1 Please read this User’s Manual carefully to understand the functions and operation of the mobile phone. This mobile phone incorporates the latest world advanced functions, enabling simple and convenient operation and satisfying your special requirements. The mobile phone supports T-FLASH (memory) card and dual SIM standby enabling WAP surfing in higher speed; in addition, the following functions are also available: SMS, MMS, MP3, MP4, alarm clock and memo, enabling you arranging your work, study and life freely; with smart games and long standby duration, as well as world clock and calculator, your communication will be easier and smoother; powerful file manager allows you managing the files conveniently. In addition, the 64-chord ringtone allows you selecting music to set as ringtone; the personalized appearance also can satisfy your selection. Users Manual Model number:Q5 2 1． Index..4 2. Safety precautions..................................5 Driving safety _______________________________________________5 Power off in aircraft ________________________________________5 Power off in the operation area of explosion _________________5 Power off near dangerous articles ____________________________5 In hospitals _________________________________________________5 Interference _________________________________________________6 Professional service _________________________________________6 Accessories and battery ______________________________________6 Rational application _________________________________________6 Emergency call _______________________________________________6 3. About the phone6 3.1 Display settings___________________________________________________6 3.2 Status icons_______________________________________________________7 4. Getting started......................................7 4.1 First call_________________________________________________________7 4.2 Installing the SIM card____________________________________________7 4.3 Installing memory card_____________________________________________8 4.4 Battery and charging_______________________________________________8 Installing the battery_________________________________________________8 3 Charging the battery___________________________________________________8 Using battery__________________________________________________________8 4.5 Switching on/off___________________________________________________9 4.6 Password___________________________________________________________9 SIM1 PIN______________________________________________________________10 SIM2 PIN______________________________________________________________10 4.7 Using handsfree kit_______________________________________________10 Keypad lock___________________________________________________________10 Number keys___________________________________________________________11 Language and input method_____________________________________________11 Service_______________________________________________________________11 Group_________________________________________________________________11 Noun__________________________________________________________________11 Shortcut functions____________________________________________________12 5. Common functions ............................................ 12 5.1 Making a call_____________________________________________________12 5.2 Adjusting receiver volume_________________________________________12 5.3 Answering calls___________________________________________________12 5.4 Call options______________________________________________________13 5.5 Missed calls______________________________________________________13 5.6 Connecting to voicemail___________________________________________14 6. Menu guide ............................................ 14 6.1 Music player______________________________________________________14 6.2 Phonebook_________________________________________________________14 6.3 Call center_______________________________________________________15 [Call log]____________________________________________________________15 [General call settings]_______________________________________________16 6.4 Services__________________________________________________________17 6.5 Messaging_________________________________________________________18 4 6.6 Multimedia________________________________________________________21 [Cameral selection]___________________________________________________21 [Camera]______________________________________________________________21 [Video recorder]______________________________________________________22 [Video Player]________________________________________________________22 [FM radio]____________________________________________________________22 [Sound recorder]______________________________________________________22 [Mobile TV]___________________________________________________________23 6.7 Organizer_________________________________________________________23 6.8 File manager______________________________________________________23 6.9 Calendar__________________________________________________________24 6.10 Game_____________________________________________________________24 6.11 Profiles_________________________________________________________25 6.12 Settings_________________________________________________________25 7. Appendix ............................................ 26 Appendix A: Please take care of your mobile phone _____________________26 Appendix B: Troubleshooting___________________________________________27 Appendix C: Abbreviation and explanation______________________________27 Appendix D: Optional parts____________________________________________27 1． Index .................................................................................... 1. Index ........................................................................ 2. Safety precautions 5 ........................................................................ 3. About the phone .......................................…

Text truncated - open the document above for the full version.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 BEST LUCK S.A 2012-7-23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OKIQ5 We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Tune up Procedure - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Carson Cheung Contact information / address: PARQUE EMPRESARIAL CELTA TRADE PARK, BODEGA, GA NO.66 FUNZA CUNDINAMARCA, COLOMBIA SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0

Lable location

Annex B. EUT Internal Photo Cover Off - Top View Cover Off - Bottom View Battery - Top View Battery - Bottom View LCD - Top View LCD - Bottom View Uncover - Top View Uncover - Bottom View Uncover without LCD - Top View Uncover Without Shielding - Top View GSM Antenna - Top View Bluetooth Antenna - Top View GSM Antenna Bluetooth Antenna

BEST LUCK S.A Mobile Phone Model: Q5 July 17, 2012 Report No.: 12070132-FCC-E1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Alan Lv Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: EMC Test Report for Mobile Phone Model: Q5 To: FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Report No: 12070132-FCC-E1 Issue Date: July 17, 2012 Page: 2 of 26 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: EMC Test Report for Mobile Phone Model: Q5 To: FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Report No: 12070132-FCC-E1 Issue Date: July 17, 2012 Page: 3 of 26 www.siemic.com.cn This page has been left blank intentionally. Title: EMC Test Report for Mobile Phone Model: Q5 To: FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Report No: 12070132-FCC-E1 Issue Date: July 17, 2012 Page: 4 of 26 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ..........................................................................................5 2 TECHNICAL DETAILS .........................................................................................................................................6 3 MODIFICATION.....................................................................................................................................................7 4 TEST SUMMARY....................................................................................................................................................8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ..................................................................9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................15 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ...........................................................................................20 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT................................................................................21 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................25 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................26 Title: EMC Test Report for Mobile Phone Model: Q5 To: FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Report No: 12070132-FCC-E1 Issue Date: July 17, 2012 Page: 5 of 26 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the BEST LUCK S.A, Mobile Phone and model: Q5 against the current Stipulated Standards. The Mobile Phone has demonstrated compliance with the FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003. EUT Information EUT Description : Mobile Phone Main Model : Q5 Serial Model : N/A Antenna Gain GSM850: 0.5dBi PCS1900: 1dBi Bluetooth:0dBi Input Power : Adapter: Model: Q5 Input: AC100-240V 50/60Hz 200mA Output: DC5.0V-500mA Li-ion Battery: Model:BL-5BT Charge Limit: 4.2Vdc Voltage: 3.7V, 800mAh Classification Per Stipulated Test Standard : Class B Emission Product Per FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Title: EMC Test Report for Mobile Phone Model: Q5 To: FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Report No: 12070132-FCC-E1 Issue Date: July 17, 2012 Page: 6 of 26 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Mobile Phone with stipulated standard Applicant / Client BEST LUCK S.A PARQUE EMPRESARIAL CELTA TRADE PARK, BODEGA, GA NO.66 FUNZA CUNDINAMARCA, COLOMBIA Manufacturer ShenZhen ChuangCheng Electronic Co.,Ltd 3-5/F, Chuangcheng Mansion, Taiwan Ind. Zone, Shiyan Town, Bao’an, Shenzhen Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 12070132-FCC-E1 Date EUT received June 20, 2012 Standard applied FCC Part 15 Subpart B Class B: 2012, ANSI C63.4: 2003 Dates of test July 09, 2012 No of Units #1 Equipment Category Class B Emission Product Trade Name MILLENIUM ELECTRONICS RF Operating Frequency (ies) GSM850 TX : 824.2 ~ 848.8 MHz; RX :869.2 ~ 893.8 MHz PCS1900 TX : 1850.2 ~ 1909.8 MHz; RX :1930.2 ~ 1989.8 MHz Bluetooth: 2402-2480MHz Number of Channels 300 CH (…

Text truncated - open the document above for the full version.

Annex B. Test Setup Photo Conducted Emissions Test Setup - Front View Conducted Emissions Test Setup - Side View Radiated Emissions Test Setup Below 1GHz - Front View Radiated Emissions Test Setup Above 1GHz – Rear View
