OM9GNT901Pager Receiver

User’s ManualCAROL POCSAG Pager GENOTECH Co., LTD. 1 POCSAG PAGER CAROL USER’S MANUAL User’s ManualCAROL POCSAG Pager GENOTECH Co., LTD. 2 Table of Contents This device complies with Part 15 of FCC Rules. Operation is subject to the condition that this device does not cause harmful interference . CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 1. Feature 2. Buttons and Displays 3. Self Test 4. Pager Operation 1) Switching to Function Mode 2) Selecting Message Receive Alert 3) Power Off 4) Time / Clock Setting 5) Alarm Setting 6) Automatic Power ON/OFF Function 7) Message Reception and Duplicate Message Detection 8) Reading Received Message 9) Received Message Lock 10) Erasing All Received or Locked Message 11) Reading Locked Message 12) Erasing Individual of Received and Locked Message 13) Battery Replacement Display 14) Night Light Function 15) Unread Message Alert 16) Reception Area Display 17) Date, Day and Time Display User’s ManualCAROL POCSAG Pager GENOTECH Co., LTD. 3
Function Description 1. Feature - Low battery indication - Duplicate message indication - Unread message reminder - Reception area indication - Time stamp indication - Individual message erase - All message erase - Up to 15 message lock - Up to 18 message storage - Alarm - Message reception alert selection (Beep / Melody / Vibrator / Silent) 2. Buttons and Displays 1) Buttons The pager is constructed of 2 buttons; Menu / Mode and Select / Read button. 2) Menu / Mode () button A. Switch to Function Mode B. Switch to next menu in Function Mode C. Change setting D. Read locked message / Exit E. Switch to Lock and erase mode during Received Message Read F. Switch to reception mode during Time Stamp Read of received / locked message G. Manual power on in power off mode 3) Select / Read (4) button A. Selection setting in each menu of the Function Mode B. Switch to next selection in each menu of Function Mode C. Read received or locked message D. Erasing of each individual received / locked message 4) Display window LCD consists of 12 digit message display and each option and message setting icon display.
Note : the LCD display for each function may differ from the actual LCD. User’s ManualCAROL POCSAG Pager GENOTECH Co., LTD. 4 3. Self Test 1) This function is to display pager setting information to the user. 2) When () button is pressed for more than 1 seconds when inserting battery, pager enters Self Test mode and “SELF TEST” is displayed on the LCD. 3) Self Test is proceeded in the following order upon each () button press. 4) Each CAP CODE cannot be the same (duplicate) and is displayed as many as the number of actual entry. 5) Decoder Option Value, PLL Option Value, Setup Time of BS3 and BS1 are displayed. 6) After Self-Test mode sequence is completed, pager automatically enters into normal reception mode. User’s ManualCAROL POCSAG Pager GENOTECH Co., LTD. 5 4. Pager Operation 1) Switching to Function Mode A. When () button is pressed for more than 2 seconds in reception mode, pager switches to Function Mode with a beep. B. Functions are selected with each () button press in the following order : TONE?  MELODY?  VIBRATE?  SILENT?  ERASE ALL?  SET TIME?  SET ALARM?  SET AUTO?  STOP WATCH?  POWER OFF?  Standby 2) Selecting Tone (TONE?) There are 5 types of tones and the selection is as follows : A. Switch to Function Mode from reception mode by pressing () button for 2 seconds. B. Switch to selection mode by pressing (4) button while “TONE?” is displayed. C. Pager waits for selection after simple generation of the displayed tone following each () button press. D. Desired tone is selected by pressing (4) button while desired tone type is displayed and enters reception mode. E. When tone 4 is selected, different tone is generated depending on the Call Type (Function Bit) *(Please refer to 4. Note). 3) Selecting Melody (MELODY?) There are 5 types of melodies and the selection is as follows : A. Switch to Function Mode from reception mode by pressing () button for 2 seconds. B. Switch to selection mode by pressing (4) button while “MELODY?” is displayed. C. Pager waits for selection after simple generation of the displayed melody following each () button press. D. Desired tone is selected by pressing (4) button while desired melody type is displayed and enters reception mode. 4) Selecting Vibrate (VIBRATE?) The selection is as follows : A. Switch to Function Mode from reception mode by pressing () button for 2 seconds. B. Switch to selection mode by pressing (4) button while “VIBRATE?” is displayed. C. The pager vibrates for 1 second and enters reception mode. 5) Selecting Silent (SILENT?) User’s ManualCAROL POCSAG Pager GENOTECH Co., LTD. 6 The selection is as follows : A. Switch to Function Mode from reception mode by pressing () button for 2 seconds. B. Pressing (4) button make the selection while “SILENT?” is displayed and the pager enters reception mode. 6) Time / Clock Setting (SET TIME?) A. Forward to “SET TIME?” menu after entering Function Mode. B. When (4) button is pressed at “SET TIME?” menu, time is displayed in “01-01 12:00A” format starting with blinking date (day of the week). C. Whenever (4) button is pressed, the blink moves in date (day of the week), time, minute order. D. Desired setting is selected by pressing () button while desired option is being blinked. E. The date setting menu (month, day) will be active according to option setting. 7) Alarm Setting (SET ALARM?) A. Forward to “SET ALARM?” menu after entering Function Mode. B. “AL ON/OFF 12:00A?” is displayed when (4) button is pressed in “SET ALARM?” menu, and the display toggles between ON and OFF with () button press. C. When (4) button is pressed in “ON ALARM?” state, the time section blinking. D. Desired alarm time is set as the method in 6). E. When (4) button is pr…

Text truncated - open the document above for the full version.

EXTERNAL TOP SIDE EXTERNAL BOTTOM SIDE FCC ID : OM9GNT901

PROPOSED FCC ID. LABEL AND MARKING BOTTOM SIDE

INTERNAL TOP SIDE INTERNAL BOTTOM SIDE FCC ID : OM9GNT901 INTERNAL TOP SIDE INTERNAL BOTTOM SIDE FCC ID : OM9GNT901 FCC ID : OM9GNT901 FCC ID : OM9GNT901

KTL Korea Testing Laboratory 1 Page of 10 TEST REPORT This test report only responds to the tested sample and shall not be reproduced except in full without written approval of the Korea Testing Laboratory. Tested and reported by Reviewed by Soun-Kweon Seol , Senior Engineer Seok-Jin Kim , EMC Team Leader KOREA TESTING LABORATORY FG101-01-02-00 222-13, Guro-Dong Guro-Gu Seoul Korea 152-053 http://www.ktl.re.kr Ref. Report No. 99-341-034 Name and address of the applicant Genotech Co., Ltd. #4304 Ma-Dong Chungang Circulation Complex 1258, Kurobon-Dong, Kuro-Ku, Seoul, Korea 152-059 Standard / Test regulation FCC Part 15, Subpart B Test result Pass Incoming date : July 7, 1999 Test item(s) ; Communications Receiver (Pager Receiver) Model/type ref. ; GENO-900 Manufacturer ; Genotech Co.,Ltd. Additional information ; -Required Authorization :Certification -FCC ID. : OM9GNT901 Test date : July 10, 1999 Issue date : July 22, 1999 Ref. Report No. 99-341 - 034 2 Page of 10 TABLE OF CONTENTS I. GENERAL INFORMATION ............................................................................................................ 3 1. Grantee Name and Mailing Address 2. Manufacturer's Name and Mailing Address 3. Equipment Descriptions 4. Rules and Regulations 5. Measuring Procedure 6. Date of Measurement . GENERAL REQUIREMENTS OF THE EUT .................................................................4 1. Labelling Requirement (Section 15.19) 2. Information to User (Sections 15.21) 3. Special Accessories (Section 15.27) . RADIATED EMISSION MEASUREMENT (Section 15.109) ........................................................... 5-9 1. Test Procedure 2. Photograph for the worst case configuration 3. Sample Calculation 4. Measurement Data . TEST EQUIPMENTS USED FOR MEASUREMENT..................................................................10 Ref. Report No. 99 - 341 - 034 3 Page of 10 . GENERAL INFORMATION 1. Grantee Name and : Genotech Co., Ltd. Mailing Address #4304 Ma-Dong Chungang Circulation Complex 1258, Kurobon-Dong, Kuro-Ku, Seoul, Korea 152-059 2. Manufacturer's Name and: Genotech Co., Ltd. Mailing Address#4304 Ma-Dong Chungang Circulation Complex 1258, Kurobon-Dong, Kuro-Ku, Seoul, Korea 152-059 3. Equipment Descriptions 3.1 Tuning Frequency : 929.0125MHz ~ 931.9875MHz (25kHz Spacing) 3.2 Detect Method : Superheterodyne Detector 3.3 Local Oscillator: 1st Local Osc. Frequency = Tuning Frequency - 21.4MHz(1st IF) 2nd Local Osc. Frequency = 20.945MHz (2nd IF : 455kHz) 3.4 Used Crystal: 1st Local Crystal =PLL Crystal = 12.8MHz 2nd Local Crystal = 20.945MHz 3.5 Power Supply : DC 1.5V (Battery) 4. Rules and Regulations: FCC Part 15, Subpart B 5. Measuring Procedure: ANSI C63.4-1992 6. Date of Measurement 6.1 Line Conducted: Not Applicable 6.2 Radiated Emission : July 10, 1999 Ref. Report No. 99 - 341 - 034 4 Page of 10 . GENERAL REQUIREMENTS OF THE EUT 1. Labelling Requirement (Section 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. 1.1 Location on Enclosure : Manual for Installation and Operating Instruction 1.2 How Applied : Printing 2. Information to User (Section 15.21) The following or similar statements were provided in the manual for user instruction. Please refer page 2 of the attached manual for details. CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 3. Special Accessories (Section 15.27) 3.1 Were the special Accessories provided? [ ] yes, [ x ] no 3.2 If yes, details for the special accessories are as follows : 3.3 If yes, were the appropriate instructions provided on the first page of the text concerned with the device? [ ] yes, [ ] no 3.4 Are these accessories provided of the type which can be readily obtained from multiple retail outlets ? [ ] yes, [ ] no And therefore does the manual specify what additional components or accessories are required to used in order to comply with the Rules? [ ] yes, [ ] no Ref. Report No. 99 - 341 - 034 5 Page of 10 . RADIATED EMISSION MEASUREMENT (Section 15.109) 1. Test Procedure 1.1 Preliminary Testing for Reference This pager receiver(EUT) is designed to operate in the band 929.0125MHz to 931.9875MHz by changing a local oscillator installed in internal PCB. According to section 15.31(m), the measurements were performed with three equipments which were selected as bottom, middle, and top frequency in the operating band. Preliminary testing was performed in a KTL absorber-lined room to determine the emission characteristics of the EUT. The EUT was placed on the wooden table which has dimensions of 0.8 meters in height, 1 meter in length and 1.5 meters in width. Receiving antenna(Biconical antenna : 30 to 300MHz, Log-periodic antenna : 200 to 1000MHz or Horn Antenna : 1 to 18GHz) was placed at the distance of 1 meter from the EUT. An attempt was made to maximize the emission level with the various configurations of the EUT while rotating the table and varying antenna height. Emissions level from the EUT with various configurations were examined on a Spectrum Analyzer connected with a RF amplifier and graphed by a plotter. 1.2 Final Radiated Emission Test at a Absorber-Lined Room The final measurement of radiated field strength was carried out in a KTL Absorber-Lined Room that was listed up at FCC according to the "Radiated Emissions Testing" procedure specified by ANSI C63.4. Based on the test results in preliminary test, measurement was made in same test set up and configuration which produced maximum emission level. Receiving antenna was installed at 3-meter distance from the EUT, and was connected to an EMI receiver or spectrum analyzer(for above 1GHz) with a RF amplifier. Turntable was rotated through 360 degrees and receiving antenna height was varied from 1 to 4 meters above the ground plane t…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS RADIATED EMISSION
