OGT-2023-HHRemote controller

INSTALLATION INSTRUCTION FOR CEILING FAN REMOTE CONTROLLER MODEL NO. OF RECEIVER: AA-24DC2023-7RFA / AA-24DC2023-7RFA-WIFIMODEL NO. OF TRANSMITTER: HH2019-12T4 IMPORTANT POINTS: 1. Please read this instruction, and save it for further use. 2. Before installation, TURN OFF THE POWER OF YOUR CEILING FAN. 3. Please note that all wiring appliances should be installed by a qualified electrician. 4. This unit is to be used in a 100-130V~ 50/60Hz supply only. (Rating: RECEIVER: Max40W for fan motor, Max 50W for Lamp. TRANSMITTER: transmitting frequency range:433.92MHz±300kHz, Maximum transmitting power: 8dBm.) 5. Do not install in damp locations or immerse in water. (For indoor use only.)6. Do not pull on or cut leads shorter.7. Do not drop or bump the unit. 8. PLEASE NOTE: The battery will weaken with age and should be replaced before leaking takes place as this will damage the transmitter. 9. The batteries must be removed from the transmitter before it is scrapped. And the batteries shall be disposed of safety. 10. The switch shall be mounted at a height greater than 1.7m.11. The electric shock protection of the RF receiver shall be depended on its installation.12. The RF remote controller shall be used within its rating range, otherwise overheating and dangerous phenomenon may occur. 13. The RF ceiling fan remote controller is made by XIN HUI A.A. ELECTRONICS LTD.14. CAUTON: To reduce the risk of fire or injury, do not use this product in conjunction with any variable (rheostat) wall control. 15. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 16. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 17. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. This limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used inaccordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct theinterference by one or more of the following measures: □ Reorient or relocate the receiving antenna.□ Increase the separation between the equipment and receiver.□ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. □ Consult the dealer or an experienced radio/TV technician for help. CONTROL INSTRUCTIONS: 1. The receiver is only control by transmitter. 2. If you would like to operate receiver by a new transmitter, you must use the transmitter to code the remote controller.3. The way of code is within 10s after the receiver is powered on, you should press and holdon the key of FAN OFF for 3s to code. If code successfully, you will hear a sound “beep”from buzzer. 4. After code successfully, the new transmitter can control the receiver and the old transmitter can not control the receiver. FUNCTIONS OF RECEIVER AND TRANSMITTER: ① lamp: The lamp will light up when you press any buttons. ② FAN OFF: Turn off ceiling fan. ③ LIGHT OFF: Turn on or Turn off the lamp. ④ SPEED 1: Turn on ceiling fan to speed 1.(the slowest speed) ⑤ SPEED 2: Turn on ceiling fan to speed 2. ⑥ SPEED 3: Turn on ceiling fan to speed 3. ⑦ SPEED 4: Turn on ceiling fan to speed 4. ⑧ SPEED 5: Turn on ceiling fan to speed 5.(the fastest speed) ⑨ 1H: The LED and ceiling fan will turn off after one hour. ⑩ 2H: The LED and ceiling fan will turn off after two hours. ⑪ F/R: Switch the Fan direction. ⑫ 4 H: The LED and ceiling fan will turn off after four hours. ⑬ 8H: The LED and ceiling fan will turn off after eight hours. Press and hold on 3s to reset the WIFI. ① ④ ⑩ ⑦ INSTALLATION INSTRUCTIONS: CAUTION: INCORRECT WIRE CONNECTION WOULD DAMAGE THIS RECEIVER. 1. Make the wiring connection must be stuck inside canopy. 2. Once the connection has been made, the receiver inserts into the drop rod hanging bracket. The canopy comes up to cover the receiver and bracket. 3. To change the batteries is to open the battery housing cover by slidingout the cover downward to the arrow shown direction while pressingdown the cover with thumb. Holder for transmitter: if desired, install onto the wall with screws. 4. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:(1) This device may not cause interference.(2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteut/récepteur ecempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Dévelopementéconomique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tour brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. INPUT MOTOR OUTPUT TO MOTOR FOR LIGHT Receiver L N AC INPUT L N LIGHT OUTPUT

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 Xin Hui A.A. Electronics Ltd Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both TianHeng Consulting,LLC (“Agent”) and Xin Hui A.A. Electronics Ltd (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I QI FANG OU HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Xin Hui A.A. Electronics Ltd Contact Name : QI FANG OU Address : Building No.110, No.1, North of Sanhe Avenue, Xinhui Jiangmen, Guangdong, 529100, China (Peoples Republic Of) Telephone No : 86(0750)6127746 Email : [email protected] FCC ID : OGT-2023-HH Applicant FRN : 0021853080 Signature: ________ _______ Date: ____ March 08,2024________________________________ I Hualing Dong HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated above. Agent Company Name : TianHeng Consulting,LLC Contact Name : Hualing Dong Address : 392 Andover Street, Wilmington, MA 01887, United States Telephone No : +1 617-997-4010 Email : [email protected] Agent FRN : 0033401258 Signature: _________ __ Date: ______March 10,2024______________________________

1.Lable Note: Thelabelcontentcanbeinanyofthefollowing threeways 1.Stickthelabelatthedesignatedposition. 2.Laserprintingrelevantcontentatthespecified location. 2.Schematicdiagramoflabellocation

HH2019-12T4 Schematic diagram of antenna positionUnit: mm 28.9 35.1 1.4 25.3 19.5

Xin Hui A.A. Electronics Ltd TEST REPORT SCOPE OF WORK EMC TESTING–HH2019-12T4 REPORT NUMBER 231114050GZU-001 ISSUE DATE [REVISED DATE] 26-January-2024 [---------------------] PAGES 21 DOCUMENT CONTROL NUMBER FCC part 15.231-f © 2017 INTERTEK TEST REPORT Room101/301/401/102/202/302/ 402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room101/301/401/102/202/302/402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 21 FCC Part 15.231-f Applicant Name & Address : Xin Hui A.A. Electronics Ltd Building No.110, No.1, North of Sanhe Avenue, Xinhui Jiangmen, Guangdong, 529100, China (Peoples Republic Of) Manufacturing Site : Same as Applicant Intertek Report No: FCC ID: 231114050GZU-001 OGT-2023-HH Test standards CFR 47, FCC PART 15 Subpart C: 2021 section 15.231 Sample Description Product : Remote controller Model No. : HH2019-12T4 Electrical Rating : DC 3V Battery Serial No. : Not Labeled Date Received : 14 November 2023 Date Test Conducted : 06 December 2023-26 January 2024 Prepared and Checked By Richard Liu Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 231114050GZU-001 Version: 14 December 2022 Page 3 of 21 FCC Part 15.231-f CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 5 2.3 TEST METHODOLOGY ........................................................................................................... 5 2.4 TEST FACILITY ...................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 6 3.1 JUSTIFICATION ..................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 7 3.3 SPECIAL ACCESSORIES ........................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 7 3.5 EQUIPMENT MODIFICATION .................................................................................................. 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 8 N/A4.0 MEASUREMENT RESULTS .................................................................................... 8 4.1 ANTENNA REQUIREMENT ...................................................................................................... 9 4.2 RADIATED EMISSIONS ......................................................................................................... 10 4.3 OCCUPIED BANDWIDTH ...................................................................................................... 18 4.4 DWELL TIME ..................................................................................................................... 19 4.5 CONDUCTED EMISSION TEST ................................................................................................ 20 5.0 TEST EQUIPMENT LIST ............................................................................................. 21 TEST REPORT Intertek Report No.: 231114050GZU-001 Version: 14 December 2022 Page 4 of 21 FCC Part 15.231-f 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Radiated Emission FCC PART 15 section 15.231(b) ANSI C 63.10: Clause 6.4, 6.5 and 6.6 PASS Occupied Bandwidth FCC PART 15 section 15.231(c) ANSI C 63.10: Clause 6.9 PASS Dwell Time FCC PART 15 section 15.231(a) FCC PART 15: Section 15.231(a) PASS Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2013 in the whole report TEST REPORT Intertek Report No.: 231114050GZU-001 Version:…

Text truncated - open the document above for the full version.

Note:EUT is positioned at the center of the turntable to keep 3 m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz)
