OTH-9002MWDTwo Line S.S.T. Cordless Phone

Tele Matrix Equipment, LLC

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Feb 21, 2000
Application Purpose: Original Equipment
Date of Application: Nov 28, 1999
Equipment Note: Two Line S.S.T. Cordless Phone
Frequency Range: 903.90000000 - 926.12000000
Company: Tele Matrix Equipment, LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Block Diagram

page-1 (3600x5100x256 jpeg)

ID Label/Location Info

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation * Privacy of communication may not be ensured when using this phone Model No.:Marquis 9002MWD FCC ID :OTH-9002MWD LABEL Size: 47 x 10 mm LABEL Position: LABEL Format: Model No.:Marquis 9002MWD FCC ID :OTH-9002MWD LABEL Size: 14 x 8 mm LABEL Position:

Schematics

BASE-1 (3600x4976x256 jpeg)

Schematics

BASE-2 (3600x4976x256 jpeg)

Schematics

BASE-3 (3600x4976x256 jpeg)

Schematics

HANDSET (3600x4976x256 jpeg)

Test Report

MEASUREMENT REPORT of CORDLESS TELEPHONE Applicant: Tele Matrix Equipment, LLC Model No.: Marquis 9002MWD, Marquis 9002MWD5 EUT: Two Line S.S.T. Cordless Phone FCC ID: OTH-9002MWD Report No.: K1215927 Test by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 2, Lane 194, Huan-Ho Street, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Test Repot ------------------------------------------------------------------------------------ 9/61 Report No.: K1215927, 900MHz S.S.T. Cordless Phone, FCC Part 15 Class B Test date: 11/15/99, Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 2.3 Test configuration Conducted emissions test placement (idle only) Test Repot ------------------------------------------------------------------------------------ 10/61 Report No.: K1215927, 900MHz S.S.T. Cordless Phone, FCC Part 15 Class B Test date: 11/15/99, Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 Conducted emissions test placement (operating only) Test Repot ------------------------------------------------------------------------------------ 23/61 Report No.: K1215927, 900MHz S.S.T. Cordless Phone, FCC Part 15 Class B Test date: 11/15/99, Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 5.3Test Instruments Configuration Pig 1 Front View of the Test Configuration ( BASE ) Pig 2 Rear View of the Test Configuration ( BASE ) Test Repot ------------------------------------------------------------------------------------ 24/61 Report No.: K1215927, 900MHz S.S.T. Cordless Phone, FCC Part 15 Class B Test date: 11/15/99, Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 Pig 1 Front View of the Test Configuration (HANDSET) Pig 2 Rear View of the Test Configuration (HANDSET) The test configuration for frequency between 1 GHz to 18 GHz is same as above.
