AK-060749-A User’s manual (Function) The functions of KOS are as below. 1. Keyless operation function 1) Door entry function (unlock) By touching a door sensor on DR/AS door or pressing Unlock SW of a tail gate while bringing a FOB, KOS and FOB performs authentication by two-way communication and all doors are unlocked. 2) Door entry function (lock) By pressing Lock SW on DR/AS/Tail gate door while bringing a FOB, KOS and FOB performs authentication by two-way communication and all doors are locked 3) Engine start function By pressing IG Push SW on a key cylinder while bringing a FOB, KOS and FOB performs authentication by two-way communication and stereing handle lock is released. After that, engine start is permitted when rotating IG knob up to RUN position. 2. Keyless entry function By pressing Lock button on a FOB, all doors are locked. By pressing Unlock button, all doors are unlocked. 3. Remote control engine starter function By operating a remote control engine starter, an engine starts/stops. 4. Immobilizer function By performing authentication by two-way communication between a KOS and transponder when engin start is performed using a mechanical key with a transponder, unauthorized engine start like stealing is avoided. 5. TPMS function This can warn a driver by lighting or flashing a warning lamp when tire air pressure decrease is detected. ○FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules and RSS-Gen of IC Rules.. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. “Complies with RSS-GEN of Industry Canada” -1/1- -

AK-060749-A Figure 8.5 G8D－640M－RAM－N appearance (front view) Figure 8.6 G8D－640M－RAM－N appearance (back view) -8/13- -

Label Drawing and Location

AK-060749-A Figure 8.7 G8D－640M－RAM－N PCB assy (front view) Figure 8.8 G8D－640M－RAM－N PCB assy (back view) -9/13- -

Test report No. : 26GE0265-HO-C Page : 1 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) RADIO TEST REPORT Test Report No.: 26GE0265-HO-C Applicant : OMRON Corporation Type of Equipment : RAM Model No. : G8D-640M-RAM-N Test standard : FCC Part 15 Subpart B Section 15.109: 2006 FCC Part 15 Subpart C Section 15.209: 2006 FCC ID : OUCG8D-640M-RAM-N Test Result : Complied 1. This test report shall not be reproduced in full or partial, without the written approval of UL Apex Co., Ltd. 2. The results in this report apply only to the sample tested. 3. This equipment is in compliance with above regulation. We hereby certify that the data contain a true representation of the EMC profile. 4. The test results in this report are traceable to the national or international standards. Date of test: __________________________________ Tested by: _________________________________ _________________________________ Mitsuru Fujimura EMC Services Norihisa Hashimoto EMC Services Approved by : _________________________________ Naoki Sakamoto Group Leader of EMC Services April 14 to 22, 2006 Test report No. : 26GE0265-HO-C Page : 2 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) CONTENTS PAGE SECTION 1: Client information ............................................................................................................ 3 SECTION 2: Equipment under test (E.U.T.)........................................................................................ 3 SECTION 3: Test specification, procedures & results......................................................................... 4 SECTION 4: Operation of E.U.T. during testing .................................................................................7 SECTION 5: Radiated emission (Fundamental and Spurious Emission and –26dB Bandwidth) .... 8 APPENDIX 1: Photographs of test setup .............................................................................................. 9 Radiated Emission (125kHz Transmitting)....................................................................................... 9 Worst Case Position (EUT: Z-axis / Antenna: Z-axis) ................................................................... 10 Radiated Emission (315MHz Receiving) ......................................................................................... 11 APPENDIX 2: Test instruments .......................................................................................................... 12 APPENDIX 3: Data of EMI test........................................................................................................... 13 Radiated Emission below 30MHz (Fundamental).......................................................................... 13 Radiated Emission below 30MHz (Spurious Emission)................................................................. 14 Radiated Emission above 30MHz (Spurious Emission)................................................................. 15 Radiated Emission (315MHz Receiving) ......................................................................................... 16 -26dB Bandwidth............................................................................................................................... 18 99% Occupied Bandwidth ................................................................................................................ 19 Test report No. : 26GE0265-HO-C Page : 3 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) SECTION 1: Client information Company Name : OMRON Corporation Address : 6368 Nenjozaka, Okusa, Komaki, Aichi, 485-0802 Japan Telephone Number : +81- 568-78-6394 Facsimile Number : +81- 568-78-7659 Contact Person : Harumi Itatsu SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : RAM Model No. : G8D-640M-RAM-N Sample No. : KR0001 for 315MHz Receiving test KR0002 for 125kHz Transmitting test Country of Manufacture : Japan Rating : DC12V Receipt Date of Sample : April 3, 2006 Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No modification by the test lab. 2.2 Product Description Model No: G8D-640M-RAM-N (referred to as the EUT in this report) is the RAM. [Transmitter Part] Frequency of Operation : 125kHz +/-0.1kHz Type of modulation : BPLM ITU code : N0N Antenna Type : Coil Antenna [Receiving Part] Type of Receiver : Super Heterodyne Receiving Frequency : 315MHz Intermediate Frequency : 10.7MHz Antenna Type : Inverted-F antenna Test report No. : 26GE0265-HO-C Page : 4 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part15 Subpart B: 2006 Title : FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators Test Specification : FCC Part15 Subpart C: 2006 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.209 Radiated emission limits, general requirements: 2006 FCC 15.31 (e) The EUT is a battery-operated device and test was performed with the full-charged battery. Therefore, this EUT complies with the requirement. FCC 15.111 (b) The receiving antenna is installed in the EUT and cannot be removed by the user. Therefore, this EUT complies with…

Text truncated - open the document above for the full version.

Test report No. : 26GE0265-HO-C Page : 12 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) APPENDIX 2: Test instruments EMI test equipment Control No. Instrument Manufacturer Model No Test Item Calibration Date * Interval(month) MAEC-01 Anechoic Chamber TDK Semi Anechoic Chamber 10m RE / ME 2005/11/14 * 12 MBA-01 Biconical Antenna Schwarzbeck BBA9106 RE 2005/10/10 * 12 MLA-01 Logperiodic Antenna Schwarzbeck USLP9143 RE 2005/10/14 * 12 MOS-01 Digital Humidity Indicator N.T NT-1800 RE / ME 2004/11/25 * 24 MLPA-02 Loop Antenna Rohde & Schwarz HFH2-Z2 ME 2005/12/06 * 12 MCC-03 Coaxial Cable Fujikura/Suhner/A gilent/TSJ - ME 2005/12/18 * 12 MCC-31 coaxial cable ULApex - ME 2006/05/29 * 12 MPA-04 Pre Amplifier Agilent 8447D RE / ME 2006/05/27 * 12 MAT-06 Attenuator(6dB) Weinschel Corp 2 RE 2005/12/16 * 12 MTR-01 Test Receiver Rohde & Schwarz ESI40 RE / ME 2005/11/10 * 12 MHA-05 Horn Antenna Schwarzbeck BBHA9120D RE 2006/01/09 * 12 MCC-18 Microwave Cable 1G-26.5GHz Suhner SUCOFLEX 104 RE 2006/02/02 * 12 MPA-01 Pre Amplifier Agilent 8449B RE 2006/02/09 * 12 MCC-01 Coaxial Cable 0.1- 3000MHz Suhner/storm/Agil ent/TSJ - RE 2006/02/20 * 12 MSTW-14 EMI measurement program TSJ TEPTO-DV RE/ME - MCC-16 Microwave Cable 1G-26.5GHz Suhner SUCOFLEX 104 RE 2006/02/02 * 12 All equipment is calibrated with traceable calibrations. Each calibration is traceable to the national or international standards. Test Item: ME: Spurious emission RE: Spurious emission Test report No. : 26GE0265-HO-C Page : 13 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) APPENDIX 3: Data of EMI test Radiated Emission below 30MHz (Fundamental) 125kHz Transmitting DATA OF MAGNETIC RADIATED EMISSION TEST UL Apex Co.,LTD. Head Office EMC Lab. No.1 Semi Anechoic Chamber Date : 2006/04/14 23:20:14 Applicant: OMRON CorporationReport No.:26GE0265-HO Kind of EUT: RAM Power:DC 12V (Car Battery) Model No.: G8D-640M-RAM-N Temp./Humi.:20deg.C / 44% Serial No.: Operator:Norihisa Hashimoto Mode / Remarks : Transmitting 125kHz LIMIT : FCC15C §15.209(a) / RSS-Gen7.2.2, AV 3m FCC15C § 15.209(a) / RSS-Gen 7.2.2, PK 3m CHART : WITH FACTOR ANT TYPE : LOOP CALCULATION : READING + ANT FACTOR + LOSS( CABLE + ATTEN.-AMP.) Page: Frequency[Hz] [dBuV/m]<< QP/AV/PEAK DATA >>90 deg :90 deg 45 deg :45 deg 0 deg :0 deg 30M .01M .02M .03M .05M .07M .1M.2M.3M.5M.7M1M2M3M5M7M10M20M 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 Freq. Reading DET Ant.Fac LossGainResultLimitMargin Antenna TableFreq. Reading DET Ant.Fac LossGainResultLimitMargin Antenna Table [MHz] [dBuV] DET [dB/m] [dB][dB][dBuV/m][dBuV/m][dB] Antenna [deg] 0.1251569.1 PEAK 19.5 0.226.262.6105.743.10deg181 0.1251568.1 PEAK 19.5 0.226.261.6105.744.10deg181 0.1251569.5 PEAK 19.5 0.226.263.0105.742.70deg181 0.1251553.2 AV 19.5 0.226.246.785.739.00deg181 0.1251558.2 QP 19.5 0.226.251.7105.754.00deg181 0.1251563.2 PEAK 19.5 0.226.256.7105.749.045deg250 0.1251567.0 PEAK 19.5 0.226.260.5105.745.290deg27 0.1251548.1 AV 19.5 0.226.241.685.744.145deg250 0.1251552.1 AV 19.5 0.226.245.685.740.190deg27 KR0002 Test report No. : 26GE0265-HO-C Page : 14 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) Radiated Emission below 30MHz (Spurious Emission) 125kHz Transmitting DATA OF MAGNETIC RADIATED EMISSION TEST UL Apex Co.,LTD. Head Office EMC Lab. No.1 Semi Anechoic Chamber Date : 2006/04/14 23:20:14 Applicant: OMRON CorporationReport No.:26GE0265-HO Kind of EUT: RAM Power:DC 12V (Car Battery) Model No.: G8D-640M-RAM-N Temp./Humi.:20deg.C / 44% Serial No.: Operator:Norihisa Hashimoto Mode / Remarks : Transmitting 125kHz / Max-axis(Z) LIMIT : FCC15C § 15.209(a) / RSS-Gen 7.2.2,PK, 3m FCC15C § 15.209(a) / RSS-Gen 7.2.2,AV 3m CHART : WITH FACTOR ANT TYPE : LOOP CALCULATION : READING + ANT FACTOR + LOSS( CABLE + ATTEN.-AMP.) Page: Frequency[Hz] [dBuV/m]<< QP/AV/PEAK DATA >>0 deg :0 deg 30M .01M .02M .03M .05M .07M .1M.2M.3M.5M.7M1M2M3M5M7M10M 20M 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 Freq. Reading DET Ant.Fac LossGainResultLimitMargin Antenna TableFreq. Reading DET Ant.Fac LossGainResultLimitMargin Antenna Table [MHz] [dBuV] DET [dB/m] [dB][dB][dBuV/m][dBuV/m][dB] Antenna [deg] 0.2500044.2 PEAK 19.5 0.327.336.799.662.90deg181 0.2500031.6 AV 19.5 0.327.324.179.655.50deg181 0.3759658.2 PEAK 19.5 0.327.750.396.145.80deg181 0.3759648.1 AV 19.5 0.327.740.276.135.90deg181 0.5000034.6 QP 19.5 0.427.826.773.646.90deg181 0.6250044.2 QP 19.5 0.327.936.171.735.60deg181 0.7500033.3 QP 19.5 0.327.925.270.144.90deg181 0.8750039.1 QP 19.5 0.427.931.168.837.70deg181 1.0000033.2 QP 19.5 0.227.925.067.642.60deg181 1.1250033.0 QP 19.5 0.327.924.966.641.70deg181 KR0002 Test report No. : 26GE0265-HO-C Page : 15 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) Radiated Emission above 30MHz (Spurious Emission) 125kHz Transmitting DATA OF RADIATED EMISSION TEST UL Apex Co., Ltd. Head Office EMC Lab. No.1 Semi Anechoic Chamber Date : 2006/04/15 05:09:28 Company : OMRON CorporationReport No.:26GE0265-HO Kind of EUT: RAM Power:DC12V(Car Battery) Model No. : G8D-640M-RAM-N Temp./Humi.:20deg.C. / 44% Serial No. : KR0002 Operator:Norihisa Hashimoto Mode / Remarks : Transmitting 125kHz Max-axis(Z) LIMIT : FCC15C § 15.209, 3m, below1GHz / RSS-Gen 7.2.2 Except for the data below : adequate margin data below the limits. CHART:WITH FACTOR ANT TYPE：-30MHz LOOP,…

Text truncated - open the document above for the full version.

Test report No. : 26GE0265-HO-C Page : 9 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) APPENDIX 1: Photographs of test setup Radiated Emission (125kHz Transmitting) Front Rear Test report No. : 26GE0265-HO-C Page : 10 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) Worst Case Position (EUT: Z-axis / Antenna: Z-axis) X-axis Y-axis Z-axis Test report No. : 26GE0265-HO-C Page : 11 of 19 Issued date : June 1, 2006 FCC ID : OUCG8D-640M-RAM-N UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(24.05.06) Radiated Emission (315MHz Receiving) Front Rear
