be measured at the installation site. However, the installer shall be responsible for ensuring that the proper antenna is employed so that the limits in this part are not exceeded. Model: RC-03: The antenna is an internal antenna directly attached to the pc board and is not accessible to the user. Furthermore, the product requires professional installation.

ISONAS HQ 4720 Walnut St., Suite 200, Boulder, CO 80301 800-581-0083 www.isonas.com Attention: Application Examiner Re: Request for confidentiality Applicant: ISONAS Security Systems FCC ID: OCZRC-03M To whom it may concern, Request is hereby submitted by ISONAS Security Systems to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Tune up procedure • Parts list • Internal photos – photos will reveal components and circuitry that make our product unique among our competitors. Our products are potted to protect this proprietary information. Rationale for Request for Confidentiality : ISONAS Security Systems has invested considerable time and materials in research and development to produce the referenced product(s). Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products but would also disclose succesful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact me at your convenience. Sincerely, Matt Morrison Chief Engineer ISONAS Security Systems

RC-03M External Product Photos External View Front of Product External View Front of Product Back of Product

ISONAS HQ 4720 Walnut St., Suite 200, Boulder, CO 80301 800-581-0083 www.isonas.com RC-03M product Label Location 12/4/2012 MJM The ability to add more information on the reader is simply not possible due to the fact that the label as it exists does not have room for more text as these can be installed in dark areas requiring larger print for the installer. Further, an additional label is not an option due to the fact that there is no room for another label. On one end we have only mounting screw access and on the other we have mounting screw access plus the tamper detection window which cannot be covered up. Note: Label shown is for the RC-03 LF product as an example of label location on product only On the left side the distance from the existing label to the left edge of the controller is 0.6” which includes the mounting hole. On the right side the distance from the right side of the tamper window edge to the right side of the controller is 1” which also includes the mounting hole. The largest open spot is between the tamper window right edge to the mounting hole which is 0.5”. I see no way to get another label applied.

RF Exposure Project #: G100781715 Test Area: Intertek Louisville Test Method: FCC CFR47 Part 1.1310 Test Date: 11/06/2012 EUT Model #: RC-03-MCT-K EUT Serial #: FCC1 Manufacturer: Isonas Security Systems EUT Description: The product tested is multi-frequency, network-enabled, RFID Security Access Reader with keypad. The product transmits at 122.8kHz or 13.56MHz. Notes: The following limit is from table 1 (B) Limits for General Population/Uncontrolled Exposure in FCC part 1.1310: 1 mW/cm² The following calculation was used to determine compliance to the above limit. The calculation is from FCC OET bulletin 65. S=PG/4πR² Where: S=power density (in appropriate units, e.g. mW/cm²) P=power input to the antenna. G=power gain of the antenna in the direction of interest relative to an isotropic radiator. R=distance to the center of radiation of the antenna (appropriate unit, e.g., cm) In this case 20cm will be used. Tx 122.8kHz: Maximum radiated field strength = 86.13dBuV/m at 3-meters = 0.123mW Tx 13.56MHz: Maximum radiated field strength = 66.05dBuV/m at 3-meters = 0.0012mW (see test report 100781715DEN-001) Maximum gain declared by the manufacture – unknown, < 6dBi Power Density Power (mW) Gain (dbi) Gain numeric Distance (cm) Power Density (mW/cm²) 0.123 0 1.0 20 0.0245 0.123 6 4.0 20 0.0974 0.0012 0 1.0 20 0.00024 0.0012 6 4.0 20 0.00095 Note: Worst-case antenna gain of 6dBi used in following calculations: Tx 122.8kHz Delta Limit: 0.0974 mW/cm² - 1.0mW/cm² = -0.9026 mW/cm 2 Tx 13.56MHz Delta Limit: 0.00095 mW/cm² - 1.0mW/cm² = -0.9991 mW/cm 2 Results: The unit complies with the requirements for Maximum Permissible Exposure (MPE) under FCC part 1.1310.

EMC Report for ISONAS on the Model: RC-03-MCT-K Page 1 of 113 TEST REPORT Report Number: 100781715DEN-001 Project Number: G100781715 Report Issue Date: 11/07/2013 Product Designation: Model: RC-03-MCT-K Standards: FCC 47CFR Part 15C RSS-210 - Issue 8: 2010 RSS-Gen - Issue 3: 2010 Tested by: Client: Intertek Testing Services NA, Inc. 1795 Dogwood St. Suite 200 Louisville, CO 80027 ISONAS Security Systems 4720 Walnut Street, Suite 200 Boulder, CO 80301 Report prepared by Report reviewed by Randy Thompson Senior EMC Project Engineer Michael Spataro Engineering Team Leader This report is for the exclusive use of Intertek’s Client and is provided pursuant to the agreement between Intertek and its Client. Intertek’s responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Report Number: 100781715DEN-001 Issued: 11/7/2013 EMC Report for ISONAS on the Model: RC-03-MCT-K Page 2 of 113 TABLE OF CONTENTS 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Description of Equipment Under Test ............................................................................................... 5 4 System setup including cable interconnection details, support equipment and simplified block diagram ........................................................................................................................................................ 8 5 Radiated Unintentional & Tx Spurious Emissions ......................................................................... 10 6 Tx Voltage Variation .......................................................................................................................... 53 7 Tx Frequency Tolerance (Stability) .................................................................................................. 56 8 Radiated Tx Intentional Emissions – Fundamental & Harmonics of the Fundamental .............. 59 9 AC Mains Conducted Emissions ...................................................................................................... 84 10 Telecom Port Conducted Emissions (CISPR 22) – Test not Applicable ................................. 104 11 Occupied Bandwidth (OBW) – RSS-GEN, Section 4.6.1 ........................................................... 105 12 Product Modifications Required to Pass ................................................................................... 111 13 Measurement Uncertainty............................................................................................................ 112 14 Revision History ........................................................................................................................... 113 Intertek Report Number: 100781715DEN-001 Issued: 11/7/2013 EMC Report for ISONAS on the Model: RC-03-MCT-K Page 3 of 113 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 3.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. 2 Test Summary Section Test full name Test date Result 5 Radiated Unintentional & Tx Spurious Emissions - FCC 15.209/15.225(d) Covers IC RSS-Gen 7.2.5/ RSS-210 A2.6(b)(c)(d) 07/02/2012 07/03/2012 Pass 6 Tx Voltage Variation - FCC 15.31(e) 07/05/2012 N/A 7 Tx Frequency Tolerance (Stability) – FCC 15.225(e) Covers RSS-Gen, Section 7.2.6/RSS-210 A2.6 07/19/2012 Pass 8 Tx Radiated Emissions - FCC 15.209/15.225(a) Covers IC RSS-Gen 7.2.5/RSS-210 A2.6(a) 07/05/2012 07/06/2012 Pass 9 AC Conducted Emissions - FCC 15.207 Covers RSS-Gen, Section 7.2.4 07/06/2012 Pass 10 Telecom Port Conducted Emissions - CISPR 22: 2008 ----- N/A 11 Occupied Bandwidth Measurement (OBW) - RSS-Gen, Section 4.6.1 09/06/2012 Pass General Notes: 1) The testing in this report covers the following product models: RC-03-MCT (non-keypad) and RC-03-MCT-K (keypad). Both models are multi-frequency Tx operation – 122.8kHz and 13.56MHz. 2) The following product options were covered in this testing: - Power Over Ethernet (POE) - 12/24VDC 3) Product is RSS-210 Category 1 equipment. Intertek Report Number: 100781715DEN-001 Issued: 11/7/2013 EMC Report for ISONAS on the Model: RC-03-MCT-K Page 4 of 113 Radio Notes: 1) FCC CFR47 Part 15.31: Measurement Standards: In any case where the device is powered off a battery, a fresh battery was used during test. In cases where the device is powered off an AC supply, voltage was varied per Part 15.31 to find worst case emissions. 2) FCC CFR47 Part 15.35 and IC RSS-Gen 4.4/ 7.2.1: Measurement Detector Functions and Bandwidths were ut…
