OUCG8C-226M-DAutomotive Security Device Receiver

! CAUTION The remote control switch is a precision electronic device. Therefore, pay attention to the following: Do not impose shock on the remote control switch. Keep the remote control switch dry. Do not disassemble the remote control switch. Your keyless entry system operates on a radio frequency subject to Federal Communications Commission (FCC) rules and Industry Canada rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following tow conditions. (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation of the device. “Complies with RSS-210 of Industry Canada.” NOTICE This equipment has been tested and found to comply with the limits for a Class B device, pursuant to part 15 of the FCC Rules, These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications However there is no guarantee that interference will not occur in particular installation. If this equipment dose cause harmful interference to radio or radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/TV technician for help. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Test report Our reference : 21KE0038-YW Page: 2 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Table of Contents Page 1 GENERAL INFORMATION3 1.1 Product Description4 1.2 Test Specification4 1.3 Methods & Procedures4 1.4 Exclusion from satndards4 1.5 Test Location4 2 SYSTEM TEST CONFIGURATION5 2. 1 Operation Environment 5 2.2 Justification5 2. 3 EUT Exercise Software5 2.4 Test Procedure5 Figure 2.1 Configuration of Tested System6 3 RADIATED MEASUREMENT PHOTOS7 Figure 3.1 Radiated Measurement Photos7 3.1 Measurement Uncertainty8 4 RADIATED EMISSION DATA9 4.1 Field Strength Calculation10 5 TEST EQUIPMENT USED11 APPENDIX12 A:Test Data A1-A2 Test report Our reference : 21KE0038-YW Page: 3 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1 GENERAL INFORMATION APPLICANT: OMRON CORPORATION TRADE NAME: OMRON ADDRESS: 6368 Nenjo-Zaka, Okusa, Komaki-City, Aichi 485-0802 Japan Tel: +81-568-78-6170 Fax: +81-568-78-6179 REGULATION(S): FCC Part 15 Subpart B Section15.109(a) MODEL NUMBER: G8C-226M-D FCC ID: OUCG8C-226M-D SERIAL NUMBER: sample No.1 KIND OF EQUIPMENT: Keyless Entry System (Receiver) TESTED DATE: June 13, 2001 RECEIPT DATE OF SAMPLE : June 9, 2001 REPORT FILE NUMBER: 21KE0038-YW TEST SITE: A-PEX Yokowa No.3 Open Test Site Test report Our reference : 21KE0038-YW Page: 4 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1.1 Product Description Model: G8C-226M-D (referred to as the EUT in this report) The specification is as following : Type of receiver: Super Heterodyne Receiving Frequency: 313.85MHz Local Oscillator Frequency : 324.55 MHz Intermediate Frequency: 10.7MHz Other Clock Frequency: 8.18MHz Operation Voltage: DC 12V 1.2 Test Specification Test Specification: FCC Part 15 Subpart B Section 15.109 Radiated emission limits Title: FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators 1.3 Methods & Procedures No.ItemTest ProcedureSpecificationRemarks 1Conducted emissionANSI C63.4:1992§15.107(a) - 2Radiated emissionANSI C63.4:1992§15.109(a)Class B / 3m 1.4 Exclusion from standards No.ItemTest ProcedureSpecificationRemarks 1Conducted emissionANSI C63.4:1992§15.107(a)- * This test was not performed since EUT dose not have AC power port. 1.5 Test Location A-PEX International Co.,Ltd. Yokowa No.3 test site 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 Japan Telephone number: +81-596-39-1485 Facsimile number: +81-596-39-0232 This site has been fully described in a report submitted to FCC office, and listed on September 12, 2000(Registration number: 90412) . *NVLAP Lab. code : 200109-0 Test report Our reference : 21KE0038-YW Page: 5 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 2 SYSTEM TEST CONFIGURATION 2.1 Operation Environment Temperature: See data Humidity: See data Power supply: DC 12V 2.2 Justification The system was configured in typical fashion (as a customer would normally use it) for testing. 2.3 EUT Exercise Software The EUT exercise program used during radiated testing was designed to exercise the various system components in a manner similar to typical use. The sequence is used: Operation Mode : Receiving 2.4 Test Procedure Tabletop Equipment Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1m, raised 80cm above the conducting ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane to obtain the maximum signal strength. The measurement distance was 3m. Test report Our reference : 21KE0038-YW Page: 6 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Figure2.1 Configuration of Tested System Front View (A):EUT (B) (C) * Cabling was taken into consideration and test data was taken under worse case conditions. Top View (A):EUT (B) (C) * Cabling was taken into consideration and test data was taken under worse case conditions. Description of EUT and Support Equipment No.ItemModel numberSerial numberManufacturerRemark A Keyless Entry System (Receiver) G8C-226M-DSample No.1OMRON Corporation EUT B Checker BoxN/AN/AOMRON Corporation - C Car Battery50B24LN/AYUASA - List of cables used No.NameLength (m)ShieldRemark Signal & DC Power Cable 0.9N– DC Power Cable 0.5N– Test report Our reference : 21KE0038-YW Page: 7 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 3 RADIATED MEASUREMENT PHOTOS Figure 3.1 Radiated Measurement Photos Test report Our reference : 21KE0038-YW Page: 8 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 3.1 Measurement Uncertainty Radiated Emission Test The measurement uncertainty (with a 95% confidence level) for this test was 3.3dB. The data listed in this test report may exceed the test limit because it does not have enough margin (more than 3.3dB). The data listed in this test report has enough margin, more than 3.3d Test report Our reference : 21KE0038-YW Page: 9 of 12 Issued date: August 9, 2001 FCC ID: OUCG8C-226M-D Testing Laborato…
