OUCG8D-325A-BSecurity System Receiver

! CAUTION The remote control switch is a precision electronic device. Therefore, pay attention to the following: Do not impose shock on the remote control switch. Keep the remote control switch dry. Do not disassemble the remote control switch. Your keyless entry system operates on a radio frequency subject to Federal Communications Commission (FCC) rules and Industry Canada rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation of the device. “Complies with RSS-210 of Industry Canada.” FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Test report Our reference : 21IE0027-YW-2 Page: 2 of 10 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Table of Contents Page 1 GENERAL INFORMATION3 1.1 Product Description4 1.2 Test Specification4 1.3 Methods & Procedures4 1.4 Ezclusion from standards4 1.5 Test Location4 2 SYSTEM TEST CONFIGURATION5 2. 1 Operation Environment 5 2.2 Justification5 2. 3 EUT Exercise Software5 2.4 Test Procedure5 Figure 2.1 Configuration of Tested System6 3 RADIATED EMISSION DATA7 3.1 Field Strength Calculation8 3.2 Measurement Uncertainty8 4 TEST EQUIPMENT USED9 APPENDIX10 A:Test Data A1 – A2 Test report Our reference : 21IE0027-YW-2 Page: 3 of 10 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1 GENERAL INFORMATION APPLICANT: OMRON CORPORATION TRADE NAME: OMRON ADDRESS: 6368 Nenjo-Zaka, Okusa, Komaki-City, Aichi 485-0802 Japan Tel: +81-568-78-6170 Fax: +81-568-78-6179 REGULATION(S): FCC Part 15 Subpart B §15.109(a) MODEL NUMBER: G8D-325A-B (3SW type) FCC ID: OUCG8D-325A-B SERIAL NUMBER: Sample No.1 KIND OF EQUIPMENT: Keyless Entry System (Receiver) TESTED DATE: April 10, 2001 RECEIPT DATE OF SAMPLE : April 6, 2001 REPORT FILE NUMBER: 21IE0027-YW-2 TEST SITE: A-PEX Yokowa No.3 Open Test Site Test report Our reference : 21IE0027-YW-2 Page: 4 of 10 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1.1 Product Description Model: G8D-325A-B (3SW type) (referred to as the EUT in this report) is a Keyless Entry System (Receiver). G8D-325A-B (3SW type) is deemed to be equal about the level of EMC since they have few differences as remarked below, therefore, G8D-325A-B (3SW type) which is a top-level model was measured as their representative. Model No PWB Parts on PWB software(basic control) G8D-325A-B (2SW type) same as G8D-325A-B(3SW type) TR4, TR5 and their support parts are not loaded.same as G8D-325A-B(3SW type) G8D-325A-B (3SW type) OriginOrigin Origin The specification is as following : Type of receiver: Super Heterodyne Receiving Frequency: 313.85MHz Local Oscillator Frequency : 324.55 MHz Intermediate Frequency: 10.7MHz Other Clock Frequency: 5.00MHz(CPU) Operation Voltage: DC 12V 1.2 Test Specification Test Specification: FCC Part 15 Subpart B § 15.109 Radiated emission limits Title: FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators 1.3 Methods & Procedures No.ItemTest ProcedureSpecificationRemarks 1Conducted emissionFCC/ANSI C63.4:1992 §15.107 - 2Radiated emissionFCC/ANSI C63.4:1992 §15.109(a)3m 1.4 Exclusion from standards No.ItemTest ProcedureSpecificationRemarks 1Conducted emissionFCC/ANSI C63.4:1992§15.107- * This test was not performed since EUT dose not have AC power port. 1.5 Test Location A-PEX International Co.,Ltd. Yokowa No.3 test site 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 Japan Telephone number: +81-596-39-1485 Facsimile number: +81-596-39-0232 This site has been fully described in a report submitted to FCC office, and listed on September 12, 2000 (Registration number: 90412). *NVLAP Lab. code : 200109-0 Test report Our reference : 21IE0027-YW-2 Page: 5 of 10 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 2 SYSTEM TEST CONFIGURATION 2.1 Operation Environment Temperature: 28 Humidity: 28% Power supply : DC 12V (Car Battery) 2.2 Justification The system was configured in typical fashion (as a customer would normally use it) for testing. 2.3 EUT Exercise Software The EUT exercise program used during radiated testing was designed to exercise the various system components in a manner similar to typical use. The sequence is used: Operation Mode : Receiving 2.4 Test Procedure Tabletop Equipment Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1m, raised 80cm above the conducting ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane to obtain the maximum signal strength. The measurement distance was 3m. Test report Our reference : 21IE0027-YW-2 Page: 6 of 10 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Figure2.1 Configuration of Tested System Front View (A):EUT (B) (C) * Test data was taken under worse case conditions. Top View (A):EUT (B)(C) *Test data was taken under worse case conditions. Description of EUT and Support Equipment No.ItemModel numberSerial numberManufacturerFCC ID AKeyless Entry System (Receiver) G8D-325A-B (3SW type) Sample No.1OMRONOUCG8D-325A-B BChecker BoxN/AN/AOMRON- CCar Battery50B24LN/AYUASA- List of cables used No.ItemLength (m)ShieldRemark Signal & DC Power Cable0.1N- DC Power Cable0.4N- Test report Our reference : 21IE0027-YW-2 Page: 7 of 10 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 3 RADIATED EMISSION DATA The initial step in collecting radiated data was a spectrum analyzer peak scan of the measurement range (30MHz-1000MHz). The final data was reported in the worst-case emissions. The minimum margin to the limit is as follows : AntReceiverCorrectionField FrequencyPolReadingFactorStrength Limit Margin (MHz)(dB V) (dB) (dB V/m) (dB V/m) (dB) 160.02V27.7 -7.2 20.543.523.0 * The test receiver setting…

Text truncated - open the document above for the full version.

Test report Our reference : 21IE0027-YW-2 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 RADIATED MEASUREMENT PHOTOS

Test report Our reference : 21IE0027-YW-2 Issued date: April 19, 2001 FCC ID: OUCG8D-325A-B Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 RADIATED MEASUREMENT PHOTOS
