OQA-J7PFJE55Transceiver Unit

J7P FJE55 label J7P FJE55 label position Labels_and_position_j6p_fjc55_rev0.pdf label MODEL: J7P TYPE FJE55 --- --- BATTERY ........................................... LPM04 (7.4 V ) .............................................................. LPM05 (7.2 V ) PROTECTION DEGREE ............................................. IP65 TA1769-01 AUTEC Srl Via Pomaroli, 65 - 36030 Caldogno (VI) - Italy www.autecsafety.com FCC ID: OQA-J7PFJE55 IC: 9061A-J7PFJE55 HVIN: J7PFJE55 RADIO MODULE ............................................. FSAACI03A FREQUENCY RANGE .........863-870 MHz (<25 mW ERP) FREQUENCY RANGE .........915-928 MHz (<50 mW ERP)

ANT039 FSAACI03A FSACAP02 FSATFT43E

DEKRA Testing and Certification S.r.l. Sede Operativa: Via della Fisica 20, 36016 Thiene (VI), Tel. +39 0445 367702 - [email protected] TRF N. 15-247_HoppingDEKRA Page 1 of 15 Test Report N. R25124501 rev.1.0 TEST REPORT Nr. R25124501 Federal Communication Commission (FCC) Report Reference N. .................. : R25124501 Date of issue: .............................. : 14.07.2025 Total number pages: ................... : 15 Customer name ......................... : Autec S.r.l. Address ....................................... : Via Pomaroli, 65 – 36030 Caldogno (VI) – Italy Test specification: Standard(s) ................................. : KDB 447498 D01 General RF Exposure Guidance v06 Non-standard test method .......... : N/A Test Report Form N. .................. : 15-247_HoppingDEKRA Test Report Form(s) Originator ... : DEKRA Testing and Certification S.r.l. Master TRF ................................. : 2025-06 General disclaimer: The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. (*) Test item description ........... : Remote station (*) Trademark .............................. : Autec (*) Manufacturer .......................... : Autec S.r.l. (*) Model / Type reference .......... : Model J7P Type FJE55 (*) FCC ID ................................... : OQA-J7PFJE55 (*) Rating(s) ................................. : 7,4 Vdc from battery Report Tested by (name + signature) ..... : S. Zanivan ............................................................. Approved by (name + signature) .................................... : F. Marenda ............................................................. (*) information provided by the customer TRF N. 15-247_HoppingDEKRA Page 2 of 15 Test Report N. R25124501 rev.1.0 1 Summary 1 Summary........................................................................................................................................... 2 2 Reference standard(s) ...................................................................................................................... 3 3 List of attachments ............................................................................................................................ 3 4 Deviation(s) from test specification ................................................................................................... 3 5 Testing location ................................................................................................................................. 3 6 General description of tested item and testing condition(s) ............................................................. 5 6.1 Photos of the test item ................................................................................................................. 6 7 Verdict summary section .................................................................................................................. 9 8 Test conditions ................................................................................................................................ 10 8.1 General ...................................................................................................................................... 10 9 Test results ..................................................................................................................................... 11 9.1 RF Exposure Analysis ............................................................................................................... 11 TRF N. 15-247_HoppingDEKRA Page 3 of 15 Test Report N. R25124501 rev.1.0 2 Reference standard(s) KDB 447498 D01 General RF Exposure Guidance v06 RF exposure procedures and equipment authorization policies for mobile and portable devices 3 List of attachments Attachment 1: Measurement uncertainty, judgement of compliance and quality manual references 4 Deviation(s) from test specification None 5 Testing location DEKRA Testing and Certification S.r.l. Via della Fisica, 20 – 36016 Thiene (VI) – Italy Test site facility’s FCC registration number: 182474 Revision index Date Change history 1.0 14.07.2025 TRF N. 15-247_HoppingDEKRA Page 4 of 15 Test Report N. R25124501 rev.1.0 Testing and sampling: Date of receipt of test item .......................................... : 16.06.2025 Testing start date ........................................................ : 25.06.2025 Testing end date ......................................................... : 10.07.2025 Sampling procedure .................................................... : Sample used for testing chosen by the customer; DEKRA Testing and Certification S.r.l. cannot be considered responsible for the selection of the sample Internal identification ................................................... : Adhesive label with the product number P250684 General remarks: This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. The test results presented in this report relate only to the object tested. “(see appended table)": refers to a table appended to the report. Throughout this report a comma is used as the decimal separator. Possible test case verdicts: Test case does not apply to the test object: N/A (Not Applicable) Test object meets the requirement: P (Pass) Test object does not meet the requirement: F (Fail) Test object was not evaluated for the requirement: N/E (Not Executed) Definition of symbols used in this test report: ☒ Indicates that the listed condition, standard or equipment is applicable for this report. ☐ Indicates that the listed condition, standard or equipment is not applicable for this report. TRF N. 15-247_HoppingDEKRA Page 5 of 15 Test Report N. R25124501 rev.1.0 6 General description of tested item and testing condition(s) Description ................................. : Remote station M…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification S.r.l. Sede Operativa: Via della Fisica 20, 36016 Thiene (VI), Tel. +39 0445 367702 - [email protected] Accredited by ACCREDIA according to UNI CEI EN ISO/IEC 17025 accreditation n. 0168 L TRF N. 15-247_Hopping_DEKRA Page 1 of 56 Test Report N. R25124301 rev.1.0 LAB N° 0168 L TEST REPORT Nr. R25124301 Federal Communication Commission (FCC) Report Reference N. .................. : R25124301 Date of issue: .............................. : 11.07.2025 Total number pages: ................... : 56 Customer name ......................... : Autec S.r.l. Address ....................................... : Via Pomaroli, 65 – 36030 Caldogno (VI) – Italy Test specification: Standard(s) ................................. : FCC Rules & Regulations, Title 47:2024 Part 15 paragraph(s): 203, 204, 205, 207, 209, 215 and 247 Non-standard test method .......... : N/A Test Report Form N. .................. : 15-247_Hopping_DEKRA Test Report Form(s) Originator ... : DEKRA Testing and Certification S.r.l. Master TRF ................................. : 2025-06 General disclaimer: The test Verdict presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. (*) Test item description ........... : Remote station (*) Trademark .............................. : Autec (*) Manufacturer .......................... : Autec S.r.l. (*) Model / Type reference .......... : Model J7P Type FJE55 (*) FCC ID ................................... : OQA-J7PFJE55 (*) Rating(s) ................................. : 7,4 Vdc from battery Report Tested by (name + signature) ..... : S. Zanivan ............................................................. Approved by (name + signature) .................................... : F. Marenda ............................................................. (*) information provided by the customer TRF N. 15-247_Hopping_DEKRA Page 2 of 56 Test Report N. R25124301 rev.1.0 LAB N° 0168 L 1 Summary 1 Summary........................................................................................................................................... 2 2 Reference standard(s) ...................................................................................................................... 3 3 List of attachments ............................................................................................................................ 3 4 Deviation(s) from test specification ................................................................................................... 3 5 Testing location ................................................................................................................................. 3 6 General description of tested item and testing condition(s) ............................................................. 5 6.1 Photos of the test item ................................................................................................................. 6 7 Verdict summary section .................................................................................................................. 9 8 Test conditions ................................................................................................................................ 10 8.1 General ...................................................................................................................................... 10 9 Test results ..................................................................................................................................... 11 9.1 Antenna requirements ............................................................................................................... 11 9.2 Emissions in restricted frequency bands and in unrestricted frequency bands ........................ 12 9.3 20 dB bandwidth ........................................................................................................................ 33 9.4 Channel separation ................................................................................................................... 36 9.5 Number of hopping channels ..................................................................................................... 39 9.6 Time of occupancy .................................................................................................................... 43 9.7 Band edge ................................................................................................................................. 46 9.8 Peak Output Power ................................................................................................................... 50 TRF N. 15-247_Hopping_DEKRA Page 3 of 56 Test Report N. R25124301 rev.1.0 LAB N° 0168 L 2 Reference standard(s) FCC Rules and Regulation Title 47 part 15:2024 -- KDB 558074 D01 15.247 Meas Guidance v05r02 Guidance for compliance measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices operating under section 15.247 of the FCC rules ANSI C63.4:2014 American National Standard for Methods of Measuring of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz – 40 GHz ANSI C63.10:2013 American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices 3 List of attachments Attachment 1: Measurement uncertainty, judgement of compliance and quality manual references 4 Deviation(s) from test specification None 5 Testing location DEKRA Testing and Certification S.r.l. Via della Fisica, 20 – 36016 Thiene (VI) – Italy Test site facility’s FCC registration number: 182474 Revision index Date Change history 1.0 11.07.2025 -- TRF N. 15-247_Hopping_DEKRA Page 4 of 56 Test Report N. R25124301 rev.1.0 LAB N° 0168 L Testing and sampling: Date of receipt of test item .........................................…

Text truncated - open the document above for the full version.

ANT039-01 pag 1 - 2 3_Description_ANT039-01 ANT039-01 The ANT039 antenna is a transducer designed to transmit and receive electromagnetic waves. It can can be used in Autec remote stations and it operates in 870-928MHz frequency band. It is a wide band dipole realized on PCB (printed circuit board). It is connected with a coaxial cable to the RF output of a radio module through a balun circuit which preserves the simmetry of currents between the two branches of the dipole. The ANT039 antenna has the following schematic diagram: ANT039-01 pag 2 - 2 3_Description_ANT039-01 The antenna characteristics is affected by the plastic material nearby it. All the Autec remote stations that use this type of antenna share the same antenna position so as to guarantee the same characteristic of it. Following an example of the resulting gain: By simulation, as this diagram reports, the realized gain of the antenna is -0.3565dBi and the System Total efficiency is -2.01dB.
