OQA-TD02C05DP11Remote Control Transmitter

Autec s.r.l.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: May 31, 2006
Application Purpose: Original Equipment
Date of Application: May 31, 2006
Equipment Note: Remote Control Transmitter
Frequency Range: 902.15000000 - 927.72500000
Company: Autec s.r.l.
Country: Italy

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Transmitter System USER’S MANUAL Light Series Light Series Transmitter System USER’S MANUAL Follow the indications and warnings given by the machine producer regarding the machine controlled by the radio remote control. The information contained in this manual considers a representative configuration of the radio remote control: please find radio remote control real configuration in the technical data sheet (attached to the manual). If this manual is lost or damaged, ask for a copy from AUTEC. Please specify the serial number of the relative radio remote control. Contact AUTEC if any of the instructions and/or warnings given in this manual are not clear. The information contained in this manual is subject to modification without notice and is not binding. No parts of this manual may be reproduced by any means without the written permission of AUTEC (including recording and photocopying). LILKNPA1-01 - AmEn.fm1 - Index and conventionsPage 1 1 INDEX AND CONVENTIONS 1.1 INDEX 1Index and conventions .......................................................................................... 1 1.1 Index ........................................................................................................................ 1 1.2 Conventions ............................................................................................................. 1 2Introduction ............................................................................................................ 2 2.1 Documentation......................................................................................................... 3 2.2 General technical data ............................................................................................. 4 3LK Transmitting Unit ............................................................................................. 5 3.1 Technical data of the LK transmitting unit................................................................ 6 4Warnings for use.................................................................................................... 7 5Warnings for maintenance.................................................................................... 8 5.1 Routine maintenance ............................................................................................... 8 5.2 Special maintenance (AUTEC SERVICE) ............................................................... 9 5.3 Disposal ................................................................................................................... 9 6Working mode of the LK transmitting unit ........................................................ 10 7Frequencies.......................................................................................................... 12 7.1 Manual selection mode .......................................................................................... 12 7.2 Automatic scan mode ............................................................................................ 12 8Programming........................................................................................................ 13 8.1 Programming the E16STXUS1 transmitting module.............................................. 13 9LK transmitting unit diagnostics........................................................................ 14 1.2 CONVENTIONS In this manual, all important information is highlighted in the following symbols and conven- tions: abcd... : WARNINGS abcd... : TECHNICAL DATA abcd... : IMPORTANT TEXTS THIS MANUAL REFERS EXCLUSIVELY TO THE TRANSMITTING UNIT: THE GENERAL INSTALLATION WARNINGS ARE INCLUDED IN THE RECEIVING UNIT MANUAL. BEFORE INSTALLING, STARTING AND USING THE RADIO REMOTE CONTROL, THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PEOPLE WHO INSTALL, USE AND CARRY OUT MAINTENANCE ON THE RADIO REMOTE CONTROL. Page 22 - IntroductionLILKNPA1-01 - AmEn.fm 2 INTRODUCTION Receiving unit Transmitting unit Industrial radio remote controls of the Light series are used to control machines from a distance. Each industrial radio remote control is made up of a por - table transmitting unit, from which the user can re- motely control the machine, and a receiving unit in- stalled on board the machine itself. The transmitting unit uses radio frequencies to transmit a coded message which contains a value called address. Each receiving unit can only de - code the messages coming from its own transmit- ting unit with the same address. This excludes the possibility of an interference ac- tivating any system function. If the radio transmis- sion is disturbed, incorrect or interrupted, the re- ceiving unit autonomously stops the whole system. Each radio remote control complies with Part 15 of the FCC rules. Operation is subject to the following conditions: - this device may not cause a harmful interference, and - this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Autec cannot be held responsible if the radio remote control is installed on applica- tions that are different from those permitted: PERMITTED USES Hoisting machines (construction cranes, bridge cranes, machines for material handling in general,...). FORBIDDEN USES Machines installed in areas where equipment with explosion-proof character- istics is required. Machines for moving, raising and transporting people. LILKNPA1-01 - AmEn.fm2 - IntroductionPage 3 All machines must undergo a risk analysis: it is therefore necessary to evaluate, within the limits of this analysis, if the machine can be radio remote controlled. The machine producer and/or the person who decides upon radio remote control use and installation is responsible for this analysis. Autec cannot be held responsible if the risk analysis is not carried out correctly. To guarantee correct radio remote con…

Text truncated - open the document above for the full version.

Block Diagram

55 44 33 22 11 D D C C B B A A di Via Pomaroli, 936030 Caldogno (VI)Tel. 0444-901000Fax. 0444-901060 Cod:Richiesto:Descrizione:Disegnato:Approvato:Verificato: Rif cs:File:Data:Foglio: Size: RADIO REMOTE CONTROL Rev: /Tuesday, May 16, 200611 A4 TD02C05DP11 Product blocks diagram /Cecconi C.Terreran M.Bonan A. / 00 di Via Pomaroli, 936030 Caldogno (VI)Tel. 0444-901000Fax. 0444-901060 Cod:Richiesto:Descrizione:Disegnato:Approvato:Verificato: Rif cs:File:Data:Foglio: Size: RADIO REMOTE CONTROL Rev: /Tuesday, May 16, 200611 A4 TD02C05DP11 Product blocks diagram /Cecconi C.Terreran M.Bonan A. / 00 di Via Pomaroli, 936030 Caldogno (VI)Tel. 0444-901000Fax. 0444-901060 Cod:Richiesto:Descrizione:Disegnato:Approvato:Verificato: Rif cs:File:Data:Foglio: Size: RADIO REMOTE CONTROL Rev: /Tuesday, May 16, 200611 A4 TD02C05DP11 Product blocks diagram /Cecconi C.Terreran M.Bonan A. / 00 KEY FOR POWERMC000341 Bottom CasingAutec enclosure TOGGLE SWITCH 1 Apem toggle switch Gasket Autec enclosure E16SCHUS1Key Code Configuration: P11Transmitting UnitModel: C05DTransmitting Unit STOP-PUSHBUTTON1 OMRON button Screw and eccessoriesHardware for enclosures PUSHBUTTON 1 ITW push-button E16STI082-Z.1 keypad Upper CasingAutec enclosureKeyboard GridAutec enclosure LBM02MHNiMh 2.4V Battery E16STXUS1E16S TX Module Type: TD3Transmitting Unit AutecSB000006-00.cdr Transmitting unit commands Receiving unit machinery di Via Pomaroli, 9 36030 Caldogno (VI) Tel. 0444-901000 Fax. 0444-901060 Cod: Richiesto: Descrizione: Disegnato: Approvato: Verificato: Rif cs: File: Data: Foglio:Size: RADIO REMOTE CONTROL Rev:SB000009.dsn Wednesday, June 11, 2003 11A3 / Schema a blocchi sistema E16S Bonan A. Marchioro G. Cecconi C. Bonan A. / 00 Receiver Unit Remote control section or Keyboard Safety circuit E16S transmitting module Address Key rx Battery Actuators Cable interface module Master board Stop circuit External Power Supply Address Key tx Relais E16S Receiving module Autec srl via Pomaroli, 65 – Caldogno 36030 (VI) - ITALY Tel. +39 0444 901000 – Fax +39 0444 901011 [email protected] - www.autec.it C.S. € 100.000,00 i.v. – R.E.A. VI: 188709 – N.I.:IT01850360247 Registro Imprese di Vicenza n. 01850360247 E16S Transmitting module Modulator ∼ Synthesis Loop filter VCO VGA LPF LD CLOC DATA ENABL CODE MESSAGE PTT PTT- RF BIAS LOGICA U10 13MHz ∼ X2=14.75MHz 902MHz ≤fVCO≤928MHz

External Photos

ID Label/Location Info

RADIO MODULE .............................E16STXUS1 FREQUENCY RANGE .................902-928MHz POWER SUPPLY ............LBM02MH 2,4V PROTECTION DEGREE ............................. IP65 T A 9 1 2 / 0 - A Ø T A R G Ø 1 P Ø 6 7 4 TYPE TD02MODEL C05D TRANSMITTER RADIO MODULE .....................E16STXUS1 FREQUENCY RANGE ..........902-928MHz POWER SUPPLY ....LBM02MH 2,4V PROTECTION DEGREE ..................... IP65 ------ T A 9 6 7 / 0 - A Ø T A R G Ø 1 P Ø 7 1 9 TYPE TD02 MODEL C05D TRANSMITTER FCC ID: OQA-TD02C05DP11 This radio device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Operational Description

1 Operational Description for Type TD02 Model C05D transmitting unit Operational Description for Type TD02 Model C05D transmitting unit 1Identification of the unit where: TYPE: identifies type of unit (transmitting, receiving or transceiving), type of casing and used electronic modules. MODEL: differentiates power supply, type of actuators and radio frequency band CONFIGURATION: refersto the specific set of components and accessories of the unit TRADE NAME: commercial reference 2Operational description Industrial radio remote controls are used to command machines from a distance. Each industrial radio remote control is made up of a portable transmitting unit, from which the user can remotely control the machine, and a receiving unit installed on board the machine itself. The LK transmitting unit is a handheld unit. Ty p eTD02 ModelC05D ConfigurationP11 Equipmentremote control transmitting unit Trasmitting radio moduleE16STXUS1 Used frequency band902 - 928 MHz Trade nameLK FCC IdentifierOQA-TD02C05DP11 Manufacturer AUTEC srl Via Pomaroli, 65 I-36030 CALDOGNO (VI) Receiving unit Transmitting unit 2 Operational Description for Type TD02 Model C05D transmitting unit The LK contains E16STXUS1. It is the radio transmitting module. A logic section collects commands coming from various actuators (switches and or pushbut- tons in the E16STI082 keyboard) and combines them with an address code stored an EEPROM memory ("address Key"); a serial data telegram at 2200-2600 baud is so obtained. After a Gaussian spectrum shaping filter, the telegram is frequency modulated on a carrier generated by a PLL synthesizer and then trasmitted over a 25kHz channel in the 902-828 MHz band; 32 different frequencies my be chosen, so as to allow cohexistence of multiple units on the same location (for details see relative block diagrams). Transmission is continuous (100% duty cycle) even with no command activated, since the reciver is expected to monitor continuously the presence of a valid radio signal. A receiving unit will decode only messages coming from a transmitter with the same address code. This excludes the possibility of an interference activating any function unwantedly. 3Exploded view STOP pushbutton Casing E16STXUS1 transmitting module (contains encoder and radio transmitter) Toggle switch Gasket Keyboard grid E16TI082 Z.1 keypad (contains the key actua- tors and their wiring) Address key (contains the address of the tel- egram) 3 Operational Description for Type TD02 Model C05D transmitting unit 4Technical data E16STXUS1 trasmitting radio module 5Power supply: LBM02MH battery pack LBM02MH batteries must be only recharged by one of the LBC___A battery chargers. Use the battery until it is totally discharged (the led of the transmitting unit flashs quickly when the battery used is discharged). Used frequency band902 - 928 MHz Type of modulation2200 - 2600 Baud GFSK Channel spacing25 kHz Designation of emission (ITU code)16K5F1D Strenght fieldsee relative Test Report Duty cycle up to 100 % (continuous duty), depends on user’s need Duplex directionsimplex Antenna type integrated λ/4 Data telegram132 bit Hamming distance> 8 Probability of non-recognition of error<10 exp-11 number of NiMH elements2 nominal voltage of 1 element (V)1,2 total nominal voltage of the battery (V)2,4 battery voltage after discharge (V)2,1 voltage of the charged battery (V)2,7÷2,8 capacity (Ah)1,6 number of cycles in average life500 autonomy (hours)up to 8 recharge time up to 4 4 Operational Description for Type TD02 Model C05D transmitting unit

Test Report

Independent Testing Laboratory TÜV Rheinland Appointed Laboratory Accredited by PTT Ministry Competent Body CMC Centro Misure Compatibilità S.r.l. - Via dell’Elettronica, 12/C - 36016 Thiene (VI) - ITALY - tel./fax +39 0445 367702 http://www.cmclab.it e-mail: [email protected] Test report R06027301_rev20 Rev. 2.0 Order M060273 page 1 of 19 TEST REPORT nr. R06027301_rev20 This test report cancel and replace document nr. R06027301 date 18.05.06 Test item Description.................................... : TRANSMITTER UNIT Trademark ..................................... : AUTEC Model and/or type reference......... : Type TD02 Model C05D Configuration P11 Manufacturer................................. : Same as client Serial Number ............................... : -- Client Name ............................................. : AUTEC S.r.l. Address ......................................... : Via Pomaroli, 65 ....................................................... : 36030 Caldogno (VI) – ITALY Test specification Standard ........................................ : FCC Rules & Regulations, Title 47 (2005) - Part 15 paragraph(s) : 33(a), 209, 215 (c) and 249 Report Tested by (+ signature) ............... : A. Bertezzolo - Supervisor Approved by (+ signature) ......... : R. Beghetto - Laboratory Manager Date of issue.................................. : 31.05.06 Contents ........................................ : 19 pages This test report shall not be reproduced except in full without the written approval of CMC. The test results presented in this report relate only to the item tested. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R06027301_rev20 Rev. 2.0 Order M060273 page 2 of 19 Index 1. SUMMARY ........................................................................................................................................................... 3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT)............................................................................... 4 3. TESTING AND SAMPLING............................................................................................................................... 4 4. OPERATIVE CONDITIONS .............................................................................................................................. 4 5. PHOTOGRAPH(S) OF EUT ............................................................................................................................... 5 6. EQUIPMENT LIST .............................................................................................................................................. 8 7. MEASUREMENT UNCERTAINTY ................................................................................................................ 10 8. REFERENCE DOCUMENTS ........................................................................................................................... 10 9. DEVIATION FROM TEST SPECIFICATION...............................................................................................11 10. TEST CASE VERDICTS .............................................................................................................................. 11 11. RESULTS........................................................................................................................................................ 11 11.1 RADIATED EMISSION 30-1000 MHZ............................................................................................................ 12 11.2 SPURIOUS EMISSION 1-10 GHZ................................................................................................................... 13 11.3 RANGE OF MODULATION BANDWIDTH.......................................................................................................... 14 12. GRAPHS AND TABLES ............................................................................................................................... 15 CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R06027301_rev20 Rev. 2.0 Order M060273 page 3 of 19 1. Summary Emission: FCC Rules & Regulations, Title 47 Test specifications Environmental Phenomena Tests sequence Result Part 15.209 + 15.249 Radiated Emission 30-1000 MHz 1 Complies Part 15.33 (a) + 15.209 Spurious Emission 1-10 GHz 2 Complies Part 15.215 (c) Range of modulation bandwidth 3 Complies The Test Report was given to the Client representatives for necessary documentation of ratification of the tested equipment and it is valid for the FCC certification. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R06027301_rev20 Rev. 2.0 Order M060273 page 4 of 19 2. Description of Equipment under test (EUT) Power supply ......................................................................... : 2,4 Vdc Type of equipment............................................................... : ; Transmitter Unit Receiver Unit Fixed station ; Portable station Mobile station Receiver class ........................................................................ : -- Alignment range .................................................................... : 902 – 928 MHz Switching frequency .............................................................. : 902 – 928 MHz Number of channels.............................................................. : -- Channel separation ............................................................... : -- Modulation............................................................................ : -- Extreme conditions ................................................................ : -- Maximum transmitter output power .................................... : -- Information on antenna ........................................................ :; Integrated Extern Other: Duty cycle .....................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos
