OD5-ZODRCSZORDCS

CANSEC SYSTEMS LTD., 3105 Unity Drive, Unit 9, Mississauga, Ontario, L5L 4L2 Tel: (905) 820-2404 Fax: (905) 820-0301 DESCRIPTION: The Zodiac SmartCard Fingerprint Reader operates by reading a user’s template stored in a contactless SmartCard or self-adhesive BioPatch for ID verification prior to gaining access. The stick-on BioPatch can be affixed to existing access cards or devices such as PDAs or cell phones. Once the card or BioPatch is presented to the Zodiac reader, the user’s ID number and encrypted fingerprint template are extracted. An indicator on the sensor is activated to prompt the user to present their finger. The reader then compares the scanned fingerprint to the template stored in the Zodiac credential. If they match, the User ID and Facility Code are transmitted to the host access control system. USING ZODIAC : Note: The user must first be enrolled at a Zodiac Enrollment Station and be assigned a Zodiac ID SmartCard or BioPatch. 1.To authenticate at a Zodiac Fingerprint Reader, the user first presents the SmartCard or BioPatch to the front of the reader. The card should be held steadily until the fingerprint sensor on Zodiac flickers RED, indicating a successful transfer of the user’s template . The Zodiac credential can now be removed. 2.After the Zodiac credential is presented successfully, the user applies their finger to the sensor for verification. Note: When applying the finger to the sensor, the same pressure should be used as during the enrollment process. 3.If the fingerprint verification is successful, Zodiac will transmit the user’s ID and system code information to the access control system to verify if the user has access through the entrance or exit being controlled. ZODIAC LED INDICATORS AND BEEPER : Zodiac has two Bi-Color (RED/GREEN) LED’s to provide visual indication of verification and access status from the host access control system. In addition, Zodiac has a beeper which is controlled by the access control system. LEFT LED: This LED provides indication of successful or unsuccessful fingerprint verification. SUCCESSFUL FINGERPRINT VERIFICATION: If the fingerprint is verified successfully, this LED turns GREEN momentarily. UNSUCCESSFUL FINGERPRINT VERIFICATION: If the fingerprint is NOT verified successfully, this LED flashes RED and beeps four times rapidly. RIGHT LED: This LED is controlled by the host access control system and is intended to indicate “Access Granted (GREEN) or “Access Denied (RED)”. BEEPER: The internal beeper is controlled by the host access control system. USER INSTRUCTIONS: MODEL CA-ZODRCS ZODIAC SMARTCARD FINGERPRINT ACCESS READER

CANSEC SYSTEMS LTD., 3105 Unity Drive, Unit 9, Mississauga, Ontario, L5L 4L2 Tel: (905) 820-2404 Fax: (905) 820-0301 WIRING TO HOST CONTROLLER: MOUNTING: Zodiac mounts on a single-gang electrical box. 1. Remove screw from bottom of unit. 2. Remove back mounting plate by pulling gently from inside the cable feed-through hole. 3. Insert the Wiegand cable from the wall through the hole in the back plate, then mount the back plate to the electrical box with the supplied screws. 4. Remove the plug-in connector from the unit and connect Wiegand cable as per wiring instructions on Page 1. Plug the connector back into the unit. Important: Confirm wiring as 12VDC applied to incorrect pin can damage the unit. 5. Attach the main unit to the back plate by tilting the bottom of the unit toward you, then sliding the top of the unit over the back plate. 6. Secure the main unit to the back plate with the screw removed in step 1. LED and BEEPER CONTROL: The LED line is used to control the LED on the right side of the unit. This LED is normally RED and will turn GREEN when the line is pulled LOW. The BEEPER line is used to activate the unit’s internal beeper. The beeper will sound if the line is pulled LOW. INSTALLATION INSTRUCTIONS: MODEL CA-ZODRCS ZODIAC FINGERPRINT ACCESS READER CANSEC SYSTEMS LTD., 3105 Unity Drive, Unit 9, Mississauga, Ontario, L5L 4L2 Tel: (905) 820-2404 Fax: (905) 820-0301 SPECIFICATIONS: Reader Output: 26 or Cansec Proprietary Wiegand Operating Temperature: -40 to +70 C Indoor (Outdoor with Heated Enclosure) Size: 3 1/4" (w) x 4 3/4" (h) x 1 1/2" (d) Weight: 10 oz Housing: High Impact Polycarbonate (Lexan) Mounting: Single gang electrical box Sensor: Manufacturer: SecuGen ® Type: Optical Verification: <1 Second (after template is read) Supply Voltage: 12VDC, 400 mA LED Indicators: Bi-Color Standard (red, green) 1 x Authentication Indicator 1 x Externally Controlled Indicator Audio Tone: Standard Cable: 22 AWG, 6 Conductor, Stranded, Overall Shield, Maximum 500 ft. to controller NOTE: This equipment has been tested and found to comply with the limits for a Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of more of the following measures: •Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by Cansec Systems Ltd. could void the user's authority to operate the equipment.

Joris JOURDAIN INSIDE Contactless Bat. 11A, Parc Club du Golf 13857 AIX EN PROVENCE FRANCE Federal Communications commission Authorization and Evaluation Division Subject : CONFIDENTIALITY REQUEST Dear Sir, Pursuant to sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below : - Schematics - Block Diagram - Operational Descriptions The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Joris JOURDAIN INSIDE Contactless Technical Support Manager e-mail : [email protected] Tel : +33 4 42 39 63 09

ANNEX 2 - EXTERNAL PHOTOSPHOTO # 1 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 2 - EXTERNAL PHOTOSPHOTO # 2 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 2 - EXTERNAL PHOTOSPHOTO # 3 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 2 - EXTERNAL PHOTOSPHOTO # 4 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS

3105 Unity Drive, Unit 9, Mississauga, Ontario, Canada L5L 4L2 Tel: 905-820-2404 Fax: 905-820-0301 BOTTOM OF READER FCC IDENTIFIER LABELLING Location of FCC Label FRONT OF READER FCC ID: OD5-ZODRCS IC: 3279A-ZODRCS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that ma y cause undesired FCC ID LABEL

ANNEX 3 - EXTERNAL PHOTOSPHOTO # 1 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 2 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 3 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 4 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 5 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 6 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 7 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 8 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS ANNEX 3 - EXTERNAL PHOTOSPHOTO # 9 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS / IC: 3279A-ZODRCS

Nov. 29, 2002 CANSEC INC. 3105 Unity Drive, Suite # 9 Mississauga, Ontario CANADA L5L 4L2 Attn.:Mr. Ed Malconian Subject:FCC Certification Application Testing under FCC PART 15, Subpart C - Unlicensed Low Power Transmitter operating in the frequency band 13.553-13.567 MHz. Product:ZODIAC FINGERPRINT READER Model No.:ZODRCS FCC ID:OD5-ZODRCS Dear Mr. Malconian, The product sample, as provided by you, has been tested and found to comply with FCC PART 15, Subpart C - Unlicensed Low Power Transmitter operating in the frequency band 13.553-13.567 MHz. Enclosed you will find copies of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering Encl UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] ZODIAC FINGERPRINT READER Model No.: ZODRCS FCC ID: OD5-ZODRCS Applicant: CANSEC SYSTEMS LIMITED 3105 Unity Drive, Suite # 9 Mississauga, Ontario CANADA L5L 4L2 In Accordance With FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15, SUBPART C Unlicensed Low Power Transmitter operating in the band 13.553-13.567 MHz UltraTech's File No.: CSC-019F15.225 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Nov. 29, 2002 Report Prepared by: Tri LuuTested by: Hung Trinh, RFI Technician Issued Date: Nov. 29, 2002Test Dates: Nov. 25, 2002 ß The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ß This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SITC-137646390-2049200093-000-034 FCC PART 15, SUBPART C - UNLICENSED LOW POWER TRANSMITTER Page 2 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ULTRATECH GROUP OF LABSFile #: CSC-019F15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Nov. 29, 2002 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 2 31040/SITC-137646390-2049200093-000-034 TABLE OF CONTENTS EXHIBIT 1.SUBMITTAL CHECK LIST....................................................................................................................................4 EXHIBIT 2.INTRODUCTION.....................................................................................................................................................5 2.1.SCOPE.......................................................................................................................................................................................5 2.2.RELATED SUBMITAL(S)/GRANT(S)........................................................................................................................................5 2.3.NORMATIVE REFERENCES.................................................................................................................................................5 EXHIBIT 3.PERFORMANCE ASSESSMENT.........................................................................................................................6 3.1.CLIENT INFORMATION........................................................................................................................................................6 3.2.EQUIPMENT UNDER TEST (EUT) INFORMATION...........................................................................................................6 3.3.THEORY OF OPERATION........................................................................................................................................................7 3.4.EUT’S TECHNICAL SPECIFICATIONS..............................................................................................................................8 3.5.LIST OF EUT’S PORTS..........................................................................................................................................................8 3.6.ANCILLARY EQUIPMENT...................................................................................................................................................8 3.7.BLOCK DIAGRAM OF TEST SETUP..................................................................................................................................9 EXHIBIT 4.EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS.......................................10 4.1.CLIMATE TEST CONDITIONS...............................................................................................................................................10 4.2.OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS...............................................................................10 EXHIBIT 5.SUMMARY OF TEST RESULTS.........................................................................................................................11 5.1.LOCATION OF TESTS.........................................................................................................................................................11 5.2.MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES............................................................11 5.3.APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS..............................................................................11 EXHIBIT 6.MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS.......................................12 6.1.TEST PROCEDURES................................................…

Text truncated - open the document above for the full version.

FCC PART 15, SUBPART C - UNLICENSED LOW POWER TRANSMITTER Page 21 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ULTRATECH GROUP OF LABSFile #: CSC-019F15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Nov. 29, 2002 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 2 31040/SITC-137646390-2049200093-000-034 6.8. FREQUENCY STABILITY @ FCC §15.225(C) 6.8.1. Limits The frequency tolerance of the carrier signal shall be maintained within <plus-minus>0.01% of the operating frequency over a temperature variation of -20 degrees to +50 degrees C at normal supply voltage, and for a variation in the primary supply voltage from 85% to 115% of the rated supply voltage at a temperature of 20 degrees C. For battery operated equipment, the equipment tests shall be performed using a new battery 6.8.2. Method of Measurements Refer to FCC § 2.1055 and Exhibit 8, Section 8.4 of this report for detailed test procedures. 6.8.3. Test Equipment List Test InstrumentsManufacturerModel No.Serial No.Frequency Range Spectrum Analyzer/ EMI Receiver Hewlett PackardHP 8593EM3412A001039 kHz – 26.5 GHz Attenuator(s)Bird.....DC – 22 GHz Temperature & Humidity Chamber TenneyT59723B-40 o to +60 o C range 6.8.4. Test Arrangement TRANSMITTER 20 dB ATTENUATOR SPECTRUM ANLYZER Environmental Chamber FCC PART 15, SUBPART C - UNLICENSED LOW POWER TRANSMITTER Page 22 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ULTRATECH GROUP OF LABSFile #: CSC-019F15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Nov. 29, 2002 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 2 31040/SITC-137646390-2049200093-000-034 6.8.5. Test Data Frequency Band:13.553 - 13.567 MHz Center Frequency:13.56 MHz Full Power Level:50.7 dBuV/m at 10meters Frequency Tolerance Limit:+ 0.01% or 1356 Hz Max. Frequency Tolerance Measured:-183 Hz or 0.0013% Input Voltage Rating:12 Vdc Center Frequency & RF Power Output Variation Ambient Temperature (°C) Supply Voltage (Nominal) 12 Vdc Supply Voltage (85 % of lowest rating) 6.8 Vdc Supply Voltage (115% of highest rating) 13.8 Vdc HzHz Hz -30 -183N/A N/A -20 -60N/A N/A -10 -9N/A N/A 0 +66N/A N/A +10 +31N/A N/A +20 0+3 +3 +30 -6N/A N/A +40 -9N/A N/A +50 -14N/A N/A FCC PART 15, SUBPART C - UNLICENSED LOW POWER TRANSMITTER Page 23 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ULTRATECH GROUP OF LABSFile #: CSC-019F15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Nov. 29, 2002 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 2 31040/SITC-137646390-2049200093-000-034 6.9. AC POWERLINE CONDUCTED EMISSIONS @ FCC PART 15, SUBPART B, PARA.15.207 6.9.1. Limits The equipment shall meet the limits of the following table: CISPR 22/EN 55022 CLASS B LIMITS Test Frequency Range (MHz) Quasi-Peak (dBμμV) Average* (dBμμV) Measuring Bandwidth 0.15 to 0.566 to 56*56 to 46*RBW = 9 kHz VBW > 9 kHz for QP VBW = 1 Hz for Average 0.5 to 55646RBW = 9 kHz VBW > 9 kHz for QP VBW = 1 Hz for Average 5 to 306050RBW = 9 kHz VBW > 9 kHz for QP VBW = 1 Hz for Average * Decreasing linearly with logarithm of frequency 6.9.2. Method of Measurements Refer to Sec. 8.2 in Exhibit 8 of this test report & ANSI C63-4:1992 6.9.3. Test Equipment List Test InstrumentsManufacturerModel No.Serial No.Frequency Range Spectrum Analyzer/ EMI Receiver Hewlett Packard HP 8593EM3412A001039 kHz – 26.5 GHz Transient LimiterHewlett Packard 11947A3107019989 kHz – 200 MHz 10 dB attenuation L.I.S.N.EMCO3825/2890715319 kHz – 200 MHz 50 Ohms / 50 μ H 12’x16’x12’ RF Shielded Chamber RF Shielding......... FCC PART 15, SUBPART C - UNLICENSED LOW POWER TRANSMITTER Page 24 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ULTRATECH GROUP OF LABSFile #: CSC-019F15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Nov. 29, 2002 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 2 31040/SITC-137646390-2049200093-000-034 6.9.4. Test Data The emissions were scanned from 150 kHz to 30 MHz at AC mains Terminal via a LISN, and all emissions less than 30 dB below the limits were recorded. RFRECEIVERQPAVG LINE FREQUENCYLEVELDETECTORLIMITLIMITMARGINPASS/TESTED (MHz)(dBuV)(P/QP/AVG)(dBuV)(dBuV)(dB)FAIL(L1/L2) 0.1746.9QP64.954.9-18.0PASSL1 0.1719.8AVG64.954.9-35.1PASSL1 0.2637.7QP61.351.3-23.6PASSL1 0.2619.8AVG61.351.3-31.5PASSL1 0.4932.1QP56.146.1-24.1PASSL1 0.4919.8AVG56.146.1-26.3PASSL1 0.9131.8QP56.046.0-24.2PASSL1 0.9119.8AVG56.046.0-26.2PASSL1 1.7538.2QP56.046.0-17.8PASSL1 1.7525.5AVG56.046.0-20.6PASSL1 13.5973.4QP No Limit for Tx Carrier No Limit for Tx Carrier--PASSL1 0.1851.3QP64.754.7-13.5PASSL2 0.1831.5AVG64.754.7-23.3PASSL2 0.2246.8QP62.752.7-15.9PASSL2 0.2229.8AVG62.752.7-22.9PASSL2 0.3534.6QP58.948.9-24.3PASSL2 0.3524.6AVG58.948.9-24.4PASSL2 0.4034.8QP57.847.8-23.0PASSL2 0.4027.7AVG57.847.8-20.1PASSL2 0.8719.8QP56.046.0-36.2PASSL2 0.8719.8AVG56.046.0-26.2PASSL2 2.0833.2QP56.046.0-22.8PASSL2 2.0826.1AVG56.046.0-19.9PASSL2 13.5973.8QP No Limit for Tx Carrier No Limit for Tx Carrier--PASSL2 FCC PART 15, SUBPART C - UNLICENSED LOW POWER TRANSMITTER Page 25 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ULTRATECH GROUP OF LABSFile #: CSC-019F15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Nov. 29, 2002 Tel. #: 905-829-1570, Fax…

Text truncated - open the document above for the full version.

ANNEX 1 - PHOTOGRAPHS OF TEST ETUPPhoto # 1 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS ANNEX 1 - PHOTOGRAPHS OF TEST ETUPPhoto # 2 ZODIAC FINGERPRINT READER, Model ZODRCSFCC ID: OD5-ZODRCS
