OQWST326-4-ITELEMETRY Transmitter

OM-06-320 REV E - i - 99-500-001 SRI/PMD SERIES 300 DIGITAL TELEMETRY SYSTEMS A BRIEF INTRODUCTION With over 25 years of experience in the field of industrial and commercial telemetry systems, SRI/PMD stands as an industry leader in providing an efficient means of transporting measurement data from one location to another. The use of Wireless Link    technology allows these systems to be utilized to obtain information from hard to get to locations, or from places where it is simply inconvenient and/or insecure to run hard wired interconnects. With the advent of our newest Series 300 Digital Telemetry Systems , we have released the power of Digital Signal Processing into what was previously a purely “analog” marketplace. The use of all digital signal processing not only furnishes a more robust and versatile means of gathering, transmitting, processing, and outputting highly accurate measurement data, but it also provides this capability at a cost affordable for even budget conscientious consumers. In developing the Series 300 systems, SRI/PMD has taken technology developed for highly critical space telemetry applications and applied it to designs suited for a wide variety of applications here on earth. Whether your particular need is gathering real-time torque, pressure, or temperature data from large industrial equipment, or is more simply oriented toward sending a basic analog signal across a parking lot, we believe you will find the right solution to your requirements at a price far below what has previously been offered. LIMITED WARRANTY SRI/PMD warrants that the receiver and accessory equipment’s of its manufacture as identified within this document shall, at the time of shipment to the original purchaser, be free from defects in material and workmanship and conform to the specifications at time of purchase (incorporated herein) for a period of one (1) year from the date of original shipment. Encapsulated transmitters and batteries shall be covered under these same warranty terms for a period of 90 days from the date of original shipment. This warranty applies only to equipment installed, operated, and maintained in accordance with SRI/PMD recommendations, and such warranty does not apply where SRI/PMD determines that any claimed defect has been caused by installation or repair, alteration, accident, or excessive deterioration due to environmental contamination. SRI/PMD’s obligation under this warranty is limited to repairing, or replacing, exclusive of cost of installation and labor charges, any part that SRI/PMD determines to be defective, provided that such part is received at SRI’s principal office, freight prepaid. All equipment's must receive prior approval for return to SRI for warranty repair, and must be sent prepaid. If they are returned collect, they will not be accepted. This warranty is subject to any existing conditions of supply which may directly affect SRI/PMD’s ability to obtain materials or manufacture replacement parts. SRI/PMD makes no warranty that the equipment shall be merchantable or fit for any particular purpose; nor does SRI make other warranties, express or implied, by operation of law or otherwise, except such as are expressly set forth herein. SRI/PMD shall not be liable to buyer, or to any third persons for any incidental, consequential, special or contingent damages for breach of any warranty. IMPORTANT NOTICE Most Series 300 products are designed as component devices that require external components to function. The products are intended to allow for full Part 15 compliance; however, they are not approved by the FCC or any other agency worldwide. The purchaser understands that approvals may be required prior to the sale or operation of this device, and agrees to utilize the component in keeping with all laws governing its operation in the country of operation. Some specific Series 300 models have been fully certified for FCC part 15 unlicensed operation. Contact SRI/PMD for further information for these units. OM-06-320 REV E - ii - 99-500-001 LIST OF EFFECTIVE PAGES Dates of issue for original and changed pages are: Revision - August 1998 Revision A February 1999 Revision B May 1999 Revision C June 1999 Revision D November 1999 Total number of pages in this publication is 85 consisting of the following: i - viii Table of Contents/List of Figures/List of Tables 1 - 77 Document Main Text NOTE: On partial document updates, insert latest changed pages and destroy superseded pages. A vertical line in the outer margin of the page indicates the portion of the text affected by changes. A vertical line in the outer margin of the Figure or Table name indicates changes to illustrations or tables. RECORD OF CHANGES REVISION DATE TITLE OR BRIEF DESCRIPTION N/A March 1998 Draft Market Research Release Breadboard Version 0.00 - August 1998 ST-320/SR-340 Beta Test Release FW Versions 1.00 A February 1999 Production Upgrade Release – ST-360/SR-380 FW Versions 2.00 B May 1999 Firmware Upgrade and Pinout Corrections FW Versions 2.01 C June 1999 Upgrade to All Firmware FW Versions 2.05 D November 1999 Production Release for Software 3.00 Including Extended SW Capabilities OM-06-320 REV E TABLE OF CONTENTS - iii - 99-500-001 SECTION 1 INTRODUCTION ..................................... 1 1.1 Scope ............................................................ 1 1.2 Product Overview ................................................. 1 1.3 Product Description .............................................. 2 1.4 Model Numbers .................................................... 3 1.5 Technical Specifications ......................................... 4 1.5.1 Transmitter Specifications .................................... 5 1.5.2 Receiver Specifications ....................................... 5 1.5.3 Optional Accessory Equipment and Software ..................... 6 SECTION 2 DIGITAL TELEMETRY SYSTEM DESCRIPTION ............. 8 2.1 Transmitter Details ........................…

Text truncated - open the document above for the full version.

Channel Select Gain and Excitation Select Analog Input 16 Differ Sensor Inputs 16 +5 VDC Excitation Outputs Excitation Voltage Digital Data Stream @ 25, 20, 18, or 12.5 Kbps Channel Select Wireless Link External Programming Interface Analog Input 2 Micro Controller Temperature Sensor Analog Multiplexers Signal Contioning Config Data in EEProm Linx HP TXM Transmitter 4 MHz Crystal Sensor Input Power Converter Primary VDC Input (+7 to +18 VDC) +5 VDC RI/PMD ST-326 TRANSMITTER BLOCK DIAGRAM

Channel Select Up to 16 Analog Outputs Digital Data Stream @ 25, 20, 18, or 12.5 Kbps Wireless Link Remote Interface Config Control Digital Data Words Programming Interface to Transmitter Receive Strength Signal Indicator Digital Outputs 2 Analog Outputs Optional Extended I/O’s Front Panel LED’s DIP Switches Back end Micro Controller Prog/Config EEProm Other Ext Interfaces RS-232 Interface Program Interface Linx HP RXM II Receiver Front End Micro Cont Opt Ext Analog Chan Digital Interface Onboard Analog Chan SRI/PMD SR-346 RECEIVER BLOCK DIAGRAM 16 MHz Crystal Osc

SRI/PMD ST-326 AND SR-346 TOP LEVEL BLOCK DIAGRAM Series 300 Digital Telemetry Equipment System ST-326 Digital Telemetry Transmitter (Intentional Radiator) SR-346 Digital Telemetry Receiver Sensor Interfaces (Up to 16) MX-301 Sensor Multiplexer Card Multiplexed Sensor Interface TP -301 Transmit Processor Card Transmit Control and Data Interface Linx HP-TXM Transmitter Card RF Transmit Link (902 to 928 MHz) Analog Outputs (Up to 16) AO-301 Analog Output Card Analog Output Control RP-301 Receive Processor Card Receiver Control and Data Interface Linx HP-RXM II Receiver Card Digital Output Serial Interface

TP-301 PCB – Top View TP-301 PCB – Bottom View MX-301 PCB – Top View MX-301 PCB – Bottom View Linx HP-TXM PCB Top View Linx HP-TXM PCB Bottom View

RP-301 Top Side RP-301 Bottom Side AO-301 Top Side AO-301 Bottom Side Linx HP-RXM II Top Side Linx HP-RXM II Bottom Side

JA-1679 i TABLE OF CONTENTS Paragraph Title Page CERTIFICATION...........................................1 ABSTRACT..............................................2 1.0INTRODUCTION...........................................3 1.1Purpose............................................ 3 1.2Requirements........................................ 3 1.3Unit Under Test Description............................. 4 1.4Summary of Results................................... 4 2.0APPLICABLE DOCUMENTS.................................7 3.0TEST SITE DESCRIPTION...................................8 3.1Environmental Conditions............................... 8 4.0TEST INSTRUMENTATION..................................9 5.0TEST SAMPLE SETUP AND CONFIGURATIONS...............10 6.0PROCEDURES AND RESULTS.............................13 6.1Radiated Emissions.................................. 13 6.2Conducted Emissions................................. 14 APPENDIX A COMPLIANCE LETTER.........................................56 APPENDIX B SYSTEM DESCRIPTION.........................................58 JA-1679 1 CERTIFICATION Rubicom Systems, Inc. (RSI) certifies the information obtained in this report was performed consistent with the requirements of ANSI C63.4-1992. The Summation Research, Inc., Series 300 Digital Telemetry System complies with the requirements of CFR 47 Part 15.249 Subpart C for intentional radiators. This data was obtained while testing a Series 300 Digital Telemetry System, s/n: 0002 furnished by Summation Research, Inc. and described in Paragraph 1.3 of this document. Any modifications, other than those listed in Figure 1.4-1, to the unit as tested may invalidate the data and void this certification. _______________________________ Joseph G. Barbee President JA-1679 2 ABSTRACT This report presents test results of the emanations found emitting from the Summation Research, Inc., Series 300 Digital Telemetry System and the comparison of these emissions to the requirements of the FCC, Title 47, Part 15.249 Subpart B for intentional Transmitter. This testing was performed on a 3-meter open area test site at Rubicom Systems, Inc. The testing was performed for Summation Research, Inc. under purchase order 99-5500446 and is filed under JA-1679 at RSI. The results of this test effort demonstrate compliance of the Series 300 Digital Telemetry System to the CFR Title 47, Part 15.249 Subpart B, intentional transmitters. The unit under test was a Series 300 Digital Telemetry System, s/n: 0002. JA-1679 3 1.0INTRODUCTION 1.1Purpose The purpose of this report is to show compliance of the Summation Research, Inc. Series 300 Digital Telemetry System to the requirements of the FCC Rules and Regulations (CFR Title 47, Part 15.249) for intentional transmitters operating in the 902-928MHz range. The tests were performed on a three meter site. 1.2Requirements The test requirements are as follows: RADIATED (15.209a) (15.205) 3 Meter Field Strength 3 Meter Freq. (MHZ)
V/M dB
V/M 30 - 88 100 40 88 - 216 150 43.5 216 - 960 200 46 960 - Above 500 54 Avg 74 Peak CONDUCTED Freq. (MHZ)
VoltsdB>
V .450-30MHz 250 48 RADIATED (CFR 15.249a) Field Strength3 Meter 3 Meter dB
V/m Fundamental50 Millivolts 94 Harmonics500 Microvolts 54 JA-1679 4 1.3Unit Under Test Description The Series 300 Digital Telemetry System is described in Appendix B (Summation Sales Brochure). The unit was powered by 9VDC supplied by a 9 volt battery. The receiver was powered by an AC/DC transformer CUI-Stack p/n: DTS 120250U/AC1-P5. 1.4Summary of Results Data is presented in Paragraph 6.0. The Series 300 Digital Telemetry System was found to be compliant to the requirements of CFR Title 47, Part 15.249. These results were found after the modifications listed in Table 1.4-1 were implemented. JA-1679 5 Filtering added to the power line on the under side of the board Supplier:Panasonic Part Number:ECS-T1AX105R Qty. Used:2 Supplier:Inductor Warehouse Part Number:28F0248-60T Qty. Used:1 Filtering directly on J1 Power Inlet Supplier:Panasonic Part Number:ECS-T1AX105R Qty. Used:1 Supplier:Panasonic Part Number:ECS-T1AX106R Qty. Used:1 Filtering directly on U13 Power Supplier:Panasonic Part Number:ECS-T1AX106R Qty. Used:1 BNC CH1 and CH2 Connectors Supplier:AMP Part Number:413879-1 TABLE 4.1-1 JA-1679 6 DB9 Remote Connector Supplier:AMP Part Number:869522-6 DB25 Digital Connector Supplier:AMP Part Number:869464-6 36 Pin Champ Analog Connector Supplier:AMP Part Number:555233-1 Capacitance Value added to each signal line on connector is 820pF (CK05BX821K) 18ea. Ferrite Beads added to the Power Line Supplier:Inductor Warehouse Part Number:28F0248-6T0 Qty. Used:1 Also: Supplier:Steward Part Number:28C0236-OEW *All Board Mounting Standoffs are Grounded TABLE 1.4-1 (Cont.) JA-1679 7 2.0APPLICABLE DOCUMENTS The following documents form a part of this report to the extent expressed herein: FCC Code of Federal Regulations Title 47, Part 15, FCC Procedure for Measuring RF Emissions from Computing Devices FCC/OET MP-4, July 1987 ANSI C63.4-1992 FCC Characteristics of Open Field Test Sites Bulletin OET 55, October 1989

JA-1679 8 3.0TEST SITE DESCRIPTION This testing was performed at Rubicom Systems, Inc. 3-meter open area test site. The description of the measurement facility was found to be compliant with the requirements of Section 2.948 of the FCC Rules. A copy of the compliance letter is attached to this report as Appendix A. 3.1Environmental Conditions Environmental conditions during testing of the EUT were as follows: Date: October 26, 1999Date: November 17, 1999 Temperature: 78Temperature: 72º  Barometer: 29.60 inchesBarometer: 29.60 inches Humidity: 59%Humidity: 59% JA-1679 9 4.0TEST INSTRUMENTATION The following test equipment was used to perform this testing. Cal. Qty. DescriptionManufacturer Model No. Due 1 Spectrum Advantest R3271 08/02/00 Analyzer 1 Spectrum Advantest R3261A 03/10/00 Analyzer 1 Bi-Log Chase CLB6111B 07/10/00 Antenna 1 Power Line Solar Elect.8012-50-5- NCR Stab. Network 24-BNC 1 PlotterHewlett Packard7440ANCR JA-1679 10

5.0TEST SAMPLE SETUP AND CONFIGURATIONS The Summation Research, Inc. Series 300 Digital Telemetry System was placed on the nonconductive 80cm high manual turntable. The unit was configured with an external AC/DC power supply and a 9 VDC battery. Cables were configured in a normal setup. Setup for the Series 300 Digital Telemetry System is shown below. The Series 300 Di gita l Telemet ry System test setup is shown in Photos 1 and 2. JA-1679 11 JA-1679 12 PHOTO 2 JA-1679 13 6.0PROCEDURES AND RESULTS 6.1Radiated Emissions Prescans were done in a shielded enclosure and are on file at Rubicom Systems. There were no signals detected from the transmitter below 903.3MHz. Tabulated data for all signals detected are listed in this section. Table 6.1-1 presents receiver frequencies within 10dB of the requirement and Table 6.1-2 through 6.1-7 presents transmit harmonics. Tests for transmitter harmonics were done at low, mid and high frequencies (903.3MHz, 912.3MHz and 921.3MHz). All testing from 30MHz to 10GHz was performed on the 3 meter site. An example of calculations are as follows: Meter Reading 20 dB
V Antenna Factor +16 Conversion Factor Cable Loss +2 Correction Factor Result +38 dB
V/m The spectrum analyzer memory card contains the correction factors for calibrated cables and antenna factors. When external attenuation is required the reference level is offset during test. Data Sheets 6.1-1 through 6.1-16 present plots of the radiated data over the range of 30MHz-10GHz. The exact levels of signals detected and maximized are presented in the tabulated tables mentioned above. Data Sheets 6.1-17 through 6.1-32 are the ambient profiles for the 30MHz- 10GHz radiated measurements. JA-1679 14 6.2Conducted Emissions Power line conducted data is presented in Data Sheets 6.2-1 and 6.2-2. No failures were experienced during conducted testing. No modifications were needed to meet conducted emission requirements. JA-1679 15 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link SR341-16-X Receiver S/N: 0002 DATE: 11/17/99 TESTER: Q.P. LIMIT MEASURED ANTENNAMEASURED (dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH(dB
V/m)3 METERS (dB) 196M H 1.25M 157  34 43.5 -9.5 248M H 1.5M 157  37 46 -9.0 256M H 1.5M 180  37.5 46 -8.5 260M H 1.5M 157  37 46 -9.0 284M H 1.5M 180  38 46 -8.0 296M H 1.25M 157  40 46 -6.0 300M H 1.25M 157  37 46 -9.0 308M H 1.25M 157  38 46 -8.0 312M H 1.25M 135  38 46 -8.0 316M H 1.25M 135  36 46-10.0 320M H 1.25M 135  36 46-10.0 324M H 1.5M 135  36 46-10.0 TABLE 6.1-1 JA-1679 16 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link ST326-16-X Transmitter Harmonics S/N: 0002 DATE: 11/17/99 FREQ: Low 903.3MHz TESTER: MEASURED Q.P. LIMIT FREQUENCY ANTENNA (dB
V/m)(dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH PEAK3 METERS (dB) 903.3M H 1.25 157  69 94>-10dB 903.3M V 1.25 157  67 94>-10dB 1.806M H 1.25 157  45 74>-10dB 1.806M V 1.25 157  46 74>-10dB 2.709M H 1.0 180  42 74>-10dB 2.709M V 1.0 157  44 74>-10dB 3613M H 1.25 135  53 74>-10dB 3613M V 1.25 180  54.5 74>-10dB 4516M H 1.25 135  51 74>-10dB 4516M V 1.0 202  48 74>-10dB 5419M H/VNOISE FLOOR LEVEL 6323M H/VNOISE FLOOR LEVEL 7226M H/VNOISE FLOOR LEVEL 8129M H/VNOISE FLOOR LEVEL 9033M H/VNOISE FLOOR LEVEL TABLE 6.1-2 JA-1679 17 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link ST326-16-X Transmitter Harmonics S/N: 0002 DATE: 11/17/99 FREQ: Low 903.3MHz TESTER: MEASURED AVG. LIMIT FREQUENCY ANTENNA(dB
V/m)(dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH AVG3 METERS (dB) 1806M H 1.25 157  45 54 -9.0 1806M V 1.25 157  46 54 -8.0 2709M H 1.0 180  40 54-14.0 2709M V 1.0 157  42 54-12.0 3613M H 1.25 135  45 54 -9.0 3613M V 1.25 150  47.5 54 -6.5 4516M H 1.25 135  44 54-10.0 4516M V 1.0 202  39 54-15.0 5419M H/VNOISE FLOOR LEVEL 6323M H/VNOISE FLOOR LEVEL 7226M H/VNOISE FLOOR LEVEL 8129M H/VNOISE FLOOR LEVEL 9033M H/VNOISE FLOOR LEVEL TABLE 6.1-3

JA-1679 18 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link ST326-16-X Transmitter Harmonics S/N: 0002 DATE: 11/17/99 FREQ: Mid 912.3MHz TESTER: MEASURED Q.P. LIMIT FREQUENCY ANTENNA(dB
V/m)(dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH PEAK3 METERS (dB) 912.3M H 1.25 157  69 94>-10dB 912.3M V 1.25 180  66 94>-10dB 1824M H 1.0 67  41 74>-10dB 1824M V 1.0 112  47 74>-10dB 2736M H 1.25 202  40 74>-10dB 2736M V 1.0 247  43 74>-10dB 3649M H 1.25 157  55 74>-10dB 3649M V 1.0 225  56 74>-10db 4561M H 1.25 225  46 74>-10dB 4561M V 1.0 112  49 74>-10dB 5473M H/VNOISE FLOOR LEVEL 6386M H/VNOISE FLOOR LEVEL 7298M H/VNOISE FLOOR LEVEL 8210M H/VNOISE FLOOR LEVEL 9123M H/VNOISE FLOOR LEVEL TABLE 6.1-4 JA-1679 19 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link ST326-16-X Transmitter Harmonics S/N: 0002 DATE: 11/17/99 FREQ: Mid 912.3MHz TESTER: MEASURED AVG. LIMIT FREQUENCY ANTENNA(dB
V/m)(dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH AVG.3 METERS (dB) 1824M H 1.0 67  34 54 -20.0 1824M V 1.0 112  45 54 -9.0 2736M H 1.25 202  33 54 -21.0 2736M V 1.0 247  35 54 -19.0 3649M H 1.25 157  50 54 -4.0 3649M V 1.0 225  51.5 54 -3.5 4561M H 1.25 225  37 54 -17.0 4561M V 1.0 112  43 54 -11.0 5473M H/VNOISE FLOOR LEVEL 6386M H/VNOISE FLOOR LEVEL 7298M H/VNOISE FLOOR LEVEL 8210M H/VNOISE FLOOR LEVEL 9123M H/VNOISE FLOOR LEVEL TABLE 6.1-5 JA-1679 20 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link ST326-16-X Transmitter Harmonics S/N: 0002 DATE: 11/17/99 FREQ: High 921.3MHz TESTER: MEASURED Q.P. LIMIT FREQUENCY ANTENNA(dB
V/m)(dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH PEAK3 METERS (dB) 912.3M H 1.5 157  69 94>-10dB 912.3M V 1.25 180  65 94>-10dB 1842M H 1.0 180  43 74>-10dB 1842M V 1.0 157  46 74>-10dB 2763M H 1.0 247  42 74>-10dB 2763M V 1.0 225  45 74>-10dB 3685M H 1.0 135  53 74>-10dB 3685M V 1.0 180  56 74>-10db 4606M H 1.25 180  46 74>-10dB 4606M V 1.0 157  48 74>-10dB 5527M H/VNOISE FLOOR LEVEL 6449M H/VNOISE FLOOR LEVEL 7370M H/VNOISE FLOOR LEVEL 8291M H/VNOISE FLOOR LEVEL 9213M H/VNOISE FLOOR LEVEL JA-1679 21 FCC RADIATED EMISSIONS TABULATED RESULTS EUT MODEL: Summation Research, Inc. Series 300 Wireless Link ST326-16-X Transmitter Harmonics S/N: 0002 DATE: 11/17/99 FREQ: High 921.3MHz TESTER: MEASURED AVG. LIMIT FREQUENCY ANTENNA(dB
V/m)(dB
V/M @MARGIN (MHZ) POL.EVALUATIONAZIMUTH AVG.3 METERS (dB) 1842M H 1.0 180  37 54 -17.0 1842M V 1.0 157  43 54 -11.0 2763M H 1.0 247  35 54 -19.0 2763M V 1.0 225  38 54 -16.0 3685M H 1.0 135  45 54 -9.0 3685M V 1.0 180  50 54 -4.0 4606M H 1.25 180  46 54 -8.0 4606M V 1.0 157  48 54 -6.0 5527M H/VNOISE FLOOR LEVEL 6449M H/VNOISE FLOOR LEVEL 7370M H/VNOISE FLOOR LEVEL 8291M H/VNOISE FLOOR LEVEL 9213M H/VNOISE FLOOR LEVEL

JA-1679 56 TABLE 6.1-7 APPENDIX A COMPLIANCE LETTER JA-1679 58 APPENDIX B SYSTEM DESCRIPTION

Bandwidth Spectrum Picture of ST-326 Transmitter Operating at 923.37 MHz
