OWGTFY3808Safe & Sounds Monitor

FCC ID: OWGTFY3808 FCC ID: OWGTFY3808

FCC ID: OWGTFY3808 FRONT VIEW OF DEVICE

FCC ID: OWGTFY3808 BOTTOM VIEW OF DEVICE WITH FCC ID LABEL

FCC ID: OWGTFY3808 FRONT VIEW OF THE PRINTED WIRING BOARD FRONT VIEW OF THE PRINTED WIRING BOARD

Date: 2000-10-09 TEST REPORT Page 1 of 13 No.: HM103354 Law Man KitKitty ChoyPatrick wong Testing EngineerVerify byPatrick Wong for Managing Director APPLICANT: (CODE: EXE001) EXCEL ENGINEERING (HK) CO., LTD. Unit 306, 3/F., Lippo Sun Plaza, 28 Canton Road, Tsim Sha Tsui, Kowloon, Hong Kong DATE OF SAMPLES RECEIVED:2000-09-26 SUBMITTED SAMPLE(S): 2 sample per model DATE OF TESTING: 2000-10-03 DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:SAFE & SOUNDS MONITOR Manufacturer:KWOK’S WINTY MANUFACTURING LTD. Model Number:3808 Brand Name:THE FIRST YEARS, INC Rating:120Va.c. 6Vd.c. Origin:CHINA INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart C - Intentional Radiator. RESULT/ REMARK: Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the clause 15.235 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 2000-10-09 TEST REPORT Page 2 of 13 No.: HM103354 T E S T S U M M A R Y *** INTENTIONAL RADIATOR *** (1)Measurement of Emission of RF energy on the carrier frequency.........Satisfactory (2)Measurement of the out-of band emissions including harmonics...........Satisfactory (3)Measurement of Emission Within Band Edges......................................Satisfactory (4)Measurement of Line-Conducted Voltage onto AC Power Line............Satisfactory T E S T D A T A Please refer to the attached result sheets. Date: 2000-10-09 TEST REPORT Page 3 of 13 No.: HM103354 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference TEST REFERENCE:FCC Rules Part 15 Section 15.235(49.82-49.90 MHz) TEST CONDITION:Channel A TEST DATE:2000-10-03 Emission of RF energy on the carrier frequency -- 49.866 MHz (PEAK VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB( μV)H-VdBdB(μV/m)μV/mμV/m 49.945.4V+15.060.41047.1100.0100000.0 ================================================================== Emission of RF energy on the carrier frequency -- 49.866 MHz (AVERAGE VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB(μV)H-VdBdB(μV/m)μV/mμV/m 49.944.2V+15.059.2912.080.010000.0 ================================================================== ... to be continued Date: 2000-10-09 TEST REPORT Page 4 of 13 No.: HM103354 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference . . Continued TEST REFERENCE:FCC Rules Part 15 Section 15.235(49.82-49.90 MHz) TEST CONDITION:Channel A TEST DATE:2000-10-03 The out-of-band emissions, including harmonics (25-1000 MHz) (CISPR VALUE) ========================================================================= EmissionPolarizationMeterAntennaField Strength (at 3m)FCC FrequencyreadingfactorLimit (at 3m)@ MHzH-VdBdB( μ V) μ V/m μ V/m ##99.7<1.0+12.2<13.2<4.644150 149.6<1.0+9.8<10.8<3.544150 199.5<1.0+11.5<12.5<4.244150 249.3<1.0+15.9<16.9<7.046200 299.2<1.0+17.0<18.0<7.946200 349.1<1.0+17.2<18.2<8.146200 398.9<1.0+18.8<19.8<9.846200 448.8<1.0+19.7<20.7<10.846200 498.7<1.0+20.6<21.6<12.046200 548.5<1.0+22.2<23.2<14.546200 598.4<1.0+23.4<24.4<16.646200 648.3<1.0+23.5<24.5<16.846200 698.1<1.0+25.0<26.0<20.046200 748.0<1.0+26.3<27.3<23.246200 797.9<1.0+27.2<28.2<25.746200 847.7<1.0+26.6<27.6<24.046200 897.6<1.0+27.1<28.1<25.446200 947.5<1.0+28.0<29.0<28.246200 997.3<1.0+28.5<29.5<29.954500 ================================================================== =================SUMMARY================ All data is within limits ======================================= Broad-band Antennas were used and both polarizations of emissions were measured. polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ======================================= Date: 2000-10-09 TEST REPORT Page 5 of 13 No.: HM103354 *** INTENTIONAL RADIATOR *** (2) Measurement of Emissions Within Band Edges TEST REFERENCE:FCC Rules Part 15 Section 15.235(49.82-49.90 MHz) TEST CONDITION:Channel A TEST DATE:2000-10-03 RESULTS AND NOTES L: FCC Lower Band Edge..............................................................................-> 49.820MHz H: FCC Higher Band Edge.............................................................................-> 49.900MHz C: Unmodulated carrier at frequency..............................................................-> 49.866MHz D: No. of dB from unmodulated carrier..........................................................-> 37.80dB SPECTRUM ANALYZER SETTINGS Resolution bandwidth : 19.6KHz Frequency span: 10.0KHz/div No. of dB/div: 10.0dB/div FCC Limit Minimum No. of dB from unmodulated carrier required : 26.0dB ======================SUMMARY======================== All data is within limits =========================================================== Date: 2000-10-09 TEST REPORT Page 6 of 13 No.: HM103354 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference TEST REFERENCE:FCC Rules Part 15 Section 15.235(49.82-49.90 MHz) TEST CONDITION:Channel B TEST DATE:2000-10-03 Emission of RF energy on the carrier frequency -- 49.868 MHz (PEAK VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB( μV)H-VdBdB(μV/m)μV/mμV/m 49.945.5V+15.060.51059.3100.0100000.0 ================================================================== Emission of RF energy on the carrier frequency -- 49.868 MHz (AVERAGE VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB(μV)H-VdBdB(μV/m)μV/mμV/m 49.944.3V+15.059.3922.680.010000.0 ================================================================== ... to be conti…
