OQA-TWSNN1WHTransceiver Unit

Model TWS Type NN1WH label Model TWS Type NN1WH CPU plate position Label_and_position_tws_nn1wh_rev0 CPU MODULE RADIOMODULE AIRTCPUFH zHM829-519YCNEUQERF zHM078-368YCNEUQERF TYPENN1WH MODEL:TWS TA1614-01 FCC ID: OQA-TWSNN1WH IC: 9061A-TWSNN1WH HVIN: TWSNN1WH Power supply plate position

DEKRA Testing and Certification S.r.l. Sede Operativa: Via della Fisica 20, 36016 Thiene (VI), Tel. +39 0445 367702 - [email protected] TRF No. 15-247_HoppingDEKRA Page 1 of 14 Test Report No. R23061401 rev.1.0 TEST REPORT Nr. R23061401 Federal Communication Commission (FCC) Report Reference No. ............... : R23061401 Date of issue: .............................. : 22.06.2023 Total number pages: ................... : 14 Customer name ......................... : Autec S.r.l. Address ....................................... : Via Pomaroli, 65 – 36030 Caldogno (VI) – Italy Test specification: Standards .................................... : KDB 447498 D01 General RF Exposure Guidance v06 Non-standard test method .......... : N/A Test Report Form No. ............... : 15-247_HoppingDEKRA Test Report Form(s) Originator ... : DEKRA Testing and Certification S.r.l. Master TRF ................................. : 2023-06 General disclaimer: The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. (*) Test item description ........... : Transmitter Wireless Sub-system (*) Trademark .............................. : Autec (*) Manufacturer .......................... : Autec S.r.l. (*) Model / Type reference .......... : Model TWS Type NN1WH (*) FCC ID ................................... : OQA-TWSNN1WH (*) Rating(s) ................................. : 24-240 V ~ 50-60 Hz single-phase + earth Report Tested by (name + signature) ..... : M. Segalla ............................................................. Approved by (name + signature) .................................... : F. Marenda ............................................................. (*) information provided by the customer TRF No. 15-247_HoppingDEKRA Page 2 of 14 Test Report No. R23061401 rev.1.0 1 Summary 1 Summary........................................................................................................................................... 2 2 Reference standard .......................................................................................................................... 3 3 List of attachments ............................................................................................................................ 3 4 Deviation(s) from test specification ................................................................................................... 3 5 Testing location ................................................................................................................................. 3 6 General description of tested item and testing condition(s) ............................................................. 5 6.1 Photos of the test item ................................................................................................................. 6 7 Verdict summary section .................................................................................................................. 8 8 Test conditions ................................................................................................................................ 10 8.1 General ...................................................................................................................................... 10 9 Test results ..................................................................................................................................... 11 9.1 RF Exposure Analysis ............................................................................................................... 11 TRF No. 15-247_HoppingDEKRA Page 3 of 14 Test Report No. R23061401 rev.1.0 2 Reference standard KDB 447498 D01 General RF Exposure Guidance v06 RF exposure procedures and equipment authorization policies for mobile and portable devices 3 List of attachments Attachment 1: Measurement uncertainty, judgement of compliance and quality manual references 4 Deviation(s) from test specification None 5 Testing location DEKRA Testing and Certification S.r.l. Via della Fisica, 20 – 36016 Thiene (VI) – Italy Test site facility’s FCC registration number: 182474 Revision index Date Change history 1.0 21.06.2023 -- TRF No. 15-247_HoppingDEKRA Page 4 of 14 Test Report No. R23061401 rev.1.0 Testing and sampling: Date of receipt of test item .......................................... : 28.03.2023 Testing start date ........................................................ : 22.06.2023 Testing end date ......................................................... : 22.06.2023 Sampling procedure .................................................... : Sample used for testing chosen by the customer; DEKRA Testing and Certification S.r.l. cannot be considered responsible for the selection of the sample Internal identification ................................................... : Adhesive label with the product number P230272 General remarks: This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. The test results presented in this report relate only to the object tested. “(see appended table)": refers to a table appended to the report. Throughout this report a comma is used as the decimal separator. Possible test case verdicts: Test case does not apply to the test object: N/A (Not Applicable) Test object does meet the requirement: P (Pass) Test object does not meet the requirement: F (Fail) Test object does not performed: N/E (Not Executed) Definition of symbols used in this test report: ☒ Indicates that the listed condition, standard or equipment is applicable for this report. ☐ Indicates that the listed condition, standard or equipment is not applicable for this report. TRF No. 15-247_HoppingDEKRA Page 5 of 14 Test Report No. R23061401 rev.1.0 6 General description of tested item and testing condition(s) Description ......................…

Text truncated - open the document above for the full version.

ANT042_870-915_description_rev0 1 External antenna ANT042 description ModelANT042 EquipmentExternal antenna Manufacturer AUTEC srl Via Pomaroli, 65 36030 CALDOGNO (VI) The external antenna ANT042 is a transducer designed to transmit and receive electromagnetic waves. It can can be used in Autec equipment and it operates in 870-928MHz frequency band. The antenna can be directly connected to the equipment or it can be remoted with a RG58 cable provided by Autec. 1. Characteristics of the antenna The diagram of the external antenna gain is the following: By simulation, as this diagram reports, the realized gain of the antenna is 1.227dBi and the System Total efficiency is -0.4847dB.
