OXVSSG20SECURE SERVICES GATEWAY 20

Juniper Networks, Inc. 1194 North Mathilda Avenue Sunnyvale, CA 94089 USA 408-745-2000 www.juniper.net Part Number: 530-015646-01, Revision Beta3 Security Products Secure Services Gateway (SSG) 20 Hardware Installation and Configuration Guide- Beta3 ScreenOS Version 5.4.0 ii„ Copyright Notice Copyright © 2006 Juniper Networks, Inc. All rights reserved. Juniper Networks and the Juniper Networks logo are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered trademarks, or registered service marks in this document are the property of Juniper Networks or their respective owners. All specifications are subject to change without notice. Juniper Networks assumes no responsibility for any inaccuracies in this document or for any obligation to update information in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice. FCC Statement The following information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency energy. If it is not installed in accordance with Juniper Network’s installation instructions, it may cause interference with radio and television reception. This equipment has been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules. These specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: „Reorient or relocate the receiving antenna. „Increase the separation between the equipment and receiver. „Consult the dealer or an experienced radio/TV technician for help. „Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Caution: Changes or modifications to this product could void the user's warranty and authority to operate this device. Disclaimer THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR JUNIPER NETWORKS REPRESENTATIVE FOR A COPY. Writer: Carrie Nowocin Editor: Lisa Eldridge Table of Contents„iii Table of Contents About This Guidevii Organization .................................................................................................. vii WebUI Conventions ...................................................................................... viii CLI Conventions............................................................................................ viii Obtaining Documentation and Technical Support ........................................... ix Chapter 1 Hardware Overview1 Port and Power Connectors ............................................................................. 2 Front Panel ...................................................................................................... 3 System Status LEDs ................................................................................... 3 Port Descriptions ....................................................................................... 5 Ethernet Ports ..................................................................................... 5 Console Port ....................................................................................... 5 AUX Port ............................................................................................. 5 Mini Physical Interface Module Port Descriptions ...................................... 6 Back Panel ....................................................................................................... 8 Power Adapter........................................................................................... 8 Radio Transceiver...................................................................................... 8 Grounding Lug ........................................................................................... 8 Antennae Types......................................................................................... 9 Universal Serial Bus (USB) Host Module ..................................................... 9 Chapter 2 Installing and Connecting the Device11 Before You Begin ........................................................................................... 11 Equipment Rack Installation .......................................................................... 12 Connecting the Interface Cable to a Device .................................................... 12 Connecting the Power .................................................................................... 13 Connect the Device to a Network ................................................................... 13 Connect an SSG 20 Device to an Untrusted Network ............................... 13 Connecting Ethernet Ports ................................................................ 13 Connecting Serial (AUX/Console) Ports.............................................. 13 Connect an SSG Device to an Untrusted Network .................................... 14 Connect Mini PIMs to an Untrusted Network .................................... 14 Connecting Other Mini PIMs ............................................................. 15 Connect the Device to an Internal Network or a Workstation .................. 16 Connecting Ethernet Ports ................................................................ 16 Connecting the Wireless A…

Text truncated - open the document above for the full version.

Attention: Application Examiner Re: Request for confidentiality Applicant: Juniper Networks Inc. FCC ID: OXV-SSG20 To whom it may concern, Permanent Confidentiality Request is hereby submitted by Juniper Networks Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Rationale for request for confidentiality: Juniper Networks Inc. has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] If you have questions or need further information, please contact the undersigned. Sincerely, Senior Compliance Engineer Juniper Networks Inc.

Photo 1: External photo of EUT SSG 20 Photo 2: External photo of EUT SSG 20 Photo 3: External photo of Antenna Antenna 1 Photo 4: External photo of Antenna Antenna 2 Photo 5: External photo of Antenna Antenna 3 Photo 6: External photo of Adapter Photo 7: External photo of Adapter Photo 8: External photo of Adapter Photo 9: External photo of Adapter

FCC ID Label Location

Photo 1: Internal photo of EUT SSG 20 Photo 2: Internal photo of EUT SSG 20 Photo 3: Internal photo of EUT SSG 20 Photo 4: Internal photo of EUT SSG 20 Photo 5: Internal photo of EUT Photo 6: Internal photo of EUT Photo 7: Internal photo of EUT SSG 20 Photo 8: Internal photo of EUT SSG 20 Photo 9: Internal photo of EUT SSG 20 Photo 10: Internal photo of EUT SSG 20 Photo 11: Internal photo of EUT SSG 20 Photo 12: Internal photo of EUT SSG 20 Photo 13: Internal photo of EUT SSG 20 Photo 14: Internal photo of EUT ADSL/ADSL2/ADSL2+ SSG 20 Photo 15: Internal photo of EUT ADSL/ADSL2/ADSL2+ SSG 20 Photo 16: Internal photo of EUT T1 Module SSG 20 Photo 17: Internal photo of EUT T1 Module SSG 20 Photo 18: Internal photo of EUT V.92 Module SSG 20 Photo 19: Internal photo of EUT V.92 Module SSG 20

FCC ID. : OXVSSG20 Report No.: EME-060849 Page 1 of 6 Maximum Permissible Exposure (MPE) Evaluation Report Report No. : EME-060774 Model No. : SSG 20 Issued Date : Jun. 14, 2006 Applicant : Juniper Networks Inc. 1194 North Mathilda Avenue, Sunnyvale, California 94089-1206 USA Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 6 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). Marx Yang Project Engineer Reviewed By Jerry Liu FCC ID. : OXVSSG20 Report No.: EME-060849 Page 2 of 6 Table of Contents Summary of Tests ............................................................................................................. 3 1. Introduction .................................................................................................................. 4 2. RF Exposure Limit ....................................................................................................... 4 3. RF Exposure calculations ............................................................................................. 5 4. Test results .................................................................................................................... 5 FCC ID. : OXVSSG20 Report No.: EME-060849 Page 3 of 6 Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997/ IEEE C95.1-1999 Secure Services Gateway 20 -Model: SSG 20 FCC ID: OXVSSG20 Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1 Pass FCC ID. : OXVSSG20 Report No.: EME-060849 Page 4 of 6 1. Introduction The EUT operates in the 2.4GHz ISM band. Due to the EUT (include antenna) at its normal operation distance is at least 20 cm from the human body, the EUT was defined as a Mobile Device. The reason to do the MPE Evaluation is to avoid the RF hazard to human body. The maximum output power and gain of the antenna were used to calculate the limited Power density (S) at 20cm distance away from the product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational / Control Exposures 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 F= Frequency in MHz FCC ID. : OXVSSG20 Report No.: EME-060849 Page 5 of 6 3. RF Exposure calculations From FCC 1.1310 table 1, the maximum permissible RF exposure for an uncontrolled environment is 1mW/(cm 2 ) Power density (S) is calculated by the following formula: S = (P * G)/4πR 2 where, S = Power density (mW/cm 2 ) P = Output power to antenna (mW) R = Distance between radiating structure and observation point (cm) G = Gain of antenna in numeric π = 3.1416 Example: Assume a mobile device operates at 2412MHz and its maximum output power is 50mW, and the maximum gain of antenna is 1 (numeric) /0dBi. then the power density (S) = (50 * 1)/4*π*20 2 = 0.00995 (mW/cm 2 ) 4. Test results Test Mode: 802.11b (DSSS Modulation) operating mode Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 1 2412 3.98 43.05 0.03410 1.0 6 2437 3.98 199.99 0.15839 1.0 11 2462 3.98 166.72 0.13204 1.0 Test Mode: 802.11g (OFDM Modulation) operating mode Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 1 2412 3.98 145.55 0.11528 1.0 6 2437 3.98 199.99 0.15839 1.0 11 2462 3.98 267.92 0.21220 1.0 FCC ID. : OXVSSG20 Report No.: EME-060849 Page 6 of 6 Test Mode: 802.11g (OFDM Modulation) turbo mode Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 6 2437 3.98 186.21 0.14748 1.0 Test Mode: 802.11a (5180MHz ~ 5240MHz) Normal mode Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 36 5180 3.98 17.50 0.01386 1.0 44 5220 3.98 14.62 0.01156 1.0 48 5240 3.98 17.06 0.01351 1.0 Test Mode: 802.11a (5260MHz ~ 5320MHz) Normal mode Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 52 5260 3.98 11.30 0.00895 1.0 56 5280 3.98 33.19 0.02628 1.0 64 5320 3.98 24.10 0.01909 1.0 Test Mode: 802.11a (5180MHz ~ 5240MHz, 5260MHz ~ 5320MHz) turbo mode Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 42 5260 3.98 25.76 0.02040 1.0 50 5280 3.98 26.00 0.02059 1.0 58 5290 3.98 20.65 0.01635 1.0 The Notice in Installation Manual has been stated as below: While installing and operating this transmitter, the radio frequency exposure limit of 1mW/(cm*cm) may be exceeded at distances close to the transmitter. therefore, the user must maintain a minimum distance of 20 cm from the device at all time.

FCC ID. : OXVSSG20 Report No.: EME-060849 Page 1 of 120 EMC TEST REPORT Report No. : EME-060849 Model No. : SSG 20 Issued Date : Jul. 14, 2006 Applicant : Juniper Networks Inc. 1194 North Mathilda Avenue, Sunnyvale, California 94089-1206 USA Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 120 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). Marx Yang Project Engineer Reviewed By Jerry Liu FCC ID. : OXVSSG20 Report No.: EME-060849 Page 2 of 120 Table of Contents Summary of Tests ..............................................................................................................5 1. General information ......................................................................................................6 1.1 Identification of the EUT ........................................................................................6 1.2 Additional information about the EUT....................................................................6 1.3 Antenna description.................................................................................................7 1.4 Peripherals equipment .............................................................................................7 2. Test specifications .........................................................................................................8 2.1 Test standard............................................................................................................8 2.2 Operation mode .......................................................................................................8 2.3 Test equipment ........................................................................................................9 3. Minimum 6dB Bandwidth test (FCC 15.247) .............................................................10 3.1 Operating environment..........................................................................................10 3.2 Test setup & procedure ..........................................................................................10 3.3 Measured data of Minimum 6dB Bandwidth test results ......................................10 4. Maximum Output Power test (FCC 15.247) ...............................................................18 4.1 Operating environment..........................................................................................18 4.2 Test setup & procedure ..........................................................................................18 4.3 Measured data of Maximum Output Power test results ........................................18 5. RF Antenna Conducted Spurious test..........................................................................20 5.1 Operating environment..........................................................................................20 5.2 Test setup & procedure ..........................................................................................20 5.3 Measured data of the highest RF Antenna Conducted Spurious test result ..........20 6. Radiated Emission test (FCC 15.247) .........................................................................42 6.1 Operating environment..........................................................................................42 6.2 Test setup & procedure ..........................................................................................42 6.3 Emission limits ......................................................................................................43 6.4 Radiated spurious emission test data.....................................................................44 6.4.1 Measurement results: frequencies equal to or less than 1 GHz..........................44 6.4.2 Measurement results: frequency above 1GHz ...................................................46 7. Power Spectrum Density test (FCC 15.247) ...............................................................49 7.1 Operating environment..........................................................................................49 7.2 Test setup & procedure ..........................................................................................49 FCC ID. : OXVSSG20 Report No.: EME-060849 Page 3 of 120 7.3 Measured data of Power Spectrum Density test results ........................................49 8. Emission on the band edge (FCC 15.247)...................................................................57 8.1 Operating environment..........................................................................................57 8.2 Test setup & procedure ..........................................................................................57 8.3 Test Result .............................................................................................................58 8.3.1 Conducted Method .............................................................................................58 8.3.2 Radiated Method ................................................................................................66 9. Peak Output Power test (FCC 15.407) ........................................................................68 9.1 Operating environment..........................................................................................68 9.2 Test setup & procedure ..........................................................................................68 9.3 Limit ......................................................................................................................68 9.4 Measured data of Maximum Output Power test results ........................................68 10. Power Spectrum Density test (FCC 15.407) …

Text truncated - open the document above for the full version.

Photo 1: Conducted Emission Test Set-up photo T1+ADSL/ADSL2/ADSL2+ SSG 20 Photo 2: Conducted Emission Test Set-up photo T1+ADSL/ADSL2/ADSL2+ SSG 20 Photo 3: Conducted Emission Test Set-up photo V.92+ADSL/ADSL2/ADSL2+ SSG 20 Photo 4: Conducted Emission Test Set-up photo V.92+ADSL/ADSL2/ADSL2+ SSG 20

Photo 1: Radiated Emission Test set-up photo SSG 5 Photo 2: Radiated Emission Test set-up photo SSG 5
