OUCG8D-694H-ATransmitter, Keyless Entry System for vehicle

-4- - 2. User’s manual REMOTE TRANSMITTER You can lock and unlock your vehicle with the remote transmitter. You don’t have to operate the receiver directly. The receiver is installed inside the vehicle and receives the signal from the remote transmitter automatically. LOCK When you push the LOCK button, all the doors will lock. You cannot lock any of the doors with the remote transmitter if any door is open or the key is in the ignition switch. UNLOCK When you push the UNLOCK button , all the doors will unlock. You cannot unlock any of the doors with the remote transmitter if the key is in the ignition switch. POP UP To open the boot , push the BOOT RELEASE button for approximately one second. The boot will not open if the key is in the ignition switch. CALL Call mode allows you to remotely sound your vehicle’s horn to attract attention. To activate this mode , press and hold the CALL button for about one seconds. Your vehicle’s horn will beep for about 30 seconds. To cancel CALL mode before 30 seconds , press any button on the remote transmitter. You can also turn the ignition switch is in ON. LOCK button UNLOCK button CALL button BOOT RELEASE button -5- - FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’ authority to operate the equipment. This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

External Photo Transmitter, Keyless Entry System for vehicle [Model: G8D-694H-A] Front Back External Photo Transmitter, Keyless Entry System for vehicle [Model: G8D-694H-A] Top Bottom External Photo Transmitter, Keyless Entry System for vehicle [Model: G8D-694H-A] Side View1 Side View2

Internal Photo Transmitter, Keyless Entry System for vehicle [Model: G8D-694H-A] Front Back

Test report No. : 31CE0028-HO-01-A-R1 Page : 2 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ············································································· 3 SECTION 2: Equipment under test (E.U.T.) ··································································· 3 SECTION 3: Test specification, procedures & results ························································ 4 SECTION 4: Operation of E.U.T. during testing ······························································ 7 SECTION 5: Radiated emission (Electric Field Strength of Fundamental and Spurious Emission) 8 SECTION 6: Automatically deactivate ·········································································· 9 SECTION 7: -20dB and 99% Occupied Bandwidth ··························································· 9 APPENDIX 1: Photographs of test setup ······································································ 10 Radiated emission ............................................................................................................................. 10 Worst case position ........................................................................................................................... 11 APPENDIX 2: Data of EMI test ················································································· 12 Automatically deactivate .................................................................................................................. 12 Radiated Emission (Electric Field Strength of Fundamental and Spurious Emission) ..................... 13 -20dB and 99% Occupied Bandwidth ............................................................................................... 14 Duty Cycle ........................................................................................................................................ 15 APPENDIX 3:Test Instruments ·················································································· 16 Test report No. : 31CE0028-HO-01-A-R1 Page : 3 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : Omron Corporation Address : 6368 Nenjozaka Okusa Komaki-City Aichi-Pref., 485-0802 JAPAN Telephone Number : +81-568-78-6159 Facsimile Number : +81-568-78-7659 Contact Person : Masashi Matsuda SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Transmitter, Keyless Entry System for vehicle Model No. : G8D-694H-A Serial No. : Refer to Clause 4.2 Rating : DC 3.0V (Lithium Battery (CR2025)) Receipt Date of Sample : October 14, 2010 Country of Mass-production : Japan Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product Description Keyless Entry System for vehicle controls locking and unlocking of doors and a trunk of the vehicle. This system consists of the transmitter and the receiver. The transmitter a device that tranasmits the radio signal when the button is pressed. The reciver is, installed into the vehicle, recieves the signal from the transmitter and controls locking and unlocking of doors and a trunk according received signal. Radio Specification Radio Type : Transmitter Frequency of Operation : 313.85MHz Modulation : FSK Power Supply (radio part input) : DC 3.0V Antenna type : Internal Antenna Test report No. : 31CE0028-HO-01-A-R1 Page : 4 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part 15 Subpart C: 2010, final revised on October 13, 2010 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.231 Periodic operation in the band 40.66 - 40.70MHz and above 70MHz 3.2 Procedures and results Item Test Procedure Specification Worst margin Results Remarks Conducted emission FCC: ANSI C63.4:2003 7. AC powerline conducted emission measurements FCC: Section 15.207 N/A N/A*1) - IC: RSS-Gen 7.2.2 IC: RSS-Gen 7.2.2 Automatically Deactivate FCC: ANSI C63.4:2003 13. Measurement of intentional radiators FCC: Section 15.231(a)(1) N/A Complied Radiated IC: - IC: RSS-210 A1.1.1 Electric Field Strength of Fundamental Emission FCC: ANSI C63.4:2003 13. Measurement of intentional radiators FCC: Section 15.231(b) 5.2dB 313.850MHz Horizontal (PK with Duty factor) Complied Radiated IC: RSS-Gen 4.8 IC: RSS-210 A1.1.2 Electric Field Strength of Spurious Emission FCC: ANSI C63.4:2003 13. Measurement of intentional radiators FCC: Section 15.205 Section 15.209 Section 15.231(b) 1.1dB 2824.608MHz Vertical (PK with Duty factor) Complied Radiated IC: RSS-Gen 4.9 IC: RSS-210 A1.1.2, 2.6, 2.7 -20dB Bandwidth FCC: ANSI C63.4:2003 13. Measurement of intentional radiators FCC: Section 15.231(c) N/A Complied Radiated IC: - IC: Reference data Note: UL Japan, Inc.’s EMI Work Procedures No.QPM05 and QPM15. *1) The test is not applicable since the EUT does not have AC Mains. FCC 15.31 (e) This test was performed with the New Battery (DC 3.0V) and the constant voltage was supplied to the EUT during the tests. Therefore, the EUT complies with the requirement. FCC Part 15.203 Antenna requirement It is impossible for end users to replace the antenna, because the antenna is mounted inside of the EUT. Therefore, the equipment complies with the antenna…

Text truncated - open the document above for the full version.

Test report No. : 31CE0028-HO-01-A-R1 Page : 12 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 APPENDIX 2: Data of EMI test Automatically deactivate Test place Head Office EMC Lab. No.4 Semi Anechoic Chamber Report No. 31CE0028-HO Date 10/14/2010 Temperature/ Humidity 23 deg.C./ 52% Engineer Motoya Imura Mode Normal use mode Time of Transmitting [sec] Limit [sec] Result 0.32 5.00 Pass Test report No. : 31CE0028-HO-01-A-R1 Page : 13 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Radiated Emission (Electric Field Strength of Fundamental and Spurious Emission) Test place Head Office EMC Lab. No.4 Semi Anechoic Chamber Report No. 31CE0028-HO-01 Date 10/14/2010 Temperature/ Humidity 23 deg.C./ 52% Engineer Motoya Imura Mode Transmitting mode PK FrequencyDetectorAntLossGainDutyLimitRemark FactorFactorInside or Outside [MHz]HorVer[dB/m][dB][dB][dB]HorVer[dBuV/m ]HorVerof Restricted Bands 313.850 PK82.278.516.29.831.9-76.372.695.519.222.9 Carrier 627.700 PK44.445.320.611.632.1-44.545.475.531.030.1 Outside 941.550 PK37.439.325.113.131.2-44.446.375.531.129.2 Outside 1255.357 PK58.460.424.92.233.9-51.653.675.523.921.9 Outside 1569.290 PK49.846.326.02.533.2-45.141.673.928.832.3 Inside 1882.960 PK48.449.226.92.632.5-45.446.275.530.129.3 Outside 2196.908 PK50.451.627.22.832.2-48.249.475.527.326.1 Outside 2510.758 PK60.757.027.23.032.1-58.855.175.516.720.4 Outside 2824.608 PK58.759.827.73.231.9-57.758.873.916.215.1 Inside 3138.500 PK52.753.228.43.331.8-52.653.175.522.922.4 Outside Result = Reading + Ant Factor + Loss (Cable+Attenuator+Filter) - Gain(Amprifier) PK with Duty factor FrequencyDetectorAntLossGainDutyLimitRemark FactorFactor [MHz]HorVer[dB/m][dB][dB][dB]HorVer[dBuV/m ]HorVer 313.850 PK82.278.516.29.831.9-6.070.366.675.55.28.9 Carrier 627.700 PK44.445.320.611.632.1-6.038.539.455.517.016.1 Outside 941.550 PK37.439.325.113.131.2-6.038.440.355.517.115.2 Outside 1255.357 PK58.460.424.92.233.9-6.045.647.655.59.97.9 Outside 1569.290 PK49.846.326.02.533.2-6.039.135.653.914.818.3 Inside 1882.960 PK48.449.226.92.632.5-6.039.440.255.516.115.3 Outside 2196.908 PK50.451.627.22.832.2-6.042.243.455.513.312.1 Outside 2510.758 PK60.757.027.23.032.1-6.052.849.155.52.76.4 Outside 2824.608 PK58.759.827.73.231.9-6.051.752.853.92.21.1 Inside 3138.500 PK52.753.228.43.331.8-6.046.647.155.58.98.4 Outside Result = Reading + Ant Factor + Loss (Cable+Attenuator+Filter) - Gain(Amprifier) + Duty factor (Refer to Duty factor data sheet) *Other frequency noises omitted in this report were not seen or had enough margin (more than 20dB). ReadingResult Reading [dBuV] Result [dBuV/m] [dBuV][dBuV/m] Margin [dB] Margin [dB] Test report No. : 31CE0028-HO-01-A-R1 Page : 14 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 -20dB and 99% Occupied Bandwidth Test place Head Office EMC Lab. No.4 Semi Anechoic Chamber Report No. 31CE0028-HO-01 Date 11/25/2010 Temperature/ Humidity 24 deg.C./ 35% Engineer Motoya Imura Mode Transmitting mode Bandwidth Limit : Fundamental Frequency 313.85MHz x 0.25% = 784.63kHz -20dB BandwidthResult [kHz] 90.15Pass 99% Occupied BandwidthResult [kHz] 160.38Pass [kHz] 784.63 Bandwidth Limit [kHz] 784.63 Bandwidth Limit Test report No. : 31CE0028-HO-01-A-R1 Page : 15 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Duty Cycle Test place Head Office EMC Lab. No.4 Semi Anechoic Chamber Report No. 31CE0028-HO-01 Date 10/14/2010 Temperature/ Humidity 23 deg.C./ 52% Engineer Motoya Imura Mode Transmitting mode ON time(One pulse)ON time(in 100ms) TypeTimes[ms][ms] A620.81150.257 *1)ON time(in 100ms) = Times * ON time(One pulse) *2)The train of pulses was exceeding 100msec, and that sampled 100msec was the worst case against the pul s (Total) ON timeCycleDutyDuty [ms][ms](On time/Cycle)[dB] 50.26100.000.50-6.0 *3)ON time = Type A's ON time (in 100ms) *4)Duty = 20log 10 (ON time/Cycle) Sweep time 100ms TypeA Pulse Width ALL Pulses are TypeA. TypeA’s are 62pulses in 100mS Test report No. : 31CE0028-HO-01-A-R1 Page : 16 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 APPENDIX 3:Test Instruments EMI test equipment Control No. Instrument Manufacturer Model No Serial No Test Item Calibration Date * Interval(month) MAEC-04 Semi Anechoic Chamber(NSA) TDK Semi Anechoic Chamber 3m DA-10005 RE 2010/02/02 * 12 MOS-15 Thermo-Hygrometer Custom CTH-180 - RE 2010/02/09 * 12 MJM-07 Measure PROMART SEN1955 - RE - COTS-MEMI EMI measurement program TSJ TEPTO-DV - RE - MSA-03 Spectrum Analyzer Agilent E4448A MY44020357 RE 2009/11/20 * 12 MTR-07 Test Receiver Rohde & Schwarz ESCI 100635 RE 2009/10/23 * 12 *1) MBA-05 Biconical Antenna Schwarzbeck BBA9106 1302 RE 2010/03/22 * 12 MLA-08 Logperiodic Antenna Schwarzbeck UKLP9140-A N/A RE 2010/01/23 * 12 MCC-50 Coaxial cable UL Japan - - RE 2010/03/18 * 12 MAT-51 Attenuator(6dB) Weinschel 2 AS3557 RE 2010/01/20 * 12 MPA-14 Pre Amplifier SONOMA INSTRUMENT 310 260833 RE 2010/03/05 * 12 MSA-05 Spectrum Analyzer Advantest R3273 160400285 RE 2009/12/15 * 12 MHA-21 Horn Antenna 1- 18GHz Schwarzbeck BBHA9120D 9120D-557 RE 2010/08/08 * 12 MCC-57 Microwave Cable Suhner SUCOFLE…

Text truncated - open the document above for the full version.

Test report No. : 31CE0028-HO-01-A-R1 Page : 10 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 APPENDIX 1: Photographs of test setup Radiated emission Photo 1 Photo 2 Test report No. : 31CE0028-HO-01-A-R1 Page : 11 of 16 Issued date : November 9, 2010 Revised date : November 26, 2010 FCC ID : OUCG8D-694H-A UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Worst case position Below 1GHz (Horizontal: X-axis/Vertical : Y-axis) Above 1GHz (Horizontal: Z-axis/Vertical : Y-axis) X-axis Y-axis Z-axis
