VONETS——VAP11N Mini WIFI Bridge 1 WiFi Bridge VAP11N Quick Setting Guide VONETS——VAP11N Mini WIFI Bridge 2 Declaration Copyright © 2012 Shenzhen HouTian Network Communication Technology Co.Ltd All rights reserved, with retained ownership Without Shenzhen HouTian Network Communication Technology Co.Ltd written authorization, any company or personal can’t copy, writer or translation part or all contents. Can’t do commodity distribution for any commercial or profitable purposes by any ways(electricity, mechanical, photoprint, record or other methods). VONETS is the registered trademark of Shenzhen HouTian Network Communication Technology Co.Ltd. The other all trademarks or registered trademarks mentioned in this documents are belong to the individual owners. The product specifications and information technology mentioned in this manual are just for reference, if any updates, without other notice. Except for special agreements, this manual is just for user guidance, any statements, information and so on in this manual can’t constitute the warranty of any forms. VONETS——VAP11N Mini WIFI Bridge 3 Chapter 1 Quick Setting Guide 1. Connect the computer Set computer IP address to automatically, please see the words in the red circle of the following picture: 2. Open the IE browser, enter vonets.cfg virtual domain name setting(VDNS). VONETS——VAP11N Mini WIFI Bridge 4 Remark: Enter domain name, then Enter, the login page will appear, the default admin and password is admin. 3. Scan Hotspots After entering the IE browser, the WiFi hotspots window will appear, can search the WIFI hotspots signal that opened SSID broadcast around, please see the following:  Choose a correct WiFi signal, then click Next, the following interface will appear:  Input the correct password, confirm it is correct one, then click Apply button.  If it is con`nected successfully, the following picture will appear. VONETS——VAP11N Mini WIFI Bridge 5  If it is connected failed, the following picture will appear: Shenzhen HouTian Network Communication Technology Co.,Ltd http://www.vonets.com.cn VONETS——VAP11N Mini WIFI Bridge 6 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation.

Shenzhen HouTian Network Communication Technology Co., Ltd. January 30, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: OM7-VAP11N To Whom It May Concern: This letter is to ascertain that Shenzhen HouTian Network Communication Technology Co., Ltd. （Product：WiFi Bridge Model name: VA P 1 1 N） has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title: Lisong Chu / General Manager Contact information / address: RM803, Floor 8, Building Five, Industrial Plant, Donghua Yuan, Nanhai Road, Nanshan District, Shenzhen, China

Shenzhen HouTian Network Communication Technology Co., Ltd. March 5, 2013 To: SIEMIC, INC. 775 Montague Expressway Milpitas , CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We , Shenzhen HouTian Network Communication Technology Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: WiFi Bridge Model name: VA P 1 1 N FCC ID: OM7-VAP11N We affirm that between SIEMIC and Shenzhen HouTian Network Communication Technology Co., Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Lisong Chu / General Manager Contact information / address: RM803, Floor 8, Building Five, Industrial Plant, Donghua Yuan, Nanhai Road, Nanshan District, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 Shenzhen HouTian Network Communication Technology Co., Ltd. March 5, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: OM7-VAP11N We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Client’s signature: Client’s name / title: Lisong Chu / General Manager Contact information / address: RM803, Floor 8, Building Five, Industrial Plant, Donghua Yuan, Nanhai Road, Nanshan District, Shenzhen, China

FCC Certification Label Location Sample Label location

FCC Certification label Sample FCC ID: OM7-VAP11N This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Antenna

FCC ID : OM7-VAP11N 1. RF EXPOSURE 1.1. The Requirement System operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See Section 15.247(b)(4) and Section 1.1307(b)(1) 1.2. Limit For Maximum Permissible Exposure (MPE) Limits for General Population/ Uncontrolled Exposure F = frequency in MHz, * Plane-wave equivalent power density 1.3. MPE Calculations E(V/m) = 30 P G d  , Power Density: S( 2 mW/cm) = 2 377 E Where E = Electric Field (V/m) P = Peak Output Power (mW) Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) ( 2 mW/cm) Averaging Time 2 E, 2 H or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 G = Antenna Numeric Gain (numeric) = 10 x , x = Antenna Gain(dBi) /10 d = Separation Distance (cm) We can change the formula to: S = 2 30 377 PG d   or, d = 30 377 PG S   Because the EUT is belong to general population/uncontrolled exposure. So 1.3.1. We considering the limit of minimum separation distance (d) is 20cm, Maximum Output Power = 24.15 Antenna Gain = 3(dBi) = 2.00(numeric) S = 2 30 377 PG d   = 0.0096 < 1.0 2 mW/cm (limit) Calculated RF Exposure power density is 0.0096 2 mW/cm , less than the limit. 1.3.2. We considering the limit of power density (S) is 1.0 2 mW/cm , Maximum Output Power = 24.15 Antenna Gain = 3(dBi) = 2.00 (numeric) d = 30 377 PG S   = 1.9605< 20 cm Calculated RF Exposure separation distance is 1.9605 less than the minimum separation distance 1.3.3.FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. Proposed RF exposure safety information to include in User’s Manual.

Page 1 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 APPLICATION CERTIFICATION FCC Part 15C On Behalf of Shenzhen HouTian Network Communication Technology Co., Ltd. WiFi Bridge Model No.: VAP11N FCC ID: OM7-VAP11N Prepared for : Shenzhen HouTian Network Communication Technology Co., Ltd. Address : RM803, Floor 8, Building Five, Industrial Plant, Donghua Yuan, Nanhai Road, Nanshan District, Shenzhen, China Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20130181 Date of Test : January 31-February 7, 2013 Date of Report : February 20, 2013 Page 2 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT)....................................................................................................................5 1.2. Carrier Frequency of Channels .................................................................................................................6 1.3. Test Procedure ..........................................................................................................................................6 1.4. Special Accessory and Auxiliary Equipment ...........................................................................................6 1.5. Description of Test Facility ......................................................................................................................7 1.6. Measurement Uncertainty.........................................................................................................................7 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 8 3. OPERATION OF EUT DURING TESTING ................................................................................. 9 3.1. Operating Mode ........................................................................................................................................9 3.2. Configuration and peripherals ..................................................................................................................9 4. TEST PROCEDURES AND RESULTS ....................................................................................... 10 5. 6DB BANDWIDTH MEASUREMENT ........................................................................................ 11 5.1. Block Diagram of Test Setup..................................................................................................................11 5.2. The Requirement For Section 15.247(a)(2) ............................................................................................11 5.3. EUT Configuration on Measurement .....................................................................................................11 5.4. Operating Condition of EUT ..................................................................................................................11 5.5. Test Procedure ........................................................................................................................................12 5.6. Test Result ..............................................................................................................................................12 6. MAXIMUM PEAK OUTPUT POWER ....................................................................................... 26 6.1. Block Diagram of Test Setup..................................................................................................................26 6.2. The Requirement For Section 15.247(b)(3)............................................................................................26 6.3. EUT Configuration on Measurement .....................................................................................................26 6.4. Operating Condition of EUT ..................................................................................................................26 6.5. Test Procedure ........................................................................................................................................27 6.6. Test Result ..............................................................................................................................................27 7. POWER SPECTRAL DENSITY MEASUREMENT.................................................................. 41 7.1. Block Diagram of Test Setup..................................................................................................................41 7.2. The Requirement For Section 15.247(e).................................................................................................41 7.3. EUT Configuration on Measurement .....................................................................................................41 7.4. Operating Condition of EUT ..................................................................................................................41 7.5. Test Procedure ........................................................................................................................................42 7.6. Test Result ..............................................................................................................................................43 8. BAND EDGE COMPLIANCE TEST ........................................................................................... 57 8.1. Block Diagram of Test Setup..................................................................................................................57 8.2. The Requirement For Section 15.247(d) ........................…

Text truncated - open the document above for the full version.

Page 101 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Date of Test: February 4, 2013 Temperature: 25 o C EUT: WiFi Bridge Humidity: 50% Model No.: VAP11N Power Supply: DC 5V (Power By PC) Test Mode: 802.11n Channel Low 2412MHz (20MHz) Test Engineer: Pei For Below 30MHz Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor(dB) Corr. QP QP QP Polarization - - - - - - X - - - - - - Y - - - - - - Z For 30MHz-1000MHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor Corr. (dB) QP QP QP Polarization 117.6815 26.58 13.68 40.26 43.50 -3.24 331.7858 20.17 17.79 37.96 46.00 -8.04 Vertical 117.6815 27.68 13.68 41.36 43.50 -2.14 213.8535 24.55 14.47 39.02 43.50 -4.48 340.0473 23.64 18.04 41.68 46.00 -4.32 827.1795 16.72 27.20 43.92 46.00 -2.08 Horizontal For 1GHz-25GHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading(dBV/m ) Result(dBV/m)Limit(dBV/m)Margin(dBV/m) Frequency (MHz) AV PEAK Factor Corr. (dB) AV PEAKAV PEAK AV PEAK Polarizati on - - - - - - - - - - Vertical - - - - - - - - - - Horizontal Note: 1. Emissions attenuated more than 20 dB below the permissible value are not reported. 2. *: Denotes restricted band of operation. 3. The fundamental radiated emissions were reduced by Band Reject Filter in the attached plots. Page 102 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Date of Test: February 4, 2013 Temperature: 25 o C EUT: WiFi Bridge Humidity: 50% Model No.: VAP11N Power Supply: DC 5V (Power By PC) Test Mode: 802.11n Channel Middle 2437MHz (20MHz) Test Engineer: Pei For Below 30MHz Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor(dB) Corr. QP QP QP Polarization - - - - - - X - - - - - - Y - - - - - - Z For 30MHz-1000MHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor Corr. (dB) QP QP QP Polarization 117.6815 26.42 13.68 40.10 43.50 -3.40 327.1554 21.27 17.64 38.91 46.00 -7.09 Vertical 117.6815 27.69 13.68 41.37 43.50 -2.13 207.1968 25.66 14.20 39.68 43.50 -3.64 342.4453 23.76 18.14 41.90 46.00 -4.10 827.1795 16.83 27.20 44.03 46.00 -1.97 Horizontal For 1GHz-25GHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading(dBV/m)Result(dBV/m)Limit(dBV/m)Margin(dBV/m) Frequency (MHz) AV PEAK Factor Corr. (dB) AV PEAKAV PEAK AV PEAK Polarizati on - - - - - - - - - - Vertical - - - - - - - - - - Horizontal Note: 1. Emissions attenuated more than 20 dB below the permissible value are not reported. 2. *: Denotes restricted band of operation. 3. The fundamental radiated emissions were reduced by Band Reject Filter in the attached plots. Page 103 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Date of Test: February 4, 2013 Temperature: 25 o C EUT: WiFi Bridge Humidity: 50% Model No.: VAP11N Power Supply: DC 5V (Power By PC) Test Mode: 802.11n Channel High 2462MHz (20MHz) Test Engineer: Pei For Below 30MHz Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor(dB) Corr. QP QP QP Polarization - - - - - - X - - - - - - Y - - - - - - Z For 30MHz-1000MHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor Corr. (dB) QP QP QP Polarization 117.9815 27.07 13.68 40.75 43.50 -2.75 330.6220 20.58 17.77 38.35 46.00 -7.65 Vertical 117.6815 28.12 13.68 41.80 43.50 -1.70 208.6580 24.22 14.23 38.45 43.50 -5.05 335.3016 23.98 17.86 41.84 6.00 -4.16 827.1795 16.40 27.20 43.60 46.00 -2.40 Horizontal For 1GHz-25GHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading(dBV/m)Result(dBV/m)Limit(dBV/m)Margin(dBV/m) Frequency (MHz) AV PEAK Factor Corr. (dB) AV PEAKAV PEAK AV PEAK Polarizati on - - - - - - - - - - Vertical - - - - - - - - - - Horizontal Note: 1. Emissions attenuated more than 20 dB below the permissible value are not reported. 2. *: Denotes restricted band of operation. 3. The fundamental radiated emissions were reduced by Band Reject Filter in the attached plots. Page 104 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Date of Test: February 4, 2013 Temperature: 25 o C EUT: WiFi Bridge Humidity: 50% Model No.: VAP11N Power Supply: DC 5V (Power By PC) Test Mode: 802.11n Channel Low 2422MHz (40MHz) Test Engineer: Pei For Below 30MHz Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor(dB) Corr. QP QP QP Polarization - - - - - - X - - - - - - Y - - - - - - Z For 30MHz-1000MHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading (dBV/m) Result (dBV/m) Limit (dBV/m) Margin (dB) Frequency (MHz) QP Factor Corr. (dB) QP QP QP Polarization 117.6815 26.91 13.68 40.59 43.50 -2.91 329.4625 20.14 17.73 37.87 46.00 -8.13 Vertical 117.6815 27.93 13.68 41.61 43.50 -1.89 190.4411 24.25 13.88 38.13 43.50 -5.37 342.4453 23.93 18.14 42.07 46.00 -3.93 827.1795 16.99 27.20 44.19 46.00 -1.81 Horizontal For 1GHz-25GHz Corrected Factor = Antenna Factor + Cable Loss – Amplifier Gain Reading(dBV/m ) Result(dBV/m)Limit(dBV/m)Margin(dBV/m) Frequency (MHz) AV PEAK Factor Corr. (dB) AV PEAKAV PEAK AV PEAK Polarizati on - - - - - - - - - - Vertical - - - - - - - - - - Horizontal Note: 1. Emissions attenuated more than 20 dB below the permissible value are not reported. 2. *: Denotes restricted band of operation. 3. The fundamental radiated emissions were reduced by Band Reject Filter in the attached plots. Page 105 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Date of Test: February 4, 2013 Temperature: 25 o C EUT: WiFi Bridge Humidity: 50% Model No.: VAP11N Power Supply: DC 5V (Power By PC) Test Mode: 802.11n Channel Middle 2437MHz (40MHz) Test Engineer: Pe…

Text truncated - open the document above for the full version.

Page 151 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 152 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 153 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 154 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 155 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 156 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 157 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 158 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 159 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 160 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 161 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 162 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 163 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 164 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 165 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 166 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 167 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 168 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 169 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 170 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 171 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 172 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 173 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 174 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 175 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 176 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 177 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 178 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 Page 179 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 10. CONDUCTED SPURIOUS EMISSION COMPLIANCE TEST 10.1.Block Diagram of Test Setup (EUT: WiFi Bridge) 10.2.The Requirement For Section 15.247(d) Section 15.247(d): In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the general limits specified in Section 15.209(a) is not required. In addition, radiated emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the radiated emission limits specified in Section 15.209(a). 10.3.EUT Configuration on Measurement The following equipment is installed on the emission measurement to meet the commission requirements and operating regulations in a manner which tends to maximize its emission characteristics in normal application. 10.3.1.WiFi Bridge (EUT) Model Number : VAP11N Serial Number : N/A Manufacturer : Shenzhen HouTian Network Communication Technology Co., Ltd. Low Loss Cable Spectrum Analyzer EUT Page 180 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 10.4.Operating Condition of EUT 10.4.1.Setup the EUT and simulator as shown as Section 10.1. 10.4.2.Turn on the power of all equipment. 10.4.3.Let the EUT work in TX modes measure it. The transmit frequency are 2412-2462 and 2422-2452MHz. We select 2412MHz, 2437MHz, 2462MHz and 2422MHz, 2437MHz, 2452MHz TX frequency to transmit. 10.5.Test Procedure 10.5.1.The transmitter output was connected to the spectrum analyzer via a low loss cable. 10.5.2.Set RBW of spectrum analyzer to 100kHz and VBW to 300kHz (below 1GHz). 10.5.3.Set RBW of spectrum analyzer to 1MHz and VBW to 3MHz (above 1GHz). 10.5.4.The Conducted Spurious Emission was measured and recorded. 10.6.Test Result Pass. The spectrum analyzer plots are attached as below. Page 181 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 TX 802.11b Channel Low 2412MHz (30MHz-1GHz) TX 802.11b Channel Low 2412MHz (1GHz-25GHz) Page 182 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 TX 802.11b Channel Middle 2437MHz (30MHz-1GHz) 08:56:37 May 7, 2012 RT C:INTUI.WMF file saved Select Marker 1234 Normal Delta Delta Pair (Tracking Ref) RefD elta Span Pair SpanCenter Off More 1 of 2 Marker Ref 5 dBm#Atten 15 dB Mkr1 474.79 MHz -58.24 dBm #Peak Log 10 dB/ Start 30 MHz #Res BW 100 kHz#VBW 300 kHz Stop 1 GHz Sweep 100.5 ms (999 pts) 1 MarkerTrace TypeX Axis Amplitude 1(1) Freq474.8 MHz-58.24 dBm TX 802.11b Channel Middle 2437MHz (1GHz-25GHz) Page 183 of 198 FCC ID: OM7-VAP11N ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20130181 TX 802.11b Channel High 2462MHz (30MHz-1GHz) 08:57:05 May 7, 2012 RT C:INTUI.WMF file saved Select Marker 1234 Normal Delta Delta Pair (Tracking Ref) RefD elta Span Pair SpanCenter Off More 1 of 2 Marker Ref 5 dBm#Att…

Text truncated - open the document above for the full version.

Conducted emissions test Radiated emissions test < 30MHz Radiated emissions test 30MHz- 1GHz Radiated emissions test > 1GHz
