Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Remote Control Kit For use with Lucky Duck™ and Rapid Flyer Lucky Duck™ decoys. Parts List: 1 Remote Receiver 1 Remote Transmitter Step 1: Disconnect the safety plug from the wire harness inside the decoy. Note: Be sure to save the plug for future use without the remote control. The unit will not operate without the remote or safety plug. Step 2: Using the two-sided tape, attach the receiver box to the battery cage towards the rear of the decoy. Step 3: Plug male end of the wire harness from the receiver into the female end of the wire harness from the decoy. Be sure wires will not interfere with the motor shafts on the Lucky Duck™ decoy. Step 4: Feed the antennae out of the decoy through the first small hole in the bottom of the decoy. Then feed the antennae back into the decoy through the second small hole in the bottom of the decoy . Finally, feed the antennae into the neck of the decoy. Make sure the antennae is relatively straight in the neck of the decoy. Step 5: To operate, turn the power switch to the “RF” (remote function) position. Use the handheld remote to activate the decoy. When not in use, turn the switch to the “OFF” position. Step 6: To remove the remote, disconnect the wire assemblies, and remove the antenna and replace the safety plug. TROUBLESHOOTING: Your remote control kit is pre-programmed at the factory. Though rare, it is possible for it to loose it’s connection with the remote receiver inside the duck. If your remote control does not work out of the box, perform the following steps to re-program your remote control to work with your decoy. You can also use these steps for setting up your remote control to control multiple ducks from the same key fob. 1) Remove the decoy wings. 2) Carefully remove the 4 screws in the top of the receiver cover to expose the PCB board inside. 3) Turn your decoy to the ON (RF) position and press and HOLD the S1 button shown below in the illustration. 4) While pressing down the S1 button, press and hold the key fob button until the Red LED illuminates on the board. At that point, your receiver has been programmed to work with that remote. 5) If you have multiple decoys that you want to control with the same remote control, repeat this process with each of the ducks. 6) Replace the cover and screws and you are ready to start hunting. If those steps do not get it back working, please check to see if the battery in the key fob is fresh and not depleted. If still a problem, contact Customer Service at the number is 715-381-2935. FCC INFORMATION FOR THE CONSUMER This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Block Diagram
6. External and Internal Photos of the EUT External Photos
FCC ID Label Information 1. Label location: 2. FCC ID Label: Expedite International, Inc. Remote Control Kits Model: ITC-RC54 FCC ID: OF6ITC-RC54 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Internal Photos
TEL: 0755-33818029 33818030 FAX: 0755-3381 8026 EMAIL: [email protected] URL: www.sz-itc.com ADD: 广东省深圳市龙华镇龙胜路旭联工业区2栋2楼 Remote Control Specialist – Innovation Technology 无线遥控专家·创新微科技 Operation Description Operation Description 1. Battery: Provides the power to remote control. 2. Step-down Circuit: step-down voltage to 3.6V and supply the encode circuit and transmitting circuit. 3. Encode circuit: encode the data signal 4. Transmitting Circuit: transmitting the encoded data 5. Antenna: output encoded data via antenna. Specification Operation Frequency: 433.92MHz Modulation: ASK Antenna type: Omni-directional antenna Gain: ≤2dBi
1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 10-Jan-2012 Sheet of File: E:\LZXDDB\ITC-RC54.ddb Drawn By: BT123A 1 2 3 U17536 VCC VDD S1 BUTTON 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 U2ITC01T Y113.56MHz C433pF C333pF VCC L1100nH C5100pF C61pF C810pF L247nH VCC AT1ANTENNA C733pF VCC R12K D1LED C1104 C2101 L347nH ITC-RC54 V1.1
Shenzhen CTL Electromagnetic Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-89486187 FCC PART 15 SUBPART C TEST REPORT FCC PART 15C Report Reference No......................: CTL120104001-S-WF Compiled by ( position+printed name+signature)..: File administrators Andy Zhang Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Kendy Wang Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Feb. 10, 2012 Testing Laboratory Name..............: Shenzhen CTL Electromagnetic Technology Co., Ltd. Address.............................................: Zone B,4/F, Block 20,Guangqian Industrial Park, Longzhu Road,Nanshan,Shenzhen 518055 China. Test Firm..........................................: Bontek Compliance Testing Laboratory Ltd Address.............................................: 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Applicant’s name............................: Expedite International, Inc. Address.............................................: 1201 Beaudry Blvd. Hudson, WI, 54016 USA Test specification: Standard ...........................................: FCC Part 15C ANSI C63.4: 2003 TRF Originator ..................................: Shenzhen CTL Electromagnetic Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Electromagnetic Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electromagnetic Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electromagnetic Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Remote Control Kits Operation Frequency........................: 433.92MHz Modulation mode: ............................: ASK Trade Mark .......................................: / Model/Type reference.......................: ITC-RC54 Listed Models ..................................: / Power Supply..............................: DC 12V Anttenna Type..............................: Integral without external RF Port Result................................................: Positive FCC ID.............................................: OF6ITC-RC54 V1.0 Page 2 of 17 Report No.: CTL120104001-S-WF T E S T R E P O R T Test Report No. : CTL120104001-S-WF February 10, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Remote Control Kits Model /Type : ITC-RC54 Listed Models : / Applicant : Expedite International, Inc. Address : 1201 Beaudry Blvd. Hudson, WI, 54016 USA Manufacturer : Shenzhen Innovation Technology Co.,Ltd. Address : Floor 2, 2#Buldg., Xulian Ind., Longsheng Rd., Longhua Town, Shenzhen, Guangdong, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 17 Report No.: CTL120104001-S-WF Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 2.8. Test Result Summary 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................. 9 4.1. Radiated Emission Test 9 4.2. Occupied Bandwidth 12 5. TEST SETUP PHOTOS OF THE EUT .......................................... 15 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 16 V1.0 Page 4 of 17 Report No.: CTL120104001-S-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15 Subpart C Section 15.231 ANSI C63.4-2003 V1.0 Page 5 of 17 Report No.: CTL120104001-S-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Feb. 02, 2012 Testing commenced on : Feb. 02, 2012 Testing concluded on : Feb. 04, 2012 2.2. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz z 12 V DC o 24 V DC o Other (specified in blank below) Not applicable 2.3. Short description of the Equipment under Test (EUT) 433.92MHz Wireless Transmitter For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: o - supplied by the manufacturer o - supplied by the lab o Power Cable Length (m) : / Shield : / Detachable : / o Multimeter Manufacturer : / Model No. : / V1.0 Page 6 of 17 Report No.: CTL120104001-S-WF 2.6. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: OF6ITC-RC54 filing to comply with the FCC Part 15, Subpart C Rules. 2.7. Modifications No modifications were implemented to meet testing criteria. 2.8. Test Result Summary Test Item Test RequirementStandard Paragrph Result Radiated Emission (25MHz to 5000MHz) FCC PART 15 Section 15.231(b) PASS Occupled Bandwidth FCC PART 15 Section 15.231(c) PASS Dwell Time FCC PART 15 Section 1…
Text truncated - open the document above for the full version.
5. Test Setup Photos of the EUT
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231 | 433.92 MHz - 433.92 MHz | - |

Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
LD3XR
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
REMOTE KIT
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
DXX - Part 15 Low Power Communication Device Transmitter
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
