OQA-ARMNC022Remote control - fixed unit

Dynamic series user manual Description, warnings and instructions Conformity and frequencies (915MHz) The attached documentation is an integral part of the radio remote control and it aims at provid- ing the instructions needed for using and maintaining the system, with an eye on its safety func- tions. Always remember that: - photos and drawings are useful examples that help understand the instructions and warnings of each radio remote control configuration - if necessary, contact Autec if any of the instructions and/or warnings are not clear No part of the documentation may be reproduced, in any form or by any means, without written permission of Autec (including recording and photocopying). If documentation is lost or damaged, ask Autec for a copy. Please specify the serial number of the related radio remote control. The documentation must be kept for the whole life of the radio remote control: after reading it, keep it on hand for future reference. Information contained in the documentation adds to and completes the information provided by the manufacturer of the remote controlled and/or by those who install the radio remote control on the machine. All installation, usage and maintenance operations must be carried out by qualified technicians who are suitably trained with respect to the relevant norms and laws. Therefore, this documentation must be read and understood in all its parts by the user and by: - the radio remote control owner and/or installer - the person responsible for and in charge of maintenance and/or safety in the workplace where the radio remote control is used. As for instructions and warnings regarding the machine where the radio remote control is installed, follow the instructions given in the machine's manual. Three symbols are employed throughout documentation, which are used to highlight specific safety-related issues. They are classified according to the hazardous situation that may arise and on the possible consequences: This symbol is also used, and it identifies texts to be read carefully. Symbol If the highlighted instructions are not respected, this leads to hazardous situations with the following characteristics: dangerous situation gravity of consequences for people gravity of consequences for property ...highly probable. ... critical (death or physical damage). ... critical. ... probable. ... critical (death or physical damage). ... critical. ... probable. ... moderate (non-severe physical damage). ... moderate. AUTEC ENG INDEX Part A: Description, warnings and instructions 1 Dynamic Series description ............................................................................... A - 1 1.1 Technical data ................................................................................................. A - 1 1.2 Applications ..................................................................................................... A - 2 1.3 Radio link ........................................................................................................ A - 2 1.4 Classification of commands ............................................................................ A - 3 1.5 Safety functions .............................................................................................. A - 3 1.6 Identifying the radio remote control ................................................................. A - 4 2 Risk assessment ................................................................................................. A - 5 2.1 Risk assessment for radio remote controlled machines ................................. A - 5 2.2 Working conditions .......................................................................................... A - 6 3 Warnings .............................................................................................................. A - 7 3.1 Before starting to work .................................................................................... A - 7 3.2 During normal operation ................................................................................. A - 7 3.3 After using the radio remote control ................................................................ A - 8 4 Radio remote control lifecycle ........................................................................... A - 9 4.1 Transportation and storage ............................................................................. A - 9 4.2 Installation ....................................................................................................... A - 9 4.3 Use .................................................................................................................. A - 9 4.4 Radio remote control maintenance ............................................................... A - 10 4.5 Machine maintenance ................................................................................... A - 14 4.6 Disposal ........................................................................................................ A - 14 5 General operating instructions ........................................................................ A - 15 5.1 Starting up the radio remote control .............................................................. A - 15 5.2 Command activation ..................................................................................... A - 15 5.3 Data Feedback Function ............................................................................... A - 15 5.4 Radio link interruption ................................................................................... A - 16 5.5 Transmitting unit automatic switch off ........................................................... A - 16 5.6 Switching off the transmitting unit ................................................................. A - 17 5.7 Switching off the receiving unit ..................................................................... A - 17 6 Working ......................................…

Text truncated - open the document above for the full version.

AUTEC Dynamic Series LIARME01-00.fmPart D: ARM receiving unit D - 1 ENG DYNAMIC SERIES Part D: ARM receiving unit INDEX 1 Description ........................................................................................................... D - 2 3 Technical data sheet ........................................................................................... D - 3 4 Plates .................................................................................................................... D - 4 5 Light signals ........................................................................................................ D - 4 6 Values of proportional outputs .......................................................................... D - 7 7 Data memory backup ........................................................................................ D - 10 8 Malfunction signalled by the receiving unit .................................................... D - 11 Dynamic Series Part D: ARM receiving unit Description D - 2 1 Description The receiving unit communicates with the machine through the outputs and their wiring and/or through a CAN network (of which it is a slave node). The STOP (STP_1 and STP_2) and SAFETY (SAF_1 and SAF_2) outputs are some of the receiving unit's outputs. Amounting holesGfuse F1 BantennaHfuse F2 CLEDsLfuse F3 DTEACH pushbuttonMfuse F4 Econnector for cable controlNfuse F5 FplugPDTK connector (for data memory) QIDK (for address key) R BKK connector (for backup data memory) A B F A C E E D GH L M N P QR Mother board Technical data sheet AUTEC Dynamic Series LIARME01-00.fmPart D: ARM receiving unit D - 3 ENG 2 Technical data Power supply ......................................................................................................... 8-30 V Antenna ................................................................................................................ dedicated Rated current of outputs STOP_1 and STOP_2 ........................................... 7.5 A (30 V ) Rated current of output SAF_1 ..................................................................... 7.5 A (30 V ) Rated current of output SAF_2 ........................................................................ 3 A (30 V ) Rated current of digital outputs ........................................................................ 4 A (30 V ) Rated current of analogue outputs (PWM) ...................................................... 2 A (30 V ) Rated current of analogue outputs (voltage) .............................................. 10 mA (28 V ) Protection SAF_2 (fuse F1) ............................................................. 3 A (32 V , autofuse) Protection of power supply (fuse F2) ............................................. 7.5 A (32 V , autofuse) Protection STOP_1 (fuse F3) ....................................................... 7.5 A (32 V , autofuse) Protection STOP_2 (fuse F4) ....................................................... 7.5 A (32 V , autofuse) Protection SAF_1 (fuse F5) .......................................................... 7.5 A (32 V , autofuse) Housing material ............................................................................................ PA6 (20% fg) Protection degree ....................................................................................... IP65 (NEMA 4) Dimensions ............................................................. 200 x 230 x 95 mm (7.9 x 9.1 x 3.8 In) Weight ............................................................................................................. 3 kg (6.6 Lb) 3 Technical data sheet The technical data sheet contains the wiring diagram showing the connection be- tween the receiving unit and the machine. It also contains the transmitting unit configuration and shows the matching be- tween commands sent and machine functions/movements. The technical data sheet must be filled in, checked and signed by the installer, who is responsible for a correct wiring. The technical data sheet must be kept together with this manual (always keep a copy of this data sheet for administrative purposes). The wiring of the receiving unit outputs must always reflect the wiring indi- cated in the technical data sheet. Dynamic Series Part D: ARM receiving unit Plates D - 4 4Plates The receiving unit has two plates. 5 Light signals The ARM receiving unit has six LEDs: - POWER is green - ALARM is red -STATUS is blue - RUN is green - ERR is red - SETUP is yellow. 1. POWER LED (green) The POWER LED indicates the status of the receiving unit and of the radio link. 2. ALARM LED (red) PlatePositionContent radio remote control identification plate On the cover of the receiving unit Radio remote control serial number, bar code (S/N) and manufacturing year. technical data plate On the cover of the receiving unit MODEL, TYPE and main receiving unit technical data, marking and possible radio remote control marks. The POWER LED ...Meaning ... is offThe receiving unit is switched off. ...blinksRadio link has been built. ... is onNo radio link. Light signals AUTEC Dynamic Series LIARME01-00.fmPart D: ARM receiving unit D - 5 ENG The ALARM LED warns about anomalies in the receiving unit. 3. STATUS LED (blue) The STATUS LED warns about anomalies on the outputs or on the power supply and indicates the reception of data from the transmitting unit. 4. RUN LED (green) The RUN LED indicates the status of the communication between the receiving unit and the CAN network Master node. RUN LED signals reflect the guidelines of the CANopen®, standard, CiA recom- mendation 303-3. The ALARM LED ...Meaning ... is offThe receiving unit works correctly. ... blinks onceError on the STOP outputs. ... blinks twiceError on the SAFETY outputs. ... blinks three times Error on the outputs corresponding to direction com- mands. ... is onThe receiving unit does not work correctly. The STATUS LED ...Meaning ... is offNo radio link. ... blinks slowlyOver-voltage on power …

Text truncated - open the document above for the full version.

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 1 of 3 EXTERNAL PHOTO Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 2 of 3 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 3 of 3

ARM label and its dimension ARM label position Labels_and_position_armpwm_rev0.cdr 6 0 , 0 m m 50,0 mm TA1146-00 A0TARG01P0893 Technical Data POWER SUPPLY...................................12-24V 300mA ........................................................max 8-30V 400mA RADIO MODULE..............................................FSARTBAU1 FREQUENCY RANGE......................................915-928MHz PROTECTION DEGREE...............................................IP65 TYPE NC022 MODEL ARM --- --- IC: 9061A-ARMNC022 This radio device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: OQA-ARMNC022 N12335

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 1 of 9 INTERNAL PHOTO Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 2 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 3 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 4 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 5 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 6 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 7 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 8 of 9 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 9 of 9

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Test report R11162201 Rev. 2.0 Order M111622 page 1 of 66 TEST REPORT nr. R11162201 Federal Communication Commission (FCC) Industry Canada (IC) Test item Description .................... : Transceiver Unit Trademark ..................... : AUTEC Model/Type ................... : Model ARM Type NC022 Test Specification Standard ........................ : FCC Rules & Regulations, Title 47 (2010) - Part 15 paragraph(s) : 247(a), 247(b), 247(c), 209 and 207 RSS-210 (2010) – Annex 8 Client’s name ............... : AUTEC S.r.l. Address ......................... : Via Pomaroli, 65 - 36030 Caldogno (VI) - ITALY Manufacturer’s name . : Same ad client Address ......................... : Report Tested by ....................... : A. Bertezzolo - Technician Approved by .................. : R. Beghetto - Laboratory Manager Date of issue .................. : 11.01.12 Contents ........................ : 66 pages This test report shall not be reproduced except in full without the written approval of CMC. The test results presented in this report relate only to the item tested. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R11162201 Rev. 2.0 Order M111622 page 2 of 66 Index 1. SUMMARY ............................................................................................................................................................. 3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ................................................................................. 4 2.1 TEST SITE .............................................................................................................................................................. 4 3. TESTING AND SAMPLING ................................................................................................................................. 4 4. OPERATIVE CONDITIONS................................................................................................................................. 4 5. PHOTOGRAPH(S) OF EUT ................................................................................................................................. 5 6. EQUIPMENT LIST ................................................................................................................................................ 6 7. MEASUREMENT UNCERTAINTY .................................................................................................................... 7 8. REFERENCE DOCUMENTS ............................................................................................................................... 8 9. DEVIATION FROM TEST SPECIFICATION ................................................................................................... 9 10. TEST CASE VERDICTS........................................................................................................................................ 9 11. RESULTS................................................................................................................................................................. 9 11.1 ANTENNA REQUIREMENTS ............................................................................................................................. 10 11.2 20DB BANDWIDTH ......................................................................................................................................... 11 11.3 OCCUPIED BANDWIDTH (99% BW) ................................................................................................................ 12 11.4 CHANNEL SEPARATION ................................................................................................................................... 13 11.5 TIME OF OCCUPANCY ..................................................................................................................................... 14 11.6 NUMBER OF HOPPING CHANNELS ................................................................................................................... 15 11.7 PEAK OUTPUT POWER .................................................................................................................................... 16 11.8 BAND EDGE .................................................................................................................................................... 18 11.9 RADIATED SPURIOUS (TRANSMITTER) ............................................................................................................ 20 11.10 RADIATED SPURIOUS (RECEIVER)................................................................................................................... 23 12. GRAPHS AND TABLES ...................................................................................................................................... 24 CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R11162201 Rev. 2.0 Order M111622 page 3 of 66 1. Summary Standard: FCC Rules & Regulations, Title 47 RSS-210 (2007) Test specifications Environmental Phenomena Tests sequence Result FCC – Title 47 Part 15.203 and 15.204 IC – RSS-210 Antenna Requirement 1 Complies FCC – Title 47 Part 15.247 IC – RSS-210 Annex 8 20 dB Bandwidth 2 Complies IC – RSS-210 Annex 8 Occupied Bandwidth (99% BW) 3 Complies FCC – Title 47 Part 15.247 IC – RSS-210 Annex 8 Channel Separation 4 Complies FCC – Title 47 Part 15.247 IC – RSS-210 Annex 8 Time of Occupancy 5 Complies FCC – Title 47 Part 15.247 IC – RSS-210 Annex 8 Number of Hopping Frequency 6 Complies FCC – Title 47 Part 15.247 IC – RSS-210 Annex 8 Peak Output Power 7 Complies FCC – Title 47 Part 15.247 IC – RSS-210 Annex 8 Band Edge 8 Complies FCC – Title 47 …

Text truncated - open the document above for the full version.

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 1 of 1 SETUP PHOTO
