OQA-TWSNN1YHTransceiver Unit

Model TWS Type NN1YH label Model TWS Type NN1YH CPU plate position Label_and_position_tws_nn1yh_rev0 CPU MODULE RADIOMODULE AIRTCPUFH zHM829-519YCNEUQERF zHM078-368YCNEUQERF TYPENN1YH MODEL:TWS TA1615-01 FCC ID: OQA-TWSNN1YH IC: 9061A-TWSNN1YH HVIN: TWSNN1YH Power supply plate position

DEKRA Testing and Certification S.r.l. Sede Operativa: Via della Fisica 20, 36016 Thiene (VI), Tel. +39 0445 367702 - [email protected] TRF No. 15-247_HoppingDEKRA Page 1 of 15 Test Report No. R23069201 rev.1.0 TEST REPORT Nr. R23069201 Federal Communication Commission (FCC) Report Reference No. ............... : R23069201 Date of issue: .............................. : 21.06.2023 Total number pages: ................... : 15 Customer name ......................... : Autec S.r.l. Address ....................................... : Via Pomaroli, 65 – 36030 Caldogno (VI) – Italy Test specification: Standards .................................... : KDB 447498 D01 General RF Exposure Guidance v06 Non-standard test method .......... : N/A Test Report Form No. ............... : 15-247_HoppingDEKRA Test Report Form(s) Originator ... : DEKRA Testing and Certification S.r.l. Master TRF ................................. : 2023-06 General disclaimer: The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. (*) Test item description ........... : Transceiver unit (*) Trademark .............................. : Autec (*) Manufacturer .......................... : Autec S.r.l. (*) Model / Type reference .......... : Model TWS Type NN1YH (*) FCC ID ................................... : OQA-TWSNN1YH (*) Rating(s) ................................. : 9-36 Vdc Report Tested by (name + signature) ..... : M. Segalla ............................................................. Approved by (name + signature) .................................... : F. Marenda ............................................................. (*) information provided by the customer TRF No. 15-247_HoppingDEKRA Page 2 of 15 Test Report No. R23069201 rev.1.0 1 Summary 1 Summary........................................................................................................................................... 2 2 Reference standard .......................................................................................................................... 3 3 List of attachments ............................................................................................................................ 3 4 Deviation(s) from test specification ................................................................................................... 3 5 Testing location ................................................................................................................................. 3 6 General description of tested item and testing condition(s) ............................................................. 5 6.1 Photos of the test item ................................................................................................................. 6 7 Verdict summary section .................................................................................................................. 9 8 Test conditions ................................................................................................................................ 11 8.1 General ...................................................................................................................................... 11 9 Test results ..................................................................................................................................... 12 9.1 RF Exposure Analysis ............................................................................................................... 12 TRF No. 15-247_HoppingDEKRA Page 3 of 15 Test Report No. R23069201 rev.1.0 2 Reference standard KDB 447498 D01 General RF Exposure Guidance v06 RF exposure procedures and equipment authorization policies for mobile and portable devices 3 List of attachments Attachment 1: Measurement uncertainty, judgement of compliance and quality manual references 4 Deviation(s) from test specification None 5 Testing location DEKRA Testing and Certification S.r.l. Via della Fisica, 20 – 36016 Thiene (VI) – Italy Test site facility’s FCC registration number: 182474 Revision index Date Change history 1.0 21.06.2023 -- TRF No. 15-247_HoppingDEKRA Page 4 of 15 Test Report No. R23069201 rev.1.0 Testing and sampling: Date of receipt of test item .......................................... : 28.03.2023 Testing start date ........................................................ : 21.06.2023 Testing end date ......................................................... : 21.06.2023 Sampling procedure .................................................... : Sample used for testing chosen by the customer; DEKRA Testing and Certification S.r.l. cannot be considered responsible for the selection of the sample Internal identification ................................................... : Adhesive label with the product number P230271 General remarks: This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. The test results presented in this report relate only to the object tested. “(see appended table)": refers to a table appended to the report. Throughout this report a comma is used as the decimal separator. Possible test case verdicts: Test case does not apply to the test object: N/A (Not Applicable) Test object does meet the requirement: P (Pass) Test object does not meet the requirement: F (Fail) Test object does not performed: N/E (Not Executed) Definition of symbols used in this test report: ☒ Indicates that the listed condition, standard or equipment is applicable for this report. ☐ Indicates that the listed condition, standard or equipment is not applicable for this report. TRF No. 15-247_HoppingDEKRA Page 5 of 15 Test Report No. R23069201 rev.1.0 6 General description of tested item and testing condition(s) Description ................................. : Transceiver unit Model Number ...…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification S.r.l. Sede Operativa: Via della Fisica 20, 36016 Thiene (VI), Tel. +39 0445 367702 - [email protected] Accredited by ACCREDIA according to UNI CEI EN ISO/IEC 17025 accreditation n. 0168 L TRF No. 15-247_Hopping_DEKRA Page 1 of 60 Test Report No. R23069001 rev.1.0 LAB N° 0168 L TEST REPORT Nr. R23069001 Federal Communication Commission (FCC) Report Reference No. ............... : R23069001 Date of issue: .............................. : 21.06.2023 Total number pages: ................... : 60 Customer name ......................... : Autec S.r.l. Address ....................................... : Via Pomaroli, 65 – 36030 Caldogno (VI) – Italy Test specification: Standards .................................... : FCC Rules & Regulations, Title 47:2021 Part 15 paragraph(s): 203, 204, 205, 207, 209, 215 and 247 Non-standard test method .......... : N/A Test Report Form No. ............... : 15-247_Hopping_DEKRA Test Report Form(s) Originator ... : DEKRA Testing and Certification S.r.l. Master TRF ................................. : 2023-06 General disclaimer: The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of DEKRA Testing and Certification S.r.l. (*) Test item description ........... : Transceiver unit (*) Trademark .............................. : Autec (*) Manufacturer .......................... : Autec S.r.l. (*) Model / Type reference .......... : Model TWS Type NN1YH (*) FCC ID ................................... : OQA-TWSNN1YH (*) Rating(s) ................................. : 9-36 Vdc Report Tested by (name + signature) ..... : M. Segalla ............................................................. Approved by (name + signature) .................................... : F. Marenda ............................................................. (*) information provided by the customer TRF No. 15-247_Hopping_DEKRA Page 2 of 60 Test Report No. R23069001 rev.1.0 LAB N° 0168 L 1 Summary 1 Summary........................................................................................................................................... 2 2 Reference standard .......................................................................................................................... 3 3 List of attachments ............................................................................................................................ 3 4 Deviation(s) from test specification ................................................................................................... 3 5 Testing location ................................................................................................................................. 3 6 General description of tested item and testing condition(s) ............................................................. 5 6.1 Photos of the test item ................................................................................................................. 6 7 Verdict summary section .................................................................................................................. 9 8 Test conditions ................................................................................................................................ 11 8.1 General ...................................................................................................................................... 11 9 Test results ..................................................................................................................................... 12 9.1 Antenna requirements ............................................................................................................... 12 9.2 Conducted emission .................................................................................................................. 13 9.3 Emissions in restricted frequency bands and in unrestricted frequency bands ........................ 19 9.4 20 dB bandwidth ........................................................................................................................ 39 9.5 Channel separation ................................................................................................................... 42 9.6 Number of hopping channels ..................................................................................................... 44 9.7 Time of occupancy .................................................................................................................... 48 9.8 Band edge ................................................................................................................................. 51 9.9 Peak Output Power ................................................................................................................... 55 TRF No. 15-247_Hopping_DEKRA Page 3 of 60 Test Report No. R23069001 rev.1.0 LAB N° 0168 L 2 Reference standard FCC Rules and Regulation Title 47 part 15:2021 -- 3 List of attachments Attachment 1: Instruments list, measurement uncertainty, judgement of compliance and quality manual references 4 Deviation(s) from test specification None 5 Testing location DEKRA Testing and Certification S.r.l. Via della Fisica, 20 – 36016 Thiene (VI) – Italy Test site facility’s FCC registration number: 182474 Revision index Date Change history 1.0 21.06.2023 -- TRF No. 15-247_Hopping_DEKRA Page 4 of 60 Test Report No. R23069001 rev.1.0 LAB N° 0168 L Testing and sampling: Date of receipt of test item .......................................... : 28.03.2023 Testing start date ........................................................ : 08.06.2023 Testing end date ......................................................... : 15.06.2023 Sampling procedure .................................................... : Sample used for testing chosen by the customer; DEKRA Testing and Certification S.r.l. cannot be con…

Text truncated - open the document above for the full version.

ANT042_870-915_description_rev0 1 External antenna ANT042 description ModelANT042 EquipmentExternal antenna Manufacturer AUTEC srl Via Pomaroli, 65 36030 CALDOGNO (VI) The external antenna ANT042 is a transducer designed to transmit and receive electromagnetic waves. It can can be used in Autec equipment and it operates in 870-928MHz frequency band. The antenna can be directly connected to the equipment or it can be remoted with a RG58 cable provided by Autec. 1. Characteristics of the antenna The diagram of the external antenna gain is the following: By simulation, as this diagram reports, the realized gain of the antenna is 1.227dBi and the System Total efficiency is -0.4847dB.

tws_nn1yh_antenna_description_rev0 1 Antenna Description for Model TWS Type NN1YH ModelTWS TypeNN1WH EquipmentTransmitter wireless sub-system Manufacturer AUTEC srl Via Pomaroli, 65 36030 CALDOGNO (VI) 1. Antenna characteristics The used antenna is a transducer designed to transmit and receive electromagnetic waves. It can operate in 915-928MHz frequency band. It is connected to the AIRTCPUFH board (see the attached “sch_airtcpufh”) in the following point: The used antenna is a monopole with ground plane. See the document “ANT042_870-915_description_ rev0” for more details. Used frequency band915 - 928 MHz Antenna typeexternal antenna Antenna gain<2 dBi
