tous les appareils Bluetooth modèle pliablemicrophone intégré Introduction: Veuillez lire ce qui suit avant d'utiliser vos écouteurs pour la première fois. 1-Mise en marche/Arrêt/Jouer/Pause/Prendre un appel/Terminer l'appel 2-Diminuer le volume 3-Augmenter le volume 4-Musique précédente 5-Musique suivante 6-Port de charge USB Micro et entrée audio 7-Microphone Opération Bluetooth 1-Activez la fonction Bluetooth de votre téléphone pour accéder au mode de recherche. 2-Appuyez et maintenez la touche mise en marche/arrêt (1) de vos écouteurs jusqu'à ce que le logo BOOMPODS apparaisse en rouge et bleu; ainsi le mode de couplage est activé. 3-Votre téléphone cellulaire trouvera automatiquement un nouvel appareil Bluetooth appelé "headpods" (écouteurs). Établissez la connexion avec cet appareil et attendez que le logo BOOMPODS devienne bleu. Ceci indique que la connexion avec vos écouteurs est réussie. 4-Ajustez le son selon votre goût et écoutez votre musique préférée. 5-Pour éteindre vos écouteurs, appuyez et maintenez la touche mise en marche/arrêt (1) jusqu'à ce que le logo BOOMPODS devienne rouge et relâchez la touche. Réception d'appels Lorsque vous recevez un appel, votre musique pause automatiquement et vous entendez la sonnerie régulière de votre téléphone. Pour accepter l'appel, appuyez une fois sur la touche mise en marche/arrêt (1). Pour refuser l'appel, appuyez deux fois. Lorsque l'appel est terminé votre musique se remet à jouer automatiquement. Opération par Câble Éteignez vos écouteurs. Connectez le câble 3.5mm à votre source audio et au port USB Micro de vos écouteurs. Chargement Pour charger, connectez le câble USB directement à votre ordinateur, votre portable ou un port USB. L'indicateur à DEL sur vos écouteurs devient rouge pendant le chargement et s'éteint quand ils sont complètement chargés. Mode Économie d'Énergie Vos écouteurs s'éteignent automatiquement s'ils sont inutilisés pour plus de 80 secondes. Contenu de cet Emballage 1 Écouteur stéréo avec microphone intégré 1 Câble USB Micro 1 Câble audio 3.5mm 1 Câble USB standard 1 Sac de voyage 1 Manuel d’utilisation Fiche Technique Puissance de sortie maximale: 20MW*2 Capacité de la batterie: 350mAh 3.7V Temps de charge: 3 heures Temps d'utilisation: 8 heures Portée du Bluetooth: 10m (espace ouvert) Temps de mise en veille: Plus de 30 heures + Bluetooth: Version 2.1 + EDR Renseignements Généraux Ne pas soumettre à des températures élevées et ne pas exposer directement au soleil. Éviter tout contact avec des liquides. Ne pas insérer d'objets conducteurs dans la boite de son. De pas désassembler. Ne pas faire tomber. Tenir hors de la portée des enfants. Manuel de l'utilisateur des BOOMPODS a été créé au Royaume-Uni par DT Design Ltd. Tous droits révervés ©2013. Ce produit utilise la technologie BOOMPODS et il est protégé par les brevets internationaux, écouteurs - IP: 201330118796.7 www.starline.com www.starline.com FCC NOTE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR CHANGE TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE COULD VOID AND CHANGE ANNTENA WHICH THE MANUFACTURER PROVIDES. IT IS THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a resi dential installation. This equipment generates, uses and can radiate radio frequenc y energy and, if not installed and used in accordance with the in structions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular insta llation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to corr ect the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experien ced radio/TV technician for help. To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.

Reference No.: WTD13S0705940E Page 60 of 64 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 19 Photographs - Constructional Details 19.1 EUT – External View Reference No.: WTD13S0705940E Page 61 of 64 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn Reference No.: WTD13S0705940E Page 62 of 64 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn

FCC Label Location for model: PH-4028BL The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. FCC ID:ODA PH-4028BL

FCC Label FCC Label Sample for model: PH-4028BL FCC ID: ODAPH-4028BL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Reference No.: WTD13S0705940E Page 63 of 64 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 19.2 EUT – Internal View RF Antenna Reference No.: WTD13S0705940E Page 64 of 64 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn =End==

Reference No.: WTD13S0705940E Page 1 of 64 FCC TEST REPORT Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn FCC ID : ODAPH-4028BL Applicant : Dongguan Yujia Industry Co., Ltd Address : Shang Ye St., Yong Jun Road, Shuilang Village, Dalingshan Town, Dongguan City, Guangdong, China. Manufacturer : The same as above Address : The same as above Equipment Under Test (EUT) : Product Name : Bluetooth handfree earphone Model No. : PH-4028BL Standards : FCC Part15.247:2012 Date of Test : July 26~31, 2013 Date of Issue : August 05, 2013 Test Result : PASS Remark: * The sample described above has been tested to be in compliance with the requirements of ANSI C63.4:2003. The test results have been reviewed and comply with the rules listed above and found to meet their essential requirements. The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Services (Shenzhen) Co., Ltd. 1/F, Fukangtai Building, West Baima Rd., Songgang Street, Baoan District, Shenzhen 518105, China Tel: +86-755-83551033 Fax: +86-755-83552400 Compiled by: Approved by: Maikou Zhang / Project Engineer Philo Zhong / Manager Reference No.: WTD13S0705940E Page 2 of 75 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 2 Test Summary Test Items Test Requirement Result Spurious Radiated Emissions 15.205(a) 15.209 15.247(d) PASS Band edge Emissions 15.247(d) PASS Spurious RF Conducted Emissions from out of band 15.247(d) PASS Duty Cycle 15.35 PASS Conducted Emissions 15.207 PASS 20dB Bandwidth 15.215c 15.247(a)(1) PASS Maximum Peak Output Power 15.247(b)(1) PASS Frequency Separation 15.247(a)(1) PASS Number of Hopping Frequency 15.247(a)(1)(iii) PASS Dwell time 15.247(a)(1)(iii) PASS Maximum Permissible Exposure (Exposure of Humans to RF Fields) 1.1307(b)(1) PASS Reference No.: WTD13S0705940E Page 3 of 75 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 TEST SUMMARY................................................................................................................................................... 2 3 CONTENTS............................................................................................................................................................. 3 4 GENERAL INFORMATION.................................................................................................................................. 5 4.1 GENERAL DESCRIPTION OF E.U.T.................................................................................................................. 5 4.2 DETAILS OF E.U.T........................................................................................................................................... 5 4.3 CHANNEL LIST................................................................................................................................................. 5 4.4 DESCRIPTION OF SUPPORT UNITS.................................................................................................................. 6 4.5 TEST FACILITY................................................................................................................................................. 6 4.6 TEST LOCATION............................................................................................................................................... 6 5 EQUIPMENT USED DURING TEST................................................................................................................... 7 5.1 EQUIPMENTS LIST........................................................................................................................................... 7 5.2 MEASUREMENT UNCERTAINTY........................................................................................................................ 7 5.3 TEST EQUIPMENT CALIBRATION..................................................................................................................... 7 6 CONDUCTED EMISSION..................................................................................................................................... 8 6.1 E.U.T. OPERATION.......................................................................................................................................... 8 6.2 EUT SETUP..................................................................................................................................................... 8 6.3 CONDUCTED EMISSION TEST RESULT............................................................................................................ 9 7 SPURIOUS RADIATED EMISSIONS............................................................................................................... 11 7.1 EUT OPERATION :......................................................................................................................................... 11 7.2 TEST SETUP.................................................................................................................................................. 12 7.3 SPECTRUM ANALYZER SETUP...................................................................................................................... 13 7.4 TEST PROCEDURE......................................................................................................................................... 14 7.5 CORRECTED AMPLITUDE & MARGIN CALCULATION..................................................................................... 14 7.6 SUMMARY OF TEST RESULTS..............................................................................................…
