OPQ2MOD-6413

Document p/n: 9M02-6413-B001, Rev. A Product Design CANAC Radio Transmitter 450 MHz User and Operation Manual Document p/n: 9M02-6413-B001, Rev. A CONFIDENTIALITY NOTICE The information contained in this document is confidential and proprietary to CANAC INC. None of the information contained in this report may be reproduced or disclosed to any other party without prior written consent of the Director of Product Design -- CANAC INC.  1999 CANAC Inc. Document p/n: 9M02-6413-B001, Rev. A Revision History DateRevisionDescriptionSignature / Date 10/13/99AInitial DRAFTPrepared Francois Methot VerifiedLuc Ethier ApprovedLuc Ethier mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved mm/dd/yyPrepared Verified Approved Document p/n: 9M02-6413-B001, Rev. A TABLE OF CONTENTS page TECHNICAL DESCRIPTION.............................................................................................................................1 1.0CONTEXT OF OPERATION:..........................................................................................................................1 2.0GENERAL DESIGN OVERVIEW.....................................................................................................................4 2.13FSK Partial Response Modulator.......................................................................................................4 2.2Up-Converter.......................................................................................................................................9 2.3Output Amplifier.................................................................................................................................11 3.0TRANSMITTER CONTROL SOFTWARE DESCRIPTION...................................................................................12 3.1-Advanced test jig:...............................................................................................................................12 TEST PROCEDURE RF BOARD......................................................................................................................14 TEST 1 - PROGRAMMING AND TCXO ADJUSTMENT.............................................................................................14 Set-up............................................................................................................................................................14 Procedure......................................................................................................................................................15 TEST 2 - SYNTHESIZER VERIFICATION.................................................................................................................16 Set-up............................................................................................................................................................16 Procedure......................................................................................................................................................17 TEST 3 - FREQUENCY PULLING VERIFICATION......................................................................................................18 TEST 4 - TEMPERATURE TESTING........................................................................................................................18 Set up.............................................................................................................................................................19 TEST 5 - OUT OF BAND SPURIOUS EMISSION..........................................................................................................19 FCC COMPLIANCE...........................................................................................................................................21 Document p/n: 9M02-6413-B001, Rev. A CANAC Radio TransmitterProprietary and ConfidentialPage 1 Technical Description The present document describes each functional block of the radio. The information regarding calculations of the detailed design; PLL loop filter, impedance matching, VCO tank circuit etc. are described in the DESIGN DETAIL of the RF Radio and is available upon request. The module contains only a transmitter but the hardware is ready to install a future receiver. 1.0Context of Operation: The purpose of this radio is to enable the locomotive engineer to remotely control the locomotive in the yard. The locomotive engineer is equipped with an operator control unit (OCU) and communicates with the locomotive directly or via a repeater unit (RPU) that is well located within the yard (figure 1). The overall system must support many operators on the same frequency with different time slots (TDMA) in half duplex. The frequencies used are between 450-470 MHz . The radio transmits at 19.2 Kbaud in a 25 KHz (or 9.6 Kbaud in a 12.5 KHz or 4.8 Kbaud in a 6.25 KHz) channel spacing at a maximum power of 1 Watt. Figure 1 Repeater Unit (RPU) TX= 455.5125 MHz RX= 455.5125 MHz TX= 460.5125 MHz. Operator Control Unit (OCU) Receiver Decoder Unit (RDU) Document p/n: 9M02-6413-B001, Rev. A Technical Description CANAC Radio TransmitterProprietary and ConfidentialPage 2 View of the Transmitter board @ 455 MHz Document p/n: 9M02-6413-B001, Rev. A CANAC Radio TransmitterProprietary and ConfidentialPage 3 Figure 3 Block Diagram of the Transmitter DDS modulator AD 9850 Band Pass Up Converter SA900 Band Pass Power Amplifier Isolator RX/ TX DDS CLK VCO control VCO control 2nd VCO out SA900 control DDS control TX/RX control 10.7 MHz. Filter TX DATA KEY Control Reset Power Supply 5.8 v. 5 v. Battery voltage (Page 2 of 3) (Page 1 of 3) (Page 1 of 3) U103 (Page 1 of 3) U101 (Page 1 of 3) Y101 (Page 3 of 3) U506 (Page 2 of 3) U701,U702, (Page 3 of 3) U501 (Page 3 of 3)…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 108 of 123 Exhibit 11 Exhibit 11: RF Exposure/Environmental Evaluation COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 109 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 110 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 111 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 112 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 113 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 114 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 115 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 116 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 117 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 118 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 119 of 123 Exhibit 11 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 120 of 123 Exhibit 11

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 122 of 123 Exhibit 13 Exhibit 13: Cover Letters September 20, 1999 FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: Enclosed is a FCC Part 90, Certification application for the Canac Inc. Model 2MOD-6413-xxxx, FCC ID: OPQ2MOD-6413. Please let me know if I can be of further assistance. Sincerely yours, COMMUNICATION CERTIFICATION LABORATORY Joseph W. Jackson V.P. Marketing COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 123 of 123 Exhibit 13 Request for Confidentiality

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 5 of 123 Exhibit 3 Exhibit 3: Photographs of Overall Appearance Front View of the 2MOD-6413-xxxx COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 6 of 123 Exhibit 3 Back View of the 2MOD-6413-xxxx COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 7 of 123 Exhibit 3 End View of the 2MOD-6413-xxxx showing the RS-232 connector COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 8 of 123 Exhibit 3 End View of the 2MOD-6413-xxxx showing the antenna connector

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 1 of 123 Exhibit 1 Exhibit 1: FCC ID Label In accordance with the requirements of Sections 15.19 (a), 2.925 and 2.926 of the FCC Rules, the following information will be permanently placed on the Canac Inc. Model 2MOD-6413-xxxx as shown in the photograph on the following page. The 2MOD-6413- xxxx is to be certified as a module; therefore, the label shown below will be provided with the 2MOD-6413-xxxx to be affixed on the outside of the host system which it is installed. Label to be placed on the 2MOD-6413-xxxx Compliance Statement to be placed on the 2MOD-6413-xxxx Label to placed on host system COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 2 of 123 Exhibit 1 Photograph showing label placement (FCC ID) COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 3 of 123 Exhibit 1 Photograph showing label placement (Compliance Statement)

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 84 of 123 Exhibit 9 Exhibit 9: Internal Photographs Inside view of 2MOD-6413-xxxx COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 85 of 123 Exhibit 9 Component side of the board (with RF cans installed) COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 86 of 123 Exhibit 9 Component side of the board (with RF cans removed) COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 87 of 123 Exhibit 9 Solder side of board

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 13 of 123 Exhibit 6 Exhibit 6: Test Report TEST REPORT FROM: COMMUNICATION CERTIFICATION LABORATORY 1940 W. Alexander Street Salt Lake City, UT 84119-2039 U.S.A. Tel: (801) 972-6146 Fax: (801) 972-8432 TEST OF: 2MOD-6413-B402(450-460 MHz, 25 kHz channel spacing) 2MOD-6413-B411(450-460 MHz, 12.5 kHz channel spacing) 2MOD-6413-B502(460-470 MHz, 25 kHz channel spacing) To Part 90 Subpart D and Part 2 Subpart J of the FCC Rules and Regulations Test Report Serial No: 73-6773 APPLICATION FOR CERTIFICATION: Modular Transmitter Applicant: Canac Inc. 3950 Hickmore Avenue Ville St. Laurent, Quebec Canada H4T 1K2 Dates of Test: August 9 – September 2, 1999 Issue Date: September 20, 1999 Equipment Receipt Date: August 6, 1999 COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 14 of 123 Exhibit 6 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Communication Certification Laboratory to verify compliance of the device described below with the requirements to Part 2 Subpart J and Part 90 Subpart D of the FCC Rules and Regulations. This report may be reproduced in full, partial reproduction may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. -Applicant:Canac Inc. -Manufacturer:Canac Inc. -Model Number:2MOD-6413-xxxx -FCC ID:OPQ2MOD-6413 -Brand Name:CANAC On this 20 th day of September 1999, I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. COMMUNICATION CERTIFICATION LABORATORY Checked by: William S. Hurst, P.E. Vice President Tested by: Roger J. Midgley EMC Engineering Manager COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 15 of 123 Exhibit 6 SECTION 1. Measurement Requirements 1.1 Introduction The following data is submitted for Certification of a RF modular radio for Canac Inc., in accordance with Part 2, Subpart J and Part 90, Subpart D of FCC Rules and Regulations. The 2MOD-6413-xxxx is the basic model number; the xxxx is replaced with B402, B411 or B502. All three units were tested and data is enclosed for all three units in this report. The 2MOD-6413-xxxx was tested as a stand-alone, but the main application is to transmit data from a CANAC communication board (encoder board) installed in an enclosure (OCU) to remotely control locomotives. Shown below is a block diagram of the OCU. 1.2 Measurements Required for Certification § 2.1033 (c)(14) Measurement Data The measurement data that is required by § 2.1046 through § 2.1057 is included in Section 2 of this report. The data was measured in accordance with the procedures set out in § 2.1041. COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 16 of 123 Exhibit 6 § 90.203 (j)(3) Spectrum Efficiency Application for part 90 certification of transmitters designed to operate on frequencies in the 150-174 and/or 421-512 MHz bands, received on or after February 14, 1997, must include a certification that the equipment meets a spectrum efficiency standard of one voice channel per 12.5 kHz of channel bandwidth. Additionally, if the equipment is capable of transmitting data, has transmitter output power greater than 500 mW, and has a channel bandwidth of more than 6.25 kHz, the equipment must be capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. § 2.1046 RF Power Output - § 90.205 § 2.1046 (a) For transmitters other than single sideband, independent sideband and controlled carrier radiotelephone, power output shall be measured at the RF output terminals when the transmitter is adjusted in accordance with the tune-up procedure to give the values of current and voltage on the circuit elements specified in § 2.983 (d)(5). § 90.205 Transmitter power shown on the radio station authorization is the maximum power the licensee is authorized to use. § 2.1047 Modulation Characteristics - § 90.211 The 2MOD-6413-xxxx uses FM modulation via a 3FSK modulator by means of a direct digital synthesizer (DDS) and transmits non- voice information; therefore, this section does not apply. Enclosed with the measurement data is the measured frequency deviation from the 2MOD-6413-xxxx with all available modulation patterns. § 2.1049 Occupied Bandwidth - § 90.209 § 2.1049 The occupied bandwidth, that is the frequency bandwidth such that, below its lower and above its upper frequency limits, the mean powers radiated are each equal to 0.5 percent of the total mean power radiated by a given emission shall be measured under COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 17 of 123 Exhibit 6 the following conditions: (h) Transmitters employing digital modulation techniques - when modulated by an input signal such that its amplitude and symbol rate represent the maximum rated conditions under which the equipment will be operated. The signal shall be applied through an filter networks, pseudo-random generators or other devices required in normal service. Additionally, the occupied bandwidth shall be shown for operation with any devices used for modifying the spectrum when such devices are optional at the discretion of the user. (i) Transmitters designed for other types of modulation - when modulated by an appropriate signal of sufficient amplitude to be representative of the type of service in which used. A description of the input signal should be supplied. § 90.209 (a) each authorization licensed under this part will show an emission designator representing the class of emission authorized. The designator shall be prefixed by the specified necessary bandwidth. This figure does not necessarily indicate the bandwidth occupied by the emission at any instant. In those case…

Text truncated - open the document above for the full version.

Occupied Bandwidth Occupied Bandwidth 2MOD-6413-B402 (450.0 MHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B402 (25.0 kHz Channel) Trace A Centre: 450.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:37:52 AMHP8568BSPUR13.SPT Spurious Emissions - Emission Mask C Trace AModulated with 7 bytes PASS 1 1 449.998200 MHz 26.0000 dBm 2-1 2-1 -8.600000 kHz -31.6000 dB 3-2 3-2 17.600000 kHz 6.0000 dB Occupied Bandwidth 2MOD-6413-B402 (460.0 MHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B402 (25.0 kHz Channel) Trace A Centre: 460.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:39:41 AMHP8568BSPUR15.SPT Spurious Emissions - Emission Mask C Trace AModulated with 7 bytes PASS 1 1 459.998200 MHz 29.5000 dBm 2-1 2-1 -7.000000 kHz -27.9000 dB 3-2 3-2 14.600000 kHz 600.0000 mdB Occupied Bandwidth 2MOD-6413-B502 (460.0 MHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B502 (25.0 kHz Channel) Trace A Centre: 460.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:34:23 AMHP8568BSPUR5.SPT Spurious Emissions - Emission Mask C Trace AModulated with 8 bytes PASS 1 1 459.998200 MHz 29.2000 dBm 2-1 2-1 -8.000000 kHz -25.3000 dB 3-2 3-2 17.400000 kHz 600.0000 mdB Occupied Bandwidth 2MOD-6413-B502 (470.0 MHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B502 (25.0 kHz Channel) Trace A Centre: 470.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:31:26 AMHP8568BSPUR7.SPT Spurious Emissions - Emission Mask C Trace AModulated with 8 bytes PASS 1 1 469.998200 MHz 28.0000 dBm 2-1 2-1 -8.600000 kHz -28.0000 dB 3-2 3-2 18.000000 kHz 1.0000 dB Conducted Spurious Emissions Conducted Spurious Emissions – 2MOD-6413-B402 (450 MHz 0 to 50 kHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B402 (25.0 kHz Channel) Trace A Centre: 450.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:37:52 AMHP8568BSPUR13.SPT Spurious Emissions - Emission Mask C Trace AModulated with 7 bytes PASS 1 1 449.998200 MHz 26.0000 dBm 2-1 2-1 -8.600000 kHz -31.6000 dB 3-2 3-2 17.600000 kHz 6.0000 dB Conducted Spurious Emissions – 2MOD-6413-B402 (460 MHz 0 to 50 kHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B402 (25.0 kHz Channel) Trace A Centre: 460.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:39:41 AMHP8568BSPUR15.SPT Spurious Emissions - Emission Mask C Trace AModulated with 7 bytes PASS 1 1 459.998200 MHz 29.5000 dBm 2-1 2-1 -7.000000 kHz -27.9000 dB 3-2 3-2 14.600000 kHz 600.0000 mdB Conducted Spurious Emissions – 2MOD-6413-B502 (460 MHz 0 to 50 kHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B502 (25.0 kHz Channel) Trace A Centre: 460.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:34:23 AMHP8568BSPUR5.SPT Spurious Emissions - Emission Mask C Trace AModulated with 8 bytes PASS 1 1 459.998200 MHz 29.2000 dBm 2-1 2-1 -8.000000 kHz -25.3000 dB 3-2 3-2 17.400000 kHz 600.0000 mdB Conducted Spurious Emissions – 2MOD-6413-B502 (470 MHz 0 to 50 kHz) dBm 40 30 20 10 0 -10 -20 -30 -40 -50 -60 Model: 2MOD-6413-B502 (25.0 kHz Channel) Trace A Centre: 470.000000 MHzSpan: 200.000000 kHz Res BW: 300 HzVid BW: 300 HzSweep: 5 s 11/24/99 8:31:26 AMHP8568BSPUR7.SPT Spurious Emissions - Emission Mask C Trace AModulated with 8 bytes PASS 1 1 469.998200 MHz 28.0000 dBm 2-1 2-1 -8.600000 kHz -28.0000 dB 3-2 3-2 18.000000 kHz 1.0000 dB Radiated Spurious Emissions (Substitution Method) 2MOD-6413-B402 Transmitting at 450.0 MHz Antenna Polarity Frequency (MHz) Uncorrected Level (dBm) Cable Loss (dB) Antenna Gain (dB) Spurious Attenuation (dB) V1800.0-78.54.66.8-47.2 H900.0-76.62.31.9-47.9 H1800.0-78.14.66.8-46.8 Note: Below 1 GHz the reference antenna was a Dipole antenna and above 1 GHz reference antenna was a Double Ridge Guide Antenna. Spurious attenuation (dB)= 10 log 10 { TX power in watts } – Calculated power (dBm) 0.001 10 log 10 { 0.813 } = 29.1 0.001 Calculated power (dBm) = Uncorrected Level – Cable Loss + Antenna Gain 2MOD-6413-B402 Transmitting at 460.0 MHz Antenna Polarity Frequency (MHz) Uncorrected Level (dBm) Cable Loss (dB) Antenna Gain (dB) Spurious Attenuation (dB) V1840.0-78.74.76.8-47.5 V2300.0-76.35.26.8-45.6 H920.0-77.22.31.9-48.5 H1840.0-76.14.76.8-44.9 H2300.0-78.85.26.8-48.1 Note: Below 1 GHz the reference antenna was a Dipole antenna and above 1 GHz reference antenna was a Double Ridge Guide Antenna. Spurious attenuation (dB)= 10 log 10 { TX power in watts } – Calculated power (dBm) 0.001 10 log 10 { 0.813 } = 29.1 0.001 Calculated power (dBm) = Uncorrected Level – Cable Loss + Antenna Gain 2MOD-6413-B411 Transmitting at 450.0 MHz Antenna Polarity Frequency (MHz) Uncorrected Level (dBm) Cable Loss (dB) Antenna Gain (dB) Spurious Attenuation (dB) V1800.0-77.24.66.8-45.8 H900.0-76.42.31.9-47.6 H1800.0-80.24.66.8-48.8 Note: Below 1 GHz the reference antenna was a Dipole antenna and above 1 GHz reference antenna was a Double Ridge Guide Antenna. Spurious attenuation (dB)= 10 log 10 { TX power in watts } – Calculated power (dBm) 0.001 10 log 10 { 0.832 } = 29.2 0.001 Calculated power (dBm) = Uncorrected Level – Cable Loss + Antenna Gain 2MOD-6413-B411 Transmitting at 460.0 MHz Antenna Polarity Frequency (MHz) Uncorrected Level (dBm) Cable Loss (dB) Antenna Gain (dB) Spurious Attenuation (dB) V1840.0-76.44.76.8-45.1 V2300.0-77.35.26.8-46.5 H1840.0-76.64.76.8-45.3 H2300.0-78.65.26.8-47.8 Note: Below 1 GHz the reference antenna was a Dipole antenna and above 1 GHz reference antenna was a Double Ridge Guide Antenna. Spurious attenuation (dB)= 10 log 10 { TX power in watts } – Calculated power (dBm) 0.001 10 log 10 { 0.832 } = 29.2 0.001 Calculated power (dBm) = Uncorrected Level – Cable Loss + Antenna Gain 2MOD-6413-B502 Transmitting at 460.0 MHz Antenna Polarity Frequency (MHz) Uncorrected Level (dBm) Cable Loss (dB) Antenna Gai…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 81 of 123 Exhibit 7 Exhibit 7: Test Set-Up Photograph Front view of the test set-up COMMUNICATION CERTIFICATION LABORATORYTEST REPORT: 73-6773 FCC ID: OPQ2MOD-6413 Page 82 of 123 Exhibit 7 Back view of the test set-up
