OR3-RSC-811U-ICamping RF Lamp with Infrared Remote Control

Intertek Testing Services ETL SEMKO Federal Communications Commission 455 12 th St. SW Washington DC 20554 November 9, 1999 Re:FCC ID OR3-RSC-811U-I Applicant:Favour Light Enterprises Limited 731 Confirmation Number:EA95841 Dear Sir/Madam, Please be informed that due to the typing mistake, we have entered an incorrect information on the form 731. In item 12, equipment specifications, the frequency range in MHz should be 0.015 instead of 15. Please revise the above-mentioned item. Sorry to make you trouble. Should you have any queries, please feel free to contact me at e-mail: [email protected]. Thank you for your attention. Best regards, Danny Chui Engineer

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited FCC ID : OR3-RSC-811U-I Favour Light Enterprises Ltd. Application For Certification (FCC ID: OR3-RSC-811U-I) RF Lighting Device WO# 9909603 CKL/at November 1, 1999 INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1:General Description EXHIBIT 2:System Test Configuration EXHIBIT 3:Emission Results EXHIBIT 4:Equipment Photographs EXHIBIT 5:Product Labelling EXHIBIT 6:Technical Specifications EXHIBIT 7:Instruction Manual INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I ii MEASUREMENT/TECHNICAL REPORT Favour Light Enterprises Ltd. - MODEL: CI811U FCC ID: OR3-RSC-811U-I November 1, 1999 This report concerns (check one:)Original Grant X Class II Change Equipment Type: RF Lighting Device (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by:C. K. Lam Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone:852-2173-8512 Fax:852-2742-9149 INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I iii Table of Contents 1.0 General Description................................................................................................................. 2 1.1 Product Description.............................................................................................................. 2 1.2 Related Submittal(s) Grants .................................................................................................2 1.3 Test Methodology ................................................................................................................ 3 1.4 Test Facility.......................................................................................................................... 3 1.5 Equipment List..................................................................................................................... 4 2.0 System Test Configuration...................................................................................................... 6 2.1 Justification .......................................................................................................................... 6 2.2 EUT Exercising Software.....................................................................................................6 2.3 Special Accessories.............................................................................................................. 6 2.4 Equipment Modification ......................................................................................................7 2.5 Support Equipment List and Description.............................................................................. 7 3.0 Emission Results....................................................................................................................... 9 3.1 Field Strength Calculation ..................................................................................................10 3.1 Field Strength Calculation (cont)........................................................................................ 11 3.2 Radiated Emission Configuration Photograph.................................................................... 12 3.3 Radiated Emission Data .....................................................................................................13 4.0 Equipment Photographs........................................................................................................ 16 5.0 Product Labelling................................................................................................................... 18 6.0 Technical Specifications......................................................................................................... 20 7.0 Instruction Manual................................................................................................................ 22 INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I iv List of attached file Exhibit typeFile Descriptionfilename Cover LetterLetter of Agencyletter.pdf Test ReportTest Reportreport.doc Test Setup PhotoRadiated Emissionradiated1.jpg to radiated2.jpg External PhotoExternal Photoophoto1.jpg, ophoto2.jpg Internal PhotoInternal Photoiphoto1.jpg to iphoto3.jpg Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I 2 1.0General Description 1.1Product Description The equipment under test (EUT) is a RF lighting consisting of an electronic ballast and fluorescent tube. The EUT is operated at 15kHz and powered by four size D batteries. The brief circuit description is listed as follows: -TR, T 1 and associated circuit act as infrared receiver. -TC 1 , IC 2 and associated circuit act as decoder and D type flip-flop. -T 4 and associated circuit act as Oscillator. The model: SI811U and RI811U are the same as the model: CI811U in hardware aspect. The difference in model number shows the difference in color of the case. 1.2Related Submittal(s) Grants This is a single application for certification of a RF lighting device. INTERTEK TESTING SERVICES FCC ID: OR3-RSC-811U-I 3 1.3Test Methodology Radiated emission measurements were performed according to the procedures in MP-5. All measurements were performed in Open Area Test Sites. Preliminary scans were performed in the Open Area Test …
