ON2BT3READER01Wireless RFID Reader

20 For more information contact AgInfoLink at 800-287-8787 FCC Compliance Information: Wireless RFID Tag Reader Bluetooth Communication Model 2 19 Notes: 18 BT3 Reader Specifications: • Repeated six-foot drop test to concrete • Physical Shock Test: >5 00G for 40 milliseconds • Water- and dust-resistant (NEMA 12 / I.P. 65) • Infrared trigger • Power: 9.6-Volt Makita rechargeable battery, model 9000 and 9033 • Multiple hours of continuous operation • Fast charger recharges battery in under one hour • RFID Reader: 134.2 KHz, ISO 11785 • Reads Full Duplex (FDXB) and Half Duplex (HDX) tags • RF communication: Bluetooth™ Class 1 • Bluetooth™ communication settings: • 115,200 Baud Standard (Configurable from 244 baud to 1.38 Mbaud in multiples of 244) • Parity: None • Data Bits: 8 • Stop Bits: 1 • “Server” or “Client” device modes • Communication range: Up to 330 ft., line-of-site • Factory default communication PIN: 1234 • U.S. Patent No. 6,346,885 3 Table of Contents: 4 - Overview 5 - Reader Parts 6 - Operation Notes 7 - Battery 8 - Bluetooth on a PDA 11 - Communication with a PDA 12 - Bluetooth on a Laptop or Desktop 13 - External Bluetooth Transceivers 14 - Communicating with a computer 15 - Communicating with a Scale 16 - Multiple Wireless Devices with one Computer 18 - Reader Specifications 19 - Notes 20 - FCC and Company Contact Information 4 The BT3 Wireless RFID Tag Reader is an environmentally-robust device that reads RFID (radio frequency identification) tags and communicates the tag number, wirelessly, back to a host device such as a computer or PDA. This means you’re no longer “tethered” to your computer — you can move about and scan items at will, sending the ID’s to the computer, wire-lessly. And, if you’re using the BT3 with a PDA, you can keep the rugged reader separate from the less-rugged hand-held PDA. BT3’s RFID reader is ISO (International Standards Organiza-tion) 11785-compliant and is capable of reading all ISO 11784 RFID tags, including both full duplex (FDX) and half duplex (HDX) tag versions. Features Overview: • Rugged construction • Water and dust-resistant (NEMA 12 / I.P. 65) • Removable, long-lasting battery • Infrared trigger doesn’t wear out • Allows for long reach into tight or dangerous areas • Only one moving part (On\Off switch) • Communicates wirelessly with host devices via Blue-tooth™ • Works with PDA’s, peripherals, desktop and laptop computers. • Can be configured as a Bluetooth™ (BT) Client or Server • User-definable communication and security settings, in-cluding password protection BT3 Overview 17 Laptop or Desktop Computer Multiple BT Devices Commu- nicating With One Computer BT-Equipped Scale Indicator BT Transceiver BT transceiver re-ceives the tag ID from BT3 and weight from scale and passes the values to the host computer software. BT Scale and BT3 Reader each send data sepa-rately to one host com-puter applica-tion, wire-lessly, from up to 330 ft. away. Custom Commu-nication Software on host computer 16 Using Multiple Wireless Devices With One Computer • With the right hardware, it’s possible to have more than one device communicating with the host computer. • For instance, two BT3 readers or one BT3 and one scale may communicate with the host computer. • When setting up a computer that’s capable of communi-cating with multiple BT devices, assign a different COM port to each BT device. • Important: Custom host computer software is usually neces-sary to communicate with more than one device. 5 TT2 Reader Parts Target “sweet spot” for read-ing RFID Tags. Also acts as recess for com-pany logo. Battery compart-ment with thumb screw and hinged door. Low battery LED indica-tor. Flickers red / green when low battery. Loop for attach-ing lanyard. Reader activation and tag-read LED indicator. Red when looking for tag; flickers yellow when a tag is read (also will hear a “beep”). On/Off toggle switch — flip it, don’t push it! Infrared trig-ger. Place finger here to read a tag. 6 BT3 Operation Notes Important — Notes and Pointers — Please Read • When turning the reader on, flip (don’t push) the On/Off toggle toward the side of the reader showing the metal screw heads. • The reader “beeps” once when first turned on. • To trigger a read, grip the reader just behind the On/Off switch to break the infrared beam. • Once the reader begins looking fo r a tag, it will remain in the “read” mode for at least ten seconds and the red LED near the end of the reader will remain on. • If the reader “times out”, you will need to grip the infrared trig- ger again so the reader will begin a new tag search. • If a tag is read before the reader times out, the reader will stay in read mode and will continue to search for tags. • When connecting to your computer or PDA you may be asked for a PIN. The factory default PIN is: 1234 . • If the reader will be idle for more than a half hour, use the tog-gle switch to turn the reader off. Also make sure to “Exit” the software application on your PDA or host computer. • To reconnect, turn on the reader, then re-start your application software and follow the Bluetooth connection instructions. • The “Low Battery” indicator LED above the trigger will flash red when the battery needs to be charged. • NEVER turn the BT3 reader off while your host application is running. Always exit the application prior to turning off the reader. 15 Reader reads RFID tag from several inches away. The reader sends ID to BT-enabled scale, wirelessly, up to a 330 feet away. Communicating With a Scale Scale’s internal or external BT Transceiver accepts tag ID and displays “record” on scale indicator. ( ( ( BT-Equipped Scale Indicator • It’s possible to send tag ID’s directly to a scale or other peripheral device if that device is Bluetooth-capable. 14 ( ( ( Laptop or Desktop Computer BT Transceiver BT transceiver receives the tag ID and passes it to the computer’s soft-ware application . The reader sends tag ID to the computer’s BT transceiver, wirelessly, up …
