OMCISRR12Treadmill Remote Control Transmitter

Nov. 12, 2012 To Whom It May Concern, ICON Health and Fitness request that the following documents be held confidential pursuant to 47 CFR Part 0 § 0.457 of the Freedom of Information Act, due to the proprietary nature of these documents. • Schematics • Block Diagram • Bills of Material • Operation Description Sincerely, Brent Thompson

Photo 3ExternalFront Page 83 of 86 Photo 4ExternalRear Page 84 of 86

__ OTHER .XX ± .XXX ± ANGLES ± .XX ± .X ± __ AEROBIC __ ANAEROBIC __ TREADMILLS DRAWINGS PREVIOUS TO LAST REVISION DATE ARE OBSOLETE R E V I S I O N S REV ECN DESCRIPTION OF CHANGE DATE OF THIS INFORMATION, EXCEPT FOR THE EXCLUSIVE BENEFIT OF ICON/WESLO/PROFORM IS PROHIBITED. THE INFORMATION CONTAINED HEREIN IS PROPRIETARY TO ICON/WESLO/PROFORM. ANY USE OR DISCLOSURE DATE SCALE: SHEET: TOLERANCES PRODUCTS TITLE: RELEASE APPROVALS DRAWN BY CHECKED BY ENG. APP. MANUF. APP. BASE PRODUCT: ICON B 1 1:1 ETPF40012 RING,SPEED, TOLERANCES 1OF 0.8 0.25 .03 .010 1 -- -- -- -- -- -- [328058] REV- -- 3D GEOM: 328058 DRAWN BY: ENG. APP.: MANF. APP.: CHECKED BY: -- METRIC ENGL

2.1033 (b) (2)FCC Identifier FCC ID: OMCISRR12 Figure 1 - Label and location Page 5 of 86

Photo 1InternalTop of PCB Page 81 of 86 Photo 2InternalBottom of PCB Page 82 of 86

15.247 (b) (5)RF Exposure Requirements RF Exposure – MPE Calculations (2400-2483.5 MHz Band) Transmitter Power: 0.230 mW Antenna Gain:2.3 dB Cable loss:0 dB Frequency range:2400 - 2483.5 MHz Assumptions 1. A single ¼ wavelength radiating antenna is assumed. 2. Closest exposure distance is assumed to be 0.5 cm. Calculations The following results shall be assumed to be accurate for the far-field only. These predictions will over-estimate power density in the near–field. Based on the use of a ¼ wavelength radiator, a distance of 0.5 cm is considered to be in the far-field for all cases. S = PG/4*PI*R 2 P is 0.23 mW G is 2.3 dB (Antenna gain – loss) or 10or 2.3 (2.3/10) R = (Distance in cm) 20cm10cm5cm2cm1cm0.5cm S =0.0000770.0003070.0012300.0076860.0307420.122970mW/cm 2 For Occupational/Controlled Exposure From 1,500 to 100,000 MHz, power density limit is 5 mW/cm for 6 minutes 2 For General Population/Uncontrolled Exposure From 1,500 to 100,000 MHz, power density limit is 1 mW/cm for 30 minutes 2 In accordance with FCC requirements for a portable device the following observations are observed: Maximum E.I.R.P. = 0.39mW This device is a low power radiator and the RF field which it generates is very low and therefore exposure to the radiated field is minor. Therefore it can be considered to comply with the requirements of FCC and IC to RF exposure in accordance with KDB 447498 v04. Conclusion:Device complies with FCC and IC RF Exposure requirements. Page 85 of 87

Application for Certification For a Transceiver Icon Health and Fitness, Inc. 1500 South 1000 West Logan, UT 81321 Transceiver for use with Icon products M/N: ISRR12 FCC ID: OMCISRR12 REPORT # UT36045F-001 This report was prepared in accordance with the requirements of the FCC Rules and Regulations Part 2, Subpart J, 2.1033, Part 15.247, and other applicable sections of the rules as indicated herein. Prepared By: DNB Engineering, Inc. 1100 E Chalk Creek Road Coalville, UT 84017 19 Nov 2012 TABLE OF CONTENTS Paragraph numbers in this report follow the application section numbers found in the FEDERAL COMMUNICATIONS COMMISSION Rules and Regulations, Part 2, Subpart J for Certification of electronic equipment. TABLE OF CONTENTS................................................................................................................2 1.0ADMINISTRATIVE DATA...............................................................................................3 1.1Certifications and Qualifications............................................................................3 1.2Measurement Repeatability Information.................................................................3 2.1033 (b) (1)Application for Certification...................................................................................4 2.1033 (b) (2)FCC Identifier.........................................................................................................5 2.1033 (b) (3)Installation and Operating Instructions...................................................................6 2.1033 (b) (4)Brief Description of Circuit Function.....................................................................7 2.1033 (b) (5)Block Diagram........................................................................................................8 2.1033 (b) (6)Report of Measurements ........................................................................................9 15.207Conducted Emissions (General Provisions) .............................................10 15.209Radiated Emissions (General Provisions) ................................................12 15.247 (c)Spurious Radiated Emissions....................................................................17 15.247 (a,2)6 dB Bandwidth........................................................................................30 15.247 (b)Maximum Peak Output Power (Conducted).............................................36 15.247 (d) Conducted Band Edge Measurements and Out of Band Emissions.........40 Spurious RF Conducted Emissions.......................................................................69 15.247(d): Power spectral density(PSD)....................................................................73 2.1055 Frequency stability...............................................................................................77 2.1033 (b) (7)Equipment Photographs ...........................................................................80 15.247 (b) (5)RF Exposure Requirements .................................................................................85 End of Report UT36045F-001......................................................................................................86 Page 2 of 86 1.0ADMINISTRATIVE DATA 1.1Certifications and Qualifications I certify that DNB Engineering, Inc conducted the tests performed in order to obtain the technical data presented in this application. Also, based on the results of the enclosed data, I have concluded that the equipment tested meets or exceeds the requirements of the Rules and Regulations governing this application. 1.2Measurement Repeatability Information The test data presented in this report has been acquired using the guidelines set forth in FCC Part 2.1031 through 2.1057, Part 15. The test results presented in this document are valid only for the equipment identified herein under the test conditions described. Repeatability of these test results will only be achieved with identical measurement conditions. These conditions include: The same test distance, EUT Height, Measurement Site Characteristics, and the same EUT System Components. The system must have the same Interconnecting Cables arranged in identical placement to that in the test set-up, with the system and/or EUT functioning in the identical mode of operation (i.e. software and so on) as on the date of the test. Any deviation from the test conditions and the environment on the date of the test may result in measurement repeatability difficulties. All changes made to the EUT during the course of testing as identified in this test report must be incorporated into the EUT or identical models to ensure compliance with the FCC regulations. C. L. Payne III (Para. 1.1) Facility Manager Coalville Facility. DNB Engineering, Inc. Tel. (435) 336-4433 FAX (435) 336-4436 Page 3 of 86 2.1033 (b) (1)Application for Certification Name of Applicant:Icon Health and Fitness, Inc. 1500 South 1000 West Logan, UT 81321 FRN Number:0009109950 Applicant is:XIcon Health and Fitness, Inc. Vendor Licensee Prospective Licensee Other Name of Manufacturer #1:ATR Manufacturing Co.LTD. Pingshan 188 Industrial Zone, Tangxia, 51170 Dongguan People’s Republic of China Name of Manufacturer #2:Chang Chen Instrument Co. No. 342 Tatung Road, Taiwan ROC Taoyuan Hsien Koeishang Hsiang Description:Transceiver for use with Icon products Part Number:ISRR12 Anticipated Production Quantity: Multiple Units Frequency Band:2401.3 - 2480.7 MHz Rated Power:0.230 mW Type of Signal:Digital Transmission System (DTS) Hopping Channels:40 Max Data Rate:1Mpbs (mega-bit) - Data transmission is not continuous, it happens for short intervals for short periods of time. Page 4 of 86 2.1033 (b) (2)FCC Identifier FCC ID: OMCISRR12 Figure 1 - Label and location Page 5 of 86 2.1033 (b) (3)Installation and Operating Instructions Supplied separately. Page 6 of 86 2.1033 (b) (4)Brief Description of Circuit Function Theory of Operati…

Text truncated - open the document above for the full version.

1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:5 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Conducted Band Edge Measurement - Single Channel Freq Delta (MHz) Pass/Fail Limit Lower (MHz)Upper (MHz) 24002401.7401.740Pass Page 41 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:5 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Conducted Band Edge Measurement - All Channels Freq Delta (MHz) Pass/Fail Limit Lower (MHz)Upper (MHz) 24002401.6381.638Pass Page 42 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Horz - X Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 24002400.39154.045.37-8.630.391Pass Page 43 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Horz - Y Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 24002400.30454.047.56-6.440.304Pass Page 44 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Horz - Z Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 24002400.92754.043.41-10.590.927Pass Page 45 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Vert - X Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 24002400.33354.045.33-8.670.333Pass Page 46 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Vert - Y Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 24002400.30454.047.34-6.660.304Pass Page 47 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Vert - Z Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 24002400.24654.048.18-5.820.246Pass Page 48 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:1 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT perfo…

Text truncated - open the document above for the full version.

1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Vert - X Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.59654.042.68-11.32-1.904Pass Page 60 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Vert - Y Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.65454.043.35-10.65-1.846Pass Page 61 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - Single Channel - Vert - Z Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.66954.041.99-12.01-1.831Pass Page 62 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - All Channels - Horz - X Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.51054.042.71-11.29-1.990Pass Page 63 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - All Channels - Horz - Y Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.24954.041.80-12.20-2.251Pass Page 64 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - All Channels - Horz - Z Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.53854.042.54-11.46-1.962Pass Page 65 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - All Channels - Vert - X Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.52454.042.92-11.08-1.976Pass Page 66 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247(d) 1Mbps data rate (Basic data rate) Ambient TemperatureRelative HumidityBarometric Pressure 19 EC28 %101.8 kPa EUT performed within the requirements of the applicable standard [X] Yes [ ] NoLes Payne Radiated Corrected Band Edge Measurement - All Channels - Vert - Y Axis Freq Delta (MHz) Pass/Fail Limit Lower (MHz) Upper (MHz) Limit (dBuV/m) Measured (dBuV/m) Delta (dBuV) 2483.5002481.55354.041.64-12.36-1.947Pass Page 67 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Band Edge Measurements DNB Job Number:36045Date:2 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness,…

Text truncated - open the document above for the full version.

1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Radiated Emissions (General) DNB Job Number:36045Date:22 Oct 2012Specification [X] 15.209 [X] IEEE C63.10 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon products Test Set Up - Bicon - Horizontal Page 14 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Radiated Emissions (General) DNB Job Number:36045Date:22 Oct 2012Specification [X] 15.209 [X] IEEE C63.10 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon products Test Set Up - Log Periodic - Horizontal Page 15 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Radiated Emissions (Spurious) DNB Job Number:36045Date:25 Oct 2012Specification [X] 15.247 (c) [X] IEEE C63.10 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon products Test Set Up - X-Axis (Horizontal/Vertical - Bicon / Log Periodic / DRG) Page 18 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Radiated Emissions (Spurious) DNB Job Number:36045Date:25 Oct 2012Specification [X] 15.247 (c) [X] IEEE C63.10 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon products Test Set Up - Y-Axis (Horizontal/Vertical - Bicon / Log Periodic / DRG) Page 19 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Radiated Emissions (Spurious) DNB Job Number:36045Date:25 Oct 2012Specification [X] 15.247 (c) [X] IEEE C63.10 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon products Test Set Up - Z-Axis (Horizontal/Vertical - Bicon / Log Periodic / DRG) Page 20 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Measurement Test Set Up DNB Job Number:36045Date:5 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247 Antenna Conducted Measurement Set Up Page 31 of 86 1100 E Chalk Creek Road Coalville, UT 84017 (435) 336-4433 FAX (435) 336-4436 Measurement Test Set Up DNB Job Number:36045Date:5 Nov 2012Conformance Standard FCC Part 15 Customer:Icon Health and Fitness, Inc. Model Number:ISRR12 Description:Transceiver for use with Icon productsClause 15.247 Frequency Stability Measurement Set Up Page 78 of 86
