DTR4000CA User Manual Satellite Solutions Copyright© 1999 GLOBAL TELEMANN SYSTEMS Inc. All rights reserved. This manual is subject to change without prior notice. GLOBAL TELEMANN SYSTEMS Inc. TEL:+1 408 955 7750 / FAX:+1 408 955 7740 2345 Harris Way, Suite 100, San Jose, CA95131, USA E-mail : [email protected] WWW : http://www.telemann.com DTR4000CA Safety Precautions Table of Contents INTRODUCTION ................................................................................................................................................. 6 A BOUT THIS MANUAL.......................................................................................................................................... 6 G ENERAL DESCRIPTION........................................................................................................................................ 6 G ENERAL FEATURES............................................................................................................................................. 6 HARDWARE DESCRIPTION............................................................................................................................. 7 F RONT PANEL CONFIGURATION............................................................................................................................ 7 R EAR PANEL CONFIGURATION............................................................................................................................. 9 H OW TO CONNECT YOUR DTR4000CA TO VARIOUS SYSTEMS......................................................................... 10 REMOTE CONTROL ........................................................................................................................................ 12 R EMOTE CONTROL UNIT.................................................................................................................................... 12 SYSTEM SET-UP................................................................................................................................................ 14 B ASIC MENU OPERATION................................................................................................................................... 14 F LOW OF MENU SYSTEM.................................................................................................................................... 15 A UTOMATIC CHANNEL SET-UP........................................................................................................................... 17 Automatic channel set-up for a satellite ........................................................................................................ 17 Automatic channel set-up for a transponder ................................................................................................. 17 MENU OPERATION .......................................................................................................................................... 18 M AIN MENU....................................................................................................................................................... 18 C HANNEL GUIDE................................................................................................................................................ 18 TV and Radio Channel Guide........................................................................................................................ 18 C HANNEL LIST................................................................................................................................................... 19 TV and Radio Channel List ........................................................................................................................... 19 P ARENTAL CONTROL.......................................................................................................................................... 19 PIN Code / TV and Radio Lock ..................................................................................................................... 19 I NSTALLATION.................................................................................................................................................... 20 PIN Code ? .................................................................................................................................................... 20 LNB Configuration ........................................................................................................................................ 21 Channel Search ............................................................................................................................................. 22 Edit Channels ................................................................................................................................................ 23 Edit TV Channel.......................................................................................................................................................... 23 Edit Radio Channel...................................................................................................................................................... 24 Add to Favorite............................................................................................................................................................ 24 Edit Favorite Channel.................................................................................................................................................. 25 System Settings .............................................................................................................................................. 26 Change PIN ................................................................................................................................................... 26 PIN Code ......................................................................…

Text truncated - open the document above for the full version.

DTR4000CA User Manual Satellite Solutions Copyright© 1999 GLOBAL TELEMANN SYSTEMS Inc. All rights reserved. This manual is subject to change without prior notice. GLOBAL TELEMANN SYSTEMS Inc. TEL:+1 408 955 7750 / FAX:+1 408 955 7740 2345 Harris Way, Suite 100, San Jose, CA95131, USA E-mail : [email protected] WWW : http://www.telemann.com DTR4000CA Safety Precautions Table of Contents INTRODUCTION ................................................................................................................................................. 6 A BOUT THIS MANUAL.......................................................................................................................................... 6 G ENERAL DESCRIPTION........................................................................................................................................ 6 G ENERAL FEATURES............................................................................................................................................. 6 HARDWARE DESCRIPTION............................................................................................................................. 7 F RONT PANEL CONFIGURATION............................................................................................................................ 7 R EAR PANEL CONFIGURATION............................................................................................................................. 9 H OW TO CONNECT YOUR DTR4000CA TO VARIOUS SYSTEMS......................................................................... 10 REMOTE CONTROL ........................................................................................................................................ 12 R EMOTE CONTROL UNIT.................................................................................................................................... 12 SYSTEM SET-UP................................................................................................................................................ 14 B ASIC MENU OPERATION................................................................................................................................... 14 F LOW OF MENU SYSTEM.................................................................................................................................... 15 A UTOMATIC CHANNEL SET-UP........................................................................................................................... 17 Automatic channel set-up for a satellite ........................................................................................................ 17 Automatic channel set-up for a transponder ................................................................................................. 17 MENU OPERATION .......................................................................................................................................... 18 M AIN MENU....................................................................................................................................................... 18 C HANNEL GUIDE................................................................................................................................................ 18 TV and Radio Channel Guide........................................................................................................................ 18 C HANNEL LIST................................................................................................................................................... 19 TV and Radio Channel List ........................................................................................................................... 19 P ARENTAL CONTROL.......................................................................................................................................... 19 PIN Code / TV and Radio Lock ..................................................................................................................... 19 I NSTALLATION.................................................................................................................................................... 20 PIN Code ? .................................................................................................................................................... 20 LNB Configuration ........................................................................................................................................ 21 Channel Search ............................................................................................................................................. 22 Edit Channels ................................................................................................................................................ 23 Edit TV Channel.......................................................................................................................................................... 23 Edit Radio Channel...................................................................................................................................................... 24 Add to Favorite.............................................................................................................Error! Bookmark not defined. Edit Favorite Channel...................................................................................................Error! Bookmark not defined. System Settings .................................................................................................Error! Bookmark not defined. Change PIN ......................................................................................................Error! Bookmark not defined. PIN Code ......................................................................................................................Error! Bookmark not defined. Receive…

Text truncated - open the document above for the full version.

DTR4000CA Menu Operation
DTR4000CA program list. Edit Radio Channel You can delete the unnecessary Radio Channels from the registry of DTR4000CA.
In Edit Channel menu, select Edit Radio Channel menu. Then the following screen pops up
From the channel list on the screen, you select the channel that you do not want to watch. Then click “F3” button twice. The channel disappears from the DTR4000CA program list. Add to Favorite Your favorite channels can be saved to your favorite channel list. So, later you can easily find your favorite channels from the list.
In Edit Channel Menu, select Add to Favorites. Then the following screen pops up
For the left side of the screen, you can choose TV channels or Radio Channels in a consecutive way by pushing “
” on the Remote Control. DTR4000CA Menu Operation
For Favorite channel side, by clicking “FAV” button on the Remote Control, you can choose your favorite channel group out of 12 favorite groups such as Sports, Children, Music, Arts/Culture, Social, Education, Leisure, Special, User, Movie/Drama, News, Show/Game
After selecting a channel that you want to save into the favorite channel list, by pressing “F1”, you can add the channel into the favorite channel list. Edit Favorite Channel You can delete channels from your favorite channel list, and you can change the order of channel selection priority.
In Edit Channel Menu, select Edit Favorite Channel. Then the following screen pops up
From the favorite channel list on the screen, you select the channel that you do not want to watch. Then click “F3” button twice. The channel disappears from the DTR4000CA program list.
In order to change channel selection priority, highlight the channel that you want to upgrade the priority by Up/Down key and push “OK” button of the Remote Control. Then by using Up/Down key, bring the channel the right place and click “OK” button again. Then the moved channel resides in that place from that time. System Settings This menu helps you set up several thing such as TV Select, PAL mode, and Factory Default, and etc.
Select the DTR4000CA setup submenu on the Main Menu. The following submenu will show up on your TV. DTR4000CA Menu Operation TV selectSelects the type of TV Receiver – RGB, CVBS, S-VHS Local TimeSelects local time by 30 minute unit RF ChannelSelect or input RF channel number when DTR4000CA is connected to TV by RF connector. PAL ModeIn the above case, you can choose PAL standard mode. Antenna Line LengthIf the line from antenna to DTR4000CA is too long, choose “long”, otherwise “choose “short” Factory DefaultSelect this option when you want to change all setting to Factory default. * In this case, all setting information of Channel, LAN, and System settings will be erased. Screen TypeYou can choose either 4:3 or 16:9 according to the TV type. Change PIN PIN Code You can change PIN number with this menu
Select Change PIN menu from the MAIN menu.
When you are asked to enter PIN Code, you enter current PIN Code. Then you will be DTR4000CA Menu Operation asked for new PIN Code. You enter new PIN code, and the system re-asks you to repeat the PIN Code. If you enter the new PIN Code again, then the PIN code is permanently changed. ** Be sure not to forget the PIN code. If you forget the PIN Code, you have to contact the distributor to clear up the problem Receiver Update
At the moment, the DTR4000CA can be upgraded via RS-232C cable from the PC. The upgrade software can be downloaded from the manufacturer’s web site. “Http://WWW.Telemann.com".
Upgrade through Satellite will be added later. Auto Installation Based on the Satellite and Transponder information attached at the end of this manual, DTR4000CA automatically sets all channels from a Satellite. This information may change from time to time. When you cannot receive any signal from any satellite or transponder, check the information of those satellite or transponder.
Select the Auto Installation from the MAIN menu. LNB SelectionFrom LNBs that you set up in LNB Setup menu, select one LNB. Region SelectionSelects from Europe, Asia, or America based on where the DTR4000CA is used. Satellite SelectionSelect the satellite that you wants.
After you set up the above three menus, press “OK”. Then, DTR4000CA will start to automatically search and set channels. To search the whole satellite, It will take time.
The Factory Default Satellite information is listed in Annex “Factory Default Satellite Information”. This satellite information can be updated. For upgrade, please refer to the manufacturer’s web site. DTR4000CA Menu Operation AccessGate AcessGate is a kind of Conditional Access System(CAS) manufactured by Global Telemann Systems Inc. CAS allows a service provider to provide its subscribers a variety of services such as Pay-Per-View Service by using a smart card. In a person’s smart card, there is the information of what channel group that person can access to, how much tokens are left in the smart card, and what are the usage record. After a certain time has passed, this information is sent back to the service provider. The service provider uses this information to charge its subscriber. To access the CAS service, a subscriber should contact the Service Provider and get assigned a Smart Card. At the main menu when you select the AccessGate, you will be asked to enter smart card PIN number. Please enter smart card PIN number that you are given when you subscribe to a service provider Entitlement Entitlement shows you what service groups you subscribe to, what channels you can watch, and the remaining amount of the token. Token is a kind of money by which you can pay for watching TV. DTR4000CA Menu Operation Group Entitlement Group entitlement displays what groups you subscribe to as of now. For detailed explanation about Group, please see materials given by the service provider. With one smart card, a subscriber can watch up to 20 groups. For group selection, please contact the se…
