OJPXA029012.4G Radio Control Airplane

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Date: July 30, 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen BATT Testing Technology Co., Ltd. 11F, Bldg.B, Xinbaoyuan, Xinanhu Commercial city, Bao’an District, Shenzhen, Guangdong, China. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with HANGZHOU ZT MODEL CO., LTD. 58TH XINGWU RD,BEIGAN INDUSRTY DISTRICT, HANGZHOU,ZHEJIANG,CHINA Dated this: July 30, 2012 Agency agreement expiration date: Usually Give 8 - 12 Months By: Haifeng Jiang Signature Printed Title: Manager On behalf of: HANGZHOU ZT MODEL CO., LTD. Tel No: +86-571-82877488

July 30, 2012 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: OJPXA02901 Product Name: 2.4G Radio Control Airplane Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this July 30, 2012 20 By: Haifeng Jiang Signature Printed Title: Sales On behalf of : HANGZHOU ZT MODEL CO., LTD. . Telephone: +86-571-82877488

Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

This device complies with pa rt 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not c ause harmful interference, and (2) this devic e must accept any interference received, including inte rference that may cause undesired operation. ZT MODELFCC ID: OJP XA02901 MADE IN CHINA Model number:XA02901Voltage:6V Current:90mA Tx

FCC ID Label Location

Photo 7 Photo 8 Photo 9 Photo 10 Photo 11

Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 1 of 35 FCC TEST REPORT Prepared For : HANGZHOU ZT MODEL CO., LTD. Product Name: 2.4G Radio Control Airplane Model : XA02901, XA02903 ,XA02902, XA03701 Prepared By : Shenzhen BATT Testing Technology Co., Ltd. 11F, Bldg.B, Xinbaoyuan, Xinanhu Commercial city, Bao’an District, Shenzhen, Guangdong, China. Tel: 86-755-27753991 Fax: 86-755-27754182 Test Date: July 17, 2012 to July 21, 2012 Date of Report : July 23, 2012 Report No.: BATT20120725090E Note: This report shall not be reproduced except in full, without the written approval of Shenzhen BATT Testing Technology Co., Ltd. This document may be altered or revised by Shenzhen BATT Testing Technology Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 2 of 35 TABLE OF CONTENTS 1 TEST CERTIFICATION .......................................................................... 3 2 TESTRESULTSUMMARY......................................................................4 3EUTDESCRIPTION.................................................................................5 4 TEST LAB DETAILS ..............................................................................5 5 Test .........................................................................................................6 5.1. CONDUCTED EMISSIONS TEST..................................................................6 5.2. RADIATED EMISSIONS TEST......................................................................9 5.3 BAND EDGE TEST....................................................................................20 5.4 ANTENNA REQUIREMENT..........................................................................25 5.5 20dB BANDWIDTH MEASUREMENT.............................................................26 6 PHOTOGRAPHS OF THE TEST CONFIGURATION.....................................29 7 PHOTOGRAPHS OF EUT ....................................................................30 Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 3 of 35 1 TEST CERTIFICATION Product: 2.4G Radio Control Airplane Model: XA02901, XA02903 ,XA02902, XA03701 Applicant: HANGZHOU ZT MODEL CO., LTD. 58 TH XINGWU RD,BEIGAN INDUSRTY DISTRICT,HANGZHOU,ZHEJIANG,CHINA Factory: HANGZHOU ZT MODEL CO., LTD. 58 TH XINGWU RD,BEIGAN INDUSRTY DISTRICT,HANGZHOU,ZHEJIANG,CHINA Trade Mark: Tested: July 17, 2012 to July 21, 2012 Test Voltage: DC6V, 4 pcs AA batteries Applicable Standards: FCC PART 15.249 The test report was prepared by Shenzhen BATT Testing Technology Co., Ltd.and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Prepared by : Hellen XiaoAssistant Reviewer : Mike Yong/Supervisor Approved & Authorized Signer : Jones Song/ Manager Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 4 of 35 2 TEST RESULT SUMMARY Standard Item Result Remarks FCC Part 15, Paragraph 15.207 Conducted Emission Test PASS Not Applicable FCC Part 15 Subpart C Paragraph 15.249(a) & 15.249(b) Limit Field Strength of Fundamental PASS Complies FCC Part 15, Paragraph 15.209 Radiated Emission Test PASS Complies FCC Part 15 Subpart C Paragraph 15.249(d) Limit Band Edge Test PASS Complies FCC Part 15, Paragraph 15.207 Conducted Emission Test PASS Complies Note: 1. The test result judgment is decided by the limit of test standard Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 5 of 35 3 EUT DESCRIPTION Product 2.4G Radio Control Airplane Model XA02901, XA02903 ,XA02902, XA03701 Trade Mark Applicant HANGZHOU ZT MODEL CO., LTD. Operational Frequency Range 2402-2479MHz Modulation Type GFSK Antenna Integral Antenna with Gain 0 dBi Housing material Plastic FCC ID: OJPXA02901 EUT Type Engineering Sample. Product Sample, Mass Product Sample. Serial Number -- Power Rating DC6V, 4 pcs AA batteries I/O PORT I/O PORT TYPES Q’TY TESTED WITH -- -- -- 4 TEST LAB Details Name: SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO LTD Address: 5/F,Block 4, Anhua Industrial Zone.,No.8 TaiRan Rd.CheGongMiao,FuTian District, Shenzhen,CHINA. FCC Registration Number: 899988 Note: All tests were done at SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO LTD Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 6 of 35 5.1. CONDUCTED EMISSION MEASUREMENT 5.1.1. LIMITS Class B (dBuV) FREQUENCY (MHz) Quasi-peak Average 0.15 - 0.5 66 - 56 56 - 46 0.50 - 5.0 56 46 5.0 - 30.0 60 50 NOTE: (1) The lower limit shall apply at the transition frequencies. (2) The limit decreases in line with the logarithm of the frequency in the range of 0.15 to 0.50 MHz. (3) All emanations from a class A/B digital device or system, including any network of conductors and apparatus connected thereto, shall not exceed the level of field strengths specified above. 5.1.2. TEST INSTRUMENTS Conducted Emission Shielding Room Test Site (743) Name of Equipment ManufacturerModel Serial Number Calibration Due EMI Test Receiver R&S ESCS30 100139 04/20/2013 LISN AFJ LS16C 10010947251 04/20/2013 NOTE: 1. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to international system unit (SI). 2. N.C.R = No Calibration Request. Shenzhen BATT Testing Technology Co., Ltd. Report No.: BATT20120725090E Page 7 of 35 5.1.3. TEST PROCEDURES Procedure of Preliminary Test The EUT and Support equipment, if needed, was set up as per the test configuration to simulate typical usage per the user’s manual. When the EUT is a tabletop system, a wooden table with a height of 0.8 meters is used and is placed o…

Text truncated - open the document above for the full version.

RADIATED EMISSION TEST
