OF6-EI-MW-RC-11LDX

Rebel 2.0 #20226-5 Thank you for purchasing the Rebel 2.0. To see more Lucky Duck products please visit your local Sporting Goods dealer or online at www.luckyduck.com. Parts Include: 1ea - Rebel 2.0 Electronic Call, 1ea - LDX Rebel 2.0 Remote Control, 1ea – Decoy, 1ea - Antenna, and 1ea - 10AA Battery Cartridge Battery Installation: The Rebel 2.0 includes a 10AA battery cartridge (batteries not included). The battery compartment is located on the back of the call. Install 10AA batteries into the included cartridge, with the negative ends of batteries up against the large springs within the cartridge for proper orientation. Simply insert the battery cartridge into the compartment, with the protrusions on the battery cartridge in the downward position. To remove the battery cartridge from the electronic call, push the “EJECT” button under the battery compartment. The remote control uses 3AA batteries (not included). Remove the battery cover on the back of the remote control and install the batteries, replace the battery cover on the remote. Note: The Rebel 2.0 is compatible with the “E-Caller Battery & Charger Kit 2.0”. Sold separately. Antenna: The antenna will either be in the box or installed on the call. If the antenna is in the box, simply locate the antenna port on the back corner of the caller and screw the antenna onto the caller. Decoy: The decoy will either be in the box or stored on the side of the call. Insert the decoy into the hole on the top of the handle. Make sure to align the keyed protrusion on the decoy base with the slot on the decoy joint located in the handle of the caller. A strong magnet holds the decoy in place. The decoy can be stored on the left side of the call. Tripod Insert: The bottom of the Rebel 2.0 has a 1/4-20 insert that can accommodate most aftermarket camera tripods or any other base system that utilizes a 1/4-20 thread. This may be helpful if you want to further elevate the caller depending on the hunting terrain. Electronic Call Operation: With the battery inserted into the caller, slide the power switch on the electronic caller to the “ON” position. A red LED light on the back of the call will illuminate when the power is on. Hold down the power button on the remote control. The remote will turn on. The remote screen will display “Finding Caller” while it searches for a connection with the caller. Once the remote connects to the caller, the remote screen (showing sound folders) will be displayed. DO NOT PRESS ANY BUTTONS WHEN REMOTE IS SEARCHING FOR THE CALLER. Remote Control Operation: • Sound Selection – All sounds are stored within folders. Use the “SEL” up/down arrows to highlight the folder you want to select. Press the play/pause button to select the folder. Use the “SEL” up/down arrows to highlight the sound you want to play. Press the play/pause button to play the sound. Pressing and holding the “SEL” up/down arrows for 1 second will cycle through the folders/sounds faster. • Volume Selection – Use the “VOL” up/down buttons to lower (down button) or increase (up button) the volume level. The volume level ranges from 1 to 32. Pressing and holding the “VOL” up/down buttons for 1 second will raise or lower the volume level quickly. • Back Button – The back button (“B”) is used to go from the sound list back to the folder list. • Recall Button – The recall button will play the previous sound. • Display Screen – The remote display screen includes information on the top line as well as the bottom line. Top Line (Left to Right) - Volume level from 1 – 32 - Stand timer which starts from zero when the remote is turned on - Remote control battery level indicator Bottom Line: - Informational line showing what function is happening. - Functions: Play/Pause/Stop – Brightness Level – Decoy On/Off/Speed Remote Screen Mode and Brightness: The LDX with the Rebel 2.0 has the ability to adjust the display screen brightness with 10 levels. To adjust the brightness level, hold the back (“B”) button down for 3 seconds. Followed by quickly using the “VOL” up/down buttons to adjust the brightness. Remote Control Distance: The Rebel 2.0 utilizes the LDX remote, with an extended range and industry leading remote technology, which does not require a line of site between the remote and the caller up to at least 100 yards. Decoy Operation: • “DY” Button – Press the “DY” button to turn the decoy on. The decoy will spin back and forth. • “DS” Button – Press the “DS” button to control the speed of the decoy. There are 3 speed settings. Favorite Buttons: The “F1” and “F2” buttons are designed to store your two favorite sounds for quick access when hunting. Press the F1 or F2 buttons once to play the programmed sound at the predefined volume level. Program F1 and F2: Simply highlight the sound you want to program as a favorite and adjust the volume to your preferred level. Hold down the corresponding F1 or F2 button. The highlighted sound will flash on the display screen confirming the programming is complete. IF THE F1 BUTTON WILL NOT PROGRAM, TRY PROGRAMMING F2 FIRST AND THEN PROGRAM F1. Sound Management: The Rebel 2.0 comes preloaded with 50 live animal sounds, organized within 20 folders for quick access. These sounds have been professionally recorded by The Verminator, Rick Paillet. We firmly believe this is the best sound library on the market. The 50 preloaded sounds have the extension .LD and will only play on Lucky Duck electronic calls. Any reproduction of these sounds is strictly prohibited. Check out www.luckyduck.com for additional sounds available to purchase. To Recharge the 12 Volt E-Caller Battery & Charger Kit 2.0 – Purchased Separately: 1. Remove the battery cartridge from the back of the caller. 2. Plug the charger into the charging port located near the bottom of the front face of the battery cartridge. 3. Plug the charger into a 110V wall outlet. The LED light on the charger will turn red when charging and green when fully charged. It should take appr…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company name: EXPEDITE INTERNATIONAL, INC FRN: 0021465885 Contact Name: Jeff Hallbeck Address: 1950 8th Ave. Baldwin, WI 54002, USA. Telephone No: 715-381-2935 Email: [email protected] Applicant: Company name: EXPEDITE INTERNATIONAL, INC Grantee Code: OF6 FCC ID: OF6-EI-MW-RC-11 FRN: 0021465885 Contact Name: Jeff Hallbeck Address: 1950 8th Ave. Baldwin, WI 54002, USA. Telephone No: 715-381-2935 Fax No: 715-381-2936 Email: [email protected] EXPEDITE INTERNATIONAL, INC certifies that, as of the date of this filing of the application with the TCB, [EXPEDITE INTERNATIONAL, INC] is our designated US agent for service of process for the above referenced FCC ID. EXPEDITE INTERNATIONAL, INC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [EXPEDITE INTERNATIONAL, INC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2026-06-03 Applicant’s Name: Jeff Hallbeck US Agent’s Name: Jeff Hallbeck Title: President Title: President Signature: Signature:

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 EXPEDITE INTERNATIONAL, INC TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: EXPEDITE INTERNATIONAL, INC Grantee code: OF6 FCC ID: OF6-EI-MW-RC-11 FRN: 0021465885 Contact Name: Jeff Hallbeck Address: 1950 8th Ave. Baldwin, WI 54002, USA. Telephone No: 715-381-2935 Fax No: 715-381-2936 Email: [email protected] i. [EXPEDITE INTERNATIONAL, INC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [EXPEDITE INTERNATIONAL, INC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [EXPEDITE INTERNATIONAL, INC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 2026/6/3 Applicant’s Name: Jeff Hallbeck Title: President Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

EXPEDITE INTERNATIONAL, INC Code 00018768 Ed. 1 Device LDX Company name EXPEDITE INTERNATIONAL, INC Grantee code OF6 FCC ID OF6-EI-MW-RC-11 FRN 0021465885 Contact name Jeff Hallbeck Address 1950 8th Ave. Baldwin, WI 54002, USA. Telephone number 715-381-2935 E-mail [email protected] Chipset/module information HC32L130 Operating System (if applicable) N/A Storage Capacity (hard drive or other permanent memory storage, if applicable) N/A 2 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A 3 # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A # General Requirements (For Linux system) Yes / No or N/A Comments 1 Hard drive: 1 GB of free space N/A 2 CPU: Intel Pentium 1 GHz or higher N/A 3 RAM: 1 GB N/A 4 Minimum software requirements: AlmaLinux OS 8 or later; AlterOS 7.5 or later; Astra Linux Common Edition 2.12 or later; CentOS 6.7 or later; Debian GNU/Linux 10.0 or later; EulerOS 2.0 or later; Oracle Linux 7.3 or later ; Red Hat Enterprise Linux 6.7 or later ; Rocky Linux 8.5 or later ; SUSE Linux Enterprise Server 12.5 or later; Ubuntu 12.04 or later ; Uncom OS Home / Business / Education / Enterprise 2.2 or later; N/A 4 ALT Linux Workstaton / Workstation K / Server / Education 8 or later; ROSA Linux Workstation / Server 12 or later ; RED OS 7.3 and later ; After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Jeff Hallbeck Date: 2026/6/3 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

TCB CALL página 1 File FCC ID: OF6-EI-MW-RC-11 Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. TCB CALL página 2 In google maps: TCB CALL página 3 Other Information: From IMPORTINFO web: https://www.importinfo.com/expedite-international-inc TCB CALL página 4 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter" >

C5266091_X10_Ed.2 1/1 EXPEDITE INTERNATIONAL, INC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: June 3, 2026 Subject: Request for Confidentiality FCC ID: OF6-EI-MW-RC-11 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info No No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: June 3, 2026 Name Jeff Hallbeck Position President Company Name EXPEDITE INTERNATIONAL, INC Address 1950 8th Ave. Baldwin, WI 54002, USA. Tel 715-381-2935 Fax 715-381-2936 Email [email protected]

C5266091_X8_Ed.1 1/1 Letter of Authorization EXPEDITE INTERNATIONAL, INC Company: EXPEDITE INTERNATIONAL, INC Address: 1950 8th Ave. Baldwin, WI 54002, USA. Product Name: LDX Model Number: EI-MW-RC-11 FCC Identifier: OF6-EI-MW-RC-11 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jeff Hallbeck Date: 2026-06-03 Title: President Signature of applicant:

Page 1 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix II external photos FCC ID: OF6-EI-MW-RC-11 Page 2 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 3 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 4 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China ------End------

Label and Location Material: Silk-screen Font color: White Size: L: 2cm*W: 1cm Label and Location W FCC ID: OF6-EI-MW-RC-11 Model No.: EI-MW-RC-11 L

Page 1 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix III internal photos FCC ID: OF6-EI-MW-RC-11 Page 2 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 3 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China ANT TX Page 4 of 4 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China ------End------

Page 1 of 1 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China RF Exposure evaluation FCC ID: OF6-EI-MW-RC-11 According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison For Worst case Mode: 434.065MHz Field strength =74.01dBuV/m @3m Ant gain 0 dBi; so Ant numeric gain=1 So pt= {[10 (74.01/20) /10 6 x3] 2 /30x0.01} x 1000 mW =0.0023mW So (0.0023mW/5mm) x √0.434065 GHz = 0.0003 < 3 for 1-g SAR Then SAR evaluation is not required

Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Page 1 of 28 Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China FCC TEST REPORT FCC ID: OF6-EI-MW-RC-11 On Behalf of EXPEDITE INTERNATIONAL, INC LDX Model No.: EI-MW-RC-11 Prepared for : EXPEDITE INTERNATIONAL, INC Address : 1950 8th Ave. Baldwin, WI 54002, USA. Prepared By : Shenzhen PSI Testing Co., Ltd. Address : 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Report Number : psi2605011-C01-R01 Date of Receipt : May 7, 2026 Date of Test : May 7, 2026–May 27, 2026 Date of Report : May 27, 2026 Version Number : V0 Page 2 of 28 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China TABLE OF CONTENTS Description Page 1. Summary of Standards And Results .................................................................................... 5 1.1. Description of Standards and Results ............................................................................. 5 2. General Information ............................................................................................................... 6 2.1. Description of Device (EUT) ........................................................................................... 6 2.2. Accessories of Device (EUT) .......................................................................................... 7 2.3. Tested Supporting System Details .................................................................................. 7 2.4. Block Diagram of connection between EUT and simulators ........................................... 7 2.5. Test Mode Description .................................................................................................... 7 2.6. Test Conditions ............................................................................................................... 8 2.7. Test Facility ..................................................................................................................... 8 2.8. Measurement Uncertainty ............................................................................................... 8 2.9. Test Equipment List ........................................................................................................ 9 3. Power Line Conducted Emission Test ................................................................................ 10 3.1. Block Diagram of Test Setup ........................................................................................ 10 3.2. Test Limits .................................................................................................................... 10 3.3. Configuration of EUT on Test ....................................................................................... 11 3.4. Operating Condition of EUT .......................................................................................... 11 3.5. Test Procedure ............................................................................................................. 11 3.6. Test Results .................................................................................................................. 12 4. Radiated Emission Test and Band Edge Test .................................................................... 13 4.1. Block Diagram of Test Setup ........................................................................................ 13 4.2. Test Limit ...................................................................................................................... 15 4.3. Configuration of EUT on Test ....................................................................................... 16 4.4. Operating Condition of EUT .......................................................................................... 16 4.5. Test Procedure ............................................................................................................. 16 4.6. Test Results .................................................................................................................. 17 5. Occupied Bandwidth Test .................................................................................................... 24 5.1. Block Diagram of Test Setup ........................................................................................ 24 5.2. Test Limit ...................................................................................................................... 24 5.3. Test Procedure ............................................................................................................. 24 5.4. Test Results .................................................................................................................. 24 6. Transmission time ................................................................................................................ 25 6.1. Standard Requirement Test limit .................................................................................. 25 6.2. Method of measurement ............................................................................................... 25 6.3. Test Setup .................................................................................................................... 25 6.4. Results .......................................................................................................................... 25 7. Antenna Requirement .......................................................................................................... 27 7.1. Standard Requirement .................................................................…

Text truncated - open the document above for the full version.

Manufacturer EXPEDITE INTERNATIONAL, INC Address 1950 8th Ave. Baldwin, WI 54002, USA. TestD ate2024/3/18 TestI nstrument KeysightE5071B antennadesignspecification Antennadimensionsasblowpictureshow:t hemateriali sFR4andthethicknessi s 1.6mmofPCB. ANT1: Model: EI-MW-RC-11 Max Gain: 0dBi Y X Total Azimuth = 0 . 0 Elevation = 0 . 0 Roll = 0. 0 Z 434M TRP 1 C ut1 Max : -2 Min: - 16 Scale:2 / div 9 0 0 3 30 30 0 2 40 21 0 1 80 Angle ( ? 2 70 C ut2 Max : 0 Min: - 2 2 Scale: 2 / div 90 0 3 3 0 3 0 0 2 4 0 2 1 0 18 0 Angle ( ? 2 7 0 Max : -2 Min: - 14 Scale: 2 / div 90 C ut3 0 330 300 24 0 21 0 180 Angle ( ? 27 0 -20 -25 0 -5 - 15 - 10 120 150 12 0 15 0 1 20 1 50 60 30 6 0 3 0 6 0 3 0 3D and 1D Radiation Patterns

Page 1 of 1 Report No.: psi2605011-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix I Test Setup Photo FCC ID: OF6-EI-MW-RC-11 Spurious Radiation Emissions Test (<1G) Spurious Radiation Emissions Test (>1G) ------End------
