COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 48 of 89 Exhibit 8 Exhibit 8: User’s Manual Since the 2MOD-6322-A411 is certified as a modular transmitter. There is not a user’s manual that is supplied. Enclosed is a certification application, since this is an internal confidential document Canac has requested that it be held confidential (see Request for Confidentiality in Exhibit 13). This certification application was sent as a separate pdf file.

ConfidentialPage 106/26/00 Page 1 of 30 Certification Application For Federal Communications Commission CANAC Radio Transmitter Model #:2MOD-6322-A411 (450-460 MHz, 12.5 KHz channel spacing) 2MOD-6322-A511 (460-470 MHz, 12.5 KHz channel spacing) May 31, 2000 ConfidentialPage 206/26/00 Page 2 of 30 Table of Contents 1.0CONTEXT OF OPERATION:...................................................................................................3 2.0GENERAL DESIGN OVERVIEW............................................................................................5 2.13FSK PARTIAL RESPONSE MODULATOR.....................................................................................5 2.2UP-CONVERTER.......................................................................................................................11 2.4RF PULSE SHAPING-................................................................................................................12 2.3POWER AMPLIFIER AND RX/TX SWITCH..................................................................................14 2.4SYNTHESIZER..........................................................................................................................15 2.5MICRO-CONTROLLER...............................................................................................................16 2.6DC POWER SUPPLY.................................................................................................................17 3.0TRANSMITTER CONTROL SOFTWARE DESCRIPTION...................................................................18 3.1-ADVANCED TEST JIG:...............................................................................................................18 4.0TEST PROCEDURE....................................................................................................................20 4.1PROGRAMMING AND TCXO ADJUSTMENT................................................................................20 4.1.1Set-up..............................................................................................................................20 4.1.2Procedure.......................................................................................................................21 4.3SYNTHESIZER VERIFICATION....................................................................................................22 4.3.1Set-up..............................................................................................................................22 4.3.2Procedure.......................................................................................................................23 4.4FREQUENCY PULLING VERIFICATION........................................................................................24 4.5TEMPERATURE TESTING...........................................................................................................24 4.5.1Set up..............................................................................................................................24 4.5.2Procedure.......................................................................................................................25 4.6OUT OF BAND SPURIOUS EMISSION...........................................................................................25 5.0FCC TEST REPORT................................................................................................................26 5.1INTRODUCTION........................................................................................................................26 5.2TRANSMITTER EXTERNAL CONTROLS:......................................................................................27 5.3SUPPLY VOLTAGE AND TEMPERATURE:....................................................................................27 5.4TYPICAL OUTPUT POWER:........................................................................................................27 5.5CHANNEL SPACING, AUTHORISED BANDWIDTHS, SPECTRUM MASK AND RESULTS:...................27 5.6SPURIOUS EMISSION.................................................................................................................28 5.7TRANSIENT FREQUENCY BEHAVIOUR.......................................................................................29 5.8VOICE INPUT...........................................................................................................................29 5.9FREQUENCY STABILITY............................................................................................................29 5.9DIFFERENCE BETWEEN MODELS...............................................................................................30 5.9.1RF Output Frequency......................................................................................................30 ConfidentialPage 306/26/00 Page 3 of 30 Technical Description The present document describes each functional block of the radio. The information regarding calculations of the detailed design; PLL loop filter, impedance matching, VCO tank circuit etc. are described in the DESIGN DETAIL of the RF Radio and is available upon request. The module contains only a transmitter however the hardware is ready to install a future receiver. 1.0Context of Operation: The main purpose of this radio is to enable the locomotive engineer to remotely control the locomotive in the yard. The locomotive engineer is equipped with an operator control unit (OCU) and communicates with the locomotive directly or via a repeater unit (RPU) that is well located within the yard. Other purposes include any type of tele- operating system. The overall system must support many operators on the same frequency with different time slots (TDMA) in half duplex. The frequencies used are between 450-470 MHz and 806-870 MHz. The radio transmits at 9.6 Kbaud in a 12.5 KHz or 4.8 Kbaud in a 6.25 KHz channel spacing at a maximum power of 1 Watt. ConfidentialPage 406/26/00 Page 4 of 3…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 88 of 89 Exhibit 13 Exhibit 13: Cover Letters June 27, 2000 FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: Enclosed is a FCC Part 90, Certification application for the Canac Inc. Model 2MOD-6322-A411, FCC ID: OPQ2MOD-6322. Please let me know if I can be of further assistance. Sincerely yours, COMMUNICATION CERTIFICATION LABORATORY Joseph W. Jackson V.P. Marketing COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 89 of 89 Exhibit 13 Request for Confidentiality

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 5 of 89 Exhibit 3 Exhibit 3: Photographs of Overall Appearance Front View of the 2MOD-6322-A411 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 6 of 89 Exhibit 3 Back View of the 2MOD-6322-A411 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 7 of 89 Exhibit 3 Side View of the 2MOD-6322-A411 showing the RS-232 connector COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 8 of 89 Exhibit 3 End View of the 2MOD-6322-A411 showing the antenna connector COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 9 of 89 Exhibit 3 Antenna COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 10 of 89 Exhibit 3 Test jig used for testing purposes only

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 1 of 89 Exhibit 1 Exhibit 1: FCC ID Label In accordance with the requirements of Sections 15.19 (a), 2.925 and 2.926 of the FCC Rules, the following information will be permanently placed on the Canac Inc. Model 2MOD-6322-A411 as shown in the photograph on the following page. The 2MOD-6322- A411 is to be certified as a module; therefore, the label shown below will be provided with the 2MOD-6322-A411 to be affixed on the outside of the host system which it is installed. Label to be placed on the 2MOD-6322-A411 Compliance Statement to be placed on the 2MOD-6322-A411 Label to placed on host system COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 2 of 89 Exhibit 1 Label placement sketch COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 3 of 89 Exhibit 1 Photograph showing label placement

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 49 of 89 Exhibit 9 Exhibit 9: Internal Photographs Inside view of 2MOD-6322-A411 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 50 of 89 Exhibit 9 Component side of the board (with RF cans installed) COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 51 of 89 Exhibit 9 Component side of the board (with RF cans removed) COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 52 of 89 Exhibit 9 Solder side of board

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 74 of 89 Exhibit 11 Exhibit 11: RF Exposure/Environmental Evaluation COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 75 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 76 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 77 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 78 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 79 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 80 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 81 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 82 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 83 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 84 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 85 of 89 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 86 of 89 Exhibit 11

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 13 of 89 Exhibit 6 Exhibit 6: Test Report TEST REPORT FROM: COMMUNICATION CERTIFICATION LABORATORY 1940 W. Alexander Street Salt Lake City, UT 84119-2039 U.S.A. Tel: (801) 972-6146 Fax: (801) 972-8432 TEST OF: 2MOD-6322-A411(450-460 MHz, 12.5 kHz channel spacing) To Part 90 Subpart D and Part 2 Subpart J of the FCC Rules and Regulations Test Report Serial No: 73-7209 APPLICATION FOR CERTIFICATION: Modular Transmitter Applicant: Canac Inc. 3950 Hickmore Avenue St. Laurent, Quebec Canada H4T 1K2 Dates of Test: June 12 - 26, 2000 Issue Date: June 27, 2000 Equipment Receipt Date: June 1, 2000 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 14 of 89 Exhibit 6 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Communication Certification Laboratory to verify compliance of the device described below with the requirements to Part 2 Subpart J and Part 90 Subpart D of the FCC Rules and Regulations. This report may be reproduced in full, partial reproduction may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. -Applicant:Canac Inc. -Manufacturer:Canac Inc. -Model Number:2MOD-6322-A411 -FCC ID:OPQ2MOD-6322 -Brand Name:CANAC On this 27 th day of June 2000, I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. COMMUNICATION CERTIFICATION LABORATORY Checked by: William S. Hurst, P.E. Vice President Tested by: Roger J. Midgley EMC Engineering Manager COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 15 of 89 Exhibit 6 SECTION 1. Measurement Requirements 1.1 Introduction The following data is submitted for Certification of a RF modular radio for Canac Inc., in accordance with Part 2, Subpart J and Part 90, Subpart D of FCC Rules and Regulations. The 2MOD-6322-A411 was tested as a stand-alone, but the main application is to transmit data from a CANAC communication board (encoder board) installed in an enclosure (OCU) to remotely control locomotives. The 2MOD-6322-A411 is to be certified as a module; therefore, the following items are applicable: 1. The 2MOD-6322-A411 provides its own RF shielding and does not rely on the host system in which it is installed to provide shielding. 2. The 2MOD-6322-A411 provides buffered modulation and data inputs; therefore, the type of modulation or the data input rate does not affect the RF output power. (See theory of operation in Exhibit 12 section 2.1 3FSK Partial Response Modulator) 3. The 2MOD-6322-A411 can operate on 10.0 to 24.0 VDC provided by the encoder board; however, the 2MOD-6322-A411 provides its own power supply regulation that delivers 5.8 VDC and 5.2 VDC to the transmitter regardless of the input voltage. (See theory of operation in Exhibit 12 section 2.6 DC Power Supply) 4. The 2MOD-6322-A411 was tested as a stand-alone device connected to an interface jig to provide DC power and data input during the tests. (See Photos in Exhibits 7 and 9). 5. The 2MOD-6322-A411 is labeled with its own FCC ID number and compliance statement. When the 2MOD-6322-A411 is installed inside of a host system and the FCC ID number on the transmitter is not visibly from the outside, a separate label is provided for the outside of the host system listing the transmitters FCC ID number. (See labels in Exhibit 1). 6. RF exposure limits. (See Exhibit 11) This application is for the transmitter portion only; the digital portion was tested and complies with the Verification procedures according to FCC Part 15 Subpart B. COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 16 of 89 Exhibit 6 Shown below is a block diagram of the OCU. 1.2 Measurements Required for Certification § 2.1033 (c)(14) Measurement Data The measurement data that is required by § 2.1046 through § 2.1057 is included in Section 2 of this report. The data was measured in accordance with the procedures set out in § 2.1041. § 90.203 (j)(3) Spectrum Efficiency Application for part 90 certification of transmitters designed to operate on frequencies in the 150-174 and/or 421-512 MHz bands, received on or after February 14, 1997, must include a certification that the equipment meets a spectrum efficiency standard of one voice channel per 12.5 kHz of channel bandwidth. Additionally, if the equipment is capable of transmitting data, has transmitter output power greater than 500 mW, and has a channel bandwidth of more than 6.25 kHz, the equipment must be capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-7209 FCC ID: OPQ2MOD-6322 Page 17 of 89 Exhibit 6 § 2.1046 RF Power Output - § 90.205 § 2.1046 (a) For transmitters other than single sideband, independent sideband and controlled carrier radiotelephone, power output shall be measured at the RF output terminals when the transmitter is adjusted in accordance with the tune-up procedure to give the values of current and voltage on the circuit elements specified in § 2.983 (d)(5). § 90.205 Transmitter power shown on the radio station authorization is the maximum power the licensee is authorized to use. § 2.1047 Modulation Characteristics - § 90.211 The 2MOD-6322-A411 uses FM modulation via a 3FSK modulator by means of a direct digital synthesizer (DDS) and transmits non- voice information; therefore, this section does not apply. § 2.1049 Occupied Bandwidth - § 90.209 § 2.1049 The occupied bandwidth, that is the frequency bandwidth such that, below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5 percent of the total mean power radiated by a given emission shall be measured under the following conditions: …
