OZLMW-RC02Predator Remote

Screamin’ Joker Digital Caller & Decoy v12 (SKU#23412-9) Thank you for purchasing an Edge Innovative Hunting Product. To view additional Edge hunting products visit your local Sporting goods dealer or log onto www.edgebyexpedite.com. Hunt with an Edge! You will find the following items in the box of Screamin’ Joker. 1. Rabbit decoy body (fur). 2. Screamin’ Joker super structure with rotating cone and embedded speaker. 3. Screamin’ Joker remote control. 4. Metal Stake. Getting started: 1. Remove the remote battery cover, and install 4 AAA batteries. Negative battery contact always faces the spring inside the remote. 2. Replace the battery cover. 3. Remove battery cover of Screamin’ Joker’s superstructure (on the back). 4. Install 4 AA batteries. Negative battery contact always faces the spring inside the unit. 5. Replace battery cover. 3 Favorite “Hot Buttons” Decoy Motion ON/OFF On/Off/Play/Pause Sound + Sound – Volume + Volume -­‐ Remote / Screamin’ Joker Functions, tips: 1. The remote is designed for one hand operation (left hand). 2. The operation of the sounds and motion are completely independent of each other allowing the hunter to customize each hunt/stand. Operation: 1. To turn on the remote press the top (side) button and hold until the Edge logo shows up. 2. To turn on the Screamin’ Joker superstructure flip the left face button to “On”. 3. The left (face button) turns the unit on and off. Up = on , down = off. 4. The right (face) button controls the rotational speed of the rabbit. 5. High speed is up and low speed is down. 6. Thread the metal stake (or tripod not included) onto the base of Screamin’ Joker. 7. Insert / place into or on the ground where you want to use Screaming Joker. Playing sounds: 1. Scroll up or down to pick your sound using the two side buttons (photo below). 2. Push (and release) the top (side) button on the remote to play a sound. 3. Push (and release) the top (side) button again on the remote, to stop playing the sound. 4. Increase or decrease the volume (1-­‐10) using the two side buttons (photo below). 5. Favorite sounds: The three face buttons are to store your three favorite sounds for quick reference. These are called “hot keys”. a. You should be able to reach any “hot key” with your left thumb. b. To store your favorite sound, choose your sound and hold either button A, B, or C for 3 seconds until the display flashes twice. c. That “Hot Key” is now a quick way to find your favorite sound(s). Sounds included: Alienator Ki Yi, Crow Gathering, Here Kitty Kitty Hunt, Lip Squeak, Nimrod, Rabbit in Distress, Rabid Viper, Screamin Tweety, Squirrel Distress, Stryker, Syco Bird, Syco Cat, Tormented Syco, Viper Bleeds, and Wicked Alienator Fast & Slow Speed On/Off Rabbit Decoy Movement: 1. The single button above the 3 Hot Keys controls turning on and off the decoy movement. 2. You should be able to reach this key with your left thumb. 3. Press this button to turn the movement on and off. Emergency Stop: 1. During your hunt if you quickly want to terminate the sound and decoy movement at the same time simply push and hold the On/Off/Play/Pause key for 2 seconds. The decoy movement and sound will terminate at one time. 2. Once you are ready to start again you will need to turn the remote on again (hold down On/Off/Play/Pause). Remote Distance: 1. Depending on conditions, optimal remote range is 300 feet. Interference can affect range. Make sure metal objects, buildings, trees, terrain etc. are not directly between the Screamin’ Joker and the remote. 2. To improve remote distance, elevate the Screamin’ Joker using a tripod. The metal stake thread fits most tripod attachments. Storing the Screamin’ Joker: 1. Please remember to turn off the Screaming Joker on the superstructure as well as on the remote control. Forgetting to do this, will completely drain all batteries over time. 2. Remove all batteries if you plan to store Screamin’ Joker and the remote for more than 30 days. 3. Wipe your unit down with a dry cloth to remove any moisture or dirt. Trouble Shooting: 1. The most common performance issue is not having good batteries. a. Example: Unit won’t turn on, remote distance is short, speaker loudness is low, etc. 2. If you see some degradation of performance, please check the batteries first. 3. Having two batteries that have a low charge, mixed with two fully charged batteries, can affect the performance. Mixing Lithium with non Lithium batteries can also affect performance. Warranty: Edge warrants this product against all manufacturing defects, for a period of 1 year from date of purchase. Proof of purchase is required. Abuse of an Edge product (submerged in water, dropped, mistreatment etc.) is not covered. Log on to our website & click “Special Offer” on the front page to receive your Free DVD! A Division of Expedite International Inc. 1201 Beaudry Blvd. Hudson WI 54016 Tech Support/Customer Service: 715-­‐338-­‐3183 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Conne…

Text truncated - open the document above for the full version.

MW Products LTD. PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 16.10.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Predator Remote Model Name MW-RC02 Brand Name EDGE We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Francis Ho Position manager Company Name MW Products LTD. Address Flat D, 2/F, Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, Hong Kong. Tel 852-26622190 Fax 852-30115796 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

MW Products LTD. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: MW Products LTD. FCC ID : OZLMW-RC02 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Francis Ho Position manager Company Name MW Products LTD. Address Flat D, 2/F, Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, Hong Kong. Tel 852-26622190 Fax 852-30115796 Email [email protected]

Label Location 30mm 16mm FCC ID: OZLMW-RC02 Label Location

ANTENNA ANTENNA

Shenzhen Certification Technology Service Co., Ltd 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, Shenzhen 518126, P.R. China. FCC ID: OZLMW-RC02 Page 1 of 34 TEST REPORT FCC ID: OZLMW-RC02 Applicant : MW Products LTD. Address : Flat D, 2/F, Effort Industrial Building, 2-8 Kun g Yip Street, Kwai Chung, Hong Kong. Equipment under Test (EUT): Name : Predator Remote Model : MW-RC02 Standards : FCC PART 15, SUBPART C : 2011 (Section 15.231) Report No. : STE120915267 Date of Test : October 7-15 , 2012 Date of Issue : October 16, 2012 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: STE120915267 FCC ID: OZLMW-RC02 Page 2 of 34 TABLE OF CONTENT Description Page 1 General Information ------------------------------------------------------------------------------ 3 1.1 Description of Device (EUT)-------------------------------------------------------------- 3 1.2 Description of Test Facility ---------------------------------------------------------------- 3 2 EMC Equipment List----------------------------------------------------------------------------- 4 3 Test Procedure-------------------------------------------------------------------------------------- 5 4 Summary of Measurement ---------------------------------------------------------------------- 6 5 Radiation Emission ------------------------------------------------------------------------------- 8 5.1 Duty cycle------------------------------------------------------------------------------------ 8 5.2 Radiation Emission Limits(15.209&231)---------------------------------------------- 12 5.3 Test Setup ---------------------------------------------------------------------------------- 12 5.4 Test Procedure----------------------------------------------------------------------------- 14 5.5 Test Equipment Setting For emission test. -------------------------------------------- 15 5.6 Test Condition----------------------------------------------------------------------------- 15 5.7 Test Result --------------------------------------------------------------------------------- 15 6 POWER LINE CONDUCTED EMISSION ----------------------------------------------- 20 6.1 Conducted Emission Limits(15.209) --------------------------------------------------- 20 6.2 Test Setup ---------------------------------------------------------------------------------- 20 6.3 Test Procedure----------------------------------------------------------------------------- 21 6.4 Test Results -------------------------------------------------------------------------------- 21 7 Occupied bandwidth ---------------------------------------------------------------------------- 22 7.1 Test limit ----------------------------------------------------------------------------------- 22 7.2 Method of measurement ----------------------------------------------------------------- 22 7.3 Test Setup ---------------------------------------------------------------------------------- 22 7.4 Test Results -------------------------------------------------------------------------------- 22 8 Transmission time------------------------------------------------------------------------------- 24 8.1 Test limit ----------------------------------------------------------------------------------- 24 8.2 Method of measurement ----------------------------------------------------------------- 24 8.3 Test Setup ---------------------------------------------------------------------------------- 24 8.4 Test Results -------------------------------------------------------------------------------- 24 9 Band Edge Check ------------------------------------------------------------------------------- 26 9.1 Test limit ----------------------------------------------------------------------------------- 26 9.2 Test Procedure----------------------------------------------------------------------------- 26 9.3 Test Setup ---------------------------------------------------------------------------------- 26 9.4 Test Result --------------------------------------------------------------------------------- 26 10 Antenna Requirement -------------------------------------------------------------------------- 27 10.1 Standard Requirement -------------------------------------------------------------------- 27 10.2 Antenna Connected Construction------------------------------------------------------- 27 10.3 Result --------------------------------------------------------------------------------------- 27 11 Photographs of Test Setup --------------------------------------------------------------------- 28 12 Photographs of EUT ---------------------------------------------------------------------------- 30 Report No.: STE120915267 FCC ID: OZLMW-RC02 Page 3 of 34 1 General Information 1.1 Description of Device (EUT) Trade Name : EDGE EUT : Predator Remote Model No. : MW-RC02 Type of Antenna : Telescope antenna, Max Gain 0dBi. Operation Frequency : 433.92 MHz Channel number : 1 Modulation type : ASK Power Supply : DC 6V Supply by battery Rated PF output Power 74.27 dBuV (Peak detector) Applicant : MW Products LTD. Address : Flat D, 2/F, Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, Hong Kong. Manufacturer : MW Products LTD. Address : Flat D, 2/…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber
